Interior Equipment: Overview Audi Q7 4L facelift

Seats 8 illustrations ~1086 words

Scheme 1

Scheme 1: STORAGE COMPARTMENTS AND COVERS ASSEMBLY OVERVIEW
Scheme 1: STORAGE COMPARTMENTS AND COVERS ASSEMBLY OVERVIEW
  1. Center console Assembly Overview, refer to «CENTER CONSOLE ASSEMBLY OVERVIEW»(ref-491666-S16096455912012073100000) Removing and Installing, refer to «CENTER CONSOLE»(ref-491666-S34044617022012073100000)
  2. Driver side instrument panel covers Assembly Overview, refer to «INSTRUMENT PANEL COVERS ON DRIVER SIDE ASSEMBLY OVERVIEW»(ref-491666-S02774107562012073100000) Instrument Panel Cover, Removing and Installing, Lower, Driver Side, refer to «LOWER DRIVER SIDE INSTRUMENT PANEL COVER»(ref-491666-S08641294672012073100000) Instrument Panel cover, Removing and Installing, Upper, Driver Side, Removing and Installing, refer to «UPPER INSTRUMENT COVER, DRIVER SIDE KNEE BAR»(ref-491666-S08315381182012073100000)
  3. Instrument panel WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «RESTRAINT SYSTEM COMPONENTS, SAFETY PRECAUTIONS AND GENERAL INFORMATION»(ref-491782-S12339759152012073100000) . Assembly Overview, refer to «INSTRUMENT PANEL COMPONENTS OVERVIEW»(ref-491662-S25940761262012073100000) Removing and Installing, refer to «INSTRUMENT PANEL»(ref-491662-S38254864582012073100000)
  4. Instrument panel central tube Assembly Overview, refer to «INSTRUMENT PANEL CENTRAL TUBE OVERVIEW»(ref-491662-S00796807222012073100000) Removing and Installing, refer to «INSTRUMENT PANEL CENTRAL TUBE»(ref-491662-S18302611422012073100000)
  5. Glove compartment and front passenger side instrument panel cover Assembly Overview, refer to «PASSENGER SIDE GLOVE COMPARTMENT AND INSTRUMENT PANEL COVER ASSEMBLY OVERVIEW»(ref-491666-S21722254032012073100000) Removing and installing the glove compartment, refer to «GLOVE COMPARTMENT»(ref-491666-S20121688542012073100000) Passenger side instrument panel cover, removing and installing, refer to «PASSENGER SIDE INSTRUMENT PANEL COVER»(ref-491666-S21688598562012073100000)
  6. Front center armrest Assembly Overview, refer to «FRONT CENTER ARMREST ASSEMBLY OVERVIEW»(ref-491666-S03136076322012073100000) Removing and Installing, refer to «FRONT CENTER ARMREST»(ref-491666-S42947847572012073100000)

Scheme 2

Scheme 2: INSTRUMENT PANEL COVERS ON DRIVER SIDE ASSEMBLY OVERVIEW
Scheme 2: INSTRUMENT PANEL COVERS ON DRIVER SIDE ASSEMBLY OVERVIEW
  1. Left mount Driver side lower instrument panel cover
  2. Connector, 16-pin - T16- Diagnostic connector
  3. Right mount Driver side lower instrument panel cover Clipped into accelerator pedal module
  4. Bolt Tightening specification - 1.4 Nm
  5. Threaded clip Quantity: 2
  6. Upper instrument panel cover, driver side Iidentified as knee bar Removing and Installing, refer to «UPPER INSTRUMENT COVER, DRIVER SIDE KNEE BAR»(ref-491666-S08315381182012073100000)
  7. Clips Quantity: 2 Before installing the upper instrument panel cover on the driver side, the knee bars must be installed in the cut-outs in the instrument panel Note location «INSTALLATION POSITION»(ref-491666-S41796314932012080600000)
  8. Bolt Tightening specification - 1.4 Nm
  9. Footwell light Removing and Installing, refer to «INSTRUMENT PANEL LAMPS AND SWITCHES»(ref-491786-S26384647582012073100000)
  10. Driver side lower instrument panel cover Removing and Installing, refer to «LOWER DRIVER SIDE INSTRUMENT PANEL COVER»(ref-491666-S08641294672012073100000)

Scheme 3

Scheme 3: DRIVER SIDE KNEE BAR ASSEMBLY OVERVIEW
Scheme 3: DRIVER SIDE KNEE BAR ASSEMBLY OVERVIEW
  1. Bolt 10 Nm
  2. Left knee bar Removing and Installing, refer to «LEFT DRIVER SIDE KNEE BAR»(ref-491666-S24897887222012073100000)
  3. Central tube
  4. Bolt 10 Nm
  5. Bolt 10 Nm
  6. Right knee bar Removing and Installing, refer to «RIGHT DRIVER SIDE KNEE BAR»(ref-491666-S00269538332012073100000)
  7. Bolt 10 Nm
  8. Bolt 3 Nm
  9. Knee bar brace Removing and Installing, refer to «DRIVER SIDE KNEE BAR BRACE»(ref-491666-S10538584192012073100000)
  10. Bolt 3 Nm

