ELECTROMECHANICAL POWER STEERING GEAR OVERVIEW

Note. Always replace self-locking nuts and bolts. Welding or straighten work on any steering components is not permissible. Use only power steering gear grease to lubricate the steering rack (on the pinion side) and the ball paths (on the engine side). Note: there are different types of grease for the left and right. The clamps -1 and 8- are tensioned to different tightening specifications.

Scheme 153

Scheme 153: ELECTROMECHANICAL POWER STEERING GEAR OVERVIEW

Clamp Always replace if removed Use the CV joint boot clamp tool to tensions the clamp (Scheme 155) NOTE: Do not open or bend the new clamp.
Tie rod 100 Nm Removing and Installing, refer to «TIE ROD»(ref-522302-S34528697992013011400000) Grease the joint with power steering gear grease.
Electromechanical Steering Gear Removing and Installing, refer to «STEERING GEAR»(ref-522302-S27241507692013011400000) Grease the steering rack with power steering gear grease. Note: there are different types of grease for the left and right.
Tie Rod End Removing and installing, refer to «TIE ROD END»(ref-522302-S08185364552013011400000). Check dust caps for damage and correct seating. Check dimension. (Scheme 154)
Nut 80 Nm Counterhold on the tie rod end when loosening or tightening.
Spring Clamp Always replace if removed. Spring clamp, installing, refer to «TIE ROD»(ref-522302-S34528697992013011400000).
Boot Check for damage. Always replace if removed. Coat the inside of slits in the boot all the way around and evenly with power steering gear grease before installing. Check the seat for the boot on the steering gear for damage before installing. If the steering gear housing is damaged, replace the steering gear. Must not be twisted when toe is being adjusted. Make sure it is installed correctly. Refer to «TIE ROD»(ref-522302-S34528697992013011400000). Replacing, refer to «BOOT»(ref-522302-S17147194972013011400000).
Clamp Always replace if removed. Use the CV joint boot clamp tool to tensions the clamp. (Scheme 155) NOTE: Do not open or bend the new clamp.
Tie Rod 100 Nm Removing and installing, refer to «TIE ROD»(ref-522302-S34528697992013011400000). Grease the joint with power steering gear grease.
Tie Rod End Removing and installing, refer to «TIE ROD END»(ref-522302-S08185364552013011400000). Check dust caps for damage and correct seating. Check dimension (Scheme 154)
Lock Nut 80 Nm Counterhold on the tie rod end when loosening or tightening.
Spring clamp Always replace if removed. Spring clamp, installing «TIE ROD»(ref-522302-S34528697992013011400000).
Boot Check for damage. Always replace if removed. Coat the inside of slits in the boot all the way around and evenly with power steering gear grease before installing. Check the seat for the boot on the steering gear for damage before installing. If the steering gear housing is damaged, replace the steering gear. Must not be twisted when toe is being adjusted. Make sure it is installed correctly. Refer to «TIE ROD»(ref-522302-S34528697992013011400000). Replacing, refer to «BOOT»(ref-522302-S17147194972013011400000).

Scheme 154

Place a steel ruler -2- on the tie rod end and push it all the up to the edge -arrow- of the tie rod end -1-.
Replace the entire steering gear along with the tie rod and tie rod end if the check dimension -a- is <188 mm.

Scheme 155

Mount the CV joint boot clamp tool -1- as illustrated. Make sure that the jaws of the clamp tool are seated in the corners -arrows- of the clamp.

Tighten the clamp by turning the spindle using a torque wrench -2- (do not tilt the pliers).

Use torque wrench -2- with a 5 to 50 Nm range (for example, V.A.G 1331).
make sure the spindle threads on the pliers -1- move freely. Grease with MoS 2 grease if necessary.
If the thread is tight e.g. dirty, the required tensioning force for the hose clamp will not be achieved in spite of correct torque specification settings.

