Maintenance and General Information - Repair Instructions BMW M5 E60/E61

00 Danger Of Poisoning Of Oil Is Ingested/Absorbed Through The Skin

Danger of poisoning!

Ingesting oil or absorbing through the skin may cause poisoning!

Possible symptoms are

1. Headaches
2. Dizziness
3. Stomach aches
4. Vomiting
5. Diarrhoea
6. Cramps/fits
7. Unconsciousness

Protective measures/rules of conduct

1. Pour oil only into appropriately marked containers
2. Do not pour oil into drinking vessels (drinks bottles, glasses, cups or mugs)
3. Observe country-specific safety regulations

First aid measures

1. Do not induce vomiting. If the person affected is still conscious, he/she must rinse out their mouth with water, drink plenty of water and consult a doctor immediately. If the person affected is unconscious, do not administer anything by mouth, place the person in the recovery position and seek immediate medical attention.

00 Risk Of Injury If Oil Comes Into Contact With Eyes And Skin

Danger of injury!

Contact with eyes or skin may result in injury!

Possible symptoms are

1. Impaired sight
2. Irritation of the eyes
3. Reddening of the skin
4. Rough and cracked skin

Protective measures/rules of conduct

1. Wear protective goggles
2. Wear oil-resistant protective gloves
3. Observe country-specific safety regulations

First aid measures

1. Eye contact: Rinse eyes immediately with plenty of water for at least 15 minutes; if available, use an eye-rinsing bottle. If irritation of the eyes persists, consult a doctor.
2. Skin contact: Wash off with soap and water immediately. If irritation persists, consult a doctor. NOTE: Do not use solvents/thinners.

00 Safety Instructions For Handling Oil

Recycling

Observe country-specific waste-disposal regulations.

Measures if oil is unintentionally released

1. Personal precautionary measures: Danger of slipping! Keep non-involved persons away from the work area. Wear personal protective clothing/equipment.
2. Environmental protection measures: Prevent oil from draining into drain channels, sewerage systems, pits, cellars, water and the ground.
3. Limiting spread: Use oil blocks to prevent the surface spread of oil.
4. Cleaning procedure: Bind and dispose of escaped oil with nonflammable absorbents. NOTE: Do not flush oil away with water or aqueous cleaning agents.

00... BMW Condition Based Service (Gasoline Vehicles)

1. Standard scopes 00 00 105 Standard scope of service
2. Engine oil 00 00 610 Service - engine oil
3. Front brakes 00 00 612 Service - front brakes
4. Rear brakes 00 00 614 Service - rear brakes
5. Microfilter 00 00 616 Service - microfilter
6. Brake fluid 00 00 618 Service - brake fluid
7. Spark plugs 00 00 622 Service - spark plugs
8. Service - vehicle check 00 00 624 Service - vehicle check

00... Notes On SMG Transmission Service Functions

Note. The service functions must be carried out in the relevant order!

SMG TRANSMISSION SERVICE FUNCTIONS

00.... Pre-Delivery Check

1. Interrogate fault memories in Diagnosis System
2. Check engine oil level, top up if necessary
3. Fuel lines, hoses and tank(s): visual inspection for routing, condition and leaks
4. Check rim size, tire size and type and tire inflation pressure (also spare wheel)
5. Connections and pipes of brake system: visual inspection for leaks, damage and correct position
6. Remove spring blocker/reset transport mode
7. Compare scope of order with scope of delivery
8. Hand over Owner's Handbook/Manual(s), Service Booklet, BMW Group Service Contacts, Upkeep and Mobile Service brochures, two remote control master keys, a spare key and a key fob with vehicle
9. Check nameplate and vehicle identification number
10. Attach sticker for BMW Group Mobile Service
11. Check battery
12. Check lighting system, instrument lighting, heater blower, horn, headlight flasher and hazard warning flashers
13. Check telltale and warning lamps
14. Check Control messages
15. Wiper blades: Remove protective sleeves
16. Check function of lighter
17. Check automatic A/C, ventilation and fan
18. Check function of central locking
19. Radio: Check functions
20. Switch through electrical consumers, check function of remote control and other optional extra fitted
21. Check function of instruments

Quality assurance by BMW Service

Scheme 170

00...... Lifting Vehicle With A Lifting Platform

Note. The lifting platform must comply with the relevant statutory accident prevention regulations and be serviced according to the manufacturer's instructions.

