Rear Axle - Special Tools - e90 BMW M3 E90

Axle Shafts 59 illustrations ~4037 words

Device MW

Replaced by: 0492079

Note. (Fixture) For all rear axle final drives - model year: From 88 - Replaced by 33 1 070.(0 492 079)

Scheme 355

Scheme 355: Device MW

Note. For pulling off drive flanges (also E46/16).

Storage Location

C18

C17

Scheme 356

Scheme 356: Storage Location

Consisting of

4 = 0494872 Plate

Note. (Adapter plate) Transmission: GS6 57DZ, GS6 53BZ (G transmission) GS6 51DZ, GS6 51BZ (H transmission)

5 = 0494873 Screw

Note. (Countersunk screws M10x30 (3 x)) Transmission: GS6 57DZ, GS6 53BZ (G transmission) GS6 51DZ, GS6 51BZ (H transmission)

1 = 0493265 Spindle

2 = 0493266 Mandrel

3 = 0494631 Washer

Note. For removing and installing rubber mount in support tube of rear axle final drive mounting.

SI number

01 01 89 (989)

Consisting of

1 = 0492394 Plate

Note. (Shaped plate, top) For removing

2 = 0492395 Plate

Note. (Shaped plate, top) For pulling in

3 = 0492396 Plate

Note. (Shaped plate, bottom) For pulling in

Scheme 357

Scheme 357: SI number

Device Minimum set: Mechanical tools MW

Note. (Extraction and pulling device) For removing and installing output shaft in drive flange as well as for removing front wheel bearing unit. Replaced by 33 2 200.(0 496 062)

C13

C38

C14

Scheme 358

Scheme 358: Storage Location

Consisting of

1 = 0492170 Spindle

Note. (Pressure spindle) For pressing out. Series: E30, E31, E32, E36, E38, E39, E46, E53, E65, E66, E67, E83, E85 Replaced by 33 2 203.(0 496 066)

1 = 0492171 Bridge

Note. Replaced by 33 2 116.(0 492 175)

1 = 0492172 Shaped part

Note. (Shaped part) Model series: E30, E31, E32, E36, E38, E39, E46, E53, E65, E66, E85, RR1 Replaced by 33 2 117.(0 492 176)

7 = 0492176 Shaped part

Note. (Shaped part) Model series: E30, E31, E32, E36, E38, E39, E46, E53, E65, E66, E67, E83, E85 Replaced by 33 2 207/0 496 070

8 = 0492177 Spindle

Note. (Spindle for installation) Model series: E31, E52, E53, E60, E61, E65, E66, E67, E83 Replaced by 33 2 205.(0 496 068)

9 = 0492178 Spindle

Note. For installing/model series: E36, E46 Replaced by 33 2 206.(0 496 069)

4 = 0492173 Spindle

Note. For installing/model series: E30 Replaced by 33 2 204/0 496 067

5 = 0492174 Nut

Note. (Nut with bearing) Series: E30, E31, E32, E36, E38, E39, E46, E52, E53, E60, E61, E65, E66, E67, E83, E85, RR1 Replaced by 33 2 208/0 496 071

6 = 0492175 Bridge

Note. New version 09/98 Model series: E30, E31, E32, E36, E38, E39, E46, E52, E53, E60, E61, E65, E66, E67, E83, E85, E90, RR1 Replaced by 332 201/0 496 063

Note. (Device) For installing split rubber mounts.

A50

B50

Scheme 359

Scheme 359: Storage Location

01 15 04 (117)

Consisting of

1 = 0495038 Spindle

Note. (Spindle with handle)

2 = 0495039 Screw

Note. (Knurled screws (2 x))

3 = 0495040 Fixture

Note. (Fixture for diameter 46 mm)

4 = 0495041 Tensioning strap

Note. (Tensioning strap)

5 = 0495042 Fixture

Note. (Fixture for diameter 51 mm)

6 = 0495043 Tensioning strap

Note. (Tensioning strap)

Note. For extracting and press-fitting the rubber mount in the trailing arm.

