General Electrical System - Special Tools - M-Coupe/roadster & Z3 (E36): Other BMW Z3 E36 рестайлинг

Horns 34 illustrations ~658 words

61 0 000 Analog/digital multimeter Metrahit 14S

NoteReplaces analog/digital multimeter M 2005
SeriesE12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39
Storage locationH 108
Order number61 0 000
Analog/digital multimeter Metrahit 14S
Consisting of
1 = 61 0 001Fuse link 16 A/600 V
NOTE: For Metrahit 14S (10 mm x 38 mm)
2 = 61 0 002Fuse link 1.6 A/500 V
NOTE: For Metrahit 14S (6.3 mm x 32 mm)
NOTE
For Metrahit 14S (10 mm x 38 mm)
NOTE
For Metrahit 14S (6.3 mm x 32 mm)

ANALOG/DIGITAL MULTIMETER METRAHIT 14S GENERAL SPECIFICATION

Scheme 122

Scheme 122
Scheme 122

61 0 021 Fuse link FF 3.15 A/500 V

NoteFor analog/digital multimeter M 2005, M 2007, M2008
Storage locationH 107
Order number61 0 021
Fuse link FF 3.15 A /500 V

FUSE LINK FF 3.15 A/500 GENERAL SPECIFICATION

61 0 030 Analog/digital multimeter Metrahit 18S

NoteReplaces analog/digital multimeter M 2008
SeriesE12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39
Storage locationH 108
Order number61 0 030
Analog/digital multimeter Metrahit 18S
Consisting of
1 = 61 0 031Fuse link 16 A/600 V
NOTE: For Metrahit 18S (10 mm x 38 mm)
2 = 61 0 032Fuse link 1.6 A/500 V
NOTE: For Metrahit 18S (6.3 mm x 32 mm)
NOTE
For Metrahit 18S (10 mm x 38 mm)
NOTE
For Metrahit 18S (6.3 mm x 32 mm)

ANALOG/DIGITAL MULTIMETER METRAHIT 18S GENERAL SPECIFICATION

Scheme 123

Scheme 123
Scheme 123

61 1 150 Releasing tool kit

Minimum set: Mechanical tools

Scheme 124

Scheme 124: 61 1 150 Releasing tool kit
Scheme 124: 61 1 150 Releasing tool kit
NoteFor circular connector/ejector tool - Contains the kits 61 1 130,61 1 140 and 61 1 180
SeriesE12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E52, E53, E65, E66, E83, E85, R50, R53, RR1
Storage locationK106
Order number61 1 150
Releasing tool kit
Consisting of
61 1 151Pressing-out tool
NOTE: For Power-Timer contacts/AMP and Bosch
61 1 152Pressing-out tool
NOTE: For Micro-Timer contacts
61 1 153Release tool
NOTE: For retaining tabs of relay holder
61 1 154Replacement sleeve dia. 1.5 mm for 61 1 139
NOTE: Order number was reserved in 8/95 on delivery of case temporarily for case insert
61 1 155Replacement sleeve dia. 3.5 mm for 61 1 133
61 1 156Replacement sleeve dia. 2.5 mm for 61 1 132
61 1 157Replacement sleeve dia. 1.5 mm for 61 1 131
61 1 158Case with insert
61 1 159Operating instructions
61 1 131Pressing-out tool
NOTE: For 1.5 mm round contacts
61 1 132Pressing-out tool
NOTE: For 2.5 mm round contacts
61 1 133Pressing-out tool
NOTE: For 3.5 mm round contacts
61 1 134Pressing-out tool
NOTE: For mini flat spring contacts
61 1 135Pressing-out tool
NOTE: For standard flat spring contacts
61 1 136Pressing-out tool
NOTE: For Power-Timer contacts (G & H)
61 1 137Pressing-out tool
NOTE: For Timer contacts
61 1 138Socket wrench
NOTE: For telltale lamps (instrument cluster)
61 1 139Pressing-out tool
NOTE: Slotted sleeve for 1.5 mm dia. Kostal round contacts
61 1 141Release tool
NOTE: For D 2.5/ELA, 4-pin, round
61 1 142Release tool
NOTE: For D 2.5/ELA, 7-pin, round
61 1 143Release tool
NOTE: For D 2.5/ELA, 12-pin, round
61 1 144Release tool
NOTE: For D 2.5/ELA, 25-pin, round
61 1 145Release tool
NOTE: For D 1.5/ELA, 10-pin, round
61 1 149Replacement blades
NOTE: For pressing-out tool
61 1 148Pressing-out tool for SLC
NOTE: SLK = Sensor Laminated Contacts
61 1 180Pressing-out tool
NOTE: For load current contacts This individual tool belongs to 61 1 150
NOTE
For Power-Timer contacts/AMP and Bosch
NOTE
For Micro-Timer contacts
NOTE
For retaining tabs of relay holder
NOTE
Order number was reserved in 8/95 on delivery of case temporarily for case insert
NOTE
For 1.5 mm round contacts
NOTE
For 2.5 mm round contacts
NOTE
For 3.5 mm round contacts
NOTE
For mini flat spring contacts
NOTE
For standard flat spring contacts
NOTE
For Power-Timer contacts (G & H)
NOTE
For Timer contacts
NOTE
For telltale lamps (instrument cluster)
NOTE
Slotted sleeve for 1.5 mm dia. Kostal round contacts
NOTE
For D 2.5/ELA, 4-pin, round
NOTE
For D 2.5/ELA, 7-pin, round
NOTE
For D 2.5/ELA, 12-pin, round
NOTE
For D 2.5/ELA, 25-pin, round
NOTE
For D 1.5/ELA, 10-pin, round
NOTE
For pressing-out tool
NOTE
SLK = Sensor Laminated Contacts
NOTE
For load current contacts This individual tool belongs to 61 1 150

