Engine - Special Tools (M57): Other BMW X5 M E70 рестайлинг

Mechanical 42 illustrations ~2800 words

MW Adapter

Replaced by: 0491003

Note. For pressure gauge for checking the oil pressure - Replaced by 11 4 030 (0 491 003)

Note. (Coupling) For adapting the test probes to pressure gauge 11 0 162

Scheme 819

Scheme 819: MW Adapter

Adapter Minimum set: Mechanical tools MW

Note. (Adapter) For connecting pipe bend 13 6 054 to pressure gauge 13 3 061 or BMW diagnosis and information system for checking oil pressure

Bush Minimum set: Mechanical tools MW

Note. (Impact bush) For fitting the radial sealing ring in the end cover of the crankshaft at the rear

SI number

01 03 95 (900)

Scheme 820

Scheme 820: SI number

Note. For fitting valve stem seal

01 06 98 (306)

Scheme 821

Scheme 821: SI number

Note. (Slip bush) For installation of the radial shaft seal in the gear case cover, bottom

01 11 98 (338)

Scheme 822

Scheme 822: SI number

Note. For fitting radial shaft seal on crankshaft in gear case cover

01 11 94 (858)

Scheme 823

Scheme 823: SI number

Compression tester Minimum set: Mechanical tools MW

Note. (Compression pressure testing set) For all petrol and diesel engines.

01 09 92 (558)

Consisting of

4 = 0490620 Probe

Note. (Test probe) For recording compression testers 11 0 224 and 11 0 160/engine: S14, S38, S50 - Replaced by 11 0 235 (0 493 129)

Scheme 824

Scheme 824: SI number

4 = 0490616 Card

Note. (Cards) 100 pieces For recording compression tester 11 0 221

4 = 0490622 Card

Note. (Cards) 100 pieces For recording compression tester 11 0 224

2 = 0494517 Adapter

Note. Measuring "absolute compression" at all cylinders. Engine: W17

2 = 0493634 Case

Note. With foam material insert for recording compression tester

16 = 0495279 Adapter

Note. M67, M67TU engine

4 = 0490614 Compression tester

Note. (Compression tester) For diesel engines.

4 = 0490615 Probe

Note. (Test probe) For recording compression testers 11 0 221 and 11 0 160/engine: M21, M41, M47, M51, M57, M57T2

4 = 0490617 Compression tester

Note. (Compression tester) For petrol engines.

4 = 0490618 Hose

Note. (Extension hose) For rubber tapered section with fitting 11 0 228

4 = 0490619 Probe

Note. (Test probe) For recording compression testers 11 0 224 and 11 0 160/engine: M10, M20, M30, M40, M42, M43, M44, M50, M52, M60, M62, M70, M73, N62, S50US, S52US, S62

4 = 0490621 Tapered section

Note. (Rubber tapered section) For recording compression testers 11 0 224 and 11 0 160.

4 = 0490625 Valve

Note. (Non-return valve)

4 = 0490626 Filter

Note. (Filter) 3 x 3 mm

9 = 0493129 Probe

Note. (Test probe, screw-in) For measuring "absolute compression" at all cylinders, engine: S14, S38, S50B30, S50B32, S50US, S52US, S54, S85

2 = 0493387 Probe

Note. (Test probe) For recording compression tester 11 0 221 or DIS pressure sensor/engine: M47, M57, M57TU, M57T2

MW Compression tester

Replaced by: 0490613

Note. (Compression recorder) manufacturer VDO - Replaced by 11 0 220 (0 490 613)

Consisting of

1 = 0490594 Card

Note. (Cards) For compression pressure inscriber Discontinuation and replaced by 11 0 220 (0 490 613)

2 = 0490595 Pressure gauge

Note. Compression pressure inscriber Discontinuation and replaced by 11 0 220 (0 490 613)

3 = 0490596 Guard

Note. (Rubber protection) Still available as replacement Discontinuation and replaced by 11 0 220 (0 490 613)

4 = 0490597 Lines

Note. Discontinuation and replaced by 11 0 220 (0 490 613)

5 = 0490598 Adapter

Note. (test adapter for petrol engine) Engine: all, except M70 Discontinuation and replaced by 11 0 220 (0 490 613)