Clamp style	CV joint boot clamp tool V.A.G 1682 A (Hazet)	CV joint boot clamp tool V.A.G 1682 (O tiker)
85 mm clamp (front passenger side), refer to item 8	7 Nm	9 Nm
59 mm clamp (driver side), refer to item 1	10 Nm	12 Nm

Outer Boot Assembly

Scheme 156

Dimension -a- 2 mm

HYDRAULIC POWER STEERING GEAR WITH TIE RODS OVERVIEW

Note. Power steering gear is completely removed and installed with tie rods.

Scheme 157

Scheme 157: HYDRAULIC POWER STEERING GEAR WITH TIE RODS OVERVIEW

Subframe
Crossbrace
Steering Column
Bolt 30 Nm + 90° turn Always replace if removed. The threaded hole for the bolt must always be cleaned (for example, using a thread tap).
Nut Always replace if removed.
Seal Always replace if removed.
Return Line CAUTION: Insert the return line completely when installing.
Bolt 80 Nm + 180° turn Always replace if removed.
Hydraulic Power Steering Gear with Tie Rods Removing and installing, left hand drive «STEERING GEAR»(ref-522302-S12867441752013011400000) . Servicing, refer to «HYDRAULIC POWER STEERING GEAR OVERVIEW»(ref-522302-S10037266352013011400000) . Adjusting, refer to «HYDRAULIC POWER STEERING GEAR, ADJUSTING»(ref-522302-S02220224812013011400000) .
Tie Rod Removing and installing, refer to «TIE RODS»(ref-522302-S02532892842013011400000) .
Tie Rod End Different versions, with long or short thread on the joint pin, WARNING: When replacing, make sure the length of the thread on the tie rod end is sufficient (there must be approximately 5 mm extra thread). If this is not the case, then install a tie rod end with a longer thread pin, Removing and installing, refer to «TIE ROD END»(ref-522302-S20686048422013011400000) .
Bolt 20 Nm
Pressurized Line There are versions with and without a separating point. CAUTION: Insert the pressure line completely when installing.
Rubber Bushing 6 Nm
Union Nut 40 Nm A pressure line without a separating point does not have a union nut.
Nut 6 Nm
Nut Different versions, Pay attention to the different nut versions and to the tightening specifications. Refer to «HYDRAULIC POWER STEERING GEAR WITH TIE RODS OVERVIEW»(ref-522302-S04879972942013011400000) . Always replace if removed.
Wheel Bearing Housing

Nut Versions for the Tie Rod Ball Joint Bracket

Scheme 158

Hex collar nut -A

Tightening specifications: 20 Nm + 90° turn

12-point combi nut -B

Tightening specifications: 100 Nm

Hex combi nut -C

Tightening specifications: 110 Nm

HYDRAULIC POWER STEERING GEAR OVERVIEW

Special tools and workshop equipment required

Torque wrench V.A.G 1332
Hose clamp pliers V.A.G 1921
Locking pliers VAS 6199

Note. Always replace self-locking nuts and bolts. Welding or straighten work on any steering components is not permissible. To grease the rack, only use steering gear grease.

