E46 CLIMATE CONTROL
Model: E46
Production Date: From 6/98
E46 IHKA Climate Control
The IHKA heater/air conditioner in the E46 is similar to the system previously installed in the E36. Design and component changes were made to improve the overall performance and operation of the system. This module will deal with the changes and highlights of the E46 IHKA system. Features of the IHKA system include
Scheme 133
- Control Panel/Module
- Single heater core for temperature regulation
- M-Bus Control of all stepper motors
- Fresh air micro filter
- Regulated A/C compressor
- Regulated auxiliary fan operation
- Heater Control Personalization
Control Panel
All heating and air conditioning functions are carried out at the control panel. The panel is constructed as follows
- The three manual air distribution buttons are located on the left side of the panel for upface vent and footwell distribution.
- The automatic air distribution button is located on the bottom of the panel along with the temperature control - blower speed control and recirculation control buttons.
- The defrost, air conditions request and rear window defogger buttons are located on the right side of the panel.
- The LCD matrix displays the requested temperature setting and blower speeds as on the previous system. There is now only one setting for temperature control.
- The interior temperature sensor and blower fan are located on the left side of the LCD matrix.
Fresh Air Micro Filter
The fresh air micro filter is installed in the fresh air inlet of the engine compartment. The filter can be serviced quickly by removing the plastic cover and removing the filter.
Scheme 134
Temperature Regulation-Heating
The E46 uses one water valve/heater core as part of interior temperature regulation. The water valve is pulsed to control the flow of coolant through the heater core as on other systems.
Temperature regulation is based on the inputs from
- Temperature control switch
- Interior temperature sensor
- Ambient temperature signal
- Heater core sensor
- Evaporator temperature signal
- "Y" factor
The rocker switch is used to select the desired cabin temperature which is displayed in the matrix of the control panel. The range for temperature display is from 60 to 90 °F.
Scheme 135
SERVICE STATION FEATURE - The "Service Station" feature introduced with the E38 IHKA is integrated into the E46 IHKA. This prevents the heater core from being flooded with hot coolant when refueling the vehicle.
Temperature Regulation - Cooling
Air conditioning control on the E46 is similar to the E39 IHKA system. The system uses the variable displacement compressor. The swash plate of the compressor is hinged so that is can vary the piston travel based on the output requirements of the system.
Scheme 136
Scheme 137
Compressor Control
Control of the A/C compressor is a function of the Engine Control Module as in the E36. However, the control has changed to include the regulated auxiliary fan operation.
Pressing the snowflake button is a request for A/C activation. As long as the evaporator temperature is Above 36°F, the IHKA will signal the DME control module to activate the compressor.
The IHKA control module sends the following signals to the DME over the K-Bus and CAN Bus via the instrument cluster
- Request for A/C activation (signal KO)
- Load torque for switching the compressor on
- Requested auxiliary fan speed
The IHKA determines the load torque for compressor activation and required auxiliary fan speed from the pressure sensor mounted on the receiver/dryer.
The pressure sensor provides a linear voltage input signal (0 - 5 volts) to the IHKA control module. The IHKA processes this signal and determines the load torque of the system (0 to 30 N.m with a variable displacement compressor). The higher the pressure in the system, the higher the voltage input signal to the IHKA.
The output signal to the DME will enable the engine control module to modify the idle speed, timing and fuel injection amount based on the load that will be imposed when the compressor is activated.
The auxiliary fan is now a variable speed fan (15 stages) based on the system load. The DME will activate the fan through a pulse modulated final stage control.
Stepper Motor M-Bus Control
The E46 uses the M-Bus for stepper motor control. All five stepper motors of the IHKA are bus controlled including
- Two fresh air/recirc-air flap motors
- Face vent flap motor
- Footwell flap motor
- Defrost flap motor
Due to the requirement for a fast acting motor for the fresh/recirc flaps, two different stepper motors (slow/fast) are used in the system.
Scheme 138
Purpose of the System
A two relay system was designed for the E46iC that supplies power to either rear window defogger grid. The two relay system will also communicates with the audio system amplifier to change the dynamics of the sound for either top up/hard top installed or top down driving
Components of the System
Two relays, located on the right side rear quarter panel behind the interior trim cover, are used for rear defroster operation.
