Connector Contact Removal Kit
The connector contact removal kit provides tools for the disassembly of connectors. Proper use of these tools enable the technician to access wiring connectors for repairs equal to factory quality.
Always refer to the latest appropriate articles for up to date information regarding new tools.
Scheme 100
Current P/N 88 88 6 611 150.
The Connector Contact Removal Kit is used for
- Releasing round plug housings.
- Releasing relay carriers.
- Pressing out contacts.
- Pulling out indicator lamps.
Scheme 101
Scheme 102
Socket and Spring contacts compress the springs while the connector is pushed from the housing.
Scheme 103
Scheme 104
Flat spring contacts depress the spring allowing the connector to be pushed or gently pulled from the connector housing.
Instrument Cluster Illumination Bulb Holder Removal Socket
The backlighting illumination bulbs are removed from the cluster by placing square head of the socket on the bulb holder and turning 90° counter clockwise.
The bulb removal socket is used on all instrument clusters.
