11 0 240 Coupling
In conjunction with: 11 0 222, 11 0 226, 11 0 227, 11 0 225
Note. For adapting test probes to pressure gauge 11 0 162
Engine: All models
Order number: 11 0 240 Coupling
Scheme 596
11 0 290 Holder
Minimum set: Mechanical tools
Note. For removing and installing triangular drive (vacuum pump) on crankcase.
Engine: N51, N52, N52K, N53, N54
Storage location: A52
SI number: 1 17 04 (130)
Order number: 11 0 290 Holder
Scheme 597
11 0 300 Plug Mandrel
Minimum set: Mechanical tools
Note. For locking flywheel in TDC position
Engine: N43, N51, N52, N52K, N53, N54
Storage location: A52
SI number: 1 17 04 (130)
Order number: 11 0 300 Plug mandrel
Scheme 598
11 0 370 Extractor
Minimum set: Mechanical tools
Note. For removing front radial shaft seal.
Engine: N43, N45T, N46T, N51, N52, N52K, N53
SI number: 01 15 07 (390)
Order number: 11 0 370 Extractor
Consisting of
1 = 11 0 371 Bushing with external thread
2 = 11 0 372 Spindle
Scheme 599
11 4 050 Reducer
Minimum set: Mechanical tools
In conjunction with: 13 3 063 or 13 6 051
Note. For connection of pipe bend 13 6 054 to pressure gauge 13 3 061 or BMW DIS for checking oil pressure
Engine: M10, M20, M21, M30, M47, M47T2, M47TU, M50, M51, M52, M54, M56, M57, M57T2, M57TU, M60, M62, M70, M73, N43, N51, N52, N52K, N53, N54, N62, N63, N73, S14, S38, S50B30, S50B32, S62
Scheme 600
Storage location: A4
Order number: 11 4 050 Reducer
11 4 120 Locking Pin
Minimum set: Mechanical tools
Note. For chain tensioner to lock chain tensioner piston in position (e.g. when removing and installing cylinder head)
Engine: M43, N47, N47S, N51, N52, N52K, N53, N54
Storage location: B5, C5
SI number: 1 12 93 (701)
Order number: 11 4 120 Locking pin
Scheme 601
11 4 190 1/4" Extension Piece
Minimum set: Mechanical tools
In conjunction with: 11 3 390, 00 2 050
Note. M73 For removing and installing pedal travel sensor M60 Pretensioning timing chain E53 Mounting airbag control unit
Series: All models
Storage location: B6
Scheme 602
SI number: 1 06 94(801)
Order number: 11 4 190 1/4" extension piece
11 4 250 Gauge With Adapter Plate
Minimum set: Mechanical tools
Note. For securing oil spray nozzles.
Engine: N43, N51, N52, N52K, N53
SI number: 1 17 04 (130)
Order number: 11 4 250 Gauge with adapter plate
Consisting of
1 = 11 4 251 Gauge
2 = 11 4 252 Adapter plate
Scheme 603
11 4 280 Gauge
Minimum set: Mechanical tools
Note. For locating camshaft in TDC position.
Engine: N43, N51, N52, N52K, N53, N54
Storage location: B52
SI number: 1 17 04 (130)
Order number: 11 4 280 Gauge
Scheme 604
Consisting of
1 = 11 4 281 Gauge
2 = 11 4 282 Adapter
3 = 11 4 283 Bracket
4 = 11 4 284 Set of M6 screws
Note. Engine: N54
11 4 290 Gauge
Minimum set: Mechanical tools
Note. For disconnecting camshaft sensor gears.
Engine: N51, N52, N52K, N53
Storage location: A51, A52
SI number: 1 17 04 (130)
Order number: 11 4 290 Gauge
Scheme 605
11 4 370 Pressing Fixture
Note. For pressing out sealing compound for bedplate.
Engine: N43, N45T, N51, N52, N52K, N53, N54, S85
Storage location: A52
SI number: 1 17 04 (130)
Order number: 11 4 370 Pressing fixture
Scheme 606
11 4 420 Torx Socket T50
Minimum set: Mechanical tools
Note. For removing and installing cylinder head.
Engine: N51, N52, N52K, N53, N54
Storage location: A51
SI number: 1 17 04 (130)
Order number: 11 4 420 Torx socket T50
Scheme 607
11 4 430 Seal Plugs (2 X)
Minimum set: Mechanical tools
Note. For sealing off oil holes in oil pump.