RELEASING TOOL KIT GENERAL SPECIFICATION

61 1 250 Pliers

Minimum set: Mechanical tools

NoteFor removing relay from fuse box
SeriesE12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39
Storage locationA27, B27
Order number61 1 250
Pliers

PLIERS GENERAL SPECIFICATION

Scheme 125

Scheme 125
Scheme 125

61 1 300 Pliers

Minimum set: Mechanical tools

NoteFor disassembling outside mirror switch/Model year: From 83
SeriesE12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39
Storage locationA27
Order number61 1 300
Pliers

PLIERS GENERAL SPECIFICATION

Scheme 126

Scheme 126
Scheme 126

61 1 360 Releasing tool

NoteFor releasing connector housing from holder/multiple locked holder
SeriesE30, E31, E32, E34, E36, E38, E39
Storage locationA25
SI number1 13 97(205)
Order number61 1 360
Releasing tool

RELEASING TOOL GENERAL SPECIFICATION

Scheme 127

Scheme 127
Scheme 127

61 1 460 Set of V-adapter leads (8 leads)

NoteFor troubleshooting on wiring harness interfaces - e.g. for door wiring harness
SeriesE32, E36, E38
Storage locationB 108, B 109, B 110, B 111, B 112, B 113, B 114, B 115
Order number61 1 460
Set of V-adapter leads (8 leads)
Consisting of
1 = 61 1 461V-adapter lead (D 2.5), 2-pin, watertight, yellow
2 = 61 1 462V-adapter lead (D 2.5), 2-pin, watertight, blue
3 = 61 1 463V-adapter lead (D 2.5), 2-pin, watertight, black
4 = 61 1 464V-adapter lead (D 2.5), 2-pin, watertight, white
5 = 61 1 465V-adapter lead (D 2.5), 2-pin
NOTE: watertight, white, offset
6 = 61 1 466V-adapter lead (D 2.5), 2-pin
NOTE: watertight, black, offset
7 = 61 1 467V-adapter lead (D 2.5), 3-pin, watertight, black
8 = 61 1 468V-adapter lead (VEK), 10-pin, gray
NOTE
Watertight, white, offset
NOTE
Watertight, black, offset

SET OF V-ADAPTER LEADS (8 LEADS) GENERAL SPECIFICATION

Scheme 128

Scheme 128
Scheme 128

61 1 470 Set of leads (6)