Necessary preliminary tasks

1. If necessary, remove jacking points from equipment pack and insert from below into openings in front and rear sill areas

Scheme 171

00...... Notes On Using Repair Instructions, Technical Data, Tightening Torques

These repair instructions are intended to help expertly carry out maintenance and repair work.

They thus supplement the practical and theoretical training of master mechanics and fitters in BMW's Service Training Centers.

The Repair Instructions describes the removal, installation and replacement of subassemblies in the vehicle.

The Repair Instructions describe tasks which can be carried out on series-production BMW Group vehicles and vehicles which have not been subsequently converted.

Cross-references to "Technical Data" and "Tightening Torques" must be complied with.

If there are no cross-references to tightening torques in the repair instructions, the excerpts from the company standard BMW N 600 02.0 must be observed.

Cross-references to other flat rate units are intended as an aid and can refer to a complete work operation or merely to individual work steps contained therein.

Cross-references to other flat rate units must not be considered as an extension of the labor performance standard.

The structure of the Repair Instructions corresponds to the numbering system of the flat rate manuals (flat rate units).

Note. With the exception of inspection operations, no flat rates are published for the E52 (Z8) model series. However, the numbering system (flat rate units) is retained.

Furthermore, the corresponding microfiches of the repair instructions are valid for the E12, E21, E24, E28, E30, E31 and E34 model series.

The microfiche is also valid for the E32 model series with the following exception: For the 750i, 750Li models and the job description 31 31 000 Replacing front left or right spring strut, the TIS CD must be used!

In general, the individual work steps of the Repair Instructions describe only the removal of subassemblies. All removed subassemblies are reinstalled in reverse sequence. If particular features need to be observed during installation, they are identified as notes on installation. In contrast, complicated removal and installation procedures are described separately.

00...... Raising Vehicle With Trolley Jack

Scheme 172

Scheme 173

1. Car jacking point
2. Side car jacking points
3. Rear differential Risk of damage: It is not permitted to raise the vehicle at the rear differential cover!

00..... Symbols Used And Information In Repair Instructions

Example

Note. Particular information on improved procedures for operation, testing, adjustment and upkeep. Also indicates the end of a repair section.

Recycling

Observe country-specific waste-disposal regulations

General information

Refers to other instructions: such as e.g.

Necessary preliminary tasks

Further instructions: refer to operating instructions for balancing machine.

Replacement

Carry out programming/coding.

Note. Many electronic control units must be programmed/coded (e.g. when replaced).

Note. Connect BMW diagnosis system

Note. Electronic control units and other electronic components - if handled incorrectly - can be damaged or destroyed by electrostatic discharge.

00 00... Battery: Checking Display. If Necessary, Recharge Battery.

Vehicles with low-maintenance battery

Check acid level, top up with distilled water if necessary

If level drops below Max. marking, top up distilled water to Max. marking.

Vehicles with maintenance-free battery

Check charge start by way of magic eye

Issue a separate invoice if the battery is recharged.

00 00... Body And Underbody: Checking For Corrosion And Damage

Inspect chassis, underbody and wheel arches and check for corrosion and damage.

Note. It is absolutely essential to rectify any identified faults after consulting the customer and to issue a separate invoice.

00 00... Body: Check For Corrosion (Except Cavities)

Visually inspect the underbody, wheel arches and frame members for rust and damage.

Rectify identified faults after consulting with customer and issue a separate invoice.

00 00... Brake Lines And Connections: Visual Inspection For Leaks, Damage And Correct Position

Check brake lines and connections

1. Visual inspection in visible area for: Check brake fluid level in expansion tank leaks traces of fluid damage crushing/flattening correct routing of brake lines correct seating of brake lines in holders

Note. Detected faults must urgently be repaired after consultation with the customer!