Scheme 139
- Relay K-13 receives KL 30 and the activation signal from the IHKA control module. The output from the relay will switch the rear defroster ON if the hard top is installed.
- Relay K-99 receives KL 30 from relay K-13 and it supplies the rear defogger grid in the soft top glass window when the top is raised.
System Operation
The rear defroster operation is a function of the IHKA system, with the control module responsible for switching the system ON/OFF. Two rear defrosted grids are used, one installed in the soft top rear glass and the other in the optional hard top rear glass.
When the button is pressed on the IHKA control panel, Relay K-13 is energized. If the hard top is installed, power is supplied to the grid through the connector strip on the hard top lock.
Scheme 140
Relay K-13 also supplies KL 30 to relay K-99 when the button is pressed on the IHKA control panel. Relay K-99 is energized when KL R is switched ON and the soft top is closed and locked to the windshield frame. This allows the grid in the soft top window to be heated. When the soft top is lowered, KL R to relay K-99 is interrupted by the CVM to prevent the grid from heating when the top is lowered into the storage compartment.
IHKA Personalization
The features of Car/Key Memory allow various functions/features of the IHKA control to be tailored to the individual owner's/driver's wishes.
The functions of the IHKA that can be programmed to the owner's/driver's wishes include
- Automatic activation of recirc when the vehicle is started
- Adjustment (raising/lowering) of the blower speed
- Automatic opening of the ventilation flaps with warm coolant
- Automatic closing of the footwell flap with A/C activation
- Automatic closing of the defroster flaps with A/C activation
- Correction of the set temperature (raise/lower)
- Automatic activation of the compressor control when the ignition is switched on
- Auto program for the blower control when the ignition is switched on
These features are programmed using the coding/programming function of the DIS/MoDiC.
Scheme 141
The balance of the E46 IHKA system's features and operation carry over from the E36 including
- Maximum defrost operation
- Rear window defogger operation
- Final stage blower control
- Road speed dependent fresh air flap operation
- Air distribution control
- Stepper motor calibration run
- Cold start interlock
Diagnosis And Troubleshooting
The "self diagnostics" of the IHKA control module monitors the status of inputs and outputs of the system. If a fault is detected, it is initially entered in RAM and than in the EEPROM when the ignition is switched off. If available, a replacement value will be activated when various sensor faults are detected as with previous systems. A maximum of six faults can be stored in the EEPROM when the ignition is switched off.
The E46 IHKA is connected to the diagnostic link via the K - Bus/instrument cluster. The system uses the E46 "Fault Symptom Troubleshooting" procedures for troubleshooting problems and faults with the system.
When troubleshooting problems with the E46 IHKA, it is important to note that because the Car/Key Memory feature can change the functionality of the system, a review of the setting should be performed prior to condemning a component as faulty.
E46 IHKA I.P.O
As introduced.
Scheme 142
SOLAR SENSOR
Model: E38, E39, E46
Production Date: E38 3/99, E46 9/99, E39 9/00
The purpose of the solar sensor is to compensate the climate control system's output for the radiant heating effect of the sun. This will aid the IHKA in maintaining a constant comfort level, in the vehicles interior, during all driving conditions.
The function of heating and air conditioning systems in BMW vehicles is to provide the driver and passengers a comfortable atmosphere regardless of conditions outside of the vehicle. Based on the temperature signal inputs, blower setting, flaps portioning, program settings in the control module and influencing variables, the IHKA control module is able to process these inputs to achieve the desired comfort level.
The following input variables are processed by the IHKA module
Scheme 143
- Interior temperature
- Heat exchanger temperature
- Ventilation temperature (E38)
- Evaporator temperature
- Air volume setting
- Engine temperature and RPM
- Exterior temperature
The processed variable "Y-factor" is determined by using the above inputs. The Y-factor then represents how much adjustment is necessary by the IHKA module to achieve the set temperature.
