INTERNAL WIRING HARNESS
Note. For identification marking of components at 14-pin wiring harness see scheme 31
Scheme 43
Scheme 44
Scheme 45
- Disconnect battery. See «BATTERY DISCONNECT PRECAUTIONS»(ref-170597-S34422722222005011200000).
- Remove oil pan. See «OIL PAN»(ref-170597-S21594399982005012000000).
- Remove ATF screen. See «ATF SCREEN»(ref-170597-S25984169962005012000000).
- Remove valve body. See «VALVE BODY»(ref-170597-S40627592352005012000000).
- On vehicles where transmission is installed, disconnect 14-pin connector (A) from transmission connector. see scheme 32
- On all vehicles remove securing bolt of 14-pin connector on outside of transmission housing. Remove connector from transmission housing, and carefully guide wiring harness (D) after it. see scheme 33
- To install, replace "O" ring on connector. Coat NEW "O" ring with ATF. Press connector with "O" ring installed to limit stop in transmission. Tighten connector bolt to specification. See «TORQUE SPECIFICATIONS»(ref-170597-S13798279542005011200000).
- Remainder of installation is reverse of removal procedure.
- Remove valve body. See «VALVE BODY»(ref-170597-S40627592352005012000000).
- Remove ATF screen. See «ATF SCREEN»(ref-170597-S25984169962005012000000).
- Remove oil pan. See «OIL PAN»(ref-170597-S21594399982005012000000).
- Disconnect battery. See «BATTERY DISCONNECT PRECAUTIONS»(ref-170597-S34422722222005011200000).
