Minimum Set: Mechanical Tools
Engine: M10, M47T2, M47TU, M52, M52TU, M54, M56, M60, M62, M67, M70, M73, N52, N62, N73, S14, S54, S62, W10, W11
SI number: 1 13 94 (888)
Order number: 11 0 000
Engine lifter for removing and installing engines
Consisting of
1 = 11 0 001 Lifting beam
2 = 11 0 002 Chain, long
3 = 11 0 003 Chain, short
4 = 11 0 009 Shackle (2 x)
Scheme 394
Engine: M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M47TU, M50, M51, M52, M54, M57, M57D25, M57D30, M57TU, N52, N62, N73, S38, S50B30, S50B32, S50US, S85
SI number: 1 13 94 (888)
Order number: 11 0 020
Engine hoist for removing and installing engines
Consisting of
1 = 11 0 021 Lifting beam
2 = 11 0 022 Chain, medium
3 = 11 0 023 Chain, long
4 = 11 0 024 Chain, short
5 = 11 0 029 Shackle (2 x)
Scheme 395
11 0 070 Engine hoist
Note: For removing and installing engines
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47T2, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M67TU, M70, M73, M88, N40, N42, N45, N46, N52, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
Scheme 396
SI number: 1 16 96 (107)
Order number: 11 0 070
Engine hoist
Consisting of
1 = 11 0 071 Lifting beam
2 = 11 0 072 Carrying chain, long
3 = 11 0 073 Carrying chain, short
4 = 11 0 079 Shackle (2 x)
Note: For all petrol/gasoline and diesel engines.
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57TU, M60, M62, M62VAN, M67, M67TU, M70, M73, M88, N40, N42, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11, W17
Scheme 397
SI number: 1 09 92 (558)
Order number: 11 0 220
Compression test kit
Consisting of
16 = 11 0 239 Adapter
Note: Engine M67, M67TU
11 0 221 Compression recorder for diesel engines
11 0 222 Test probe
Note: For compression recorder 11 0 221 and 11 0 160/Engine: M21,M41, M47, M51, M57
In conjunction with: 11 0 240
11 0 223 Test sheets (100 x)
Note: For compression recorder for 11 0 221
11 0 224 Compression recorder for petrol/gasoline engines
11 0 226 Test probe
Note: For compression recorder 11 0 224 and 11 0 160/engine: M10, M20, M30, M40, M42, M43, M44, M50, M52, M60, M62, M70, M73, S50US, S52US, S62
In conjunction with: 11 0 240
11 0 228 Rubber taper with fitting
Note: For compression recorder 11 0 224 and 11 0 160/engine: M10, M20, M30
In conjunction with: 11 0 240
11 0 229 Test charts (100 x)
Note: For compression recorder 11 0 224
11 0 231 Case
Note: With foam inlay for compression recorder
11 0 233 Non-return valve
11 0 234 Filter 3 x 3 mm
11 0 235 Test probe, screw-in
Note: For measuring "absolute compression"at all cylinders, engine
S14, S38, S50B30, S50B32, S50US, S52US, S54
In conjunction with: DIS and DIS pressure sensor
11 0 236 Test probe
Note: For compression recorder 11 0 221 or DIS pressure sensor/engine: M47, M57, M57TU
11 0 237 Adapter
Note: For measuring "absolute compression"at all cylinders. Engine: W17
In conjunction with: 11 0 221, 11 0 235 or DIS pressure sensor, 11 0 235
11 0 240 Coupling
In conjunction with: 11 0 222, 11 0 226, 11 0 227, 11 0 225
Note: For adapting test probes to pressure gauge 11 0 162
Engine: All models
Order number: 11 0 240
Coupling
Scheme 398
Note: For fitting valve stem seals
Engine: M20, M21, M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, S14, S38, S50B30, S50B32, S54, S62
Storage location: B14, C14
Order number: 11 1 200
Drift
Scheme 399
Note: For removing valve stem seal
Engine: M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, N52, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11
Storage location: A10, B10
SI number: 1 01 93(621)
Order number: 11 1 480
Pliers
Scheme 400
Note: For fitting valve stem seals, 6 mm diameter
Engine: M41, M42, M44, M47, M50, M51, M52, M52TU, M54, M56, M57, M57TU, M60, M62, S54, S62
Order number: 11 1 960
Assembly sleeves
Scheme 401
Note: For locking flywheel in position