Minimum set: Measuring and testing equipment

NoteFor measuring and test purposes
SeriesE12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E53
Storage locationC 102, G 103, G 104, G 105, G 106, G 107, G 108, G 109
Order number61 1 470
Set of leads (6)
Consisting of
1 = 61 1 4716-pin V-adapter lead (Modu), black
NOTE: For IHR/IHKA stepper motors - Series: E31, E32, E34
2 = 61 1 4721-pin test lead (D 4.0), red
3 = 61 1 4731-pin test lead (D 2.5), red
4 = 61 1 4741-pin test lead (D 4.0), black
5 = 61 1 4751-pin test lead (D 2.5), black
6 = 61 1 476Test cable with fuse 12 A (D 2.5)
NOTE
For IHR/IHKA stepper motors - Series: E31, E32, E34

SET OF LEADS (6) GENERAL SPECIFICATION

Scheme 129

Scheme 129
Scheme 129

61 2 040 V-adapter lead

NoteFor infrared locking system
SeriesE31, E32, E34, E36
Storage locationE 111
SI number2 03 89(038)
Order number61 2 040
V-adapter lead

V-ADAPTER LEAD GENERAL SPECIFICATION

Scheme 130

Scheme 130
Scheme 130

61 2 070 Cable set

Minimum set: Measuring and testing equipment

NoteFor performing installation and adjustment work with front seat with electric seat adjustment removed 61 2 071 for activating removed convertible top E85 and R52
SeriesE31, E36, E38, E46, E52, E60, E61, E65, E66, E85, R52, RR1
Storage locationR 204, R 205, R 206, R 207
SI number2 12 91(450)
Order number61 2 070
Cable set
Consisting of
1 = 61 2 071Power supply cable
NOTE: Connection between a battery and different adapter cables
2 = 61 2 072Adapter cable
NOTE: Model series: E36
3 = 61 2 073Adapter lead
NOTE: Model series: E38
In conjunction with61 2 071
4 = 61 2 074Adapter lead
NOTE: Model series: E46, E52
In conjunction with61 2 071
NOTE
Connection between a battery and different adapter cables
NOTE
Model series: E36
NOTE
Model series: E38
NOTE
Model series: E46, E52

CABLE SET GENERAL SPECIFICATION

Scheme 131

Scheme 131
Scheme 131

61 2 300 Adapter for measuring closed-circuit current

SeriesE12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39
Storage locationI 108
SI number2 02 96(047)
Order number61 2 300
Adapter for measuring closed-circuit current

ADAPTER FOR MEASURING CLOSED-CIRCUIT CURRENT GENERAL SPECIFICATION

Scheme 132

Scheme 132
Scheme 132

61 2 310 Adapter for measuring closed-circuit current

In conjunction withMoDiC/DIS
NoteModified measurement method, also suitable for voltage measurement
SeriesE12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E85, R50, R53
Storage locationI 108
SI number2 05 99(511)
Order number61 2 310
Adapter for measuring closed-circuit current

ADAPTER FOR MEASURING CLOSED-CIRCUIT CURRENT GENERAL SPECIFICATION

Scheme 133

Scheme 133
Scheme 133

61 2 410 Battery trickle charger

SeriesE12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, R50, R52, R53, RR1
Storage locationSingle
SI number2 02 00(545)
Order number61 2 410
Battery trickle charger
Consisting of
1 = 61 2 411Trickle charger
NOTE: With connecting cable (flat cable) for cigarette lighter socket
2 = 61 2 412Power supply cable
NOTE: Country-specific equipment
3 = 61 2 413Adapter cable
NOTE: For direct connection to battery or terminal
9 = 61 2 419Operating instructions
NOTE
With connecting cable (flat cable) for cigarette lighter socket
NOTE
Country-specific equipment
NOTE
For direct connection to battery or terminal

BATTERY TRICKLE CHARGER GENERAL SPECIFICATION

Scheme 134

Scheme 134
Scheme 134

61 3 010 Tester and set of plug adapters (8)

NoteFor relay, for checking relay functions
SeriesE12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39
Storage locationK107
SI number2 08 90(257)
Order number61 3 010
Tester and set of plug adapters (8)
Consisting of
61 3 011Tester for relay functions
61 3 013Plug insert (impact sensor)
61 3 014Plug insert (hazard warning system)
61 3 015Plug insert (hazard warning system C 2)
61 3 017Plug insert (changeover relay)
61 3 018Plug insert (closing relay)
61 3 019Plug insert (heated rear window)
61 3 021Plug insert (heated windshield)
61 3 016Plug insert (ABS)
61 3 029Operating instructions

