61 0 021 Fuse Link FF 3.15 A/500 V
Note. For analog/digital multimeter M 2005, M 2007, M2008
Storage location: H 107
Order number: 61 0 021 Fuse link FF 3.15 A/500 V
61 0 200 Crimping Set (Basic Tool)
Minimum set: Measuring and testing equipment
Note. Consisting of case + basic crimping tool
Note. Series: E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E71, E81, E82, E83, E85, E86, E87, E88, E90, E91, E92, E93, F01, R50, R52, R53, R55, R56, RR1, RR2
Scheme 278
SI number: 02 02 05 (194)
Order number: 61 0 200 Crimping set (basic tool)
Consisting of
1 = 61 0 201 Plastic case
Note. As storage system for complete set.
2 = 61 0 202 Crimping tool
Note. Basic tool for assorted matrices (crimping insert set)
3 = 61 0 203 Allen key
Note. For securing individual matrices in crimping tool
61 0 210 Matrix LSK 8
In conjunction with: 61 0 202 (crimping tool)
Note. (crimping insert set for load current contact 8)
SI number: 02 02 05 (194)
Order number: 61 0 210 Matrix LSK 8
Scheme 279
61 0 220 Matrix For SLK 2.8
In conjunction with: 61 0 202 (crimping tool)
Note. (crimping insert set for load contact tube 2.8)
SI number: 02 02 05 (194)
Order number: 61 0 220 Matrix for SLK 2.8
Scheme 280
61 0 230 Stencil For Contacts "DFK 40" and "MAK 8"
In conjunction with: 61 0 202 (crimping tool)
Note. For crimping contacts when replacing interior fuse box (up to model year 09/2005) and for further applications.
SI number: 02 07 05 233
Order number: 61 0 230 Stencil for contacts "DFK 40" and "MAK 8"
Scheme 281
61 0 300 Releasing Tool (Complete Kit)
Minimum set: Measuring and testing equipment
Note. Replaces from 09/2005 special tool 61 1 150. From 06/2006 extended by tools 61 0 325 - 61 0 331 (see SI 02 05 06 294). From 02/2008 extended by 61 0 332 and 61 0 333 (see SI 02 03 08 440).
Series: E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E71, E81, E82, E83, E85, E86, E87, E88, E90, E91, E92, E93, F01, F02, R50, R52, R53, R55, R56, RR1, RR2, RR3
Scheme 282
SI number: 2 05 05 (217)
Order number: 61 0 300 Releasing tool (complete kit)
Consisting of
1 = 61 0 301 Release tool for round contacts (diameter 1.5)
Note. Replaces from 09/2005 special tool 61 1 131
2 = 61 0 302 Replacement sleeve D=1.5
Note. Replaces from 09/2005 special tool 61 1 157
In conjunction with: 61 3 301
3 = 61 0 303 Release tool for round systems with D=2.5
Note. Replaces from 09/2005 special tool 61 1 132
4 = 61 0 304 Replacement sleeve (D=2.5)
Note. Replaces from 09/2005 special tool 61 1 156
5 = 61 0 305 Release tool for round contacts (D=3.5)
Note. Replaces from 09/2005 special tool 61 1 133
6 = 61 0 306 Replacement sleeve (D=3.5) for 61 0 305
Note. Replaces from 09/2005 special tool 61 1 155
7 = 61 0 307 Release tool for socket-side round contacts (D=1.5)
8 = 61 0 308 Replacement sleeve for special tool 61 0 307 (D=1.5)
9 = 61 0 309 Release tool for pin-side round contact (D=1.5) manufacturer: Kostal
Note. Replaces from 09/2005 special tool 61 1 139
10= 61 0 311 Replacement sleeve for special tool 61 0 309
Note. Replaces from 09/2005 special tool 61 1 154
11= 61 0 312 Release tool for flat spring contact with a retaining lug (1.6 mm)
Note. Replaces from 09/2005 special tool 61 1 134
12= 61 0 313 Release tool for flat spring contacts with a snap-in pin (1.9 mm)
Note. Replaces from 09/2005 special tool 61 1 137
13= 61 0 314 Release tool for flat spring contact with a snap-in pin (2.7 mm)
Note. Replaces from 09/2005 special tool 61 1 135
14= 61 0 315 Release tool for flat spring contacts with double snap-in pin "Micro-Timer 2"
Note. Replaces from 09/2005 special tool 61 1 151
15= 61 0 316 Release tool for flat spring contacts with double snap-in pin "SPT 4.8" "JPT 2.8"
Note. Replaces from 09/2005 special tool 61 1 136
16= 61 0 317 Release tool for LSK 8
Note. Replaces from 09/2005 special tool 61 1 200
17= 61 0 318 Release tool for "Maxi Power Timer 9.5"
Note. Replaces from 09/2005 special tool 61 1 180
19= 61 0 321 Release tool for sensor laminated contacts with unlocking element ("SLK 2.8")
20= 61 0 322 Release tool for mini laminated contact ("MLK 1.2 mm")
21= 61 0 323 Release tool for flat spring contacts with a snap-in pin (MQS)
Note. Replaces from 09/2005 special tool 61 1 152
22= 61 0 324 Release tool for secondary locking
Note. Universal tool for damage-free opening/removal of secondary locks
23= 61 0 329 Case with foam inlay without tools
Note. Storage system for release tools from set 61 0 300
24= 61 0 325 Release tool "JPT"
25= 61 0 326 Release tool "MQS"
Note. For releasing all micro contacts
26= 61 0 327 Plug-in aid
Note. For inserting contacts (0.64 - 1.2 mm) in housing
27= 61 0 328 Plug-in aid
Note. For inserting contacts (2.8 - 4.8 mm) in housing
28= 61 0 331 Release tool "SLK 5.8"
Note. For release "SLK 5.8 mm" contacts
29= 61 0 332 Release tool
Note. For releasing "MQS 0.64 mm" contacts
30= 61 0 333 Release tool
Note. For releasing "Mcon 2.8" contacts. Replaces special tool 61 0 319 from 2008.