Engine: M20, M21, M40, M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, S50B30, S50B32, S54
Storage location: C4
Order number: 11 2 170
Holder
Scheme 402
Note: For compressing piston rings while installing pistons
Engine: M47T2, M47TU, M52, M52TU, M54, M56, M57, M57TU, M60, M62, S14, S38
Storage location: C1
Order number: 11 2 260
Piston ring compressor
Scheme 403
Note: For locking crankshaft in ignition TDC position when adjusting timing
Engine: M21, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57TU, M60, M62, M70, M73, S50B30, S50B32, S54, S62
Storage location: C32
Order number: 11 2 300
Plug mandrel
Scheme 404
In conjunction with: 11 2 016 (M60, M62)
Note: For guide bearing in crankshaft, stem diameter 15 mm
Engine: M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57TU, M60, M62, M70, M73, N40, N42, N45, N46, S50B30, S50B32, S54, S62, S85
Storage location: C26
Scheme 405
SI number: 1 05 90(207)
Order number: 11 2 340
Extractor
Consisting of
1 = 11 2 341 Extractor claw with threaded bush
2 = 11 2 342 Extractor claw
3 = 11 2 343 Pressure spindle
4 = 11 2 344 Sleeve
Note: For fitting guide bearing of crankshaft
Engine: M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M57, M57TU, M60, M62, M70, M73, N40, N42, N45, N46, S50B30, S50B32, S52US, S54, S62, S85
Storage location: A28
SI number: 1 05 90(207)
Order number: 11 2 350
Drift
Scheme 406
Note: For removing rotary shaft seal from timing case cover
Engine: M41, M47, M50, M51, M52, M52TU, M54, M56, M60, M62, S50B30, S50B32, S54, S62, W10, W11
Storage location: A38, C25
SI number: 1 05 92(507)
Order number: 11 2 380
Scheme 407
Puller
Consisting of
1 = 11 2 381 Threaded bell housing
2 = 11 2 382 Spindle
3 = 11 2 383 Thrust piece
Note: Engine: M41, M47, M50, M51, M52, M60, M62, PENT
11 2 384 Thrust piece
Note: Engine: S50, S54
11 2 385 Spacer bushing
Note: Engine: M41, M50, M51, M52
11 2 386 Thrust piece
Note: Engine: S62
Note: For installing connecting rods with piston
Engine: M40, M41, M50, M52, M52TU, M54, M56, M60, M62
Storage location: B2, C2
SI number: 1 05 92(507)
Order number: 11 2 470
Guide mandrel (2)
Scheme 408
11 3 030 Placement board for tappet
Engine: M10, M20, M21, M30, M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, M88, S14, S38, S50B30, S50B32, S62
Order number: 11 3 030
Placement board for tappet
Scheme 409
Note: For locking camshaft in position when adjusting timing
Engine: M42, M44, M50, M52, M52TU, M54, M56, S50US, S52US
Storage location: A11
SI number: 1 05 89(099)
Order number: 11 3 240
Locking fixture
Scheme 410
Consisting of
1 = 11 3 241 Gauge for inlet side
2 = 11 3 242 Gauge for exhaust side
4 = 11 3 244 Support bracket
Note: For securing camshaft marking fixture on cylinder head
Note: For lifting out tappets in cylinder head
Engine: M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, S62
Storage location: A 104
SI number: 1 05 89(099)
Order number: 11 3 250
Suction cup
Scheme 411
Consisting of
1 = 11 3 251 Sucker (8 x)
Note: For evenly pressing down camshaft (with bearing cap) while releasing and tightening camshaft bearing caps
Engine: M42, M50, M52, M52TU, M54, M56, S50US, S52US
SI number: 1 05 89(099)
Order number: 11 3 260
Scheme 412
Fixture
Consisting of
1 = 11 3 261 Assembly fixture
2 = 11 3 262 Fastener bolt (2)
Note: For fitting rotary shaft seal in bottom of timing case
Engine: M50, M51, M52, M52TU, M54, M56, S50B30, S50B32
Storage location: C28
SI number: 1 01 90(165)
Order number: 11 3 280
Installer bush
Scheme 413
In conjunction with:12 6 410
Note: For checking function of VANOS adjustment unit
Engine: M50, M52, M52TU, M54, M56, N73
Storage location: B10
SI number: 1 08 92 (555)
Order number: 11 3 450
Compressed air connection
Scheme 414
Note: For installing connecting rods with pistons. Note: With the phase-in of engine S50B32 the guide mandrels have been revised and adapted to the new connecting rods.
