61 0 021 Fuse link FF 3.15 A / 500 V
Note: For analog/digital multimeter M 2005, M 2007, M2008
Storage location: H 107
Order number: 61 0 021
Fuse link FF 3.15 A / 500 V
61 0 200 Crimping set (basic tool)
Minimum set: Measuring and testing equipment
Note: Consisting of case + basic crimping tool
SI number: 02 02 05 (194)
Order number: 61 0 200
Crimping set (basic tool)
Scheme 1
Consisting of
1 = 61 0 201 Plastic case
Note: As storage system for the complete set.
2 = 61 0 202 Crimping tool
Note: Basic tool for different matrices (crimping insert set)
3 = 61 0 203 Allen key
Note: For securing individual matrices in the crimping tool
61 0 210 Matrix LSK 8
In conjunction with: 61 0 202 (crimping tool)
Note: (crimping insert set for load current contact 8)
SI number: 02 02 05 (194)
Order number: 61 0 210
Matrix LSK 8
Scheme 2
61 0 220 Matrix for SLK 2.8
In conjunction with: 61 0 202 (crimping tool)
Note: (crimping insert set for load contact tube 2.8)
SI number: 02 02 05 (194)
Order number: 61 0 220
Matrix for SLK 2.8
Scheme 3
61 0 300 Releasing tool (complete kit)
Minimum set: Measuring and testing equipment
Note: Replaces special tool 61 1 150 from 09/2005
SI number: 2 05 05 (217)
Order number: 61 0 300
Releasing tool (complete kit)
Scheme 4
Consisting of
1 = 61 0 301 Releasing tool for round contacts (dia. 1.5)
Note: Replaces special tool 61 1 131 from 09/2005
2 = 61 0 302 Replacement sleeve D=1.5
Note: Replaces special tool 61 1 157 from 09/2005
3 = 61 0 303 Releasing tool for round systems with D=2.5
Note: Replaces special tool 61 1 132 from 09/2005
4 = 61 0 304 Replacement sleeve (D=2.5)
Note: Replaces special tool 61 1 156 from 09/2005
5 = 61 0 305 Releasing tool for round contacts (D=3.5)
Note: Replaces special tool 61 1 133 from 09/2005
6 = 61 0 306 Replacement sleeve (D=3.5) for 61 0 305
Note: Replaces special tool 61 1 155 from 09/2005
7 = 61 0 307 Releasing tool for jack-side round contacts (D=2.5)
8 = 61 0 308 Replacement sleeve for special tool 61 0 307 (D=2.5)
9 = 61 0 309 Releasing tool for pin-side round contact (D=1.5) - Kostal
Note: Replaces special tool 61 1 139 from 09/2005
10 = 61 0 311 Replacement sleeve for special tool 61 0 309
Note: Replaces special tool 61 1 154 from 09/2005
11 = 61 0 312 Releasing tool for flat spring contacts with a snap-in lug (1.6 mm)
Note: Replaces special tool 61 1 134 from 09/2005
12 = 61 0 313 Releasing tool for flat spring contacts with a snap-in pin (1.9 mm)
Note: Replaces special tool 61 1 137 from 09/2005
13 = 61 0 314 Releasing tool for flat spring contact with a snap-in pin (2.7 mm)
Note: Replaces special tool 61 1 135 from 09/2005
14 = 61 0 315 Releasing tool for flat spring contacts with double snap-in pin "Micro-Timer 2"
Note: Replaces special tool 61 1 151 from 09/2005
15 = 61 0 316 Releasing tool for flat spring contacts with double snap-in pin "SPT 4.8" "JPT 2.8"
Note: Replaces special tool 61 1 136 from 09/2005
16 = 61 0 317 Releasing tool for LSK 8
Note: Replaces special tool 61 1 200 from 09/2005
17 = 61 0 318 Releasing tool for "Maxi Power Timer 9.5"
Note: Replaces special tool 61 1 180 from 09/2005
18 = 61 0 319 Releasing tool for sensor laminated contacts ("SLK2.8")
Note: Replaces special tool 61 1 148 from 09/2005
19 = 61 0 321 Releasing tool for sensor laminated contacts with releasing element ("SLK 2.8")
20 = 61 0 322 Releasing tool for mini laminated contact ("MLK 1.2 mm")
21 = 61 0 323 Releasing tool for flat spring contacts with a snap-in pin (MQS)
Note: Replaces special tool 61 1 152 from 09/2005
22 = 61 0 324 Releasing tool for secondary locking
Note: Universal tool for damage-free opening/removal of secondary locking
23 = 61 0 329 Case with foam inlay without tools
Note: Storage system for releasing tools from kit 61 0 300
61 1 150 Releasing tool kit
Note: For circular connector / press-out tool -Contains the kits 61 1 130, 61 1 140 and 61 1 180 Replaced by special tool 61 0 300 from 09/2005.
