Removal & Installation (a5s 360r/390r) BMW X3 E83

Automatic Trans 18 illustrations ~717 words

IDENTIFICATION

Note. For further information, see AUTOMATIC TRANSMISSION .

Model (Chassis Code)Engine Size (Code)
2004-05
X3 (E83)2.5 L (M54)
X3 (E83)3.0 L (M54)

VEHICLE IDENTIFICATION

CAUTIONDisconnecting vehicle battery will cancel fault codes of control units. On vehicles with radio codes, after disconnecting battery, radio codes must be re-entered. Obtain radio code card from customer. Note stored stations and restore then after connecting battery. Also, where applicable, initialize sunroof and set steering angle.

AUTOMATIC TRANSMISSION

CAUTIONUse only the approved transmission fluid in this automatic transmission. Failure to comply with this requirement will result in serious damage to the automatic transmission. Catch and dispose properly escaping transmission fluid.

Note. For filling and servicing, see SERVICING - A/T .

Note. Numbers in text refer to numbers in figures.

  1. Disconnect battery.
  2. Remove front underbody protection. Remove reinforcement plate. (Scheme 191)
  3. Remove exhaust system as necessary to remove transmission. See EXHAUST article.
  4. Remove heat shield.
  5. Unfasten screws and remove front propeller shaft at transfer box and tie to one side. See FRONT DRIVE SHAFT article.
  6. Supporting engine and transmission: install Special Tool (11 0 250) between dome cross-brace and engine suspension eye and secure with dowel pin. (Scheme 192) Pretension special tool with adjusting screw (1) to measurement "A". Installation position, measurement "A" = 36 cm.
  7. Remove propeller shaft from transmission. See «DRIVE SHAFTS & UNIVERSAL JOINTS»(/bmw/x3/e83-2003-2006/remont/driveshaft-universal-joints/#propeller-shaft-removal-installation) article. Release center bearing. Tie propeller shaft to one side.
  8. Grip clamping sleeve (1) and loosen selector lever nut (2). (Scheme 193)
  9. Release screws (1). (Scheme 194) Remove holder with shift cable (2).
  10. Unscrew bolt (1). (Scheme 195) Disconnect hydraulic lines (2) to transmission fluid cooler.
  11. Release screw (1) on engine carrier. (Scheme 196) Lay hydraulic lines to one side.
  12. Lift off cover. (Scheme 197)
  13. Crank engine at vibration damper in direction of rotation until screw is visible in opening. (Scheme 198) Release all screws of torque converter with Special Tool (24 1 110). Crank engine further and release remaining 2 screws.
  14. Protect torque converter from slipping out. To do so, insert Special Tools (24 4 131 / 24 4 137) in opening in transmission housing. Clamp torque converter. (Scheme 199)
  15. Unfasten screws and remove cross member. (Scheme 200)
  16. Detach plugs (1) and (2) from servomotor. (Scheme 201)
  17. Unlock plug (1) and remove. (Scheme 202) Unclip cable from transmission housing.
  18. Lowering transmission: turn Special Tool (11 0 250) back with adjusting screw (1) to measurement "A". (Scheme 192) Transmission removal position, measurement "A" = approx. 34 cm.
  19. Support transmission with Special Tools (00 2 030 / 24 5 301 / 24 5 305). (Scheme 203)
  20. Unscrew bolt (1) (Scheme 204)
  21. Unfasten screws. (Scheme 205) Pull transmission of engine towards rear and lower.