00 00... Check Windscreen Wash/Wipe System

1. Check wipe pattern for smearing; if necessary, replace wiper blades after consulting with customer
2. The spray jet must emerge uniformly from the spray nozzle, replace nozzle if necessary and issue a separate invoice.
3. The spray nozzles are preset at the factory and cannot be adjusted later

00 00... Checking Coolant Level And Concentration, Correcting If Necessary

1. Check connections, hose clamps and hoses for coolant residues and damage such as e.g. cracks.
2. Check coolant level in expansion tank. Coolant level must be between Min. and Max. markings. If necessary, top up coolant to max. fill level.
3. In event of topping up: Check concentration with antifreeze tester (special tool) in coolant expansion tank. If necessary, drain off the difference quantity at the coolant drain plug and top up with recommended coolant (issue a separate invoice).

00 00... Checking Horn, Headlight Flashers And Hazard Warning System

Horn

Check function.

Note. In the case of twin-tone fanfares, make sure that both fanfares are working properly.

Headlight flasher

Activate headlight flashers, check high-beam headlights and blue indicator lamp in instrument cluster for correct operation.

Hazard warning system

Check function.

Note. After consultation with the customer, rectify faults and issue a separate invoice.

00 00... Checking Instrument And Indication Field Lighting, Heater Blower

Instrument lighting

Check function of instrument and indicator/warning lamps.

Indication field lighting

Check function of light switches; dimmer; controls; heater/air conditioning; rear window demister; radio; (depending on equipment) on-board computer; power windows; electric sunroof; fog lamp.

Heater

Check function of all blower stages, air distribution and air outlet.

Note. After consultation with the customer, rectify faults and issue a separate invoice.

00 00... Checking Lighting System

1. Check lighting system for correct operation: Check headlights, rear lights and associated telltale/indicator lamps Check side lamps, parking lights, dipped-beam and main-beam headlights for correct operation Check headlight flasher for correct operation Check signal horn Check left/right direction indicators and hazard warning system for correct operation Check brake lights for correct operation Check reversing lights and license plate lights for correct operation Check front and rear fog lights for correct operation Check inside light on interior rearview mirror for correct operation Check instrument and indication field lighting

Note. Perform a check of headlight adjustment, only at the customer's request and issue a separate invoice.

00 00... Checking Roadworthiness (Test Drive)

1. Checking roadworthiness Take vehicle for a test drive, checking service and parking brakes in the process For vehicles with rear disc brakes, brake in parking brake as instructed Check steering for play, ease of movement and directional stability Check clutch for problem-free disengagement and non-spasmodic driving off at normal operating temperature Check function of all drive positions and driving programs in cars with automatic transmissions Visually inspect shock absorbers for leaks Check indicator/warning lamps and Check Control system for correct operation Check due date for statutory roadworthiness and exhaust emission tests and advise customer of test dates

00 00... Diagnostic Brief Test

Connect diagnostic system to OBD socket.

Switch on ignition.

Carry out vehicle identification.

Click on Brief test.

The brief test is carried out.

Note. For motor vehicle diagnostics, the brief test is essential for evaluating possible stored diagnostic trouble codes. In the brief test, the control units are physically identified in succession and their fault memories read out. If the fault memory has been read out, the faults appear in the "Fault pattern selection" mask in the "Fault memory contents" field. Check identified faults and if necessary rectify these faults after consulting with customer.

Scheme 174

INFORMATION/WARNING LABELS SPECIFICATION

Key

US = United States

CDN = Canada

CCC = Car Communication Computer

OBD = On-Board Diagnosis

00 00... M Mobility System: Checking Expiry Date On Sealant Bottle

Note. Check expiry date on sealant bottle and if necessary replace sealant bottle Issue a separate invoice for replacing the sealant bottle

00 00... Microencapsulated Screws

Screw locking is a means to preventing a screwed connection from being loosened by external influences.

After the screw has been coated with the adhesive, the adhesive remains inactive until it is activated by capsule breakage when the screw is inserted and then cures at room temperature.

Installation

1. Microencapsulated screws (Loctite) must be replaced and may not be reused
2. Screw connection must be completed within 20 mins. (start of curing)
3. Microencapsulated screws must not be retightened
4. Thread of nut must be cleaned beforehand in event of repeated use

00 00... Raising BMW Multi-Trailer

The lifting platform must comply with the relevant statutory accident prevention regulations and be serviced according to the manufacturer's instructions. It is essential to follow the lifting platform operating instructions, in particular the safety instructions and carrying capacity!

