Front Axle - Special Tools - e90 BMW M3 E90

Adapter MW

Replaced by: 0495567

Note. (Mounting adapter) For lowering or removing and fitting the front axle support. Drive type: All-wheel drive Replaced by: 31 5 250 (0 495 567)

SI number

01 17 05 (212)

Scheme 323

Consisting of

1 = 0495375 Fixture

Note. (Fixture 1 and 2)

2 = 0495376 Fixture

Note. (Fixture 3 and 4)

Note. (Adapter) For pulling off the taper roller bearings from the equalization housing in the front axle differential

Scheme 324

Bush MW

Note. (impact bush) For fitting the radial sealing ring to the drive flange of the front axle differential

Storage Location

X7

01 04 93 (664)

Scheme 325

Device Minimum set: Mechanical tools MW

Note. For detaching drive flange from all rear axle final drives

C7

Consisting of

5 = 0491903 Plate

Note. (Extractor plate) - Model series: E31, E32, E36 Replaced by 33 2 201.(0 496 063)

1 = 0491899 Spindle

Note. All rear axle final drives

2 = 0491900 Frame

Note. All rear axle final drives

3 = 0491901 Plate

Note. (Extractor plate) Model series: E28

4 = 0491902 Plate

Note. (Extractor plate) Model series: E30 and all rear axle final drives

6 = 0491904 Synchronizing key

Note. Series: E31, E32, E36

Scheme 326

Note. For installing front wheel bearing unit, special tool 31 2 113 for E67 and RR

C14

B14

Consisting of

3 = 0491908 Nut

Note. (Nut with bearing)

1 = 0491906 Spindle

Note. With guide sleeve

2 = 0491907 Bush

Note. (Pressure bush)

Scheme 327

Device MW

Note. For determining the fitting dimension at the drive bevel gear in the front axle differential

Consisting of

1 = 0491979 Bridge

Note. (Measuring bridge)

2 = 0491980 Washer

Note. (Measuring disc 7 mm)

Scheme 328

Replaced by: 0492053

Note. For pressing the wishbone off the spring strut/Replaced by 32 3 090 (0 492 053)

Consisting of

1 = 0493260 Spindle

Note. Replaced by 32 3 090.(0 492 053)

2 = 0493261 Bolt

Note. Replaced by 32 3 090.(0 492 053)

Scheme 329

Fixture MW

Note. (Universal axle take-up) Fixture for accommodating all front and rear axles when removing and installing.

01 24 06 (309)

Consisting of

1 = 0495817 Basic body

Note. (basic body)

2 = 0495818 Support

Note. (telescopic supports) 4 pieces

Scheme 330

3 = 0495819 Adapter

Note. (take-up adapter U-section (2 pieces))

4 = 0495820 Adapter

Note. (take-up adapter (2 pieces))

5 = 0495821 Adapter

Note. (take-up adapter for bore holes (2 pieces))

6 = 0495822 Adapter

Note. (take-up adapter for bore holes (2 pieces))

7 = 0495824 Belt

Note. (Tensioning strap)

Note. For securing wheel hub when removing and installing spring strut.

A19

01 23 05 (224)

Scheme 331

Replaced by: 0495567

Note. (Support set) For removing and installing front axle. Replaced by: 31 5 250 (0 495 567)

01 15 04 (117)

Scheme 332

Note. (mounting fixture) For the front axle differential

Scheme 333

Note. (Fixture set) For mounting the front axle. Replaced by: 31 5 250

01 24 03 (040)

Consisting of

1 = 0494838 Fixture

Note. (Fixture 1 and 2)

2 = 0494839 Fixture

Note. (Fixture 3 and 4) Series: E83

Scheme 334

Fork MW

Note. (Press-off fork) For pressing the output shaft off of the front axle differential (all-wheel drive vehicles)

01 17 05 (212)

Scheme 335

Holder MW

Note. (spring retainer) For accommodating coil springs when tensioning. No. 31 3 350 reserved for consecutive sub-number spring tensioner 31 3 340.

Individual

01 11 99 (438)

Consisting of

8 = 0494397 Ring

Note. (insert ring) For use with repair instructions only. For insertion in spring retainer ring 31 3 354. Model series:E87

Scheme 336

9 = 0494624 Ring

Note. (spring retainer ring) For use with repair instructions only.

4 = 0493568 Ring

Note. (spring retainer ring) For use with repair instructions only.

6 = 0493570 Ring

Note. (centering ring) For use with repair instructions only.

7 = 0494053 Holder

Note. (spring retainer (2 pieces)) For use with repair instructions only.

10 = 0494625 Holder

Note. (spring retainer) For use with repair instructions only.

11 = 0494804 Holder

Note. (spring retainer) For use with repair instructions only.

1 = 0493561 Holder

Note. (spring retainer (2 pieces)) For use with repair instructions only.

2 = 0493566 Holder

Note. (spring retainer (2 pieces)) For use with repair instructions only.