6 = 0490599 Adapter

Note. (test adapter for petrol engine) Engine: M70 Discontinuation and replaced by 11 0 220 (0 490 613)

7 = 0490600 Adapter

Scheme 825

Scheme 825: MW Compression tester

Note. (Test adapter extension) Discontinuation and replaced by 11 0 220 (0 490 613)

Connection piece Minimum set: Mechanical tools MW

Note. For turning over engine at crankshaft hub (vibration absorber) when adjusting valve timing

01 11 98 (338)

Scheme 826

Scheme 826: SI number

Counter support Minimum set: Mechanical tools MW

Note. (Counter support device) For slackening and tightening the central bolt on the vibration absorber

01 11 98 (338)

Consisting of

2 = 0493393 Support

3 = 0493394 Screw

Note. (Mounting bolt M8 (2 x))

1 = 0493392 Holder

Note. (counter support)

Scheme 827

Scheme 827: SI number

Device MW

Replaced by: 0490504

Note. For retightening the connecting rod and cylinder head bolts - Replaced by 00 9 120 (0 490 504)

Consisting of

1 = 0490827 Extension

Note. (Extension 1/1") Replaced by 00 9 120 (0 490 504)

2 = 0490828 Washer

Note. (Graduated disc 180°) Replaced by 00 9 120 (0 490 504)

3 = 0490829 Sleeve

Note. (Guide sleeve) Replaced by 00 9 120 (0 490 504)

4 = 0490830 Nut

Note. (Knurled nut) Replaced by 00 9 120 (0 490 504)

5 = 0490831 Wrench socket

Note. (Socket wrench insert WAF 10) Replaced by 00 9 120 (0 490 504)

Scheme 828

Scheme 828: Device MW

6 = 0490832 Washer

Note. (Graduated disc up to 270°) Replaced by 00 9 120 (0 490 504)

= 0490833

7 = 0490833 Tab

Note. For counter-holding on the cylinder head Replaced by 00 9 120 (0 490 504)

8 = 0490834 Adapter

Note. (Adapter) Replaced by 00 9 120 (0 490 504)

Note. (Pressure testing fixture) For sealing coolant openings when pressure-testing cylinder head for watertightness

01 06 98 (306)

Consisting of

1 = 0493237 Strip

Note. (sealing strips (2 x) with rubber seal)

1 = 0493238 Rubber seal

Note. (rubber seals (2 x)) For sealing strips 11 6 401

Scheme 829

Scheme 829: SI number

3 = 0493239 Cover

Note. Engine: M47, M57/for water pump connection

3 = 0493240 O-ring

Note. Engine: M47/for spindle on cover 11 6 403

6 = 0493242 Screw

Note. (Screw plug M12 with valve) Engine: M47, M57, M47TU

7 = 0493307 Screw

Note. (Mounting bolts (14 x)) M12 x 125 with nuts and 28 U washers for sealing strips

9 = 0493376 Plate

Note. (Sealing plate) Engine: M57, M47TU/For sealing off coolant outlet opening

Replaced by: 0494362

Note. For removing and installing camshafts and valve springs. Replaced by 11 9 000 (0 494 362)

Consisting of

9 = 0490697 Frame

Note. (Pressure frame) Replaced by 11 9 000 (0 494 362)

9 = 0490698 Spindle

Note. (Spindle (4 pieces)) Replaced by 11 9 000 (0 494 362)

9 = 0490699 Pin

Note. (Dowel pins (4 pieces)) Replaced by 11 9 000 (0 494 362)

9 = 0490700 Oddments tray

Note. (Board) Replaced by 11 9 000 (0 494 362)

9 = 0490701 Frame

Note. (Support frame) Replaced by 11 9 000 (0 494 362)

Scheme 830

Scheme 830: Device MW

9 = 0490704 Lever

Note. (Pressure lever with hook)

Replaced by 11 0 342/11 0 343 Engine

S14, M20, M30, S38, M40, M42, M50, M70 Replaced by 11 9 000 (0 494 362)

9 = 0490705 Cage

Note. (Valve spring cage) Replaced by 11 9 000 (0 494 362)

9 = 0490707 Retaining bracket

Note. (Guide bracket, bent) Replaced by 11 9 000 (0 494 362)