Scheme 159

Tie Rod End Different versions, with long or short thread on the joint pin, WARNING: When replacing, make sure the length of the thread on the tie rod end is sufficient (there must be approximately 5 mm extra thread). If this is not the case, then install a tie rod end with a longer thread pin, Check dust caps for damage and correct seating. Removing and installing, refer to «TIE ROD END»(ref-522302-S20686048422013011400000) .
Nut 60 Nm
Spring Clamp Always replace if removed.
Boot Check for damage. Do not twist after adjusting the toe. Can be replaced with steering gear installed. Replacing, refer to «BOOT»(ref-522302-S29599387812013011400000) .
Clamp Always replace if removed. Clamping sleeves, installing «TIE RODS»(ref-522302-S02532892842013011400000) .
Tie Rod 90 Nm Removing and installing, refer to «TIE RODS»(ref-522302-S02532892842013011400000) . Grease joint with steering gear grease.
Steering Gear Grease joint with steering gear grease.
Strainer Always replace if removed.
Seal Always replace if removed.
Seal Always replace if removed.
Servotronic Solenoid Valve -N119- Removing and installing, refer to «SERVOTRONIC SOLENOID VALVE -N119»(ref-522302-S20123288852013011400000) . follow values can be requested vehicle diagnostic tester: Speed signal The voltage supply from Vehicle Electrical System Control Module 2 -J520-. Solenoid valve status. Measured current for solenoid valve control. -- Connect vehicle diagnostic tester and select troubleshooting using "Functions/Component selection". -- Then "body". -- Select "Electrical system". -- "01- On Board Diagnostic (OBD) capable systems". -- "vehicle electrical system control module". -- "Electrical components". -- "Servotronic solenoid valve".
Bolt 3 Nm CAUTION: Always follow screw tightening sequence. Tightening sequence, refer to «SERVOTRONIC SOLENOID VALVE -N119»(ref-522302-S20123288852013011400000) .

POWER STEERING PUMP, HYDRAULIC LINES AND RESERVOIR OVERVIEW, VEHICLES WITH DYNAMIC STEERING

Note. The power steering pump is not designed to be serviced. If there are customer complaints, the cause must be determined using a pressure and leak test. If there is a malfunction, replace the pump. If power steering fluid is low in reservoir, check steering system for leaks. If there are leaks in the area of the line connections, the lines/connections must first be inspected for leaks, tightened as necessary and wiped dry. Power steering pump is delivered without oil. Therefore, hydraulic oil must be filled before installation and turned by hand. Otherwise, noises when driving or damage to power steering pump may occur.

Scheme 160

Scheme 160: POWER STEERING PUMP, HYDRAULIC LINES AND RESERVOIR OVERVIEW, VEHICLES WITH DYNAMIC STEERING

Tensioning Strap Secure to body. Refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) .
Reservoir Note installed position. Refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) . Installation position of hoses on the reservoir. Refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) .
Cap with Dip Stick Check fluid level. Refer to «POWER STEERING FLUID LEVEL, CHECKING»(ref-522302-S40413887992013011400000) .
Bolt 9 Nm
Bolt 9 Nm
Spring Clamp Removing and install using the hose clip pliers V.A.G 1921.
Return Hose From the hydraulic oil cooler to the reservoir. Mounting on longitudinal member, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) . Note location on reservoir. Refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) . Note location on hydraulic oil cooler. Refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) .
Clip
Clamp Tension using hose clamp pliers V.A.G 1275. Always replace if removed.
Return Line From the power steering gear to the hydraulic oil cooler. CAUTION: Insert the return line completely when installing. Mounting on the subframe, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) . Note location on hydraulic oil cooler. Refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) . Installation location on the wiring connection, refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) .
Seal Always replace if removed.
Bolt 9 Nm
Hydraulic Oil Cooler Clipped to the condenser. Refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) . Removing and installing, refer to «HYDRAULIC OIL COOLER, VEHICLES WITH DYNAMIC STEERING»(ref-522302-S09781093442013011400000) .
Steering Gear Removing and installing, refer to «STEERING GEAR»(ref-522302-S12867441752013011400000) .
Bolt 20 Nm
Pressurized Line From the power steering pump to the power steering gear. CAUTION: Insert the pressure line completely when installing. Mounting on crossbrace, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) . Wiring connection installation location, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) .
Rubber Bushing 6 Nm
Nut 6 Nm
Union Nut 40 Nm Wiring connection installation location, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) .
Pressurized Line From the power steering pump to the power steering gear. CAUTION: Insert the pressure line completely when installing. Union nut tightening specification: 38 Nm Mounting on engine mount, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) . Wiring connection installation location, refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) .
Nut 9 Nm
Bracket
Connector For the engine mount.
Bolt 9 Nm
Bolt 25 Nm
Power Steering Pump Fill with hydraulic oil before installation Checking delivery pressure, refer to «POWER STEERING PUMP, CHECKING DELIVERY PRESSURE»(ref-522302-S02669386902013011400000) . Removing and installing, refer to «POWER STEERING PUMP, VEHICLES WITH DYNAMIC STEERING»(ref-522302-S37361234292013011400000) .
Bolt 25 Nm
Intake Hose Note location on reservoir. Refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) . Note power steering pump location. Refer to «POWER STEERING PUMP, VEHICLES WITH DYNAMIC STEERING»(ref-522302-S37361234292013011400000) .