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E52, E53, E65, E66, E83, E85, R50, R53, RR1
Storage location: K 106
Order number: 61 1 150
Releasing tool kit
Scheme 5
Consisting of
61 1 151 Pressing-out tool
Note: For Power-Timer contacts / AMP and Bosch Replaced by special tool 61 0 315 from 09/2005.
61 1 152 Pressing-out tool
Note: For Micro-Timer contacts Replaced by special tool 61 0 323 from 09/2005.
61 1 153 Release tool
Note: For retaining tabs of relay holder
61 1 154 Replacement sleeve dia. 1.5 mm for 61 1 139
Note: Order number was temporarily assigned for case inlay in 8/95 on delivery of case Replaced by special tool 61 0 311 from 09/2005.
61 1 155 Replacement sleeve dia. 3.5 mm for 61 1 133
Note: Replaced by special tool 61 0 306 from 09/2005.
61 1 156 Replacement sleeve dia. 2.5 mm for 61 1 132
Note: Replaced by special tool 61 0 304 from 09/2005.
61 1 157 Replacement sleeve dia. 1.5 mm for 61 1 131
Note: Replaced by special tool 61 0 302 from 09/2005.
61 1 158 Case with inlay
Note: Replaced by special tool 61 0 329 from 09/2005.
61 1 159 Operating instructions
61 1 131 Pressing-out tool
Note: Replaced by special tool 61 0 301 from 09/2005
61 1 132 Pressing-out tool
Note: For 2.5 mm round contacts Replaced by special tool 61 0 303 from 09/2005.
61 1 133 Pressing-out tool
Note: For 3.5 mm round contacts. Replaced by special tool 61 0 305 from 09/2005.
61 1 134 Pressing-out tool
Note: For mini flat spring contacts. Replaced by special tool 61 0 312 from 09/2005.
61 1 135 Pressing-out tool
Note: For standard flat spring contacts. Replaced by special tool 61 0 314 from 09/2005.
61 1 136 Press-out tool
Note: For Power-Timer contacts (G & H). Replaced by special tool 61 0 316 from 09/2005.
61 1 137 Pressing-out tool
Note: For Timer contacts. Replaced by special tool 61 0 313 from 09/2005.
61 1 138 Socket wrench
Note: For telltale lamps (instrument cluster)
61 1 139 Pressing-out tool
Note: Slotted sleeve for Kostal round contacts with 1.5 mm dia. Replaced by special tool 61 0 311 from 09/2005.
61 1 141 Releasing tool
Note: For D 2.5 / ELA, 4-pin, round
61 1 142 Releasing tool
Note: For D 2.5 / ELA, 7-pin, round
61 1 143 Releasing tool
Note: For D 2.5 / ELA, 12-pin, round
61 1 144 Releasing tool
Note: For D 2.5 / ELA, 25-pin, round
61 1 145 Releasing tool
Note: For D 1 5 / ELA 10-pin round
61 1 149 Replacement blades
Note: For press-out tool 61 1 148
61 1 148 Press-out tool for SLK
Note: SLK = Sensor Laminated Contacts. Replaced by special tool 61 0 319 from 09/2005.
61 1 180 Press-out tool
Note: For load current contacts Replaced by special tool 61 0 318 from 09/2005.