Engine: M44, M52, M52TU, M54, M56, S50B30, S50B32, S62
Storage location: B2, C2
SI number: 1 12 92(606)
Scheme 415
Order number: 11 3 480
Guide mandrel (2)
In conjunction with: 13 3 063 or 13 6 051
Note: For connection of pipe bend 13 6 054 to pressure gauge 13 3 061 or BMW DIS for checking oil pressure
Engine: M10, M20, M21, M30, M47, M47T2, M47TU, M50, M51, M52, M54, M56, M57, M57TU, M60, M62, M70, M73, N62, N73, S14, S38, S50B30, S50B32, S62
Storage location: B9
Order number: 11 4 050
Reducer
Scheme 416
In conjunction with: 11 3 390, 00 2 050
Note: M73 For removing and installing pedal travel sensor M60 Pretensioning timing chain E53 Mounting airbag control unit
Series: All models
Storage location: B6
SI number: 1 06 94(801)
Order number: 11 4 190
1/4" extension piece
Scheme 417
In conjunction with: 00 9 250, 00 2 050
Note: For tensioning primary chain when adjusting valve timing
Engine: M52, M52TU, M54, M56
Storage location: C27
SI number: 1 10 94(840)
Order number: 11 4 220
Chain tensioner
Scheme 418
Consisting of
1 = 11 4 221 Holding sleeve
3 = 11 4 223 Spindle
Note: For tensioning primary chain when adjusting valve timing
Engine: M52TU, M54, M56, M62, M62VAN, N40, N42
Storage location: A40
SI number: 1 15 99(483)
Order number: 11 4 230
Chain tensioner
Scheme 419
Consisting of
1 = 11 4 231 Nut
Note: With external thread
2 = 11 4 232 Spindle
Note: For pulley on water pump when releasing and tightening fan/Model year: From 80
Engine: M10, M20, M21, M30, M50, M51, M52, M52TU, M54, M56, M70, M73, S14, S38, S50B30, S50B32, S54
Storage location: B3, C3
Order number: 11 5 030
Holder
Scheme 420
In conjunction with: Torque wrench 3/8" connection
Note: For loosening and tightening fan wheel
Engine: M10, M20, M21, M30, M40, M41, M42, M43, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M60, M62, M70, M73, M88, N42, N62, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62
Storage location: A11, B11
Scheme 421
SI number: 1 01 87(670)
Order number: 11 5 040
Open-ended spanner WAF 32
Note: For locking flywheel in TDC position
Engine: M47T2, M54, M57TU, M62, M62VAN, M67
Storage location: C39
SI number: 1 15 99 (483)
Order number: 11 5 180
Plug mandrel, angled
Scheme 422
Note: For adjusting valve timing on engines with twin VANOS
Engine: M52TU, M54, M56
Storage location: B36, B37
SI number: 1 05 98(305)
Order number: 11 6 150
Adjusting plate
Scheme 423
Note: For removing and installing plastic sealing caps on twin VANOS.