01 01 89 (989)

Consisting of

1 = 0492379 Sleeve

Note. (support sleeve) During extraction

2 = 0492380 Sleeve

Note. (press-out sleeve)

3 = 0492381 Sleeve

Note. (press-in sleeve)

4 = 0492382 Shaped element

Note. For press-fitting

Scheme 360

Scheme 360: SI number

Note. For removing and installing the rubber mount in the wishbone

01 01 89 (989)

Consisting of

1 = 0492384 Sleeve

Note. (Support sleeve) For pressing out

2 = 0492385 Sleeve

Note. (Press-out sleeve)

Scheme 361

Scheme 361: SI number

3 = 0492386 Sleeve

Note. (Press-in sleeve)

4 = 0492387 Shaped element

Note. For pressing in

0Device MW

Note. For gripping output shafts when press-fitting constant-velocity joint

C23

01 06 94 (801)

Consisting of

Scheme 362

Scheme 362: SI number

1 = 0492166 Frame

2 = 0492167 Shell

Note. (shells) 2 pcs. Diameter 30 mm - model series: E38/model: 730i

3 = 0492168 Shell

Note. (shells) 2 pcs. Diameter 35 mm - model series: all, except E38

Note. For removing inner wheel bearing races on rear axle

01 05 99 (426)

Consisting of

1 = 0493816 Basic body

2 = 0493817 Spindle

Scheme 363

Scheme 363: SI number

3 = 0493818 Key

Note. (wrench)

4 = 0493819 Key

Note. (wrench)

5 = 0493820 Pliers

Note. (clamping ring (45...51 mm))

6 = 0493821 Pliers

Note. (clamping ring (50...55 mm))

7 = 0494617 Pliers

Note. (clamping ring (55...61 mm))

Model series: E67

8 = 0496538 Ring

Note. (clamping ring) Model series: F01, F02 See SI: 01 18 08 (482)

9 = 0496539 Synchronizing key

Note. Series: F01, F02 See SI: 01 18 08 (482)

Note. For installing front rubber mount on rear axle final drive

C47

01 08 03 (988)

Consisting of

Scheme 364

Scheme 364: SI number

1 = 0494722 Bush

Note. (Bush with taper)

2 = 0494723 Thrust piece

Note. For installing drive pinion in rear axle final drive housing

C22

Consisting of

1 = 0492111 Adapter

Note. (adapter)

2 = 0492112 Bush

Note. (spacer bush) For transmissions S5D 260Z, S5D 310Z and S5D 320Z

Scheme 365

Scheme 365: Storage Location

Note. For removing and installing rubber mount in rear axle final drive.

C18

01 02 08 (425)

Consisting of

Scheme 366

Scheme 366: SI number

1 = 0496391 Bush

Note. Removing rubber mount

2 = 0496392 Synchronizing key

Note. Removing rubber mount

3 = 0496393 Synchronizing key

Note. Installing rubber mount

4 = 0496394 Washer

Note. (Shaped washer) Installing rubber mount

5 = 0496395 Spindle

Note. (Spindle M14x1.5, length 190 mm)

6 = 0496396 Nut

Note. (Nut M14x1.5 with thrust bearing)

Note. For removing and installing rubber mount of rear final drive at rear in rear axle support.

01 15 05 (200)

Consisting of

1 = 0495340 Washer

Note. (Washer (pull out))

Scheme 367

Scheme 367: SI number

2 = 0495341 Washer

Note. (Washer (pull in))

3 = 0495342 Washer

Note. (Support washer (pull in))

4 = 0495343 Bearing shell

Note. (Bearing shells) 2 pieces

5 = 0495344 Bush

Note. (Bush)

6 = 0495440 Ring

Note. (Clamping ring)

7 = 0495441 Washer

Note. (Support washer (hydraulic rubber mount))

8 = 0495442 Washer

Note. (Form washer (hydraulic rubber mount))

Note. For removing and installing ball joint mount in wishbone.

01 01 89 (989)

Consisting of

1 = 0492389 Shaped element

Note. For hanging up when pressing out the ball joint

2 = 0492390 Bush

Note. (Pressure bushing) For pressing the ball joint out of the wishbone

Scheme 368

Scheme 368: SI number

3 = 0492391 Shaped element

Note. For hanging up the wishbone when pressing in the ball joint

4 = 0492392 Bush

Note. (Pressure bushing) For pressing the ball joint into the wishbone

Note. For removing rubber mount in rear axle support.