Solar Radiation
Solar radiation, from the sun, passes through the earths atmosphere in the form of light (both visible and non-visible) and heat (sunshine). To date, the influence of solar radiation on the climate control system in the vehicle has only been compensated for by an average value stored in the control module and based on control settings and outside temperature values.
The solar sensor can detect the amount of solar radiation that is influencing the temperature and climate in the vehicles interior. The IHKA control module monitors the input from the solar sensor and adds the value to its processing factors. The settings of the climate control system are changed to compensate for this additional influence.
The settings of the following IHKA components are adjusted to compensate for changes in solar radiation
Scheme 144
- Blower - The blower curve is changed
- Stratification (mixing flaps) - The stratification outlet air temperature is changed (not E46)
- Ventilation - The opening angles of the ventilation flaps are changed.
Components
In the E38, The solar sensor is integrated in the housing of the anti-theft warning system LED. The warning indicator LED is installed on the outlet grille in the top center of the instrument panel where solar radiation can directly reach the solar sensor.
The DWA LED with solar sensor is an additional wiring harness with a 4-pin plug connector.
DWA LED with integrated solar sensor
Scheme 145
The solar sensor consists of two photoresistors, which are integrated on the left and right sides of the DWA housing next to the DWA LED. The photoresistors sense the different intensity levels of the solar radiation.
Scheme 146
DWA LED dismantled; housing and pc-board with LED and solar sensor housing
Scheme 147
- The photoresistor on the right is fitted under the plastic cover
- The photoresistor on the left is fitted under the plastic cover
- PC-board, DWA LED and solar sensor
- DWA LED housing
The E46 solar sensor is located in the right defroster outlet at the base of the windshield. The E46 sensor contains one photoresistor for sensing solar radiation.
The solar sensor receives power (5 volts) and ground from the IHKA control module. The module then reads the voltage drop across the photoresistor and determines the degree of solar heating based on the change in voltage. The voltage drop across the photoresistor increases as solar radiation increases. The IHKA control module monitoring voltage will decrease indicating an increase in solar heating. The module processes the input every 10 seconds and checks it for plausibility based on a limit value monitoring function.
Values outside the limit indicate a malfunction and the signal from the sensor is ignored by the module.
As solar radiation levels increase, the control curves, stored in the IHKA module, for the blower fan, mixing flaps and ventilation (face vent) flaps are shifted to compensate for the additional heat.
The solar sensor inputs to the IHKA control module can influence the settings on the relevant side (driver/front passenger) on the E38 and E39. No separate regulation is possible on the E46.
When driving at night, during cloudy periods or through tunnels, the control maps are shifted back to their base settings.
Blower Intervention
The graph below illustrates the solar influence on the blower fan with a constant Y factor and the solar influence changing from 0 to 100%.
Scheme 148
Blower Power Curves
The middle curve illustrates a blower curve without any solar influence. At a constant Y factor of 20%, the solar influence on the IHKA control module will cause the blower curve to shift as the radiation increases from 0 to 100%.
With a solar influence of 0%, curve "B" is used, providing 25% power to the blower.
As the solar influence increases, the curve shifts upward until the solar influence reaches 100%. At this point, curve "A" is used providing 36% power to the blower.
During heating, the blower power decreases as solar influence increases.
While cooling, the blower power will increase as solar influence increases.
Stratification (Temperature Intervention) E38 only
The mixing flaps will open less in the direction of heat for blending air as the solar influence increases. The graph below represents the influence of the solar sensor on the stratification flap settings
Scheme 149
To illustrate the influence of the solar sensor on the mixing flap position, the Y factor remains constant at 20%.
With a solar influence of 0% curve "A" is adopted for the various outside temperatures. As the outside temperature decreases, the mixing flap is moved toward the warmer setting blending more heat.
With a solar influence of 100% curve "B" is adopted for the various outside temperatures. As the outside temperature decreases, the mixing flap is still moved toward the warmer setting but it does not move as far. The solar influence is compensating to provide the same comfort level.
With the mixing flap thumbwheel at 100 or 0% (full hot or cold), the flaps are in the default position and there will be no solar influence.
The left and right mixing flaps are controlled independently based on the individual settings and left and right solar sensor inputs.