9 = 0490708 Tab

Note. (Securing clip) For securing the cylinder head on the clamping frame 11 1 065 Replaced by 11 9 000 (0 494 362)

9 = 0490702 Oddments tray

Note. (Board) Replaced by 11 9 000 (0 494 362)

9 = 0490703 Rod

Note. (guide rod)

Replaced by: 0494362

Note. For removing and installing camshaft and valve springs. Replaced by 11 9 000 (0 494 362)

Consisting of

1 = 0490682 Frame

Note. (Pressure frame)

2 = 0490683 Spindle

Note. (Threaded spindle with nut (2 pieces))

3 = 0490684 Retaining bracket

Note. (Clamping collar)

4 = 0490685 Spindle

Note. (Pressure spindle)

5 = 0490686 Pin

Note. (Lock pins) To secure boards for cylinder heads

Scheme 831

Scheme 831: Device MW

6 = 0490687 Frame

Note. (Support frame with guide clips)

7 = 0490688 Oddments tray

Note. (Board)

8 = 0490689 Rod

Note. (Guide rod)

9 = 0490690 Lever

Note. (Pressure lever) With hook and valve spring cage

Device Minimum set: Mechanical tools MW

Note. (Cylinder head expander tool)

01 03 02 (833)

Consisting of

17 = 0495028 Cage

Note. (Valve spring cage) Engine N52

1 = 0494366 Device

5 = 0494370 Quick fastener

7 = 0494372 Shaped part

Note. (Shaped part)

Scheme 832

Scheme 832: SI number

8 = 0494373 Shaped part

Note. (Shaped part) Shaped part made of plastic

9 = 0494374 Lever

2 = 0494367 Rod

3 = 0494368 Adapter

Note. (Sliding block)

4 = 0494369 Tab

6 = 0494371 Insert

Note. (Aluminium strip)

10 = 0494375 Hook

11 = 0494376 Cage

Note. (Valve spring cage) Engine M41, M51, S50

12 = 0494377 Cage

Note. (Valve spring cage) Engine M43, M73

13 = 0494378 Cage

Note. (Valve spring cage) Engine M44, M52, M54, M56, M62, S52, S54, S62

14 = 0494379 Cage

Note. (Valve spring cage) Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73

15 = 0494380 Cage

Note. (Valve spring cage) Engine M21, M40

Replaced by: 0491007

Note. For installation of the dipstick guide tube - Replaced by 11 4 070 (0 491 007)

Note. (Pulling device) For pulling the radial shaft seal into the gear case cover

01 11 98 (338)

Consisting of

10 = 0493538 Screw

Scheme 833

Scheme 833: SI number

Engine support plate

In conjunction with: 00 1 450" 00 2 300

Note. For supporting engine on assembly stand

Engine: M57T2, M57TU

1 05 05 (180)

Scheme 834

Scheme 834: SI number

Fitting aid MW

Replaced by: 0494362

Note. (Installation accessory) For removing and installing valve springs. Replaced by 11 9 000.(0 494 362)

01 05 89 (099)

Consisting of

1 = 0490772 Oddments tray

Note. (Board) Replaced by 11 9 000. (0 494 362)

2 = 0493414 Tab

Note. (Retaining tab) Engine: M52, M44, M50, M52, M47, M47TU, M57 Replaced by 11 9 000. (0 494 362)

Scheme 835

Scheme 835: SI number

10 = 0493537 Tab

Note. (Retaining tab) Engine: M67

Replaced by: 0494362

Note. (Installation accessory) For removing and installing valve springs. Replaced by 11 9 000.(0 494 362)

01 09 91 (416)

Consisting of

1 = 0490603 Tab

Note. (Securing clip and 2 screws) Replaced by 11 0 213/Engine: M41, M51 Replaced by 11 0 213 (0 490 611)

2 = 0490604 Tube

Note. (Guide tube) Engine: All

3 = 0490605 Lever

Note. (Pressure lever with hook) Replaced by 11 0 342, 11 0 343/Engine: M51, S50, M60

4 = 0490606 Cage

Note. (Valve spring cage) Engine: M41, M51, S50

Scheme 836

Scheme 836: SI number

Replaced by: 0494362

Note. (Mounting accessory) For removing and installing the valve springs Replaced by 11 9 000 (0 494 362)

