Prepackaged Wiring Repair Sets
Included with the Electrical Repair Kit IV are a variety of wiring repair sets. These sets contain various pre-crimped wiring connectors on assorted gauge wire lengths for simple splice connection repair into a wiring harness.
The repair kits also contain
- Various gauge lengths of wire with precrimped connectors.
- In-line splice connectors.
- Heat shrink tubing.
Scheme 106
When used correctly the in-line splice connectors provide a BMW factory approved wire crimp. Use the correct size nest in the crimper tool and connect one side of the in-line crimp with the wire.
Slide a piece of heat shrink tubing on the wire and crimp the other side of the in-line connector.
Scheme 107
Use a heat gun to shrink the tube around the splice connector to provide a moisture resistant seal.
Part numbers for the wire sets or any component of all four electrical repair kits can be reordered from
- The P/N reference card inside each repair kit.
- Special tools microfiche.
- The Electrical Repair Kit 1-4 component catalog (SD 92-036).
Scheme 108
As new connectors are developed for new vehicles, the repair kits will be added to appropriate articles.