TESTER AND SET OF PLUG ADAPTERS (8) GENERAL SPECIFICATION

Scheme 135

Scheme 135
Scheme 135

61 3 050 Bypass Switch

NoteFor relay, for checking fuel pump
SeriesE12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E53
Storage locationF118
SI number2 04 84(318)
Order number61 3 050
Bypass switch

BYPASS SWITCH GENERAL SPECIFICATION

Scheme 136

Scheme 136
Scheme 136

61 3 100 Releasing tool

NoteFor light switch
SeriesE36/7, E46
Storage locationA25
SI number1 03 96 (042)
Order number61 3 100
Releasing tool

RELEASING TOOL GENERAL SPECIFICATION

Scheme 137

Scheme 137
Scheme 137

61 4 300 Adapter lead for OBD socket

NoteFor connecting diagnosis system to OBD socket from 06/2000.
Storage locationSingle
SI number2 04 00(561)
Order number61 4 300
Adapter lead for OBD socket

ADAPTER LEAD FOR OBD SOCKET GENERAL SPECIFICATION

Scheme 138

Scheme 138
Scheme 138

61 4 320 Crimping set with pliers

Minimum set: Measuring and testing equipment

NoteFor optical fibres and cable repair
SeriesE12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E65, E66, E67, E85, R50, R53, RR1
SI number1 14 01(766)
Order number61 4 320
Crimping set with pliers
Consisting of
1 = 61 4 321Pliers without crimping head
2 = 61 4 322Crimping head
NOTE: For stripping insulation and cutting fiber optic cable to length
3 = 61 4 323Crimping head
NOTE: For crimping fiber optic cable contacts
4 = 61 4 324Crimping head
NOTE: For crimping MQS contacts
5 = 61 4 325Crimping head
NOTE: For crimping MPQ contacts
6 = 61 4 326Substitute blade
NOTE: For face-cutting fiber optic cables
7 = 61 4 327Substitute blade
NOTE: With tool for replacing blade in cable stripping unit
NOTE
For stripping insulation and cutting fiber optic cable to length
NOTE
For crimping fiber optic cable contacts
NOTE
For crimping MQS contacts
NOTE
For crimping MPQ contacts
NOTE
For face-cutting fiber optic cables
NOTE
With tool for replacing blade in cable stripping unit

CRIMPING SET WITH PLIERS GENERAL SPECIFICATION

Scheme 139

Scheme 139
Scheme 139

61 4 370 V-adapter lead (2-pin), zero-coded

Minimum set: Measuring and testing equipment

NoteCan be used on different plug housings in engine wiring harness (e.g. from Kostal - "SLK 2.8", Tyco -"Junior-Power-Timer" or Bosch) with different codings.
SeriesE34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91, R50, R52, R53, RR1
SI number02 01 05 186
Order number61 4 370
V-adapter lead (2-pin), zero-coded

V-ADAPTER LEAD (2-PIN), ZERO-CODED GENERAL SPECIFICATION

Scheme 140

Scheme 140
Scheme 140

61 4 390 Measuring box, 60-pin

Minimum set: Measuring and testing equipment

NoteFor connecting all adapter cables with 27-pin to 60-pin plug connections
SeriesE12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, R50, R52, R53, RR1
Storage locationT210
SI number2 02 98(308)
Order number61 4 390
Measuring box, 60-pin

MEASURING BOX, 60-PIN GENERAL SPECIFICATION

Scheme 141

Scheme 141
Scheme 141

61 4 450 20-pin V-adapter lead (D 2.5), black

In conjunction with61 1 459, 61 4 440
NoteFor LKM and EM convertible top GM, LCM, AMP
SeriesE30, E31, E36, E38, E39, E46, E52, E53, E60, E61, E63, E64
Storage locationC 105
SI number1 08 90(250)
Order number61 4 450
20-pin V-adapter lead (D 2.5), black