61 1 100 Releasing Kit
Minimum set: Measuring and testing equipment
Note. For releasing assorted electrical contacts on all 4-cylinder diesel engines.
Series: E46, E46/16, E46/2, E46/3, E46/5, E46/C, E60, E61, E81, E82, E83, E85, E86, E87, E88, E90, E91, E92, E93
SI number: 02 01 08 438
Order number: 61 1 100 Releasing kit
Scheme 283
Consisting of
1 = 61 1 101 Case
Note. For storing release tools from set 61 1 100.
2 = 61 1 102 Release tool
Note. For releasing "MLK 1.2" contacts (connector)
3 = 61 1 103 Release tool
Note. For releasing "MLK 1.2" contacts (sleeve)
4 = 61 1 104 Release tool
Note. For releasing "SLK 2.8" mm contacts with second lock and supplementary slide
5 = 61 1 105 Release tool
Note. For releasing "SLK 5.8" mm contacts with second lock and supplementary slide
61 1 190 Pliers
Note. For insulation displacement connectors for repairing ribbon cables
Series: E60, E61, E63, E64, E65, E66, E67, E71, E81, E82, E83, E86, E87, E88, E90, E91, E92, F01, R50, R52, R55, R56, RR1, RR2
SI number: 1 14 01 (766)
Order number: 61 1 190 Pliers
Scheme 284
61 2 440 System Connecting Cable (Country-Specific)
Note. System connecting cable for battery trickle charger 61 2 410
Order number: 61 2 440 System connecting cable (country-specific)
Consisting of
1 = 61 2 441 System connecting cable (country-specific)
Note. Algeria/Armenia/Belarus/Belgium/Brazil/Denmark/Dubai/Egypt/Finland/France/Germany/Greece/Korea/Luxembourg/Martinique/Morocco/Norway/Saudi Arabia/Sweden/Spain and others
2 = 61 2 442 System connecting cable (country-specific)
Note. Australia/New Zealand
3 = 61 2 443 System connecting cable (country-specific)
Note. Italy
4 = 61 2 444 System connecting cable (country-specific)
Note. Bahrain/Brunei Dar es Salaam/England/Hong Kong/India/Kuwait/Nigeria/Northern Ireland/Oman/Qatar/Singapore/Sri Lanka (Ceylon)
5 = 61 2 445 System connecting cable (country-specific)
Note. Switzerland
6 = 61 2 446 System connecting cable (country-specific)
Note. Argentina/Barbados/Canada/China/Guam/Honduras/Jamaica/Mexico/Panama/Philippines/Tahiti/Taiwan/USA
7 = 61 2 447 System connecting cable (country-specific)
Note. Japan
61 3 140 Adapter Lead, 38-Pin
Minimum set: Measuring and testing equipment
Note. For diagnosis work on DSC
SI number: 02 06 08 475
Order number: 61 3 140 Adapter lead, 38-pin
Scheme 285
61 4 300 Adapter Lead For OBD Socket
Note. For connecting diagnosis system to OBD socket from 06/2000.
Storage location: Single
SI number: 2 04 00 (561)
Order number: 61 4 300 Adapter lead for OBD socket
Scheme 286
61 4 320 Crimping Set With Pliers
Minimum set: Measuring and testing equipment
Note. For repairing fibre optics conductors and cables. Universal crimp head 61 4 328 added as from 06/2006, see SI 2 04 06 293.