A8

B8

01 02 99 (417)

Scheme 369

Scheme 369: SI number

Consisting of

1 = 0492398 Tube

Note. (threaded pipe)

2 = 0492399 Shaped part

Note. (shaped part) 2 pieces Model series: E38, E39, E46

3 = 0492400 Shaped part

Note. (Shaped part) Replaced by 31 2 313 (0 495 802)

4 = 0492401 Rod

Note. (Guide rod)

5 = 0492402 Rod

Note. (guide rod) With thread dog point

6 = 0492403 Plate

Note. (locating plate) With screws

= 0492404

7 = 0492404 Synchronizing key

Note. (synchronizing key (2 pieces)) With screws - model series: E38, E39, E46

8 = 0492405 Shaped part

Note. (shaped part) 2 pieces Model series: E39/2, E65, E67, RR1

9 = 0492406 Synchronizing key

Note. (synchronizing key (2 pieces)) With countersunk screw - model series: E39/2, E65, E67, E87

01 22 06 (307)

Scheme 370

Scheme 370: SI number

01 22 06 (307)

01 22 06 (307)

01 22 06 (307)

0Extension Minimum set: Mechanical tools MW

Note. (2 pieces) Pullout extension for 33 5 040, 33 5 050, 33 5 060.

A18

B18

Scheme 371

Scheme 371: Storage Location

01 21 06 (300)

Consisting of

1 = 0495592 Extension

Note. (Extension (1 piece))

Extractor MW

Note. (Rillex extractor) For bevel pinion and differential case (rear diff)/for installation of camshaft sprocket on crankshaft (M70)/for removing bearing inner race from drive flange (E36, E46)

B6

C6

Scheme 372

Scheme 372: Storage Location

Consisting of

2 = 0492098 Washer

Note. (Disc) Replaced by 33 1 311.(0 492 107)

3 = 0492099 Washer

Note. (Disc) Replaced by 33 1 311.(0 492 107)

4 = 0492100 Washer

Note. (Disc) Replaced by 33 1 311.(0 492 107)

1 = 0492097 Connector

Note. (basic body) For transmission S5D 260Z, S5D 310Z and S5D 320Z

5 = 0492101 Synchronizing key

Note. (Synchronizing key (old))

6 = 0492102 Synchronizing key

= 0492103

7 = 0492103 Synchronizing key

8 = 0492104 Synchronizing key

9 = 0492105 Synchronizing key

Note. For rear axle final drive and for installation of the camshaft sprocket on the crankshaft (M70)

1 = 0492107 Washer

Note. (washer)

2 = 0492108 Synchronizing key

Note. For pulling the bearing inner race off the drive flange - Series: E36/5

Fixture MW

Note. For holding rear axle final drive during removal and installation.

01 01 07 (333)

Consisting of

1 = 0496019 Joint

2 = 0496020 Frame

Note. (Main frame)

Scheme 373

Scheme 373: SI number

3 = 0496077 Support

4 = 0496078 Fixture

Note. (Fixture for foam material insert)

5 = 0496079 Insert

Note. (insert) Foam material insert (1 set = 2 pieces)

5 = 0496080 Belt

Note. (Tensioning strap)

Replaced by: 0495567

Note. (Mounting set) For removing and installing the rear axle. Replaced by: 31 5 250.(0 495 567)

01 01 94 (766)

Consisting of

Scheme 374

Scheme 374: SI number

1 = 0492297 Fixture

Note. For cross member

2 = 0492298 Adapter

Note. (Adapter (2 pieces))

3 = 0492299 Plate

Note. (Floor plate) For hydraulic lifting equipment

4 = 0492300 Lifting gear

Note. (Hydraulic lifting equipment) Small hydraulic lifter, model series: E36/5, E60, E65, E66, E67

5 = 0492301 Synchronizing key

Note. (Synchronizing key (rubber part)) For hydraulic lifting equipment

Note. For mounting rear axle final drive during removal and installation.