20-PIN V-ADAPTER LEAD (D 2.5), BLACK GENERAL SPECIFICATION

Scheme 142

Scheme 142
Scheme 142

61 4 460 Set of 26-pin V-adapter leads (ELO), zero-coded

Minimum set: Measuring and testing equipment

In conjunction with61 1 459
NoteFor IHR 2 KEEK
SeriesE30, E31, E34, E36, E65, E66
Storage locationC 106, C 107, C 108, C 109
SI number2 09 90(258)
Order number61 4 460
Set of 26-pin V-adapter leads (ELO), zero-coded
Consisting of
61 4 46126-pin V-adapter lead (ELO), zero-coded, cable 1
61 4 46226-pin V-adapter lead (ELO), zero-coded, cable 2
61 4 46426-pin V-adapter lead (ELO), zero-coded, cable 4
61 4 46326-pin V-adapter lead (ELO), zero-coded, cable 3

SET OF 26-PIN V-ADAPTER LEADS (ELO), ZERO-CODED GENERAL SPECIFICATION

Scheme 143

Scheme 143
Scheme 143

61 4 470 18-pin V-adapter lead (ELO), zero-coded

Minimum set: Measuring and testing equipment

In conjunction with61 1 459
SeriesE31, E34, E36, E65, E66
Storage locationC 110
SI number2 12 91(450)
Order number61 4 470
18-pin V-adapter lead (ELO), zero-coded

18-PIN V-ADAPTER LEAD (ELO), ZERO-CODED GENERAL SPECIFICATION

Scheme 144

Scheme 144
Scheme 144

61 4 480 12-pin V-adapter lead (ELO), zero-coded

Minimum set: Measuring and testing equipment

In conjunction with61 1 459
NoteFor EDC
SeriesE31, E36
Storage locationC 111
SI number2 12 91(450)
Order number61 4 480
12-pin V-adapter lead (ELO), zero-coded
Consisting of
61 4 489Handbook

12-PIN V-ADAPTER LEAD (ELO), ZERO-CODED GENERAL SPECIFICATION

Scheme 145

Scheme 145
Scheme 145

61 4 490 20-pin V-adapter lead (D 2.5), white

In conjunction with61 1 459
NoteFor lamp control module and wiring harness
SeriesE31, E36
Storage locationC 112
SI number2 04 91(321)
Order number61 4 490
20-pin V-adapter lead (D 2.5), white

20-PIN V-ADAPTER LEAD (D 2.5), WHITE GENERAL SPECIFICATION

Scheme 146

Scheme 146
Scheme 146

61 6 060 Universal wiper arm puller

Minimum set: Mechanical tools

NoteFor removing windscreen wiper arm from drive shaft
SeriesE12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, RR1
Storage locationB40
SI number1 10 99(433)
Order number61 6 060
Universal wiper arm puller
Consisting of
1 = 61 6 061Basic body
2 = 61 6 062Claw, left/right
3 = 61 6 063Spindle
4 = 61 6 064Thrust piece

UNIVERSAL WIPER ARM PULLER GENERAL SPECIFICATION

Scheme 147

Scheme 147
Scheme 147

61 6 200 Setting wrench

NoteFor adjusting nozzles on headlight washer system
SeriesE36, E36/7, E38, E39, E46
SI number1 26 97(274)
Order number61 6 200
Setting wrench

SETTING WRENCH GENERAL SPECIFICATION

Scheme 148

Scheme 148
Scheme 148

61 9 020 Repair kit IV for vehicle electrical system

Minimum set: Measuring and testing equipment

NoteScope of delivery includes: Basic equipment 61 9 030, 61 9 040, 61 9 050, 61 9 070 as well as supplementary kits 61 6 070, 61 6 080, 61 6 090, 61 9 110, 61 9 120 and supplement to repair kits 61 9 210
SeriesE30, E31, E32, E34, E36, E38, E39, E46
Storage locationK 108
Order number61 9 020
Repair kit IV for vehicle electrical system
Consisting of
61 9 029Handbook
NOTE: Volume 1 to 4
NOTE
Volume 1 to 4

