Engine Cooling System - 3.2L V6 4V - Bhe: Overview Audi TT 8N facelift

Thermostat housing, component overview

Note. The following list refers to items in (Scheme 2).

1. O-ring Replace
2. Retaining clip
3. Thermostat housing Removing and installing, see «THERMOSTAT HOUSING, REMOVING AND INSTALLING»(ref-200990-S15323189872005102400000)
4. Bracket
5. 10 Nm
6. Thermostat Removing and Installing, see «THERMOSTAT HOUSING, REMOVING AND INSTALLING»(ref-200990-S15323189872005102400000) Checking, see «THERMOSTAT HOUSING, CHECKING»(ref-200990-S00349822512005102400000)
7. Connection
8. Gasket Replace
9. Engine Coolant Temperature (ECT) sensor -G62- With ECT sensor -G2- Dissipate cooling system pressure before removal if necessary
10. Sealing plug Dissipate cooling system pressure before removal if necesary

Scheme 1

Scheme 2

1. Drip tray V.A.G 1306
2. Hose clamp pliers V.A.G 1921

Scheme 3

Radiator and coolant fan, component overview

Note. The following list refers to items in see scheme 57.

1. Coolant fan -V7- Removing and Installing, see «COOLANT FAN -V7- AND COOLANT FAN -2- -V177-, REMOVING AND INSTALLING»(ref-200990-S37111330312005102400000)
2. Retaining clips For electrical wiring going to fans Check for firm attachment
3. Coolant Fan Control (FC) thermal switch -F18- Tighten to 35 Nm
4. Seal Replace
5. Coolant hose To disconnect, release retaining clip
6. O-ring Replace
7. Radiator Removing and Installing, see «RADIATOR, REMOVING AND INSTALLING»(ref-200990-S03409993622005102400000) After replacing, fill with new coolant
8. 15 Nm
9. Bracket for radiator Note installed position
10. 10 Nm
11. 10 Nm
12. Radiator cowl
13. Coolant fan -2- -V177- Removing and Installing, see «COOLANT FAN -V7- AND COOLANT FAN -2- -V177-, REMOVING AND INSTALLING»(ref-200990-S37111330312005102400000)

Scheme 4