POWER STEERING PUMP, HYDRAULIC LINES AND RESERVOIR OVERVIEW, VEHICLES WITHOUT DYNAMIC STEERING

Scheme 161

Scheme 161: POWER STEERING PUMP, HYDRAULIC LINES AND RESERVOIR OVERVIEW, VEHICLES WITHOUT DYNAMIC STEERING

Tensioning Strap Secure to body. Refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) .
Reservoir Note installed position. Refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) . Installation position of hoses on the reservoir, refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) .
Cap with Dip Stick Check fluid level. Refer to «POWER STEERING FLUID LEVEL, CHECKING»(ref-522302-S40413887992013011400000) .
Bolt 9 Nm
Bolt 9 Nm
Spring Clamp Removing and install using the hose clip pliers V.A.G 1921.
Bolt 9 Nm
Return Line From the power steering gear to the reservoir. CAUTION: Insert the return line completely when installing. Mounting on the subframe, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) . Note location on reservoir. Refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) .
Seal Always replace if removed.
Steering Gear Removing and installing, refer to «STEERING GEAR»(ref-522302-S12867441752013011400000) .
Bolt 20 Nm
Rubber Bushing 6 Nm
Pressurized Line From the power steering pump to the power steering gear; there are different versions with and without a separating point. Mounting on crossbrace, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) . Wiring connection installation location, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) . CAUTION: Insert the pressure line completely when installing.
Nut 6 Nm
Union Nut 40 Nm Wiring connection installation location, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) . A pressure line without a separating point does not have a union nut.
Pressurized Line From the power steering pump to the power steering gear. CAUTION: Insert the pressure line completely when installing. Mounting on engine mount, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) . Wiring connection installation location, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S25940130812013011400000) .
Nut 9 Nm
Bracket
Connector For the engine mount.
Bolt 9 Nm
Bolt 25 Nm
Power Steering Pump Fill with hydraulic oil before installation. Checking delivery pressure, refer to «POWER STEERING PUMP, CHECKING DELIVERY PRESSURE»(ref-522302-S02669386902013011400000) . Removing and installing, refer to «POWER STEERING PUMP, VEHICLES WITHOUT DYNAMIC STEERING»(ref-522302-S35333497082013011400000) .
Bolt 25 Nm
Clamp Tension using hose clamp pliers V.A.G 1275. Always replace if removed.
Intake Hose Note location on reservoir. Refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) . Note power steering pump location. Refer to «POWER STEERING PUMP, VEHICLES WITHOUT DYNAMIC STEERING»(ref-522302-S35333497082013011400000) .

Scheme 162

Scheme 162: LINES AND HOSES OVERVIEW

Reservoir bracket to body (Scheme 163)
Reservoir in bracket (Scheme 164)
Bolt in bracket (Scheme 164)
Return line clip to the longitudinal member (Scheme 165)and intake hose clip to the pressure pipe (Scheme 166).
Hydraulic oil cooler to condenser (Scheme 167)
Power steering pump in bracket, refer to «POWER STEERING PUMP, VEHICLES WITH DYNAMIC STEERING»(ref-522302-S37361234292013011400000) or «POWER STEERING PUMP, VEHICLES WITHOUT DYNAMIC STEERING»(ref-522302-S35333497082013011400000).
Pressurized line to crossbrace (Scheme 168)
Pressure line connection installation location (Scheme 168)
Pressurized line to the engine mount (Scheme 169)
Return line to the subframe (Scheme 171), return line bracket to the longitudinal member (Scheme 170)

Scheme 163

Secure the bracket -2- to the body with bolts -1-.

