TEST DATA
| 3.0L TFSI Engine | ||
|---|---|---|
| Engine idle speed | Cannot be adjusted, it is regulated by idle stabilization | |
| Ignition timing | Not adjustable, regulated by the control module | |
| Ignition/Glow Plug System | Single coil ignition system with 6 ignition coils (output stages integrated) that are connected directly to the spark plugs via the ignition cables. | |
| Spark plugs | Names | |
| Tightening specifications | ||
| Ignition sequence | 1-4-3-6-2-5 | |
Scheme 12
Remove the front engine cover -1- upward.
Disconnect the connector -1-.
Scheme 13
Remove the bolt -arrow- and remove the Camshaft Position (CMP) sensor (cylinder bank 1).
Disconnect the connector -1-.
Scheme 14
Remove the bolt -arrow- and remove CMP sensor 2 (cylinder bank 2).