Make sure you adhere to the BMW-recommended work area of 5 x 7 m and to an escape route of 0.6 m between two lifting platforms.

Before raising the BMW multi-trailer, please observe the following points

1. Raise the trailer only when it is unloaded
2. Remove a supplied loading ramp from the loading ramp frame so that all chassis areas of the BMW multi-trailer are freely accessible
3. There must be sufficient clearance between the carrier arms/flat girder bridges and the GFK aprons or the front guard of the BMW multi-trailer
4. The BMW multi-trailer must always be positioned in the middle of the lifting platform.

The areas (2) on the longitudinal members (1) marked in the adjacent diagram are the best areas for attaching the additional supports.

Scheme 175

General notes on using twin-pillar lifting platforms

For the twin-pillar lifting platforms described, the BMW multi-trailer is positioned in the direction of travel on the platform. For lifting platforms which do not create sufficient clearance between disk wheel and carrier arms, move the BMW multi-trailer against the direction of travel onto the platform.

Becker & Sohne twin-strut underfloor platform

The BMW multi-trailer can only be raised if it is supported at right angles to the direction of travel. For raising, use the high additional supports (1) of Becker & Sohne.

Scheme 176

MAHA twin-pillar lifting platform

The BMW multi-trailer can only be raised if you use the support plate attachment sleeves for transporters (1). Position the axle of the BMW multi-trailer in the direction of travel in front of the pillars of the platform in order to obtain the specified lifting ranges and to establish sufficient clearance between disk wheel and carrier arms. The long carrier arms raise the front and the short carrier arms raise the rear of the BMW multi-trailer.

Scheme 177

Romaico-Lift twin-pillar lifting platform

The BMW multi-trailer can only be raised if you use the 146 mm high attachments (1). Position the axle of the BMW multi-trailer in the direction of travel in front of the pillars of the platform in order to obtain the specified lifting ranges and to establish sufficient clearance between disk wheel and carrier arms. The long carrier arms raise the front and the short carrier arms raise the rear of the BMW multi-trailer.

Scheme 178

Working pit

The BMW multi-trailer can be serviced or repaired in conjunction with a working pit if the following measures are taken into consideration. The BMW multi-trailer must be secured against slipping/tilting sideways. The drawbar jockey wheel must be firmly secured against rolling.

Belt strap, retractor mechanism, belt interlock

Pull out strap and make sure it emerges without jerking.

Check belt strap for

1. folding
2. unraveling
3. pinches
4. cracks and tears
5. traces of melting

Retract belt strap; here the inertia reel mechanism must retract the strap automatically and without squeaking noises, the last section of the strap may have to be fed in.

Pull out belt strap in short tugs - locking reel must lock.

Belt buckle

The tongue on the belt strap must easily snap into place with an audible click.

When the "Press" button is pressed, the tongue must be ejected from the buckle under spring pressure.

Note. If the seat belt is damaged, you must replace the seat belt completely after consulting the customer; issue a separate invoice for this work. Instructions on how to proceed, refer to PASSIVE SAFETY SYSTEM - OVERVIEW .

00 00... Steering Components: Checking For Zero Clearance, Leaks, Damage And Wear

Checking play

1. For hydraulically assisted steering systems, the engine must be running
2. For electrically assisted steering systems, the ignition must be on
3. Steering wheel: Move steering wheel back and forth and check for play
4. Tie rod joint: There must no clearance between tie rod arm (2) and tie rod joint (1).

Scheme 179

Checking for leaks

The following illustration shows the arrangement of the power steering components and lines.

Scheme 180

00 00... Steering Fluid Reservoir: Check Oil Level.

Visual inspection and leak test

Check connections, hoses and steering gear for traces of fluid.

Checking fluid level

Check fluid level with engine switched off at expansion tank of power steering/ride-height control system. The fluid temperature should be approx. 20 °C here.

Ensure that the cap is fully screwed in prior to the fill level check.

If necessary, add hydraulic fluid (refer to OPERATING FLUIDS - STEERING ) up to Max. marking (1).