Consisting of

2 = 0494831 Angle

Note. (Support angle) Replaced by 33 4 425. (0 495 317)

Scheme 375

Scheme 375: Fixture MW

4 = 0495575 Adapter

Note. (mounting adapter) mounting for E85 Z4 M. SI 01 10 06 (264)

1 = 0494829 Plate

Note. (Base plate)

2 = 0494830 Adapter

Note. (adapter kit)

4 = 0494832 Spindle

Note. (spindle with synchronizing key)

5 = 0495317 Angle

Note. (support angle)

Replaced by: 0495567

Note. (Holding set) For removing and installing the rear axle. Replaced by: 31 5 250 (0 495 567)

01 15 04 (117)

Consisting of

Scheme 376

Scheme 376: SI number

1 = 0494957 Fixture

Note. (Fixture 1 and 2)

2 = 0494958 Fixture

Note. (Fixture 3 and 4) Replaced by 31 5 250

01 22 06 (307)

01 22 06 (307)

Key MW

Note. (Key) To counter-hold the drive flange - Replaced by universal key

Mandrel Minimum set: Mechanical tools MW

Note. (Drift) For inserting radial shaft seal on output flange of rear axle final drive. Rear axle final drive: 168K/L

A16

Scheme 377

Scheme 377: Storage Location

Note. (Drift) For driving in radial shaft seal on output flange in rear axle final drive. Rear axle final drive: 188K/L

B16

Scheme 378

Scheme 378: Storage Location

Note. (drift) For installing radial seals on output flanges, flange diameter 44 mm

A16

01 01 94 (766)

Scheme 379

Scheme 379: SI number

Note. (drift) For fitting the radial sealing ring on the drive flange

A16

01 01 94 (766)

Scheme 380

Scheme 380: SI number

Replaced by: 0495314

Note. (drift) For driving in radial shaft seal on output flange in rear axle final drive. Replaced by 33 4 330.(0 495 314)

B16

01 10 95 (976)

Scheme 381

Scheme 381: SI number

Replaced by: 0496596

Note. (drift) For driving radial shaft seal onto drive flange. Replaced by 33 3 470/0 496 596

A16

01 05 94 (789)

Scheme 382

Scheme 382: SI number

Mandrel MW

Replaced by: 0495313

Note. (Drift) For driving in radial shaft seal on output flange of rear axle final drive. Replaced by 33 4 320 (0 495 313)

A37

01 02 98 (302)

Scheme 383

Scheme 383: SI number

Note. (drift) For driving radial shaft seal onto drive flange.

B26

01 09 09 (532)

Scheme 384

Scheme 384: SI number

Replaced by: 0491891

Note. (Drift) Replaced by 31 2 040.(0 491 891)

Replaced by: 0492338

Note. (Drift) For radial seal on output flange - Replaced by 33 3 420.(0 492 338)

Scheme 385

Scheme 385: Mandrel MW

Replaced by: 0495593

Note. (Drift) For fitting the radial seal (with the axial sealing lip) on the drive flange Replaced by 33 5 080 (0 495 593)

A31

01 05 94 (789)

Scheme 386

Scheme 386: SI number

Replaced by: 0495315

Note. (Drift) For driving in radial shaft seal into output flange. Replaced by 33 4 340.(0 495 315)

B16

01 02 96 (035)

Note. (drift) For fitting the retainer on the drive shaft when replacing the shaft sealing ring and drive flange

B16

01 05 94 (789)

Scheme 387

Scheme 387: SI number

Note. (Drift) For fitting the retainer on the drive shaft (final drive types K and M) and for fitting the circlip in the front axle differential drive flange (E34AWD, E46)

B16

01 01 94 (766)

Scheme 388

Scheme 388: SI number

Note. (Drift) For inserting radial shaft seal on drive flange of rear axle final drive

A16

01 02 98 (302)

Scheme 389

Scheme 389: SI number

Replaced by: 0492338

Note. (Drift) For fitting the radial sealing ring, right-hand output end/Replaced by 33 3 420.(0 492 338)

Scheme 390

Scheme 390: Mandrel MW

Note. For driving in shaft seal on drive shaft.

A16

01 21 06 (300)

Scheme 391

Scheme 391: SI number

Replaced by: 0492339

Note. (Drift) For driving the radial seal into the output flange with flange diameter 38 mm - Replaced by 33 3 430.(0 492 339)

Scheme 392

Scheme 392: Mandrel MW

Mounting adapter

Note. Locator for E85 Z4 M. SI 01 10 06 (264)

01 10 06 264

Open-end wrench Minimum set: Mechanical tools MW

Note. Open-end spanner SW50 with retaining clip For releasing and tightening down the insert nuts for the screw connection of the propeller shaft on the rear axle final drive.

