Automatic HVAC System 7 illustrations ~235 words

Blower Control Knob

Blower speed can be placed in 5 different levels from off (0) to high speed setting (4). The airflow to vent outlets is dependent on driving speed. (Scheme 26)

Temperature Control Knob

This knob, in center of control panel, allows the increase or decrease of temperature in passenger compartment. The knob controls the cable connected to temperature flap lever. (Scheme 26)

Air Distribution Knob

Airflow can be directed to windshield, upper body area, or to footwells. Intermediate positions are also possible. In the footwell position, a small amount of air flows to the windows to keep them from fogging up. (Scheme 26)

Scheme 26

Scheme 26: Air Distribution Knob

COMPRESSOR

CAUTIONIf replacing compressor, follow instructions for compressor break-in or damage may occur. See step 10 .

PIN VOLTAGE CHARTS

Pin voltage charts are supplied to reduce diagnostic time. Checking pin voltages at the A/C-heater control unit determines whether it is receiving and transmitting proper voltage signals. See the following A/C-HEATER CONTROL UNIT PIN ASSIGNMENTS tables.

Note. All voltage tests should be performed with a Digital Volt-Ohmmeter (DVOM) with minimum 10-megohm input impedance.

Pin No.Function/DescriptionSignal TypeConnection
1Terminal 15Input SignalHeating Blower Relay
2Activate Compressor ClutchOutput SignalInstrument Cluster
3Bower Level 1 (Air Conditioning)Output SignalBlower Resistor
4Terminal 15Input SignalHeating Blower Relay
5Bower Level 1 (Air-Recirculation)Output SignalBlower Resistor
6Ground For Function LightsGroundGround Point
7Terminal 15Input SignalHeating Blower Relay
8Activate Fresh Air-RecirculationOutput SignalFresh Air-Recirculation Motor

A/C-HEATER CONTROL UNIT PIN ASSIGNMENTS (Z3 - BLACK 8-PIN CONNECTOR X18349)

Pin No. (1)Function/DescriptionSignal TypeConnection
2GroundGround CircuitGround Point
3Climate-On-SignalInput SignalAir Conditioning/Recirculated Air Operating Unit
5Activate A/C CompressorOutput SignalPressure Switch
6Evaporator TemperatureInput SignalEvaporator Temperature Sensor
(1) Pin assignments not listed are not used.
(1)Pin assignments not listed are not used.

A/C-HEATER CONTROL UNIT PIN ASSIGNMENTS (Z3 - BLACK 6-PIN CONNECTOR X18350)

Pin No.Function/DescriptionSignal TypeConnection
1GroundGround CircuitGround Point
2A/C-On-SignalOutput SignalEvaporator Controller
3A/C-On-SignalOutput SignalNormal Speed Relay
4Terminal 15Input SignalHeating Blower Relay
5Blower Level 1 (Air Recirculation)Output SignalBlower Resistor
6Function Light GroundGround CircuitGround Point
7Terminal 15Input SignalHeating Blower Relay
8Activate Fresh Air-RecirculationOutput SignalFresh Air-Recirculation Motor

A/C-HEATER CONTROL UNIT PIN ASSIGNMENTS (M VEHICLES - BLACK 8-PIN CONNECTOR X18349)

Pin No. (1)Function/DescriptionSignal TypeConnection
2GroundGround CircuitGround Point
3Climate-On-SignalInput SignalAir Conditioning/Recirculated Air Operating Unit
5Activate A/C CompressorOutput SignalPressure Switch
6Evaporator TemperatureInput SignalEvaporator Temperature Sensor
(1) Pin assignments not listed are not used.
(1)Pin assignments not listed are not used.

A/C-HEATER CONTROL UNIT PIN ASSIGNMENTS (M VEHICLES - BLACK 6-PIN CONNECTOR X18350)

Scheme 27

Scheme 27: WIRING DIAGRAMS

Scheme 28

Scheme 28
Scheme 29: Manual A/C-Heater System Wiring Diagram (2000 Z3 - 3.2L)
Scheme 30: Manual A/C-Heater System Wiring Diagram (2000-01 Z3 - 2.5L & 2.8L)

Manual A/C -Heater System Wiring Diagram (2002 Z3). Scheme 29

Scheme 29: Manual A/C -Heater System Wiring Diagram (2002 Z3)

Manual A/C Circuit - (2002 M-Versions). Scheme 30

Scheme 30: Manual A/C Circuit - (2002 M-Versions)