Scheme 181

Note. To avoid mix-ups when filling with hydraulic fluid, mark the fluid reservoirs or their caps with identification marks. ATF Automatic transmission fluid CHF Pentosin CHF 11S

Scheme 182

00 00... Tires: Checking Inflation Pressure, Correcting If Necessary (Incl. Spare Wheel), Checking External Condition, Tread Depth, Pattern

1. Checking tire inflation pressure: Check tire inflation pressure in accordance with information plate on B-pillar The inflation pressure in the spare wheel must be 0.5 bar higher than the maximum specified value on the information plate Initialize Run Flat Indicator
2. Checking tire condition: Check tread depth of all tires with tire tread gauge Check tire tread surfaces and side walls for incisions and foreign particles such as nails or screws Check tire tread pattern for localized flattening and wear on one side; if necessary, carry out wheel/chassis alignment after consulting with customer and issue a separate invoice for this work

Note. For reasons of driving safety, only use tires of the same type and tread pattern on a single vehicle Inform customer of any incorrect or worn tires

00 00... Underbody Incl. All Visible Components: Checking For Damage, Leaks, Corrosion

1. Visually inspect underbody: For leaks (transmission, brake components, steering) Damage to underbody Corrosion on underbody

Rectify identified faults after consulting with customer and issue a separate invoice.

00 00... Upkeep Measures For Stored Vehicles (New And Used Cars) And Vehicles To Be Laid Up At Customer's Premises

MEASURE VEHICLES AND IMPLEMENTATION CHART

00 00... Windscreen Washer System: Checking Fluid Level, Topping Up If Necessary

1. Top up windscreen washer fluid reservoir, if necessary rear window washer fluid reservoir and (depending on equipment specification) intensive cleaning reservoir up to edge or mark.

00 00 005 Interrogate Fault Memories In Diagnosis System

Connect diagnostic system to OBD socket.

Switch on ignition.

Carry out vehicle identification.

Click on Brief test.

The brief test is carried out.

Note. For motor vehicle diagnostics, the brief test is essential for evaluating possible stored diagnostic trouble codes. In the brief test, the control units are physically identified in succession and their fault memories read out. If the fault memory has been read out, the faults appear in the "Fault pattern selection" mask in the "Fault memory contents" field.

00 00 105 Standard Scope Of Service

1. Standard scope of service Check Control messages Check telltale and warning lamps

00 00 600 Service Running-In Check (S85)

1. Service running-in check Engine oil service Oil change in SMG transmission incl. oil strainer cleaning Oil change in rear differential Reset CBS display according to factory specification

00 00 602 Service - Intake Muffler

1. Change air cleaner element in accordance with repair instructions
2. Reset CBS display according to factory specification

00 00 610 Engine Oil Service (S85)

Note. The S85 engine is equipped with an engine oil sump (oil pan) with separate oil chambers. During an oil change, the oil is drained solely from the main oil sump (rear chamber). The oil from the front chamber is pumped permanently into the main oil sump by a separate oil pump. For this purpose, the engine must be run at idle for at least 1 minute immediately prior to an oil change.

Recycling

Catch and dispose of engine oil with suitable equipment.

Note national regulations.

Necessary preliminary tasks

1. M5: Release service flaps.
2. M6: Detach underbody protection.

Explanation of instrument displays

1. Oil level is OK.
2. Oil level at minimum.
3. Oil level too high (overfilled > or = 0.5 liters).
4. Oil level at maximum.
5. Rapid measurement running: oil level is being determined.
6. A reading cannot be taken at present (engine oil temperature > or = 70°).

Scheme 183

Run engine at idle speed.

Keep pressing on-board computer button on direction indicator lever until oil level reading can be read off in instrument display.

Press on-board computer button for longer than 3 seconds to reset the display value.

Run engine at idle until the oil level is determined again (engine oil temperature of > or = 70 °C).

The required oil temperature for an engine oil change is thus achieved.

Measurement range from minimum (3) to maximum (2) = 1 liter.

Scheme 184

Open oil drain plug (1) on oil filter housing.

Tightening torque. See ENGINE - TIGHTENING TORQUES -- M5 .

Installation

Replace sealing ring.

Release oil filter housing (2).

Tightening torque. See ENGINE - TIGHTENING TORQUES -- M5 .

Installation

Replace all sealing rings.

Replace filter element.

Scheme 185

Carry out all tasks only when wearing oil-resistant, heat-resistant protective gloves incl. underarm protection, face guard and protective apron.

Open screw plug (1) with socket and a long extension (2).

