- Hold crankshaft in position using 3242 crankshaft holder, see «A - DUAL-MASS FLYWHEEL»(ref-196260-S00548759012005100700000) .
- Mark positions of shim -1- (in front of drive plate) and washer -2- (behind drive plate).
- Install drive plate together with washer -2- and shim -1-. Washer -2-: Part No. 035 105 303 A Shim -1-: 3.00 mm, Part No. 054 105 301 Shim -1-: 4.00 mm, Part No. 054 105 202 Always replace drive plate mounting bolts Drive plate to crankshaft bolts tightening torque: 60 (44 ft lb) + 1/4 -turn (90°)
| CAUTION | Part numbers are listed here for reference only. Always check with your Parts department for the latest information. |
Note. Short engines and exchange engines are supplied without a bushing in the crankshaft. For vehicles equipped with an automatic transmission, install the bushing before installing the drive plate.
- Measure distance -a- at three points and calculate average value. Dimension -a-: approx. 12.3 mm (0.484 in.).
- If necessary, install different shim.
Note. Before installing the engine, make sure the engine to transmission centering sleeves are installed in the engine block.
