64 1 010 Release and installation aid
Minimum set: Mechanical tools
| Note | For heater controls |
|---|---|
| Series | E46, E53 |
| Storage location | C35 |
| SI number | 1 02 98 (302) |
| Order number | 64 1 010 Release and installation aid |
AID SPECIFICATION
Scheme 1
64 1 020 Release hook
Minimum set: Mechanical tools
| Note | For releasing and removing fresh air grille. For removing various trims. |
|---|---|
| Series | E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, R50, R52, R53, RR1 |
| Storage location | C33 |
| SI number | 1 15 99(483) |
| Order number | 64 1 020 Release hook |
HOOK SPECIFICATION
Scheme 2
64 1 251 Spray lance, RHD vehicles
| In conjunction with | Guide 64 1 252 |
|---|---|
| Note | From spray apparatus set 64 1 250 (RHD vehicles) |
| SI number | 1 26 03 (044) |
| Order number | 64 1 251 Spray lance, RHD vehicles |
SPRAY LANCE, RHD VEHICLES SPECIFICATION
Scheme 3
64 1 252 Guide
| In conjunction with | Lance 64 1 251 |
|---|---|
| Note | Guide from spray apparatus set 64 1 250 |
| SI number | 1 26 03 (044) |
| Order number | 64 1 252 Guide |
GUIDE SPECIFICATION
Scheme 4
64 1 450 Spray unit
| In conjunction with | Pressure vessel spray gun, manufacturer: SATA (81 45 9 429 217) |
|---|---|
| Note | For cleaning and disinfecting evaporator in A/C system |
| Series | E39, E46, E53, E83 |
| SI number | 1 22 00(648) |
| Order number | 64 1 450 Spray unit |
| Consisting of: 1 = 64 1 451 | Spray lance |
| 2 = 64 1 452 | Drilling hole template |
| Note: Model series: E39, E53 IHKA | |
| 3 = 64 1 453 | Center bit |
| Note: Model series: E39, E53 IHKA | |
| 4 = 64 1 454 | Guide |
| Note: Model series: E39, E53 IHKA | |
| 5 = 64 1 455 | Positioner |
| Note: Model series: E39, E53 IHKA | |
| 6 = 64 1 456 | Retaining screw |
| Note: Model series: E39, E53 IHKA | |
| 7 = 64 1 457 | Adapter |
| Note: Model series: E46 IHKA / R Model series: E39, E53 IHKR | |
| 8 = 64 1 458 | Seal plug |
| Note: Model series: E46 IHKA / R Model series: E39, E53 IHKR |
SPRAY UNIT SPECIFICATION
Scheme 5
64 1 491 Spray lance (LHD vehicles)
| In conjunction with | Guide 64 1 492 |
|---|---|
| Order number | 64 1 491 Spray lance (LHD vehicles) |
SPRAY LANCE (LHD VEHICLES) SPECIFICATION
Scheme 6
64 1 492 Guide for spray lance (LHD vehicles)
| In conjunction with | Spray lance 64 1 491 for evaporator cleaning |
|---|---|
| Order number | 64 1 492 Guide for spray lance (LHD vehicles) |
GUIDE FOR SPRAY LANCE (LHD VEHICLES) SPECIFICATION
Scheme 7
64 5 100 Set of sealing adapters
| Note | For closing off line flanges of A/C components (evaporator, condenser, compressor) for leak testing. Set consists of 1 = 64 5 102 "2 = 64 5 103" 3 = 64 5 105 (replaces 64 5 10) "4 = 64 5 106 (from 01/2005)" 5 = 64 5 104 |
|---|---|
| Series | E32, E34, E36, E38, E39, E46, E53, E64, E83 |
| SI number | 1 17 98(359) |
| Order number | 64 5 100 Set of sealing adapters |
| Consisting of: 1 = 64 5 101 | Filler adapter |
| Note: Replaced by 64 5 105 (from 01/2005) | |
| 2 = 64 5 102 | Sealing adapter |
| Note: For sealing off suction line | |
| 3 = 64 5 103 | Sealing adapter |
| Note: For sealing off suction connection on compressor | |
| 4 = 64 5 104 | Connecting hose |
| Note: For connecting pressure bottle to filler adapter | |
| 5 = 64 5 105 | Filler adapter |
| Note: For sealing off pressure line and connection on connecting hose (has replaced special tool SWZ 64 5 101 since 01/2005) | |
| 6 = 64 5 106 | Sealing adapter |
| Note: Sealing adapter for sealing off leak-testing line (from 01/2005 in scope of delivery) |
SET OF SEALING ADAPTERS SPECIFICATION