Installation

Replace sealing ring.

Tightening torque. See ENGINE - TIGHTENING TORQUES -- M5 .

Scheme 186

Tilt long extension (1) with socket and screw plug in direction of arrow.

Catch and dispose of engine oil with suitable equipment.

Scheme 187

Pour in engine oil.

Park vehicle on a horizontal surface.

Start engine and run at idle until an engine oil temperature > or = 70° is reached.

Press on-board computer button for longer than 3 seconds.

Determine the oil level again.

Measurement range from minimum to maximum = 1 liter.

1. Oil level (+0.6 l)
2. Range for maximum
3. Range for minimum

The oil fill quantity is 0.6 l above the permissible minimum.

Top-up quantity to be calculated

1 liter - 0.6 liter (display) = 0.4 liter top-up quantity.

Allow engine at normal operating temperature to run at idle for 1 minute.

1. Running-in check!

Carry out distance travelled reset only with the BMW diagnosis system.

Top up engine oil.

1. Engine oil service!

Distance travelled RESET can be carried out with the BMW diagnosis system or with the instrument cluster.

An exact measurement of the engine oil fill quantity can be read out via the BMW diagnosis system in the DME in the test module (Oil condition measurement) .

Top up engine oil.

1. Overfilling of engine oil

Start engine and run at idle (engine oil temperature > or = 70°).

Run engine at idle speed.

Keep pressing on-board computer button on direction indicator lever until oil level reading can be read off in instrument display.

Press on-board computer button for longer than 3 seconds to reset the display value.

Run engine at idle until the oil level is determined again (engine oil temperature of greater than 70 °C).

The required oil temperature for an engine oil change is thus achieved.>

Note. An overfill value of up to 0.5 liter can be displayed in the instrument cluster. Further overfilling of more than 0.5 liter can be read out via the BMW diagnosis system. The BMW diagnosis system can display overfilling of up to 3.5 liters. If overfilling is suspected, we recommend that the oil filling be corrected with the BMW diagnosis system.

Select following steps on BMW diagnosis system

1. Complete vehicle
2. Drive
3. Engine electronics
4. Oil supply
5. Oil condition sensor

Switch off engine and detach underbody protection.

Open oil drain plug (1) on oil filter housing.

Tightening torque. See ENGINE - TIGHTENING TORQUES -- M5 .

Note. Drain quantity in air cleaner housing approx. 0.4 liter . Perform this work step several times if necessary.

Add final details to vehicle.

00 00 610 Service - Engine Oil (S85 From 03/2007)

1. Service - engine oil Change engine oil and oil filter Handbrake Brake in and check for correct function A/C system or automatic A/C: Change microfilter At every 1st and every 3rd engine oil change: Change gearbox oil, clean oil filter Change rear differential oil At every 3rd engine oil change Intake silencer: change air cleaner element. Shorten intervals accordingly for vehicles operated in dusty regions. Replace spark plugs Resetting CBS display according to factory specification

00 00 610 Service - Engine Oil (S85 Up To 02/2007)

1. Service - engine oil Change engine oil and oil filter Handbrake Brake in and check for correct function At every 1st and every 3rd engine oil change: Change SMG transmission oil, clean oil filter Change rear differential oil At every 3rd engine oil change Intake silencer: change air cleaner element. Shorten intervals accordingly for vehicles operated in dusty regions. Resetting CBS display according to factory specification

00 00 610 Service - Engine Oil (S85)

1. Service - engine oil Change engine oil and oil filter Handbrake is to be checked for correct operation At every 1st and every 3rd engine oil change: Change SMG transmission oil, clean oil filter Change rear differential oil At every 3rd engine oil change Intake silencer: change air cleaner element. Shorten intervals accordingly for vehicles operated in dusty regions. Resetting CBS display according to factory specification

00 00 610 Service - Engine Oil (Gasoline Vehicles)

1. Service - engine oil Change engine oil and oil filter Handbrake is to be checked for correct operation At 1st and every 3rd engine oil change Change SMG transmission oil and clean oil filter Change rear differential oil At every 3rd engine oil change Intake silencer: change air cleaner element. Shorten intervals accordingly for vehicles operated in dusty regions. Resetting CBS display according to factory specification

00 00 612 Service - Front Brakes

1. Service - front brakes Change brake pads, clean brake air ducts Brake discs Check surface and thickness If necessary: Replace Reset CBS display according to factory specification

Note. Clean brake air ducts. Replace brake discs if they are below the minimum brake disc thickness and if scoring, heat cracks or thickness difference are detected. Apply a thin coat of grease to wheel centering on light alloy wheels. Issue a separate invoice for replacing the brake discs.