A18

Scheme 393

Scheme 393: Storage Location

01 21 06 (300)

Consisting of

2 = 0495582 Retaining bracket

3 = 0495583 Pin

Note. (Pin with chain (2 x))

1 = 0495581 Basic body

Reversible ratchet MW

Note. (Reversible ratchet) Reversible ratchet with hexagon socket SW22 For size of spring tensioner 33 5 010.

01 15 04 (117)

Scheme 394

Scheme 394: SI number

Ring spanner Minimum set: Mechanical tools MW

Note. Multi-tooth ring spanner SW65 For releasing and tightening down flange nut on rear axle final drive.

A18

01 21 06 (300)

Scheme 395

Scheme 395: SI number

Socket nut Minimum set: Mechanical tools MW

Note. (Socket nut) z34 For counter-holding the gearbox input shaft when releasing and tightening down flange nut.

A18

01 21 06 (300)

Scheme 396

Scheme 396: SI number

Spindle Minimum set: Mechanical tools MW

Note. (spindle TR12 with nut) For installing and removing rubber mounts, see "In conjunction with".

01 16 08 (476)

Consisting of

3 = 0496555 Nut

Note. (nut M12x1.5 (high wall))

Scheme 397

Scheme 397: SI number

1 = 0496553 Spindle

Note. (spindle TR12)

2 = 0496554 Nut

Note. (nut TR12 with thrust bearing)

Note. (spindle TR20 with nut) For installing and removing rubber mounts, see "In conjunction with".

01 16 08 (476)

Consisting of

1 = 0496535 Spindle

Note. (spindle TR20 (length 300 mm))

3 = 0496551 Nut

Note. (nut TR20)

2 = 0496536 Nut

Note. (nut TR20 with thrust bearing)

Spring tensioner Minimum set: Mechanical tools MW

Note. For removing and installing spring on rear axle.

01 15 04 (117)

Consisting of

1 = 0494992 Spring cup

Note. (Spring cup, top)

Scheme 398

Scheme 398: SI number

2 = 0494993 Spring cup

Note. (Spring cup, bottom)

3 = 0494994 Spindle

3 = 0494995 Synchronizing key

Note. (Synchronizing key with fitting key)

4 = 0494996 Nut

5 = 0494997 Box wrench

Note. (Box wrench) SW24

6 = 0494998 Box wrench

Note. (Box wrench) SW10

Scheme 399

Scheme 399: Thrust piece with splined key

Tool Minimum set: Mechanical tools MW

Note. (Tool set) Removal and installation of the ball joint in the wheel carrier.

B49

01 15 04 (117)

Consisting of

Scheme 400

Scheme 400: SI number

1 = 0494988 Washer

Note. (draw-in disc)

2 = 0494989 Washer

Note. (Pull-out disc)

Note. (Tool set) For removing and installing trailing arm rubber mount on rear axle support.

B49

01 15 04 (117)

Scheme 401

Scheme 401: SI number

Consisting of

1 = 0494983 Washer

Note. (Draw-in disc)

2 = 0494984 Washer

Note. (Pullout disc)

3 = 0494985 Washer

Note. (Draw-in disc)

4 = 0494986 Sleeve

Note. (Support sleeve)

5 = 0494987 Holder

Note. (Counter support)

Note. (Tool set) For removing and installing rear wheel bearings Components 33 4 032, 33 4 038 and 33 4 039 are discontinued and are replaced in the order by 33 4 301, 33 4 302 and 33 4 303

C7

Consisting of

2 = 0492351 Spindle

Note. (Spindle) Series: E28 Replaced by 33 4 301 (0 496 535)

8 = 0492357 Nut

Note. (Nut with bearing) Series: E28 Replaced by 33 4 302 (0 496 536)

5 = 0492354 Washer

Note. (thrust washer) For installing wheel bearing, rear/Series: E28/model: 518, 520i

7 = 0492356 Washer

Note. (thrust washer) For installing wheel bearing, rear/Series: E28/model: 525i, 528i

9 = 0492358 Nut

Note. (nut)

1 = 0492350 Bell housing

Note. For counter support when removing the rear wheel bearing

= 0492352

Scheme 402

Scheme 402: Storage Location

Note. (Tool set) For removing and installing rear wheel bearings Components 33 4 032, 33 4 038 and 33 4 039 are discontinued and are replaced in the order by 33 4 301, 33 4 302 and 33 4 303

C7

Consisting of

2 = 0492351 Spindle

Note. (Spindle) Series: E28 Replaced by 33 4 301 (0 496 535)