Engine: N51, N52, N52K, N53, N54
Storage location: A52
SI number: 1 17 04 (130)
Order number: 11 4 430 Seal plugs (2 x)
Scheme 608
11 4 450 Locating Fixture
Minimum set: Mechanical tools
Note. For locating guide blocks during installation.
Engine: N51, N52, N52K, N53
Storage location: A52
SI number: 1 17 04 (130)
Order number: 11 4 450 Locating fixture
Scheme 609
11 4 460 Locating Fixture
Minimum set: Mechanical tools
Note. For locating upper and lower bearing strip when installing exhaust camshaft.
Engine: N51, N52, N52K, N53
SI number: 1 17 04 (130)
Order number: 11 4 460 Locating fixture
Consisting of
Scheme 610
1 = 11 4 461 Press-down tool, 2nd cylinder
2 = 11 4 462 M7 screws (2 x)
3 = 11 4 463 Thrust pieces (6 x)
11 4 470 Cleaning Kit
Minimum set: Mechanical tools
Note. For cleaning sealing surfaces on magnesium crankcase/cylinder head.
Engine: N43, N45T, N46T, N47, N51, N52, N52K, N53, N54, N63
SI number: 1 17 04 (130)
Order number: 11 4 470 Cleaning kit
Consisting of
Scheme 611
1 = 11 4 471 Scraper
2 = 11 4 472 Grindstone
11 4 480 Placement Boards (2 X)
Minimum set: Mechanical tools
Note. For storing individual components of cylinder head.
Engine: N12, N14, N43, N45T, N47, N47S, N51, N52, N52K, N53, N54, N63
SI number: 1 17 04 (130)
Order number: 11 4 480 Placement boards (2 x)
Consisting of
Scheme 612
1 = 11 4 481 Placement board, inlet side
2 = 11 4 482 Placement board, exhaust side
11 5 190 Torx Socket T60
Minimum set: Mechanical tools
Note. For removing and installing cylinder head.
Engine: N51, N52, N52K, N53, N54
Storage location: A51
SI number: 01 17 04 (130)
Order number: 11 5 190 Torx socket T60
Scheme 613
11 5 200 Spacer Ring
Minimum set: Mechanical tools
In conjunction with: 11 9 280 Counterholder
Note. For releasing and tightening down central bolt.
Engine: N43, N51, N52, N52K, N53, N54
Storage location: B51
SI number: 1 17 04 (130)
Order number: 11 5 200 Spacer ring
Scheme 614
Consisting of
1 = 11 5 201 Shim
2 = 11 5 202 M8x40 mm screws (3 x)
11 6 260 Mounting Sleeves With Case
Minimum set: Mechanical tools
Note. For installing pistons of 85 mm diameter (urgently required for pistons with U-Flex ring)
Engine: M43TU, M44, N51, N52, N52K, N53, N54
Order number: 11 6 260 Mounting sleeves with case
Consisting of
Scheme 615
1 = 11 6 261 Assembly bush
Note. Diameter 85.00 mm
2 = 11 6 262 Assembly bush
Note. Diameter 85.08 mm, repair
3 = 11 6 263 Assembly bush
Note. Diameter 85.25 mm, stage 1
4 = 11 6 264 Assembly bush
Note. Diameter 85.50 mm, stage 2
9 = 11 6 269 Case with foam inlay
Note. For holding assembly bushes, gauge 11 6 270 and lever gauge 11 6 250
11 6 380 Bush
Minimum set: Mechanical tools
Note. For fitting valve stem seal
Engine: M47, M47TU, M57, M57T2, M57TU, N12, N14, N40, N42, N43, N45, N45T, N46, N46T, N47, N47S, N51, N52, N52K, N53, N54, N57, N62, N63, N73
Storage location: B15
SI number: 1 06 98(306)
Order number: 11 6 380 Bush
Scheme 616
11 6 410 Adapter
Minimum set: Mechanical tools
In conjunction with: 11 9 250
Note. For measuring oil pressure via oil filter housing.
Engine: N52K, N53
SI number: 1 07 08 (443)
Order number: 11 6 410 Adapter
Scheme 617
11 8 330 Insertion tool
Minimum set: Mechanical tools
Note. For installing and removing conrod with piston
Engine: N42, N43, N45, N45T, N46, N46T, N51, N52, N52K, N53
Storage location: A47, B47
SI number: 1 02 04 (069)
Order number: 11 8 330 Insertion tool
Scheme 618
11 8 540 Engine Support Plate
In conjunction with: 00 1 450" 00 2 300
Note. For accommodating engine on assembly stand.