00 00 614 Service - Rear Brakes

1. Service - rear brakes Change brake pads, clean brake air ducts Brake discs Check surfaces and thickness. If necessary: Replace Handbrake Check condition, brake lining thickness and function If necessary: Replace Reset CBS display according to factory specification

Note. Clean brake air ducts. Replace brake disks if they drop below minimum thickness (refer to BRAKES - TECHNICAL DATA ) and in event of scoring, heat cracks or thickness difference. Apply a thin coat of grease to wheel centering on light alloy wheels. Issue a separate invoice for replacing the brake discs and handbrake shoes.

00 00 616 Service - Microfilter

1. Service - microfilter Heating/air conditioning: change microfilter / carbon canister Reset CBS display according to factory specification

00 00 618 Service - Brake Fluid

1. Service - brake fluid Changing brake fluid Reset CBS display according to factory specification

00 00 622 Service - Spark Plugs

1. Service - spark plugs Replace spark plugs Reset CBS display according to factory specification

00 00 625 Service - Vehicle Check

1. Service - vehicle check Diagnostic brief test Checking horn, headlight flashers and hazard warning system Checking instrument and indication field lighting and heater blower Check lighting system Seat belts: check condition of belt strap, function of inertia reel mechanism, locking reel and belt buckle Check windscreen wash/wipe system Body: Check for corrosion (except cavities) M Mobility system: Check expiry date on sealant bottle and replace if necessary Tires: Check tread depth, pattern, external condition and inflation pressure and correct if necessary (spare wheel as well) Initialize Run Flat Indicator Check battery (magic eye), if necessary recharge battery (issuing a separate invoice for this work) Check display (magic eye) If necessary: Charge battery Steering fluid reservoir: Check fluid level. Check coolant level and concentration, top up if necessary Windscreen washer system: Check fluid level, top up if necessary Brake lines and connections: Check for leaks, damage and correct position Floor plate incl. all visible components: check for damage, leaks, corrosion Steering components: check for zero clearance, leaks, damage and wear Check roadworthiness (test drive): Brakes Steering Shock absorbers Transmission Reset CBS display according to factory specification

00 11... Checking/Topping Up Oil Level In Rear Differential

Undo oil filler plug (1).

Check oil level.

If necessary, pour in rear differential oil up to lower edge of opening for oil filler plug (1).

Scheme 188

Installation

1. Oil filler plug with sealing ring: Replace sealing ring (1). Tightening to specified torque ( «33 11 3AZ»(/bmw/m5/e60e61-2004-2010/remont/axle-shafts/#rear-axle-repair) ).
2. Oil filler plug with O-ring: Replace oil filler plug (2). Tightening to specified torque ( «33 11 9AZ»(/bmw/m5/e60e61-2004-2010/remont/axle-shafts/#rear-axle-repair) ).

Scheme 189

00 11 Draining/Topping Up Gear Oil In Manual Transmission

Note. Gearbox must be at normal operating temperature. Gear oil

1. Refer to «OPERATING FLUIDS - MANUAL TRANSMISSION»(ref-217929) .

Filling capacities

1. Refer to «00 11 230 CHANGING / TOPPING UP / CHECKING GEAR OIL IN MANUAL TRANSMISSION»(/bmw/m5/e60e61-2004-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions__00-11-230-changing-topping) .

Draining gear oil

1. Release oil drain plug (1) and filler plug (2).
2. Clean oil drain plug (1) and screw in.

Fill transmission with ATF.

1. Pour in gear oil until overflowing.
2. Tighten in filler screw (2).

Scheme 190

00 11 230 Changing / Topping Up / Checking Gear Oil In Manual Transmission

Recycling

Catch and dispose of gear oil with suitable equipment.

Observe country-specific waste-disposal regulations.