REPAIR KIT IV FOR VEHICLE ELECTRICAL SYSTEM GENERAL SPECIFICATION

Scheme 149

Scheme 149
Scheme 149

61 9 030 Drawer bag not including content

NoteFor Repair Kit IV
SeriesE30, E31, E32, E34, E36, E38, E39, E46
Storage locationK 108
SI number2 02 92(505)
Order number61 9 030
Drawer bag not including content
Consisting of
61 9 031Tray insert (20 x) with compartment separator
61 9 032Storage tray for tools
61 9 033Cover inlay for repair kit IV

DRAWER BAG NOT INCLUDING CONTENT GENERAL SPECIFICATION

Scheme 150

Scheme 150
Scheme 150

61 9 040 Set of tools for repair kit IV

SeriesE12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E52, E53, E65, E85, R50, R53
Storage locationK 108
SI number2 02 92(505)
Order number61 9 040
Set of tools for repair kit IV
Consisting of
1 = 61 9 041Hand pliers without crimper
2 = 61 9 042Crimper
NOTE: For crimping butt connectors and contact sleeves for strip connectors
3 = 61 9 043Cable stripper with wire cutter
4 = 61 9 044Crimper
NOTE: For crimping antenna connector (antenna cable/radio plug connection
NOTE
For crimping butt connectors and contact sleeves for strip connectors
NOTE
For crimping antenna connector (antenna cable/radio plug connection

SET OF TOOLS FOR REPAIR KIT IV GENERAL SPECIFICATION

Scheme 151

Scheme 151
Scheme 151

61 9 045 Female die

In conjunction with61 9 041 Crimping tool
NoteFor crimping 2.5 mm (dia.) sleeves
Order number61 9 045
Female die

FEMALE DIE GENERAL SPECIFICATION

61 9 050 Repair kits A - N

NoteFor repair range IV for vehicle electrical system 61 9 020 - Preassembled cable ends with connector housings as well as contacts fitted on both ends, connectors, shrink sleeves and dummy grommets
SeriesE30, E31, E32, E34, E36, E38
Storage locationK 108
SI number2 02 92(505)
Order number61 9 050
Repair kits A - N
Consisting of
61 9 051Repair kit A
NOTE: Receptacles for strip connectors
61 9 052Repair kit B
NOTE: Plug contact system D 2.5 ELA
61 9 053Repair kit C
NOTE: Plug contact system D 2.5
61 9 055Repair kit E
NOTE: Plug contact system Timer
61 9 056Repair kit F
NOTE: Plug contact system MDK/DFK
61 9 057Repair kit G
NOTE: Plug contact system Modu
61 9 058Repair kit H
NOTE: Plug contact system ELO
61 9 061Repair kit K
NOTE: Plug contact system Timer, gold
61 9 062Repair kit L
NOTE: Pin housing for plug contact system ELO/ELA
61 9 063Repair kit M
NOTE: Pin and socket housing for plug contact system ELO/ELA
61 9 054Repair kit D
NOTE: Plug contact system D 2.5 WD -for orders of individual parts of repair kit D, see 61 9 080
61 9 059Repair kit I
NOTE: Plug contact system ELO ELA
61 9 064Repair kit N
NOTE: Plug contact system D 1.5 ELA
NOTE
Receptacles for strip connectors
NOTE
Plug contact system D 2.5 ELA
NOTE
Plug contact system D 2.5
NOTE
Plug contact system Timer
NOTE
Plug contact system MDK/DFK
NOTE
Plug contact system Modu
NOTE
Plug contact system ELO
NOTE
Plug contact system Timer, gold
NOTE
Pin housing for plug contact system ELO/ELA
NOTE
Pin and socket housing for plug contact system ELO/ELA
NOTE
Plug contact system D 2.5 WD -for orders of individual parts of repair kit D, see 61 9 080
NOTE
Plug contact system ELO ELA
NOTE
Plug contact system D 1.5 ELA