Ventilation Intervention (Center Vent Air Distribution)
The influence of the solar sensor on the ventilation flaps is shown in the graph below.
Scheme 150
The normal curve "B" applies when there is no solar sensor influence 0%, or if the sensor is defective.
The maximum curve "A" applies when the solar influence is 100%.
The ventilation flaps will close less as the solar influence increases. This allows more cool air from the center vents as the solar radiation increases.
This adjustment is also independently adjustable on the E38 based on the left/right solar sensor inputs.
Diagnosis
Troubleshooting of the solar sensor (left/right) is carried out through the IHKA diagnostic program using the DIS or MoDiC.
Status displays for the solar sensor input are available in percentages. The status displays can be checked while applying a light or heat source to the solar sensor to view the change in value.
Scheme 151
The E46 diagnostic program for the IHKA system contains a test module B6450- 00011 for testing the operation of the solar sensor.
The IHKA control module monitors the solar sensor and will set a fault code for
- Shorts to B+ or ground
- Open circuits
The IHKA control module will function as a system without solar influence correction if the sensor is defective.
Recognition of the solar sensor and its influencing capabilities is enabled via ZCS coding. Remember to adopt the code whenever possible to avoid loosing car/key memory function changes. Also the IHKA control module must be disconnected from B+ before coding can become permanent.
E38 vehicles
To remove the solar sensor from an E38, refer to Removal Of The Center Outlet Grille At The Top Of The Dash in REPAIR INSTRUCTIONS article. After removal of the grille, disconnect the plug connector of the DWA indicator and solar sensor and pull the sensor from the grille.
Scheme 152
E46 vehicles
Removal of the E46 solar sensor requires removal of the instrument panel. However, for testing purposes, the connector is located in-line, attached to the harness for connector X610.
Scheme 153
E46 IHKR
Model: E46 (325i/it/Ci/Cic, M3)
Production Date: From 9/00
Beginning M.Y. 2001, the 325i/it/Ci/Cic and M3 are fitted with IHKR as standard equipment. The IHKA system is available as an option on these models.
IHKR is a semi-automatically regulated heating and air-conditioning system, similar to the IHKR introduced for the 2001 E39 and E53.
The purpose of the system is to allow the vehicle occupants to select the desired temperature, air outlet distribution and volume manually.
The system then automatically regulates the temperature of the cabin based on the manual settings.
Scheme 154
The functions provided by the E46 IHKR are
- Control of the blower.
- Air distribution control.
- Stratification flap controlled by a Bowden cable
- Temperature Control
- Service Station feature
- Air conditioning request to DME
- Recirculation air
- Ram effect air compensation
- Rear window defroster
System Components
The E46 IHKR consists of the following components
- IHKR control unit with operating controls
- IHKR integrated heater and air conditioning case
- Heater core temperature sensor
- Evaporator temperature sensor
- Refrigerant circuit pressure sensor
- Double cage blower motor and final stage
- Water valve
- Air distribution micro-switch
- M-bus with 3 smart stepper motors: Air distribution Fresh air/re-circulation left (high speed motor) Fresh air/re-circulation right (high speed motor)
- Compressor relay (DME controlled)
- Auxiliary fan (DME controlled)
- Rear window defroster relay
- K-bus interface The following signals are transmitted and received over the K-bus: Vehicle speed Engine speed Coolant temperature Outside temperature Terminal 15, 61, 50,58G (panel lighting) Compressor load Diagnosis and coding Compressor request
- Fresh air Micro-filter
Scheme 155
IHKR control unit with operating controls
The IHKR control unit is incorporated into the control panel. The control panel consists of three buttons and three rotary dials. The control unit communicates over the K bus.
Scheme 156
IHKR Case
The E46 IHKR case is similar in design to the E46 IHKA heating and A/C case.
Scheme 157
Blower Adjustment
The blower rotary dial potentiometer has four settings. Each progressive step represents a 25% increase in blower volume. The control unit determines the desired blower setting by the signal from the potentiometer and then sends a voltage signal to the final stage unit. The voltage signal to the final stage unit ranges from 1.8V to a maximum of 7.1V (Normal blower power in Key Memory).