Necessary preliminary tasks

1. Unscrew and remove splash guard.

Draining gear oil

1. Open oil drain plug (1) and drain gear oil.
2. Activate transmission oil pump using DIS Tester ("Control unit functions-Component activation") for approx. 30 seconds. Pump activation can be performed several times in succession so that the specified time is achieved! Here the residual oil is pumped out of the pump circuit of the gear oil cooler into the transmission housing and drains off.
3. Clean oil drain plug (1) and screw in.

Scheme 191

Release screw (1).

Clean gear oil screen, replace if necessary

Installation

Replace sealing ring

Scheme 192

Release screw (1).

Remove gear oil cooler in direction of arrow.

Scheme 193

Installation

Journal (1) on gear oil cooler must be secured in rubber grommet (2)!

Scheme 194

Adding gear oil.

1. Undo oil filler plug (2).
2. Add 2.0 ltrs. of gear oil.
3. Refit oil filler plug (2).
4. Check gear oil level (see below).

Checking gear oil level

Note. Can also be carried out individually - without an oil change!

1. Activate gear oil pump for approx. 1 minute with DIS Tester (Component activation). Pump activation can be performed several times in succession so that the specified time is achieved.
2. Open oil filler plug.
3. Add gear oil up to lower edge of filler aperture.
4. Refit oil filler plug.

00 11 259 Oil Change In Rear Differential Incl. Used Oil Disposal

Note. The oil does not need to be changed in rear differentials carrying the "Life-Time-Oil" sticker. Only change oil when rear differential is at normal operating temperature.

Recycling

Catch and dispose of emerging differential oil.

Observe country-specific waste-disposal regulations

Oil drain plug present

Place oil collecting apparatus underneath.

Remove oil drain plug (1).

Drain and dispose of differential oil.

Undo oil filler plug (2).

Add differential oil up to lower edge of opening for oil filler plug (2); if necessary.

Scheme 195

Installation

Scheme 196

1. Oil drain or oil filler plug with sealing ring: Replace sealing ring (1). Tightening to specified torque ( «33 11 3AZ»(/bmw/m5/e60e61-2004-2010/remont/axle-shafts/#rear-axle-repair) ).
2. Oil drain or oil filler plug with O-ring: Replace oil drain or oil filler plug (2). Tightening to specified torque ( «33 11 9AZ»(/bmw/m5/e60e61-2004-2010/remont/axle-shafts/#rear-axle-repair) ). No oil drain plug: Undo oil filler plug (1). Drain and dispose of differential oil. Add differential oil up to lower edge of opening for oil filler plug (1); if necessary. Installation: Oil filler plug with sealing ring: Replace sealing ring (1). Tightening to specified torque ( «33 11 3AZ»(/bmw/m5/e60e61-2004-2010/remont/axle-shafts/#rear-axle-repair) ). Oil filler plug with O-ring: Replace oil filler plug (2). Tightening to specified torque ( «33 11 9AZ»(/bmw/m5/e60e61-2004-2010/remont/axle-shafts/#rear-axle-repair) ).

86 10... Positioning Of Multitrailer Hood For Maintenance And Repair Work

For maintenance and repair work, raise the hood using a lifting platform. Twin-column lifting platforms, body lifting platforms and twin-stamp underfloor platforms are suitable. The seating plates and areas of the lifting platform must be adjustable according to the dimensions. (Scheme 197)

Scheme 197

The lifting platform must conform to the relevant legal provisions of the accident prevention regulations and be serviced as specified. Comply with the lifting platform operating instructions, in particular the safety instructions and the carrying capacity.

Make sure you adhere to the BMW-recommended work area of 5 x 7 m and to an escape route of 0.6 m between two lifting platforms.

Please comply with the following instructions before raising the hood

1. Raise only when it is unloaded
2. Ensure sufficient clearance between the seating plates/seating areas and the GFP edge of the hood
3. The hood must always be positioned in the middle of the lifting platform.

Scheme 198

See also:
• PASSIVE SAFETY SYSTEM - OVERVIEW
• ENGINE - TIGHTENING TORQUES -- M5
• BRAKES - TECHNICAL DATA
• 33 11 3AZ
• 00 11 230 CHANGING / TOPPING UP / CHECKING GEAR OIL IN MANUAL TRANSMISSION