Engine: N51, N52, N52K, N53, N54
SI number: 1 20 06 (299)
Order number: 11 8 540 Engine support plate
Scheme 619
Consisting of
1 = 11 8 541 Engine take-up
2 = 11 8 542 Set of screws (4 x)
11 8 580 Wrench Socket Torx T60
Minimum set: Mechanical tools
Note. For removing and installing cylinder head (outside dia. 13.5 mm).
Engine: N52K, N53, N54
Storage location: A20, B20
SI number: 1 20 06 (299)
Order number: 11 8 580 Wrench socket Torx T60
Scheme 620
11 9 180 Installer
Minimum set: Mechanical tools
Note. For RSS into engine block at rear
Engine: N40, N42, N43, N45, N45T, N46, N46T, N51, N52, N52K, N53, N54
Storage location: C43
SI number: 1 01 01(662)
Order number: 11 9 180 Installer
Scheme 621
Consisting of
1 = 11 9 181 Bushing
2 = 11 9 182 Thrust piece
3 = 11 9 183 Nut
4 = 11 9 184 Screws (2 x)
11 9 200 Puller
Minimum set: Mechanical tools
Note. For RSS out of engine block at rear
Engine: N40, N42, N43, N45, N45T, N46, N51, N52, N52K, N53, N54
Storage location: C43
SI number: 1 01 01(662)
Order number: 11 9 200 Puller
Scheme 622
11 9 220 Puller
Minimum set: Mechanical tools
Note. For RSS out of engine block at front
Engine: N40, N42, N43, N45, N45T, N46, N51, N52, N52K, N53, N54
Storage location: C43
SI number: 1 01 01(662)
Order number: 11 9 220 Puller
Scheme 623
Consisting of
1 = 11 9 221 Thrust member
In conjunction with
4 = 11 9 224 Screws (3 x)
5 = 11 9 225 Screw
6 = 11 9 226 Extractor
11 9 230 Installer
Minimum set: Mechanical tools
Note. For RSS into engine block at front
Engine: N40, N42, N43, N45, N45T, N46, N51, N52, N52K, N53, N54
Storage location: C43
SI number: 1 01 01(662)
Order number: 11 9 230 Installer
Scheme 624
Consisting of
1 = 11 9 231 Bushing
2 = 11 9 232 Spindle
3 = 11 9 233 Nut
4 = 11 9 234 Screws (3 x)
11 9 240 Oil Filter Wrench
Minimum set: Mechanical tools
Note. For unfastening and tightening oil filter cap
Engine: N40, N42, N43, N45, N45T, N46, N46T, N51, N52, N52K, N53, N54, N63
Storage location: A43
SI number: 1 01 01 (662)
Order number: 11 9 240 Oil filter wrench
Scheme 625
11 9 250 Cap
Minimum set: Mechanical tools
Note. For measuring oil pressure via oil filter housing.
Engine: N40, N42, N43, N45, N45T, N46, N46T, N52K, N53
Storage location: B43
SI number: 1 01 01(662)
Order number: 11 9 250 Cap
Scheme 626
11 9 280 Holder
Minimum set: Mechanical tools
Note. For crankshaft when releasing/tightening central bolt
Engine: N12, N14, N40, N42, N43, N45, N46, N51, N52, N52K, N53, N63
Storage location: A43, B43, C43
SI number: 1 01 01(662)
Order number: 11 9 280 Holder
Scheme 627
11 9 340 Chain Tensioner, Complete
Minimum set: Mechanical tools
Note. For tensioning timing chain when adjusting timing
Engine: N12, N14, N40, N42, N43, N45, N45T, N46, N46T, N51, N52, N52K, N53, N54
Storage location: B43
SI number: 1 01 01(662)
Order number: 11 9 340 Chain tensioner, complete
Scheme 628
Consisting of
1 = 11 9 341 Screw
2 = 11 9 342 Spindle
11 9 360 Drift
Minimum set: Mechanical tools
Note. For driving valve into engine block (sealing compound)
Engine: N40, N42, N43, N45, N45T, N46, N46T, N51, N52, N52K, N53, N54, S85
Storage location: A43
SI number: 1 01 01(662)
Order number: 11 9 360 Drift
Scheme 629
11 9 811 Holder
Order number: 11 9 811 Holder
Scheme 630
11 9 812 Screw
Order number: 11 9 812 Screw
