11 12 503 Disassembling and assembling cylinder head (N62)
Special tools required
- 11 9 000
- 11 9 001
- 11 9 002
- 11 9 005
- 11 9 006
- 11 9 007
- 11 9 008
- 11 9 009
- 11 9 011
- 11 9 015
Have special tool 11 9 000 ready for removing valve springs.
Secure cylinder head (1) on special tool 11 9 001.
Note. Secure cylinder head from above with screws contained in scope of delivery on special tool 11 9 001.
Turn special tool 11 9 001 through 180°.
Scheme 431
Align special tool 11 9 008 in conjunction with special tool 11 9 007 on special tool 11 9 006 to relevant combustion chamber.
Place special tool 11 9 006 on cylinder head.
Scheme 432
Scheme 433
11 12 527 Remachining a valve seat-cylinder head disassembled (N62)
Special Tools Required
- 00 3 520
- 00 3 580
Machine valve seat surface with special tool 00 3 520 or with 00 3 580 in accordance with tool manufacturer's instructions.
Scheme 434
Note. After machining valve-seat surface: Remachine outside and inside diameters with correction milling tool to the specified diameters until you obtain valve seat width (5).
- Valve-seat angle
- Correction angle, external diameter
- Correction angle, internal diameter
- Valve seat, external diameter
- Valve seat width