Secure the reservoir -4- in the bracket -2- using the bolt -3-.

Scheme 164

Insert the reservoir with the tab -1- in the opening in the bracket -2-.

Scheme 165

Secure the return line -1- to the left longitudinal member using the clip -2-.

Scheme 166

Insert the intake hose -1- in the clip -2- on the pressure tube -3-.

Scheme 167

Position the hydraulic oil cooler -1- on the brackets -2- and then engage it into the brackets -3-.

Lines to the hydraulic oil cooler, refer to HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION .

Scheme 168

Install the pressure line on the crossbrace using the nut -3- and rubber bushing -4-.

Note the line installation location when bolting the line connection. The markings -1- and -2- must be opposite each other.

Scheme 169

Route the pressure line -4- between the connector -2- and the engine mount -3-.

Tighten the retaining bracket -5- on the threaded pin -1- using the nut -6-.

Scheme 170

Secure the return line with the wiring bracket -1- to the left front of the subframe -2-.

Scheme 171

Install the return line -4- on the subframe -3- using the bracket -2- and bolt -1-.

Scheme 172

Scheme 172: POWER STEERING PUMP, HYDRAULIC LINES AND RESERVOIR OVERVIEW, VEHICLES WITH DYNAMIC STEERING

Tensioning Strap Secure to body. Refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) .
Reservoir Note installed position. Refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) . Installation position of hoses on the reservoir. Refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) .
Cap with Dip Stick Check fluid level. Refer to «POWER STEERING FLUID LEVEL, CHECKING»(ref-522302-S40413887992013011400000) .
Bolt 9 Nm
Bolt 9 Nm
Spring Clamp Removing and install using the hose clip pliers V.A.G 1921.
Return Hose From the hydraulic oil cooler to the reservoir. Mounting on longitudinal member, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) . Note location on reservoir, refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) . Note location on hydraulic oil cooler, refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) .
Nut 6 Nm
Clip
Return Line From the power steering gear to the hydraulic oil cooler. Mounting on the subframe, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) . Note location on reservoir, refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) . Note location on hydraulic oil cooler, refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) .
Clamp Tension using hose clamp pliers V.A.G 1275. Always replace if removed.
Bolt 9 Nm
Bolt 9 Nm
Seal Always replace if removed.
Return Line From the power steering gear to the hydraulic oil cooler. CAUTION: Insert the return line completely when installing. Mounting on the subframe, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) . Installation location on the wiring connection, refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) .
Hydraulic Oil Cooler Clipped to the condenser. Refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) . Removing and Installing, refer to «HYDRAULIC OIL COOLER, VEHICLES WITH DYNAMIC STEERING»(ref-522302-S09781093442013011400000) .
Steering Gear Removing and installing, refer to «STEERING GEAR»(ref-522302-S12867441752013011400000) .
Bolt 20 Nm
Pressure Line From the power steering pump to the power steering gear. CAUTION: Insert the pressure line completely when installing. Mounting on crossbrace, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) . Wiring connection installation location, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) .
Rubber Bushing 6 Nm
Nut 6 Nm
Union Nut 40 Nm Wiring connection installation location, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) .
Pressure Line From the power steering pump to the power steering gear. CAUTION: Insert the pressure line completely when installing. Mounting on crossbrace, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) . Wiring connection installation location, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) .
Nut 9 Nm
Bracket
Connector For the engine mount.
Bolt 20 Nm
Power Steering Pump -V119- With power steering pump control valve -(V119)-. The pump and control valve are a single component and are replaced together. Fill with hydraulic oil before installation. Checking delivery pressure, refer to «POWER STEERING PUMP, CHECKING DELIVERY PRESSURE»(ref-522302-S09432981902013011400000) . Removing and installing, refer to «POWER STEERING PUMP, VEHICLES WITH DYNAMIC STEERING»(ref-522302-S04436216142013011400000) .
Bolt 20 Nm
Intake Hose Note location on reservoir. Refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) . Note power steering pump location. Refer to «POWER STEERING PUMP, VEHICLES WITHOUT DYNAMIC STEERING»(ref-522302-S03518884972013011400000) .

