Assembling Audi TT 8N

Rear Final Drive 02d 3 illustrations

Assembling

  1. Insert thrust washer union with transmission fluid.
  2. Insert both large differential bevel gears and secure (e.g. with flanged shaft).

Scheme 810

Scheme 810
Scheme 810
  1. Insert small differential bevel gears at 180 ° offset and swing in by rotating on one of the two flanged shafts.
  2. Drive differential planetary gear axle into final position and secure with spring pin.

Scheme 811

Scheme 811
Scheme 811
  1. Press ball bearing into cover.
  2. Secure with large circlip.

Scheme 812

Scheme 812
Scheme 812
  1. Pressing cover on differential.
  2. Secure with small circlip.
  3. Drive in new seal flush --> «Installing»(/audi/tt/8n-1998-2003/remont/differentials-drive-axles/#rear-final-drive-02d) .
