12 1 305 Zero-Coded Cover Cap For 52-Pin Test Box (12 1300/304)
Note: New plugs in E61/E61/E63 and E64 on SGM control unit Cover cap 12 1 300/305 for diagnosis on wiring harness. From 08/2004 cover cap will be supplied with test box.
SI number: 2 07 04 (138)
Order number: 12 1 305
Zero-coded cover cap for 52-pin test box (12 1300/304)
12 7 060 Antistatic Mat (ESD)
Note: ESD (Electro Static Discharge) For protection against ESD during repairs to electronic components. (Replaces the sub-number 12 7 192 from EPROM tool kit 12 7 190)
Series: E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E81, E82, E83, E85, E87, E90, E91, R50, R52, R53, R55, R56, RR1
SI number: 2 06 04 (128)
Order number: 12 7 060
Antistatic mat (ESD)
Scheme 81
12 7 121 Counterholder Wrench
In conjunction with: Socket
Note: Alternator N42 engine
Order number: 12 7 121
Counterholder wrench
12 7 122 Socket
In conjunction with: Counterholder wrench
Note: Hazet 8808 lg10
SI number: 1 28 03 (051)
Order number: 12 7 122
Socket
12 7 190 EPROM Tools / ID Marking
Note: Set no longer available. Antistatic mat can be ordered using number 12 7 060.
Storage location: J 101
Order number: 12 7 190
EPROM tools / ID marking
Consisting of
1 = 12 7 191 EPROM puller pliers
Note: No longer available. Antistatic mat can be ordered using special tool number 12 7 060.
2 = 12 7 192 Antistatic mat
Note: Is replaced by main number 12 7 060.
12 7 200 Set Of Tools
Note: For opening & closing control unit box
Storage location: J 106
Order number: 12 7 200
Set of tools
Consisting of
1 = 12 7 201 Pliers
Note: For bending open tab washers
2 = 12 7 202 Lever
Note: For bending tab washers
3 = 12 7 203 Pliers
Note: For closing tab washers
4 = 12 7 204 Torx socket T20
5 = 12 7 205 Torx socket T10
6 = 12 7 206 Fine pen
Note: Black, waterproof
8 = 12 7 208 Slotted screwdriver 2 mm
9 = 12 7 209 Straightening tool
Note: For EPROM connections
12 7 210 Control Unit Seal
Storage location: J 106
Order number: 12 7 210
Control unit seal
Consisting of
1 = 12 7 211 Seal marks
2 = 12 7 212 Hole punch
Note: For seal mark dating