REPAIR KITS A - N GENERAL SPECIFICATION

Scheme 152

Scheme 152
Scheme 152

61 9 080 Repair kit

NoteFor individual orders only, not part of repair range IV for vehicle electrical system 61 9 020 Consisting of: - Cable ends (26 x) - Connectors 61 9 474/61 9 475/61 9 476 - Shrink sleeve with fuse wire 61 9 425
SeriesE30, E31, E32, E34, E36, E38
Storage locationK 108
Order number61 9 080
Repair kit
Consisting of
61 9 081Cable end with contact tube 1.0 mm 2
NOTE: 4-pack
61 9 082Cable end with contact tube 2.5 mm 2
NOTE: 4-pack
61 9 083Cable end with pin contact 1.0 mm 2
NOTE: 2-pack
61 9 084Cable end with pin contact 2.5 mm 2
NOTE: 2-pack
61 9 086Cable end with angle jacks 2.5 mm 2
NOTE: 4-pack
61 9 085Cable end with angle jacks 1.0 mm 2
NOTE: 10-pack
NOTE
4-pack
NOTE
4-pack
NOTE
2-pack
NOTE
2-pack
NOTE
4-pack
NOTE
10-pack

REPAIR KIT GENERAL SPECIFICATION

Scheme 153

Scheme 153
Scheme 153

61 9 110 Supplementary kit (engine electrical system)

NoteFor repair kit IV for electrical system 61 9 020 - Consisting of six assorted socket housings. Note: Reordering of individual components through BMW Parts Service only.
SeriesE36, E38, E39, E46
Order number61 9 110
Supplementary kit (engine electrical system)
Consisting of
61 9 111Socket housing, 2-pin
NOTE: Black, without release, coding 1, packaging unit 3 pieces
61 9 112Socket housing, 2-pin
NOTE: Black, with release, coding 1, packaging unit 3 pieces
61 9 114Socket housing, 2-pin
NOTE: Black, without release, coding 3, packaging unit 3 pieces
61 9 115Socket housing, 3-pin
NOTE: Gray, with release, coding 1, packaging unit 3 pieces
61 9 116Socket housing, 3-pin
NOTE: Black, with release, coding 1, packaging unit 3 pieces
61 9 117Socket housing, 3-pin
NOTE: Black, with release, coding 2, packaging unit 3 pieces
NOTE
Black, without release, coding 1, packaging unit 3 pieces
NOTE
Black, with release, coding 1, packaging unit 3 pieces
NOTE
Black, without release, coding 3, packaging unit 3 pieces
NOTE
Gray, with release, coding 1, packaging unit 3 pieces
NOTE
Black, with release, coding 1, packaging unit 3 pieces
NOTE
Black, with release, coding 2, packaging unit 3 pieces

SUPPLEMENTARY KIT (ENGINE ELECTRICAL SYSTEM) GENERAL SPECIFICATION

Scheme 154

Scheme 154
Scheme 154

61 9 120 Supplementary kit (body electrical system)

NoteFor repair kit IV for electrical system 61 9 020 - Consisting of nine assorted socket housings and sealing plugs for component conductor sealing. Note: Reordering of individual components through BMW Parts Service only.
SeriesE36, E38, E39, E46
Storage locationK 108
SI number2 05 98(380)
Order number61 9 120
Supplementary kit (body electrical system)

SUPPLEMENTARY KIT (BODY ELECTRICAL SYSTEM) GENERAL SPECIFICATION

Scheme 155

Scheme 155
Scheme 155

61 9 211 Repair kit O

NoteConnector system SLK 2.8 ELA For extending repair kits for repair range 61 9 020 - Preassembled cable ends with contacts fitted on both ends, connectors, shrink sleeves and dummy grommets
SeriesE36, E38, E39, E46
Storage locationK 108
Order number61 9 211
Repair kit O

REPAIR KIT O GENERAL SPECIFICATION

61 9 212 Repair kit P

NoteConnector system MPQ 2.8 with strand sealing For extending repair kits for repair range 61 9 020 - Preassembled cable ends with contacts fitted on both ends, connectors
SeriesE36, E38, E39, E46
Storage locationK 108
Order number61 9 212
Repair kit P

REPAIR KIT P GENERAL SPECIFICATION

61 9 213 Repair kit Q

NoteConnector system ELO Power 2.8 without strand sealing For extending repair kits for repair range 61 9 020 - Preassembled cable ends with contacts fitted on both ends, connectors
SeriesE36, E38, E39, E46
Storage locationK 108
Order number61 9 213
Repair kit Q

REPAIR KIT Q GENERAL SPECIFICATION

More articles — General Electrical System - Special Tools - M-Coupe/roadster & Z3 (E36)