8 = 0492357 Nut

Note. (Nut with bearing) Series: E28 Replaced by 33 4 302 (0 496 536)

5 = 0492354 Washer

Note. (thrust washer) For installing wheel bearing, rear/Series: E28/model: 518, 520i

7 = 0492356 Washer

Note. (thrust washer) For installing wheel bearing, rear/Series: E28/model: 525i, 528i

9 = 0492358 Nut

Note. (nut)

1 = 0492350 Bell housing

Note. For counter support when removing the rear wheel bearing

3 = 0492352 Washer

Note. (thrust washer) For removing wheel bearing, rear/Series: E28/model: 518, 528i

4 = 0492353 Sleeve

Note. (guide sleeve) For installing wheel bearing, rear/Series: E28/model: 518, 520i

6 = 0492355 Sleeve

Note. (guide sleeve) For installing wheel bearing, rear/Series: E28/model: 525i, 528i

Note. (tool set) For removing and fitting rear wheel bearings in wheel carrier and for fitting drive flange also for E46/16)

B7

B8

Scheme 403

Scheme 403: Storage Location

01 05 90 (207)

Consisting of

3 = 0492290 Sleeve

Note. (fitting bush) For extracting the wheel bearing from the wheel carrier - Series: E31, RR1

4 = 0492291 Sleeve

Note. (fitting bush) For fitting the wheel bearing into the wheel carrier - Series: E31, E34, E38, E46/16, E52, E53, E83, RR1

7 = 0492294 Washer

Note. (thrust washer) For fitting the drive flange - Series: E31, E34, E38, E46/16, E52, E53

2 = 0492289 Sleeve

Note. (spacer sleeve) For extracting the wheel bearing from wheel carrier and for fitting the drive flange - Series: E31, E34, E38, E46/16, E52, E53, E83

5 = 0492292 Washer

Note. (thrust washer) For fitting the wheel bearing into the wheel carrier - Series: E31

6 = 0492293 Sleeve

Note. (fitting bush) For fitting the drive flange and for extracting the wheel bearing - Series: E38, E52, E53, E60, E61, E83, RR1

8 = 0492295 Washer

Note. (support disc) for fitting the wheel bearing - Series: E38, E52, E53, E60, E61, E83, RR1

1 = 0492288 Spindle

Note. (Spindle with 2 nuts) Series: E31, E34, E38, E46/16, E52, E53, E60, E61, E83, RR1 Replaced by 33 4 300/0 496 534

Note. (tool set) Removal and installation of the front rubber mount on the rear axle support.

B49

C49

Scheme 404

Scheme 404: Storage Location

01 15 04 (117)

Consisting of

2 = 0494971 Holder

Note. (counter support)

3 = 0494972 Washer

Note. (draw-in disc)

4 = 0495033 Spindle

Note. (spindle 225 mm, M16)

5 = 0495034 Nut

Note. (thrust nut)

6 = 0495035 Spindle

Note. (spindle 320 mm, M18)

1 = 0494970 Washer

Note. (pull-out disc)

7 = 0495036 Nut

Note. (thrust nut)

Tool MW

Note. (Press-out/-in tool set) For pressing the rubber mount out of and into the control arm special tools 33 3 202 and 33 3 203 for E87 and E90

B32

01 05 90 (207)

Consisting of

1 = 0492261 Bush

Note. For accommodating control arm when pressing out rubber mount Series: E31

2 = 0492262 Thrust piece

Note. For pressing out rubber mount Series: E31, E46, E85, F01, F02

3 = 0492263 Sleeve

Note. (Spacer sleeve) For pressing rubber mount into control arm Series: E31, E46, E85, F01, F02

Scheme 405

Scheme 405: SI number

Note. (Tool set) For removing and installing wheel bearings, rear

C8

Consisting of

3 = 0492362 Nut

Note. Series: E30, E46 Replaced by 33 4 303 (0 496 551)

Scheme 406

Scheme 406: Storage Location

8 = 0492367 Bush

Note. (Draw-in bushing for rear axle shaft)

4 = 0492363 Bell housing

Note. For gripping when removing wheel bearing, rear/series: E30

6 = 0492365 Sleeve

Note. (Guide sleeve) For installing wheel bearing, rear/series: E30

5 = 0492364 Washer

Note. (Pullout disc)

7 = 0492366 Washer

Note. (Thrust washer) For installing wheel bearing, rear

9 = 0492368 Sleeve

Note. (Guide sleeve) For installing wheel bearings

1 = 0492360 Spindle

Note. (Spindle) Series: E30, E46 Replaced by 33 4 301/0 496 535

2 = 0492361 Nut

Note. (Nut with bearing) Series: E30, E46 Replaced by 33 4 302/0 496 536

Note. For removing and fitting camber arm rubber mount on rear axle support.