Consisting of

3 = 0490934 Lever

Note. (Pressure lever with hook) Replaced by 11 0 342, 11 0 343/Engine: M21 Replaced by 11 0 342 (0 490 948) 11 0 343 (0 490 949)

1 = 0490932 Retaining bracket

Note. (Guide clip, straight (2 pieces))

2 = 0490933 Oddments tray

Note. (Board) Engine: M21, M41, M51, M57, M47, M47TU

4 = 0490935 Cage

Note. (Valve spring cage) Engine: M21, M40

Scheme 837

Scheme 837: Fitting aid MW

5 = 0490936 Bolt

Note. (Mounting bolt) Engine: M21

6 = 0493286 Support

Note. (Rubber support) For board 11 3 132/Engine: M47, M47TU, M57

Replaced by: 0494362

Note. (fitting accessories) For removing and fitting the valve springs. Replaced by 11 9 000 (0 494 362)

01 12 93 (701)

Consisting of

3 = 0490649 Hook

Note. (hook) Length 220 mm - Engine: all, except M10 Replaced by 11 9 000 (0 494 362)

Scheme 838

Scheme 838: SI number

5 = 0490651 Cage

Note. (Valve spring cage) Engine: M44, M52, M62, S62, S54 Replaced by 11 9 000 (0 494 362)

1 = 0490647 Cage

Note. (Valve spring cage) Engine: M43, M73

2 = 0490648 Lever

Note. (compression lever) Engine: all, except M10

6 = 0493285 Cage

Note. (Valve spring cage) Engine: M47, M47TU, M57, N40, N42, M67, M67TU

4 = 0490650 Cage

Note. (valve spring cage) Replaced by 11 0345, engine: M52

Gauge Minimum set: Mechanical tools MW

Note. For fixing the camshaft at the top dead centre.

01 07 10 (634)

Scheme 839

Scheme 839: SI number

Note. (Disconnecting gauge) For disconnecting the camshaft when adjusting the timing

01 06 98 (306)

Consisting of

1 = 0493236 Gauge

Note. (Disconnecting gauge)

2 = 0493288 Holder

Note. For securing the disconnecting gauge on the cylinder head

Scheme 840

Scheme 840: SI number

Holder Minimum set: Mechanical tools MW

Note. (counter support) For locking the flywheel

Holder MW

Replaced by: 0490855

Note. (Counter support) - Nov. 88 Replaced by 11 2 240 (0 490 855)

Note. (Installation bracket)

Holding sleeve Minimum set: Mechanical tools MW

Note. (Assembly sleeve) For fitting valve stem seals, 6 mm diameter

Scheme 841

Scheme 841: Holding sleeve Minimum set: Mechanical tools MW

1 13 05 (197)

Consisting of

1 = 11 0 331 Installation aid

Note. (installation tool)

2 = 11 0 332 Ring

Note. (adapter ring)

Scheme 842

Scheme 842: SI number

Scheme 843

Scheme 843: Installation drift

Lifting gear Minimum set: Mechanical tools MW

Note. (Lifting gear) For removing and installing engines

01 16 96 (107)

Consisting of

4 = 0493753 Shackle

Note. (Shackle) 2 x

1 = 0490580 Lifting gear

Note. (cross-member)

2 = 0490581 Chain

Note. (Chain) Version: long

3 = 0490582 Chain

Note. (Chain) Version: short

Scheme 844

Scheme 844: SI number

Note. (Hoist) For removing and installing engines.

01 13 94 (888)

Consisting of

1 = 0490562 Lifting gear

Note. (Cross-member)

2 = 0490563 Chain

Note. (Chain) Version: long

3 = 0490564 Chain

Note. (Chain) Version: short

4 = 0490565 Shackle

Note. (Shackle) 2 x

Scheme 845

Scheme 845: SI number

Note. For removing and installing engines.

