3.0L - Lubrication - Engine Code(s): Ccba (Cabriolet): Overview Audi S5 I facelift

Lubrication System 3 illustrations ~354 words

OIL PAN UPPER AND LOWER SECTIONS, OIL PUMP AND OIL COOLER OVERVIEW

CAUTIONDanger of catalytic converter damage. The oil level must not exceed the "MAX" marking.

Note. Crankshaft Or Rod Bearing Damage Prevention: If large quantities of metal particles or abraded material are detected during engine repairs, it may mean the crankshaft or rod bearings are damaged. To prevent subsequent damage, the following work must be performed after the repair: Oil channels must be cleaned carefully; replace oil spray jets, engine oil cooler and oil filter. Oil injector jet for piston cooling (Scheme 39)

Scheme 39

Scheme 39
  1. Nut 9 Nm
  2. Oil Level Thermal Sensor -G266- Removing and installing, refer to «OIL LEVEL THERMAL SENSOR -G266»(ref-522376-S02683347142013011400000)
  3. Seal Replace
  4. Lower Oil Pan Removing and installing, refer to «LOWER OIL PAN»(ref-522376-S00128468592013011400000)
  5. Bolt Replace 3 Nm plus an additional 90° turn
  6. Lower Oil Baffle
  7. Bolt Replace Tightening specification and sequence see scheme 11
  8. Upper Oil Pan Removing and installing, refer to «UPPER OIL PAN»(ref-522376-S37096768332013011400000)
  9. Alignment Bushing Quantity: 2
  10. O-ring Insert into guide frame Replace
  11. Bolt 9 Nm Insert with locking compound.
  12. Upper Oil Baffle
  13. Gasket Insert into guide frame Replace
  14. Gasket Replace
  15. Bolt 9 Nm
  16. Engine Oil Cooler See note, refer to "Crankshaft Or Rod Bearing Damage Prevention" under: «OIL PAN UPPER AND LOWER SECTIONS, OIL PUMP AND OIL COOLER OVERVIEW»(ref-522376-S34939452522013011400000) Removing and installing, refer to «ENGINE OIL COOLER»(ref-522376-S16047001562013011400000) With oil cooler bypass valve
  17. Bolt 9 Nm
  18. Oil Pump Input Shaft
  19. Pressure Spring
  20. Sleeve Quantity: 2
  21. Bracket
  22. Bolt 9 Nm
  23. Chain Sprocket for Oil Pump Can only be placed onto driveshaft in one position
  24. Bolt 30 Nm plus an additional 90° turn Replace For loosening and tightening, counter hold on the chain sprocket with a spanner wrench 3212
  25. O-ring Replace
  26. Gasket Replace
  27. O-ring Replace
  28. Oil Pump Do not disassemble Removing and installing, refer to «OIL PUMP»(ref-522376-S37794936862013011400000)
  29. Bolt 20 Nm
  30. Bolt Replace Tightening specification and sequence (Scheme 41)
  31. Seal Replace
  32. Oil Drain Plug 30 Nm

Scheme 40

Scheme 40

Note. Replace any bolts that were tightened with an additional turn.

Tighten bolts in 2 stages as follows

StageTightening Specification/Additional Turn
1.3 Nm in a diagonal sequence
2.In a diagonal sequence, turn an additional 90°

Scheme 41

Scheme 41

Note. Replace any bolts that were tightened with an additional turn.

Tighten bolts in 2 stages as follows

StageBoltsTightening Specification/Additional Turn
1.1 through 68 Nm in a diagonal sequence
2.1 through 6In a diagonal sequence, turn an additional 90°
