BRAKE BAND ADJUSTMENT
- Drain fluid. Remove bolts, main case oil pan and gasket. see scheme 5 Remove bolts, servo cover and gasket. Loosen lock nut on servo adjusting screw.
- Using an INCH-lb. torque wrench, tighten servo adjusting screw to 40 INCH lbs. (4.5 N.m). Back off servo adjusting screw 5 revolutions. Hold sleeve on servo piston. Tighten lock nut to 14 ft. lbs. (19 N.m). Ensure servo adjusting screw does not rotate while tightening lock nut.
- Using a NEW gasket, install servo cover. Install and tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-57009-S00687949562001011700000). Using a NEW gasket, install main case oil pan. Install and tighten bolts to specification. Fill transmission with Dexron-III ATF.
SHIFT LOCK CABLE ADJUSTMENT
Key lock system prevents ignition switch from being placed in LOCK position unless gearshift lever is in "P" position. Shift lock cable is connected between gearshift lever and ignition switch. When gearshift lever is placed in "P" position, check that ignition switch may be placed in LOCK position. If ignition switch cannot be placed in LOCK position, perform the following shift lock cable adjustment.
1) Place ignition switch in LOCK position. Ensure gearshift lever is in "P" position. Remove console components for access to shift lock cable at gearshift lever.
2) Adjust cable screw cap on gearshift lever side of shift lock cable to provide slack in shift lock cable so a gap of.059-.098" (1.50-2.5 mm) exists between rod on steering lock side and the stopper. (Scheme 14)
3) Tighten lock nut "A" against bracket while pulling cable screw cap toward instrument panel side (front) of center console. (Scheme 14) This prevents slack in the inner cable.
4) Loosen lock nut "A" 2 turn to provide slack in the inner cable. Hold lock nut "A" and tighten lock nut "B" to 35 INCH lbs. (4 N.m). To recheck system operation, ensure gearshift lever cannot be moved from "P" position with ignition switch in LOCK position.
5) Ensure ignition switch can be turned to LOCK position only when gearshift lever is in "P" position. If operation is not as specified, readjust shift lock cable.