The final stage unit then regulates blower motor voltage to control the blower volume. There is no automatic influence on the blower setting.
The blower control potentiometer is the master on/off switch for the IHKR system. The water valve is closed (energized) in the blower zero (off) position. The LEDs for re-circulated air and air conditioning are switched off and the compressor is switched off. The rear defroster operation is not affected by the system being switched off.
Air Distribution
The selection of air distribution is carried out using the rotary dial potentiometer (42 steps). Each step of the potentiometer represents a percentage. The percentage indicates the desired air distribution setting.
Movement of the stratification flap for face ventilation is carried out by rotating a thumb wheel between the face vent discharge nozzles. The thumb wheel is connected to a Bowden cable that moves the flap.
Scheme 158
The air distribution for defrost, ventilation and footwell is performed by a single air distribution stepper motor that is connected to the M-bus and controlled by the IHKR control unit.
The stepper motor drives a cam/lever assembly (1) that articulates all three air distribution flaps. The position of the cam is confirmed by the air distribution micro-switch (2).
The air distribution micro-switch is provided 5V by the IHKR control unit. The micro switch is closed by the rotating cam lobe in two positions
Scheme 159
- Full defrost 97% to 0%
- Mixed face vent/footwell 37% (quick confirmation)
When the switch is closed the signal at the control unit goes low, informing the control unit that it has reached that particular position. The display in diagnosis recognizes this position as "off".
Located on the right side of the IHKR case
A reference run is initiated the first time KL30 is switched on to the IHKR control unit. The reference run is required to determine the position of the cam disc. The cam disc is rotated until the micro-switch sends a signal to the control unit. After the reference run is completed, the control unit recognizes what position the cam disc is in and thus the position of all three air distribution flaps.
If the air distribution micro-switch is not able to produce a signal at the correct position, the control unit will continue to operate the stepper motor at an estimated position. Eventually the air distribution setting will not match the actual output. The air distribution micro-switch circuit is fault monitored.
Temperature Control
The desired interior temperature is set with the rotary dial potentiometer (34 steps). The face of the dial itself has no marked temperatures, just a blue, white and red line that represents a comfort zone.
All of the air flowing into the IHKR housing must pass through the evaporator first before being re-heated by the heater core. This is the principle used by all IHKR and IHKA systems.
The IHKR maintains the temperature of the discharge air by cycling the water valve to regulate the temperature of the heater core. The duty cycle applied to the water valve is based on the "Y-factor" (correcting variable) and other variables.
The Y-factor of the E46 IHKR is determined by
- Setting of the temperature control dial
- Outside temperature (from Kombi via the K-bus)
- Heater core temperature
Automatic temperature control is switched off when the temperature control dial is turned all the way to the left (blue: water valve closed) or right (red: water valve full open) stop.
Each step of the potentiometer represents a temperature from max. cold (10°C) to max. warm (49.5°C). This temperature value is combined with the outside temperature to form a calculated set-point. The E46 IHKR does not use an interior temperature sensor.
The Y-factor is then determined by comparing the calculated set-point to the actual value of the heater core sensor which is in the stream of air to the outlet ducts.
In addition to the Y-factor, the control unit evaluates coolant temperature and engine RPM to determine water valve opening time. The valve opening times are
- 0 ms at max. COLD
- 3600 ms at max. WARM
Engine Map Cooling
Map cooling is used by the DME MS 43.0 for the M54 engines. This can create very high coolant temperatures which could be damaging to the climate control system. If the heater core temperature exceeds 80°C, the water valve is closed until the temperature drops below 80°C.
If the temperature at the heater core increases above 93°C (i.e. water valve faulty), the IHKR will signal the DME (via K-bus/Kombi/CAN) to energized the map cooling thermostat.
Service Station Feature
The service station feature prevents the vehicle occupants from getting a blast of hot air after the vehicle is restarted following a short stop. The water valve is powered closed by the IHKR control unit for three minutes after shut-off. This prevents the heater core from being flooded with hot coolant.
Air Conditioning Control
The air conditioning system is switched on by pressing the snow flake button and having the blower dial on position 1 or greater. The LED in the button signals that the A/C is in stand-by.