Scheme 191

Scheme 191
Scheme 191

Scheme 192

Scheme 192
Scheme 192

Scheme 193

Scheme 193
Scheme 193

Scheme 194

Scheme 194
Scheme 194

Scheme 195

Scheme 195
Scheme 195

Scheme 196

Scheme 196
Scheme 196

Scheme 197

Scheme 197
Scheme 197

Scheme 198

Scheme 198
Scheme 198

Scheme 199

Scheme 199
Scheme 199

Scheme 200

Scheme 200
Scheme 200

Scheme 201

Scheme 201
Scheme 201

Scheme 202

Scheme 202
Scheme 202

Scheme 203

Scheme 203
Scheme 203

Scheme 204

Scheme 204
Scheme 204

Scheme 205

Scheme 205
Scheme 205
CAUTIONOil cooler and lines must always be flushed before a replacement transmission is installed.
CAUTIONWhen joining up engine and transmission, ensure ease of movement of torque converter.
  1. If replacing transmission, fit shift lever, brackets for cables and retainers from old transmission to new transmission.
  2. Check dowel sleeves (1) and (2) for correct seating. (Scheme 206) Replace damaged dowel sleeves.
  3. The sheet metal flywheel is equipped with three recesses for the torque converter retaining tabs. (Scheme 207) When guiding the engine and transmission together the three mounting tabs on the torque converter must be aligned with the three indentations in the sheet metal flywheel. Non-conformance leads to follow-up damage on the automatic transmission. Turning on the torque converter, or engine, is no longer possible after guiding the engine and transmission together and would lead to damage.
  4. Before joining transmission with engine, remove Special Tools (24 4 131 / 24 4 137).
  5. Tighten transmission-to-engine screws to specification. (Scheme 205) See «TORQUE SPECIFICATIONS»(/bmw/x3/e83-2003-2006/remont/automatic-trans/#removal-installation-a5s-360r390r__torque-specifications).
  6. Tighten guard bolt to specification. (Scheme 204) See «TORQUE SPECIFICATIONS»(/bmw/x3/e83-2003-2006/remont/automatic-trans/#removal-installation-a5s-360r390r__torque-specifications).
  7. Before installing transmission cross-member, turn Special Tool (11 0 250) back with adjusting screw (1) to measurement "A" (installation position). (Scheme 192) Installation position, measurement "A" = approx. 36 cm. Tighten cross-member screws to specification. See «TORQUE SPECIFICATIONS»(/bmw/x3/e83-2003-2006/remont/automatic-trans/#removal-installation-a5s-360r390r__torque-specifications).
  8. Tighten torque converter-to-flywheel screws to specification. (Scheme 198) See «TORQUE SPECIFICATIONS»(/bmw/x3/e83-2003-2006/remont/automatic-trans/#removal-installation-a5s-360r390r__torque-specifications).
  9. Replace sealing rings on hydraulic lines.
  10. Install nut for selector lever cable to specification. See «TORQUE SPECIFICATIONS»(/bmw/x3/e83-2003-2006/remont/automatic-trans/#removal-installation-a5s-360r390r__torque-specifications).
  11. Grip clamping sleeve (1). (Scheme 208) Slacken nut (2). Press selector lever (3) forwards into park position. Press cable (4) in direction of arrow and release again. Grip clamping sleeve (1). Tighten down nut (2) to specification. See «TORQUE SPECIFICATIONS»(/bmw/x3/e83-2003-2006/remont/automatic-trans/#removal-installation-a5s-360r390r__torque-specifications). Check whether parking gear is engaged by turning propeller shaft.
  12. Install propeller shaft. See «DRIVE SHAFTS & UNIVERSAL JOINTS»(/bmw/x3/e83-2003-2006/remont/driveshaft-universal-joints/#propeller-shaft-removal-installation) article.
  13. Install front propeller shaft and tighten fasteners to specification. See «TORQUE SPECIFICATIONS»(/bmw/x3/e83-2003-2006/remont/automatic-trans/#removal-installation-a5s-360r390r__torque-specifications).
  14. To install reinforcement plate, torque screws (2) to specification. (Scheme 191) See «TORQUE SPECIFICATIONS»(/bmw/x3/e83-2003-2006/remont/automatic-trans/#removal-installation-a5s-360r390r__torque-specifications).
  15. After completion of work, check transmission fluid level. Top up if necessary.

Scheme 206

Scheme 206
Scheme 206

Scheme 207

Scheme 207
Scheme 207

Scheme 208

Scheme 208
Scheme 208

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Center Mount-To-Body15 (21)
Flexible Disk-To-Front Axle Differential44 (60)
Flexible Disk-To-Transmission Output Flange66 (90)
Front Propeller Shaft-To-Transfer Box/Front Differential63 (85)
Reinforcement Plate-To-Front Axle Support/Engine Carrier55 (74)
Torque Converter-To-Flywheel33 (45)
Transmission Cross-Member-To-Body15 (21)
Transmission Cross-Member-To-Rubber Mounts55 (74)
Transmission-To-Engine
Hex Screws
M8 Thread18 (24)
M10 Thread33 (45)
M12 Thread60 (82)
Torx Bolts
M8 Thread15 (21)
M10 Thread31 (42)
M12 Thread53 (72)
INCH Lbs. (N.m)
Clamping Screw On Shift Lever89 (10)
Guard80 (9)

TORQUE SPECIFICATIONS