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E71, E81, E82, E83, E85, E86, E87, E88, E90, E91, E92, E93, F01, R50, R52, R53, R55, R56, RR1, RR2, RR3
Scheme 287
SI number: 1 14 01(766)
Order number: 61 4 320 Crimping set with pliers
Consisting of
1 = 61 4 321 Pliers without crimping head
2 = 61 4 322 Crimping head
Note. For stripping insulation and cutting fibre optic cable to length
3 = 61 4 323 Crimping head
Note. For crimping fibre optic cable contacts
4 = 61 4 324 Crimping head
Note. For crimping MQS contacts
5 = 61 4 325 Crimping head
Note. For crimping MPQ contacts
6 = 61 4 326 Substitute blade
Note. For face-cutting fiber optic cables
7 = 61 4 327 Substitute blade
Note. With tool for replacing blade in cable stripping unit. Must be ordered separately, not included in 61 4 320 delivery specification!
8 = 61 4 328 Universal crimping head
Note. For crimping contacts (without seal) and cable cross-sections of 0.35 - 2.5 mm, see SI 2 04 06 293.
In conjunction with: in conjunction with 61 4 321
61 4 360 Adapter Cable, 19-Pin (Electric Seat)
Minimum set: Measuring and testing equipment
Note. In repair and test work the seat can also be tested outside the vehicle by means of this adapter cable.
Series: E81, E82, E87, E90, E91, E92, E93, RR2
SI number: 02 01 05 186
Order number: 61 4 360 Adapter cable, 19-pin (electric seat)
Scheme 288
61 4 380 Measuring Box, 105-Pin, Complete
Minimum set: Measuring and testing equipment
Note. For connecting all adapter cables with 61- to 105-pin plug connections
Series: E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, F01, R50, R52, R53, R55, R56, RR1, RR2, RR3
Storage location: G 110, S 205, U 202, U 205
Scheme 289
SI number: 2 04 01(710)
Order number: 61 4 380 Measuring box, 105-pin, complete
Consisting of
1 = 61 4 381 Measuring box, 105-pin
Note. Without accessories
2 = 61 4 382 Test lead, black
Note. 2 mm system, lead length: 750 mm
3 = 61 4 383 Test lead, red
Note. 2 mm system, lead length: 750 mm
4 = 61 4 384 Test lead set
Note. 2/4 mm system, lead length: 200 mm
5 = 61 4 385 Earth/ground cable
Note. For shield pick-off, lead length: 1.5 m
61 4 390 Measuring Box, 60-Pin
Minimum set: Measuring and testing equipment
Note. For connecting all adapter cables with 27- to 60-pin plug connections
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, F01, R50, R52, R53, R55, R56, RR1, RR2, RR3
Scheme 290
Storage location: T 210
SI number: 2 02 98(308)
Order number: 61 4 390 Measuring box, 60-pin
61 6 060 Universal Wiper Arm Puller
Minimum set: Mechanical tools
Note. For removing windshield wiper arm from drive shaft
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E71, E81, E82, E83, E85, E86, E87, E88, E90, E91, RR1, RR2
Scheme 291
Storage location: B7
SI number: 1 10 99 (433)
Order number: 61 6 060 Universal wiper arm puller
Consisting of
1 = 61 6 061 Basic body
2 = 61 6 062 Claw, left/right
3 = 61 6 063 Spindle
4 = 61 6 064 Thrust piece
61 6 100 Angle Measuring Instrument
Minimum set: Mechanical tools
Note. For measuring contact/approach angle of wiper blades to window (angle when setting wiper arms)
Series: E36, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E71, E81, E82, E83, E85, E86, E87, E88, E90, E91, E92, E93, F01, F02, R50, R52, R53, R55, R56, RR1, RR2, RR3
Storage location: A54
Scheme 292
SI number: 1 21 05 220
Order number: 61 6 100 Angle measuring instrument
61 8 081 Additions To Repair Kit I
Note. Order through BMW EPC (Electronic Parts Catalogue), refer to SI 2 07 06 311 (order numbers: 12 52 1 706 059" 12 52 1 706 068" 12 52 1 706 069" 61 13 1 352 607" 61 31 1 378 942)
Storage location: K 108
Order number: 61 8 081 Additions to repair kit I
61 8 082 Additions To Repair Kit II
Note. Order through BMW EPC (Electronic Parts Catalogue), refer to SI 2 07 06 311 (order numbers: 61 13 1 368 534" 61 13 1 369 747" 61 13 1 374 225" 61 13 1 378 722)
Storage location: K 108
Order number: 61 8 082 Additions to repair kit II
61 8 083 Additions To Repair Kit III
Note. Order through BMW EPC (Electronic Parts Catalogue), refer to SI 2 07 06 311 (order numbers: 61 13 1 378 110" 61 13 1 378 130" 61 13 1 378 136" 61 13 1 378 137" 61 13 1 378 138" 61 13 1 378 139" 61 13 1 378 908" 61 13 1 378 944" 61 13 1 378 987)
Storage location: K 108
Order number: 61 8 083 Additions to repair kit III
61 9 045 Female Die
In conjunction with: 61 9 041 Crimping tool
Note. For crimping 2.5 mm (dia.) sleeves
Order number: 61 9 045 Female die
