61 13 Special tools for wiring harness repairs
Note. For Special Tools identification, see SPECIAL TOOLS - Z3 .
Special Tools Required
- 61 1 150
- 61 1 190
- 61 4 320
- 61 8 084
- 61 9 020
- 61 9 029
- 61 9 041
- 61 9 042
- 61 9 043
- 61 9 044
Repair ranges I, II, III for vehicle electrical system.
- Order No.: 81 24 9 408 080.
- Order No.: 81 24 9 408 300.
- Order No.: 81 24 9 408 400.
Scheme 3
Repair range IV for vehicle electrical system, special tool 61 9 020
Contents
- Special tool 61 9 041 (hand pliers).
- Special tool 61 9 042 (matrix).
- Special tool 61 9 043 (wire stripper).
- Special tool 61 9 044 (matrix).
Scheme 4
Special tool 61 9 043 (wire stripper with wire cutter) for cutting and stripping wires.
Scheme 5
Handling
Cutting to length and stripping insulating from cables.
Special tool 61 9 041 (hand pliers) with special tool 61 9 042 (matrix) for crimping connectors and contact tubes for fan connectors up to a wire cross-section of 2.5 mm and for pushing on contact tubes for fan connectors.
Handling
Crimping stop parts (contacts).
Fan connector for retrofitting/repairs.
Scheme 6
Special tool 61 1 150 (release and pressing-out tool) for
- Releasing round plug housings.
- Releasing relay carriers.
- Pressing out contacts.
- Removing indicator lights.
Scheme 7
Handling
Opening plug housings and removing contacts of different plug systems, refer to 61 13 ... OPENING PLUG HOUSINGS AND REMOVING CONTACTS OF DIFFERENT PLUG SYSTEMS .
Scheme 8
Repair kit for ignition cables and for crimping fan connector receptacles 4 mm 2 .
Handling
Crimping stop parts (contacts).
Special tool 61 4 320 (crimping set with pliers) for
- Crimping MPQ contacts, refer to «61 13 ... CRIMPING MICRO POWER QUADLOCK CONTACTS (MPQ)»(ref-202366-S02036663802005102700000) .
- Crimping MQS contacts, refer to «61 13 ... CRIMPING MICRO QUADLOCK SYSTEM CONTACTS (MQS)»(ref-202366-S20439167302005102700000) .
