Engine Cooling System - 3.2L V6 4V - Bhe: Component Locations Audi TT 8N facelift

Special tools and equipment required

1. Adapter for cooling system tester V.A.G 1274/8
2. Drip tray V.A.G 1306
3. Hose clamp pliers V.A.G 1921
4. Cooling system charge unit VAS 6096 with VAS 6096/1
5. Refractometer T10007

Scheme 8

1. Support bracket 10-222 A
2. Shackle 10-222 A/12
3. Drip tray V.A.G 1306
4. Coolant pump spanner V.A.G 1590
5. Hose clamp pliers V.A.G 1921
6. Bolt M8 x 40

Scheme 9

1. Hose clip pliers V.A.G 1921
2. Drip tray V.A.G 1306

Scheme 10

Special Tools and Equipment

1. VAG1274 Cooling system tester
2. VAG1274/8 Adapter
3. VAG1274/9 Adapter

Scheme 11