Scheme 173

Scheme 173: POWER STEERING PUMP, HYDRAULIC LINES AND RESERVOIR OVERVIEW, VEHICLES WITHOUT DYNAMIC STEERING

Tensioning Strap Secure to body. Refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) .
Reservoir Note installed position. Refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) . Installation position of hoses on the reservoir. Refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) .
Cap with Dip Stick Check fluid level. Refer to «POWER STEERING FLUID LEVEL, CHECKING»(ref-522302-S40413887992013011400000) .
Bolt 9 Nm
Bolt 9 Nm
Spring Clamp Removing and install using the hose clip pliers V.A.G 1921.
Bolt 9 Nm
Bolt 9 Nm
Wiring Bracket For securing the intake hose on the longitudinal member, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) .
Return Line From the power steering gear to the reservoir. CAUTION: Insert the return line completely when installing. Mounting on the subframe, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) . Note location on reservoir. Refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) .
Seal Always replace if removed.
Steering Gear Removing and installing, refer to «STEERING GEAR»(ref-522302-S12867441752013011400000) .
Bolt 20 Nm
Pressure Line From the power steering pump to the power steering gear; there are different versions with and without a separating point. Mounting on crossbrace, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) . Wiring connection installation location, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) . CAUTION: Insert the pressure line completely when installing.
Rubber Bushing 6 Nm
Nut 6 Nm
Union Nut 40 Nm Wiring connection installation location, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) . A pressure line without a separating point does not have a union nut.
Pressure Line From the power steering pump to the power steering gear. CAUTION: Insert the pressure line completely when installing. Mounting on crossbrace, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) . Wiring connection installation location, refer to «LINES AND HOSES OVERVIEW»(ref-522302-S00484814792013011400000) .
Nut 9 Nm
Bracket
Connector For the engine mount.
Bolt 20 Nm
Power Steering Pump Fill with hydraulic oil before installation. Checking delivery pressure, refer to «POWER STEERING PUMP, CHECKING DELIVERY PRESSURE»(ref-522302-S09432981902013011400000) . Removing and installing, refer to «POWER STEERING PUMP, VEHICLES WITHOUT DYNAMIC STEERING»(ref-522302-S03518884972013011400000) .
Bolt 20 Nm
Clamp Tension using hose clamp pliers V.A.G 1275. Always replace if removed.
Intake Hose Note location on reservoir. Refer to «HOSE LINES TO RESERVOIR, HYDRAULIC FLUID COOLER AND RETURN LINE INSTALLED POSITION»(ref-522302-S36717529812013011400000) . Note power steering pump location. Refer to «POWER STEERING PUMP, VEHICLES WITHOUT DYNAMIC STEERING»(ref-522302-S03518884972013011400000) .

Scheme 174

Scheme 174: LINES AND HOSES OVERVIEW

Reservoir bracket to body see scheme 33
Reservoir in bracket see scheme 34
Bolt in bracket see scheme 33
Hydraulic oil cooler to condenser see scheme 35
Power steering pump in the bracket, refer to «POWER STEERING PUMP, VEHICLES WITH DYNAMIC STEERING»(ref-522302-S04436216142013011400000) or «POWER STEERING PUMP, VEHICLES WITHOUT DYNAMIC STEERING»(ref-522302-S03518884972013011400000).
Pressurized line to crossbrace see scheme 36
Pressure line connection installation location see scheme 36
Pressurized line to the engine mount see scheme 37
Return line to the subframe see scheme 39
Return line bracket to the longitudinal member (Scheme 175)