01 13 94 (888)

Consisting of

1 = 0490568 Lifting gear

Note. (Cross-member)

2 = 0490569 Chain

Note. (Chain)

3 = 0490570 Chain

Note. (Chain) Version: long

Scheme 846

Scheme 846: SI number

4 = 0490571 Chain

Note. (Chain) Version: short

5 = 0490572 Shackle

Note. (Shackle) 2 pieces

Mandrel Minimum set: Mechanical tools MW

Note. (drift) For fitting the crankshaft guide bearing

01 05 90 (207)

Scheme 847

Scheme 847: SI number

Mandrel 111310 MW

Note. (Drift) For driving needle bearing out of crankcase (M20) and pressing out propeller shaft centring mount

Scheme 848

Scheme 848: Mandrel 111310 MW

Note. (Alignment pin) For locking the crankshaft in TDC firing position when adjusting the timing

Note. (drift) For driving guide bearing into crankshaft (S14, S38, M10, M20, M21, M30, M40, M42, M50, M51 M52) and driving centring mount into propeller shaft

Mandrel MW

Note. (Installation drift)

Note. (Mandrel) Replaced by 11 1 200

Note. (Drift) Replaced by 11 1 200

Note. (Guide mandrels (2 pieces)) For installing the connecting rods with pistons.

01 06 98 (306)

Scheme 849

Scheme 849: SI number

Replaced by: 0490724

Note. (Drift) Replaced by 11 1 200 (0 490 724)

Open-end spanner MW

Note. (open-end spanner WAF 27) For adjusting left track rod on rack

Open-end wrench Minimum set: Mechanical tools MW

Note. (Open-end wrench AF 32) For releasing and tightening the fan wheel

01 01 87 (670)

Scheme 850

Scheme 850: SI number

Pin Minimum set: Mechanical tools MW

Note. (lock pin (2 pieces)) For retaining the chain tensioner piston (e.g. when removing and installing the cylinder head) and to lock the drive belt tensioner

01 09 91 (416)

Scheme 851

Scheme 851: SI number

Piston ring compressor Minimum set: Mechanical tools MW

Note. For compressing piston rings while installing pistons

Plate MW

Note. (Fixture) For mounting the engine on the assembly stand

01 09 94 (839)

Scheme 852

Scheme 852: SI number

Pliers MW

Replaced by: 0490796

Note. For removal of the valve stem seals - Replaced by 11 1 480 (0 490 796)

Scheme 853

Scheme 853: Pliers MW

Replaced by: 0490796

Note. For removing and installing the valve stem seal. Only free for motorcycle! Replaced by 11 1 480 (0 490 796)

Note. (Removal pliers)

Note. (Installation pliers)

Plug mandrel Minimum set: Mechanical tools

Note. For locking flywheel in TDC position

Engine: M57T2

1 05 05 (180)

Scheme 854

Scheme 854: SI number

Puller Minimum set: Mechanical tools MW

Note. For guide bearing in crankshaft, shaft diameter 15 mm

01 05 90 (207)

Consisting of

1 = 0490869 Claw

Note. (Removal claw with threaded bush)

2 = 0490870 Claw

Note. (Removal claw)

3 = 0490871 Spindle

Note. (Pressure spindle)

4 = 0490872 Holding sleeve

Scheme 855

Scheme 855: SI number

Note. For radial seal in gear case cover

01 02 87 (721)

Consisting of

1 = 0493383 Puller

2 = 0493384 Thrust piece

Note. For inserting in the crankshaft when pulling the radial shaft seal out of the gear case cover/engine: M57

Scheme 856

Scheme 856: SI number

1 05 05 (180)

Consisting of

1 = 11 6 111 Mounting holder

2 = 11 6 112 Mounting pliers

3 = 11 6 113 Drift

Scheme 857

Scheme 857: SI number

Sleeve Minimum set: Mechanical tools MW

Note. (Assembly sleeve) For fitting the valve stem seal, diameter 7 mm

Sleeve MW

Replaced by: 0490744

Note. (Assembly sleeves) For fitting the valve stem seal - Replaced by 11 1 360 (0 490 744)

Tool Minimum set: Mechanical tools MW

Note. (Extractor tool) For pulling off the valve stem seal

01 06 98 (306)

Scheme 858

Scheme 858: SI number

Wrench socket MW

Note. (Wrench insert WAF 10) Bihexagonal - exhaust manifold model 745i/glow elements

01 06 98 (306)

Scheme 859

Scheme 859: SI number

Wrench socket Minimum set: Mechanical tools MW

Note. (Wrench socket 22 mm) For loosening and tightening the oxygen sensor

Scheme 860

Scheme 860: Wrench socket Minimum set: Mechanical tools MW