3 = 0493567 Holder

Note. (spring retainer (2 pieces)) For use with repair instructions only.

5 = 0493569 Holder

Note. (spring retainer) For use with repair instructions only.

Insert ring

Note. For inserting spring retainer ring 31 3 354 model series (PL2)

Mandrel MW

Note. (drift) For output shaft radial sealing ring in the front axle differential

Scheme 337

Mandrel Minimum set: Mechanical tools MW

Replaced by: 0495858

Note. (Drift set) For driving in the radial seal rings of the output shafts on the front axle differential (E46/16) Replaced by 31 4 160 (0 495 858)

C12

01 15 99 (483)

Scheme 338

Note. (drift) For radial sealing ring of the drive shaft in the front axle differential

Scheme 339

Open-end spanner Minimum set: Mechanical tools MW

Note. (Open-end spanner) Open-end spanner SW16/18 For counter-holding ball joint of anti-roll bar link.

C48

C47

01 24 03 (040)

Scheme 340

Pin MW

Note. (drive pin) For radial gears in the front axle differential for checking the coefficient of friction

Scheme 341

Pliers Minimum set: Mechanical tools MW

Note. For tensioning low profile binders of rubber cup on front output shaft (all-wheel drive).

01 04 05 (175)

Consisting of

1 = 0495268 Basic body

2 = 0495269 Die

Scheme 342

Pressing-out tool Minimum set: Mechanical tools MW

Note. For pressing track rod off wheel carrier.

B86

01 23 06 (308)

Consisting of

1 = 0495800 Bolt

Note. (Pressure bolt) Replaced by 31 2 311 (0 495 800)

Scheme 343

2 = 0495801 Shaped part

Note. (Shaped part) Replaced by 31 2 313 (0 495 802)

3 = 0495802 Shaped part

Note. (Shaped part) Replaced by 31 2 313 (0 495 802)

4 = 0495803 Spindle

Note. (Spindle and cylindrical pin) Replaced by 31 2 314 (0 495 803)

Replaced by: 0495799

Note. For pressing track rod off wheel carrier. Replaced by 31 2 310 (0 495 799)

C48

01 24 03 (040)

Scheme 344

Consisting of

1 = 0494808 Bolt

Note. (Pressure bolt) Replaced by 31 2 311 (0 495 800)

2 = 0494809 Shaped part

Note. (Shaped part) Replaced by 31 2 313 (0 495 802)

3 = 0494810 Shaped part

Note. (Shaped part) Replaced by 31 2 313 (0 495 802)

4 = 0494811 Spindle

Note. (Spindle and cylindrical pin) Replaced by 31 2 314 (0 495 803)

Socket Minimum set: Mechanical tools MW

Note. For expanding steering knuckle during spring strut removal

C47

01 05 03 (969)

Scheme 345

Spring tensioner Minimum set: Mechanical tools MW

Note. For tensioning coil springs when removing and installing spring strut. Used only in conjunction with repair instructions.

Individual

01 11 99 (438)

Scheme 346

Consisting of

1 = 0493556 Spring tensioner

Note. (spring tensioner, individual)

2 = 0493557 Pin

Note. (replacement pin)

Support MW

Note. (Support) For supporting the front axle support and the exhaust system during installation work

B7

01 06 94 (801)

Scheme 347

Thrust piece MW

Note. For press-fitting the roller bearing onto the differential casing

Scheme 348

Tool Minimum set: Mechanical tools MW

Note. (Pressing-in/-out tool) For rubber mount on trailing arm

B46

01 14 01 (766)

Consisting of

2 = 0494188 Bell housing

1 = 0494189 Bush

Scheme 349

Note. (Extractor) For pressing off wishbone from steering stub.

C12

01 06 94 (801)

Consisting of

6 = 0494805 Shaped part

Note. (Shaped part) Pressing off wishbone from wheel control joint E53, E83

Scheme 350

7 = 0496006 Shaped part

Note. (Shaped part) Pressing off wishbone from wheel control joint E70. SI 1 01 07 (333)

1 = 0491934 Shaped part

Note. (Shaped part) Replaced by 31 2 313 (0 495 802)

2 = 0491935 Shaped part

Note. (Shaped part) Replaced by 31 2 313 (0 495 802)

3 = 0491936 Spindle

4 = 0491937 Bolt

Note. (Pressure bolt) Replaced by 31 2 311 (0 495 800)

5 = 0491938 Pin

Note. (Cylindrical pin)

Washer MW

Note. (Spring washer) For pretensioning the differential side gears when determining the installation size in the front axle differential

Scheme 351

Note. For pulling the outer bearing race into the bearing housing in the front axle differential

Scheme 352

Note. For determining the fitting clearance of the radial gears in the front axle differential

Scheme 353

Wrench socket Minimum set: Mechanical tools MW

Note. (Wrench socket SW21) For releasing the bumper screw connection (front axle with EDC)

A11

01 06 94 (801)
