Multi-Function Transmission Range (TR) Switch, removing Audi TT 8N

1.8l 4-cyl 5v Turbo Generic Scan Tool Engine Code(s): Amu, Bea, Atc, Awp 3 illustrations ~145 words

Multi-Function Transmission Range (TR) Switch, removing

  1. Place selector lever in "N" position.
  2. Switch off ignition.

Scheme 569

Scheme 569
Scheme 569
  1. Disconnect hose - 5 - from air filter housing.
  1. Press selector lever cable - 1 - off of lever/selector shaft - 6 - using screwdriver.
  2. Do not loosen screws - 2 -.
  3. Do not kink selector lever cable.
  4. Disconnect connector - 5 - at Multi-Function Transmission Range (TR) Switch.

Scheme 570

Scheme 570
Scheme 570
  1. Remove lever/selector shaft - 1 -.

Scheme 571

Scheme 571
Scheme 571
  1. Bend hooks of locking washer - 2 - back using a screwdriver.

Note. If one or more hooks on lock washer are broken during bending, these must be replaced.

  1. Remove nut - 3 - with washers - 2 - and - 1 -.
  2. Remove both screws - B - and pull Multi-Function Transmission Range (TR) Switch - A - upward over selector shaft.
