64 1 020 Release hook
Minimum set: Mechanical tools
| Note | For releasing and removing fresh air grille. For removing various trims. |
|---|
| Series | E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, R50, R52, R53, RR1 |
| Storage location | C33 |
| SI number | 1 15 99(483) |
| Order number | 64 1 020 |
| Release hook |
RELEASE HOOK GENERAL SPECIFICATION
Scheme 33
64 1 120 Releasing tool
| Note | For releasing Bowden operating cable assys |
|---|
| Series | E34, E36, E36/5 |
| Storage location | A27 |
| SI number | 1 04 94(788) |
| Order number | 64 1 120 |
| Releasing tool |
RELEASING TOOL GENERAL SPECIFICATION
Scheme 34
64 1 220 Spray unit
| In conjunction with | Spray gun 81 45 9 429 217 |
|---|
| Note | For cleaning and disinfecting evaporator in air conditioning system IHKR |
| Series | E36 |
| SI number | 1 07 92(516) |
| Order number | 64 1 220 |
| Spray unit |
| Consisting of | |
| 1 = 64 1 222 | Connecting hose |
| 2 = 64 1 221 | Lance with cover |
| 3 = 64 1 223 | Cover cap |
| NOTE: For resistance opening on rear side |
| NOTE |
|---|
| For resistance opening on rear side |
SPRAY UNIT GENERAL SPECIFICATION
Scheme 35
64 1 251 Spray lance, RHD vehicles
| In conjunction with | Guide 64 1 252 |
|---|
| Note | From spray apparatus set 64 1 250 (RHD vehicles) |
| SI number | 1 26 03 (044) |
| Order number | 64 1 251 |
| Spray lance, RHD vehicles |
SPRAY LANCE, RHD VEHICLES GENERAL SPECIFICATION
Scheme 36
64 1 252 Guide
| In conjunction with | Lance 64 1 251 |
|---|
| Note | Guide from spray apparatus set 64 1 250 |
| SI number | 1 26 03 (044) |
| Order number | 64 1 252 |
| Guide |
GUIDE GENERAL SPECIFICATION
Scheme 37
64 1 491 Spray lance (LHD vehicles)
| In conjunction with | Guide 64 1 492 |
|---|
| Order number | 64 1 491 |
| Spray lance (LHD vehicles) |
SPRAY LANCE (LHD VEHICLES) GENERAL SPECIFICATION
Scheme 38
64 1 492 Guide for spray lance (LHD vehicles)
| In conjunction with | Spray lance 64 1 491 for evaporator cleaning |
|---|
| Order number | 64 1 492 |
| Guide for spray lance (LHD vehicles) |
GUIDE FOR SPRAY LANCE (LHD VEHICLES) GENERAL SPECIFICATION
Scheme 39
64 5 000 Puller
| Note | For V-belt pulley on swash plate compressor in air conditioning system |
|---|
| Series | E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39 |
| Storage location | C27 |
| Order number | 64 5 000 |
| Puller |
PULLER GENERAL SPECIFICATION
Scheme 40
64 5 010 Puller
| Note | For pulley on vane cell compressor in air conditioning system |
|---|
| Series | E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39 |
| Storage location | C27 |
| SI number | 1 05 86(604) |
| Order number | 64 5 010 |
| Puller |
PULLER GENERAL SPECIFICATION
Scheme 41
64 5 020 Holder
| Note | For pulley on vane cell compressor and Seiko compressor |
|---|
| Series | E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39 |
| Storage location | A25, B25 |
| SI number | 1 05 86(604) |
| Order number | 64 5 020 |
| Holder |
HOLDER GENERAL SPECIFICATION
Scheme 42
64 5 030 Puller
| Note | For thrust washer in front housing cover of swash plate compressor |
|---|
| Series | E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39 |
| Storage location | A26 |
| Order number | 64 5 030 |
| Puller |
PULLER GENERAL SPECIFICATION
Scheme 43
64 5 080 Adapter
| Note | For setting expansion valve |
|---|
| Series | E31, E32, E34, E36 |
| Storage location | C14 |
| Order number | 64 5 080 |
| Adapter |
ADAPTER GENERAL SPECIFICATION
Scheme 44
64 5 100 Set of sealing adapters
| Note | For closing off line flanges of A/C components (evaporator, condenser, compressor) for leak testing. Set consists of (see Fig.): 1 = 64 5 102" 2 = 64 5 103" 3 = 64 5 105 (replaces 64 5 10)" 4 = 64 5 106 (from 01/2005)" 5 = 64 5 104 |
|---|
| Series | E32, E34, E36, E38, E39, E46, E53, E64, E83 |
| SI number | 1 17 98(359) |
| Order number | 64 5 100 |
| Set of sealing adapters |
| Consisting of | |
| 1 = 64 5 101 | Filler adapter |
| NOTE: Replaced by 64 5 105 (from 01/2005) |
| 2 = 64 5 102 | Sealing adapter |
| NOTE: For sealing off suction line |
| 3 = 64 5 103 | Sealing adapter |
| NOTE: For sealing off suction connection on compressor |
| 4 = 64 5 104 | Connecting hose |
| NOTE: For connecting pressure bottle to filler adapter |
| 5 = 64 5 105 | Filler adapter |
| NOTE: For sealing off pressure line and connection on connecting hose (has replaced special tool SWZ 64 5 101 since 01/2005) |
| 6 = 64 5 106 | Sealing adapter |
| NOTE: Sealing adapter for sealing off leak-testing line (from 01/2005 in scope of delivery) |
| NOTE |
|---|
| Replaced by 64 5 105 (from 01/2005) |
| NOTE |
|---|
| For sealing off suction line |
| NOTE |
|---|
| For sealing off suction connection on compressor |
| NOTE |
|---|
| For connecting pressure bottle to filler adapter |
| NOTE |
|---|
| For sealing off pressure line and connection on connecting hose (has replaced special tool SWZ 64 5 101 since 01/2005) |
| NOTE |
|---|
| Sealing adapter for sealing off leak-testing line (from 01/2005 in scope of delivery) |
SET OF SEALING ADAPTERS GENERAL SPECIFICATION
Scheme 45