Engine: M52TU, M54, M56
Storage location: A36
SI number: 1 05 98(305)
Order number: 11 6 170
Pliers for twin VANOS
Scheme 424
Note: For preassembling secondary chain wheels with chain on camshafts
Engine: M52TU, M54, M56
Storage location: B37
SI number: 1 05 98(305)
Order number: 11 6 180
Fixture
Scheme 425
Note: For removing and installing solenoid valves
Engine: M54, M62VAN
Storage location: A38
SI number: 1 12 98(339)
Order number: 11 6 420
Socket wrench WAF32
Scheme 426
Note: For loosening and tightening oxygen sensor
Engine: M10, M20, M30, M40, M42, M50, M52TU, M54, M56, M57, M60, M70, M73, N42, N45, N46, S14, S38, S50B30, S50B32, S50US, S52US, S54
Storage location: C13
Order number: 11 7 020
Socket wrench socket WAF 22
Scheme 427
Note: For loosening and tightening oxygen sensor
Engine: M40, M43, M43TU, M44, M52, M52TU, M54, M56, M62, N40, N42, N45, N46, N62, N62TU, N73, S54, S62
Storage location: B15
SI number: 1 06 95(963)
Order number: 11 7 030
Socket wrench socket WAF 22
Scheme 428
11 8 040 Engine support plate
In conjunction with: 00 1 450
Note: For securing engine on assembly stand
Engine: M41, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57TU, S50B30, S50B32, S54
SI number: 1 09 94(839)
Order number: 11 8 040
Engine support plate
Scheme 429
Note: For installing pistons
Engine: M52, M52TU, M54, M56, M67, N40, N42, N45, N46, N62, S52US
SI number: 1 12 99(452)
Order number: 11 8 140
Assembly sleeves
Scheme 430
Consisting of
1 = 11 8 141 Bushing
Note: Bushing for piston mounting 84.00mm
2 = 11 8 142 Bushing
Note: Bushing for piston mounting 84.08 mm
3 = 11 8 143 Bushing
Note: Bushing for piston mounting 84.25 mm
In conjunction with: 11 8 200
Note: For gripping vibration damper
Engine: M52TU, M54, M56
SI number: 1 08 00(579)
Order number: 11 8 190
Brace (part 1)
Scheme 431
In conjunction with: 11 8 190 and 11 8 210
Note: For gripping and pulling on vibration damper
Engine: M52TU, M54, M56, W10, W11
Storage location: C41
SI number: 1 08 00(579)
Order number: 11 8 200
Brace (part 2)
Scheme 432
In conjunction with: 11 8 200
Note: For detaching vibration damper
Engine: M52TU, M54, M56
SI number: 1 08 00(579)
Order number: 11 8 210
Puller
Scheme 433
In conjunction with: Assembly stand 00 1 450
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N40, N42, N45, N46, N52, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
Scheme 434
Storage location: Single
SI number: 1 03 02 (833)
Order number: 11 9 000
Cylinder head expander tool
Consisting of
1 = 11 9 001 Fixture
2 = 11 9 002 Rod
3 = 11 9 003 Sliding block with M10 thread
4 = 11 9 004 Tab
5 = 11 9 005 Quick tensioner
6 = 11 9 006 Aluminum profile insert
7 = 11 9 007 Slide
8 = 11 9 008 Profile plastic part
9 = 11 9 009 Lever
10 = 11 9 011 Hook
11 = 11 9 012 Valve spring cage
Note: Engine M41, M51, S50
12 = 11 9 013 Valve spring cage
Note: Engine M43, M73
13 = 11 9 014 Valve spring cage
Note: Engine M44, M52, M54, M56, M62, S52, S54, S62
14 = 11 9 015 Valve spring cage
Note: Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73
15 = 11 9 016 Valve spring cage
Note: Engine M21, M40
16 = 11 8 421 Valve spring cage
Note: Engine: W10, W11, W17
18 = 11 9 017 Valve spring cage
Note: Engine N52
In conjunction with: 11 7 030
Note: For releasing and tightening down oxygen sensors
Engine: M54, M56, N42, N45, N46, N62, N62TU, N73, S54
Storage location: A42
SI number: 01 15 00 (609)
Order number: 11 9 150
Special wrench
Scheme 435
Note: For locking flywheel with transmission removed
Engine: M47TU, M54, M57T2, M57TU, N40, N42, N45, N46, N52, N62, N73, S85, W17
Storage location: A45, B43, C44
SI number: 1 01 01 (662)
Order number: 11 9 260
Scheme 436
Counter support with screw connection
Consisting of
1 = 11 9 261 Counterholder, individual
2 = 11 9 262 Bolt (M10 thread) with washer
Note: For bolting down counterholder
3 = 11 9 263 Sleeve for counterholder
Note: For counterholder for locking flywheel with transmission removed engine: N62, N73
4 = 11 9 264 Bolt (M12 thread)
Note: For counterholder for locking flywheel with transmission removed
5 = 11 9 265 Sleeve
6 = 11 9 266 Sleeve
Note: For counterholder for locking flywheel with transmission removed Engine: M57TU2