B49

C49

Scheme 407

Scheme 407: Storage Location

01 15 04 (117)

Consisting of

1 = 0494977 Washer

Note. (Draw-in disc)

2 = 0494978 Washer

Note. (Pullout disc)

3 = 0494979 Holder

Note. (Counter support)

4 = 0494980 Sleeve

Note. (Support sleeve)

5 = 0494981 Spindle

Note. (spindle 205 mm, M12)

6 = 0494982 Nut

Note. (Thrust nut)

Note. (Press-out/-in tool set) For removing and installing rubber mounts in rear axle final drive mounting, front and rear

A7

01 05 90 (207)

Consisting of

1 = 0492311 Sleeve

Note. (Locator sleeve) For removing and installing rubber mount/model series: E31, E36

2 = 0492312 Synchronizing key

Note. For removing rubber mount at rear axle final drive cover/model series: E31, E36, E38, E60, E61, E63, E64, E65, E66, E67, RR1

3 = 0492313 Synchronizing key

Note. For installing rubber mount at rear axle final drive cover - model series: E31, E36, E38 For removing rubber mount at rear axle final drive cover - model series: E46

6 = 0492316 Synchronizing key

Note. For installing rear rubber mount in rear axle support/model series: E31

4 = 0492314 Spindle

Note. For removing and installing rubber mount Model series: E31, E36, E38, E46, E60, E61, E63, E64, E65, E66, E67, E85, RR1 Replaced by 33 3 011/0 496 553

5 = 0492315 Nut

Scheme 408

Scheme 408: SI number

Note. (Nut with bearing) Series: E31, E36, E38, E46, E60, E61, E63, E64, E65, E66, E67, E85, RR1 Replaced by 33 3 012/0 496 554

Note. (Tool set) For removing and installing front wheel bearing in the wheel carrier

C41

Consisting of

1 = 0493824 Bush

Note. For removing wheel bearing from the wheel carrier

Scheme 409

Scheme 409: Storage Location

2 = 0493825 Washer

Note. For pulling wheel bearing into the wheel carrier

Note. For removing and installing rubber mount of rear axle final drive mounting at rear.

C45

01 14 01 (766)

Consisting of

Scheme 410

Scheme 410: SI number

6 = 0496310 Washer

Note. (disc (draw-in dimension 3.5 mm)) model series: E83, E85 see SI 01 18 07 (396)

1 = 0494049 Bush

2 = 0494050 Washer

4 = 0494052 Washer

5 = 0495623 Washer

Note. (disc (draw-in dimension 5.0 mm)) model series: E85, E86

3 = 0494051 Bush

Note. (slip bush)

Note. (Set of tools) For removing and installing rear rubber mounts on rear axle carrier.

A50

01 15 04 (117)

Consisting of

Scheme 411

Scheme 411: SI number

2 = 0494975 Holder

Note. (counter support)

3 = 0494976 Washer

Note. (draw-in disc)

4 = 0495037 Shaped part

Note. (shaped part)

1 = 0494974 Washer

Note. (pull-out disc)

Tool set Minimum set: Mechanical tools MW

Note. (Tool set) Discs/bushes for withdrawing and fitting the rubber mount on the front rear axle final drive (split rubber mount)

B33

01 06 94 (801)

Scheme 412

Scheme 412: SI number

Consisting of

2 = 0492417 Plate

Note. (support plate) For extracting

4 = 0492418 Thrust piece

Note. For installing

5 = 0492419 Tube

Note. (Guide tube) For installing

6 = 0492420 Plate

Note. (support plate) For installing

1 = 0492416 Tube

Note. (support tube) For removing

Washer Minimum set: Mechanical tools MW

Note. For removing and installing output shaft in drive flange, front and rear, as well as for removing front wheel bearing unit

C8

B8

01 17 03 (012)

Scheme 413

Scheme 413: SI number