The IHKR control module sends the following signals to the DME over the K-bus-Kombi-CAN - bus connection
- IHKR on stand-by (signal AC)
- Request for A/C activation (signal KO)
- Calculated compressor load
- Request for auxiliary fan
The IHKR determines the load torque for compressor activation and required auxiliary fan speed from the pressure sensor mounted on the high side line next to the receiver dryer.
The refrigerant pressure sensor provides a voltage input signal (0-5 volts) to the IHKR. The voltage value increases as pressure in the high side refrigerant circuit increases. The IHKR processes this signal to determine the calculated load that will be placed on the engine when the compressor is switched on. Pressure values that are too high or too low will cause the compressor to be switched off.
Once all of the criteria for compressor operation have been met, the DME control module will activate the compressor relay to energize the compressor magnetic clutch.
Control of the evaporator temperature is carried out by the IHKR signalling the DME to shut off the compressor when the evaporator reaches the freezing point.
The IHKR cycles the compressor at 1°C if the outside temperature is above 68°F. The compressor is cycled at 3°C if the outside temperature is below 68°F.
Scheme 160
Air Intake
The fresh air/re-circulation flaps are controlled by a separate stepper motor for the left and right side.
Scheme 161
The stepper motors are controlled by the M-bus and are located on the left and right sides of the housing inside the passenger compartment.
The fresh air flaps are closed and the re-circ doors are opened when the re-circ. button is pressed with the system switched on.
When the key is turned off with re-circulation on, the fresh air flaps will open. Re-circulation memory in the IHKR control unit is 15 minutes. If the vehicle is started within 15 minutes the re-circulation setting will be restored.
If the system is shut off with the blower switch, the re-circulation function will have to be reenabled.
Ram Effect Air Compensation
Similar to IHKA, when the fresh air flaps are open their position is affected by vehicle road speed. This is to prevent an increase in air volume to the cabin with increasing vehicle speed.
The IHKR receives the vehicle speed input every 2 seconds over the K-bus from the Kombi. At a speed of 36mph the fresh air flaps will close progressively until the vehicle reaches 96mph, at which time the opening of the flaps will be 20%.
Scheme 162
Rear Window Defroster Operation (All Models)
The rear window defroster is controlled via a request from the button on the panel. After switching on for the first time, the rear window is heated for 17 minutes. Output voltage to the window is provided by the K13 rear defogger relay.
After automatic switch off, if the button is pressed once again the control unit will provide another 17 minutes of operation. If the vehicle voltage drops below 11.4V during this second heating operation the function is stopped, however the LED on the button will not be extinguished. If voltage increases past 12.2V for at least one second, operation will resume. The control circuit of the convertible varies slightly due to the folding top.
Scheme 163
When the button is pressed on the IHKR control panel, relay K13 is energized. K13 supplies KL 30 to defroster relay K99. Relay K99 is energized when the KLR is switched on and the soft top is closed and locked to the windshield frame. This completes the circuit and allows the rear window to be heated.
If the soft top is lowered during defroster operation, voltage to relay K99 is interrupted by the CVM to prevent the rear window grid from heating when the top is lowered into the storage compartment.
Diagnosis of the E46 IHKR system is carried out using the DISplus or MoDiC. The IHKR is connected to the diagnostic bus via the K-bus/Kombi connection. The system uses the E46 test module driven diagnostic concept for troubleshooting faults with the system.
Scheme 164
Coding
Coding must be performed if the IHKR control unit is replaced. ZCS coding is found in the Coding and Programming selection from the start screen or when pressing the Change button. Follow on-screen instructions to remove KL 30 power to the IHKR control unit. This step is necessary to complete the coding process.
Car and Key Memory
When troubleshooting complaints with the E46 IHKR it is important to note that because the Car/Key Memory feature can change the operation of the system, a review of the settings should be made prior to beginning troubleshooting.
Scheme 165
Only Key Memory selections are possible for the E46 IHKR. The selections are
- Set Blower Power (Raise, Normal, Lower)
- Correction Set Temperature (raise/lower)
- A/C on at key on (Automatic activation of the compressor control when the ignition is switched on.)