61 1 180 Removal tool
Minimum set: Mechanical tools
Note: For load current contacts
Series: All models
SI number: 20600(636)
Order number: 61 1 180
Removal tool
Scheme 6
61 1 350 Set of assembly tools
Note: For removing and installing socket in transmission connector on automatic transmission
Transmission: 4 HP 22, 4 HP 24
Storage location: I 103
Order number: 61 1 350
Set of assembly tools
Scheme 7
Consisting of
1 = 61 1 351 Removal tool
2 = 61 1 352 Fitting drift
61 1 410 Set of DIS test prods
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E39tou, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91, R50, R52, R53, RR1
Storage location: H 107
Order number: 61 1 410
Set of DIS test prods
Scheme 8
Consisting of
1 = 61 1 411 Clip SAGK4-K, red
1 = 61 1 421 Clamping test probe XB/100, black
2 = 61 1 412 Clip SAGK4-K, black
3 = 61 1 413 Clip SAGK4, red
4 = 61 1 414 Clip SAGK4, black
5 = 61 1 415 Clip XDK-1033, red
6 = 61 1 416 Clip XDK-1033, black
7 = 61 1 417 Test probe SPP4-S, red
8 = 61 1 418 Test probe SPP4-S, black
9 = 61 1 419 Clamping test probe XB/100, red
61 2 410 Battery trickle charger
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, R50, R52, R53, RR1
Storage location: Single
SI number: 2 02 00(545)
Order number: 61 2 410
Battery trickle charger
Scheme 9
Consisting of
1 = 61 2 411Trickle charger
Note: With connecting cable (flat cable) for cigarette lighter socket
2 = 61 2 412 Power supply cable
Note: Country-specific equipment
3 = 61 2 413 Adapter cable
Note: For direct connection to battery or terminal
9 = 61 2 419 Operating instructions
61 3 080 V-adapter lead for transfer case - ECU E83 (8-pin)
Minimum set: Measuring and testing equipment
Note: For checking function of engine at transfer box (X3)
Series: E83
Scheme 10
SI number: 02 08 03 (045)
Order number: 61 3 080
V-adapter lead for transfer case - ECU E83 (8-pin)
61 3 090 V-adapter lead DXC control unit E83 (6-pin)
Minimum set: Measuring and testing equipment
Note: For checking function of DXC control unit in X3
Series: E83
Scheme 11
SI number: 02 08 03 (045)
Order number: 61 3 090
V-adapter lead DXC control unit E83 (6-pin)
61 3 130 I-adapter lead airbag control unit E83 (75-pin)
Minimum set: Measuring and testing equipment
In conjunction with: Test box 61 4 380
Note: For checking function of airbag control unit in X3
Scheme 12
Series: E83
SI number: 02 08 03 (045)
Order number: 61 3 130
I-adapter lead airbag control unit E83 (75-pin)
61 3 300 Removal tool
Minimum set: Mechanical tools
Note: For removing ring antenna at ignition lock
Series: E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/C, E38, E38/3, E39, E39tou, E46, E52, E53, E60, E61, E63, E64,E83, E85, R50, R52, R53
SI number: 1 17 97 (228)
Order number: 61 3 300
Removal tool
Scheme 13
61 4 300 Adapter lead for OBD socket
Note: For connecting diagnosis system to OBD socket from 06/2000.
Storage location: Single
Scheme 14
SI number: 2 04 00 (561)
Order number: 61 4 300
Adapter lead for OBD socket
61 4 370 V-adapter lead (2-pin), zero-coded
Minimum set: Measuring and testing equipment
Note: Can be used on different plug housings in engine wiring harness (e.g. from Kostal - "SLK 2.8", Tyco - "Junior-Power-Timer" or Bosch) with different codings.
Series: E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91, R50, R52, R53, RR1
Scheme 15
SI number: 02 01 05 186
Order number: 61 4 370
V-adapter lead (2-pin), zero-coded
61 4 380 Measuring box, 105-pin, complete
Minimum set: Measuring and testing equipment
Note: For connecting all adapter cables with 61-pin to 105-pin plug connections
Series: E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91, R50, R52, R53, RR1
Storage location: G 110, S 205, U 202, U 205
SI number: 2 04 01(710)
Order number: 61 4 380
Measuring box, 105-pin, complete
Scheme 16
Consisting of
1 = 61 4 381 Measuring box, 105-pin
Note: Without accessories
2 = 61 4 382 Measuring cable, black
Note: 2 mm system, lead length: 750 mm
3 = 61 4 383 Measuring cable, red
Note: 2 mm system, lead length: 750 mm
4 = 61 4 384 Measuring cable set
Note: 2/4 mm system, lead length: 200 mm
5 = 61 4 385 Grounding cable
Note: For shield pick-off, lead length: 1.5 m
61 4 390 Measuring box, 60-pin
Minimum set: Measuring and testing equipment
Note: For connecting all adapter cables with 27-pin to 60- pin plug connections
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91, R50, R52, R53, RR1
Storage location: T 210
SI number: 2 02 98(308)
Order number: 61 4 390
Measuring box, 60-pin
Scheme 17
61 6 060 Universal wiper arm puller
Minimum set: Mechanical tools
Note: For removing windscreen wiper arm from drive shaft
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91, RR1
Storage location: B40
SI number: 1 10 99 (433)
Order number: 61 6 060
Universal wiper arm puller
Scheme 18
Consisting of
1 = 61 6 061 Basic body
2 = 61 6 062 Claw, left/right
3 = 61 6 063 Spindle
4 = 61 6 064 Thrust piece
61 6 210 Wiper arm puller
Minimum set: Mechanical tools
Series: E52, E53, E60, E61, E63, E64, E83, E85, E87, E90, E91, R50, R52, R53
SI number: 1 01 05 (172)
Order number: 61 6 210
Wiper arm puller
Scheme 19
61 9 045 Female die
In conjunction with: 61 9 041 Crimping tool
Note: For crimping 2.5 mm (dia.) sleeves
Order number: 61 9 045
Female die