Scheme 4

Scheme 4: PASSENGER SIDE GLOVE COMPARTMENT AND INSTRUMENT PANEL COVER ASSEMBLY OVERVIEW
Scheme 4: PASSENGER SIDE GLOVE COMPARTMENT AND INSTRUMENT PANEL COVER ASSEMBLY OVERVIEW
  1. Clips
  2. Cold air vent/cover plate
  3. Hinge pin
  4. Lid dampening mechanism With Glove compartment lamp switch -E26- Removing and Installing, refer to «GLOVE COMPARTMENT COVER BRAKE COMPONENT»(ref-491666-S41647723522012073100000)
  5. Rubber stop for instrument panel
  6. Glove compartment unlock motor -V327- Removing and Installing, refer to «GLOVE COMPARTMENT UNLOCK MOTOR V327»(ref-491666-S32390271472012073100000) Activate the glove compartment cover emergency release «GLOVE COMPARTMENT COVER EMERGENCY RELEASE, ACTIVATING»(ref-491666-S03083567192012073100000)
  7. Bolt Tightening specification - 1 Nm
  8. Cover For the glove compartment unlock motor -V327- With the control cable bracket for the glove compartment cover release Removing and Installing, refer to «GLOVE COMPARTMENT UNLOCK MOTOR V327»(ref-491666-S32390271472012073100000)
  9. Glove compartment cover release control cable Cannot be replaced separately; replacing, refer to «GLOVE COMPARTMENT LID»(ref-491666-S02757861082012073100000) Adjusting, refer to «GLOVE COMPARTMENT COVER CONTROL CABLE, ADJUSTING»(ref-491666-S12648074012012073100000)
  10. Glove compartment Removing and Installing, refer to «GLOVE COMPARTMENT»(ref-491666-S20121688542012073100000)
  11. Compensation disc For the glove compartment hinge
  12. Hinge pin For securing the glove compartment cover Removing and Installing, refer to «GLOVE COMPARTMENT LID»(ref-491666-S02757861082012073100000)
  13. Locking pin mount
  14. Rubber stop For the glove compartment cover
  15. Glove compartment cover Activate the glove compartment cover emergency release «GLOVE COMPARTMENT COVER EMERGENCY RELEASE, ACTIVATING»(ref-491666-S03083567192012073100000) Removing and Installing, refer to «GLOVE COMPARTMENT LID»(ref-491666-S02757861082012073100000)
  16. Bolt Tightening specification - 1.4 Nm
  17. Glove compartment light Removing and Installing, refer to «GLOVE COMPARTMENT LAMP»(ref-491786-S02842017482012073100000)
  18. Front Passenger Airbag -Off- Key Switch -E224- WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «RESTRAINT SYSTEM COMPONENTS, SAFETY PRECAUTIONS AND GENERAL INFORMATION»(ref-491782-S12339759152012073100000) .
  19. Passenger side instrument panel cover Removing and Installing, refer to «PASSENGER SIDE INSTRUMENT PANEL COVER»(ref-491666-S21688598562012073100000)
  20. Footwell light Removing and Installing, refer to «FRONT FOOTWELL LAMP»(ref-491786-S15457532922012073100000)

Scheme 5

Scheme 5: PASSENGER SIDE KNEE BAR ASSEMBLY OVERVIEW
Scheme 5: PASSENGER SIDE KNEE BAR ASSEMBLY OVERVIEW
  1. Left knee bar Removing and Installing, refer to «KNEE BAR, LEFT PASSENGER SIDE»(ref-491666-S32560752522012073100000)
  2. Bolt 10 Nm
  3. Central Tube
  4. Bolt 10 Nm
  5. Right knee bar Removing and Installing, refer to «RIGHT PASSENGER SIDE KNEE BAR»(ref-491666-S07366406892012073100000)
  6. Bolt 10 Nm
  7. Bolt 3 Nm
  8. Knee bar brace attach self-adhesive felt strips between A/C unit and knee bar brace Removing and Installing, refer to «PASSENGER SIDE KNEE BAR BRACE»(ref-491666-S12671961022012073100000)
  9. Bolt 10 Nm
  10. Bolt 3 Nm
  11. Bolt 10 Nm

MULTIBOX COMPONENTS ASSEMBLY OVERVIEW

Note. The components in the exploded view are shown on one side only, the opposite side is identical.

Scheme 6

Scheme 6: MULTIBOX COMPONENTS ASSEMBLY OVERVIEW
Scheme 6: MULTIBOX COMPONENTS ASSEMBLY OVERVIEW
  1. Center armrest, upholstery Removing and Installing, refer to «CENTER ARMREST UPHOLSTERY»(ref-491666-S06495260562012073100000)
  2. Center armrest frame multibox Cannot be replaced separately
  3. Trim Be careful when removing; the trim cannot be replaced separately
  4. Circlip
  5. Gas strut Removing and Installing, refer to «GAS-FILLED STRUT»(ref-491666-S36734465782012073100000)
  6. Circlip
  7. Bolts
  8. Trim support base 2 Removing and Installing, refer to «CENTER ARMREST SUPPORT BASE 1 AND 2 TRIM»(ref-491666-S00112395502012073100000)
  9. O-ring
  10. Bolts
  11. Trim support base 1 Removing and Installing, refer to «CENTER ARMREST SUPPORT BASE 1 AND 2 TRIM»(ref-491666-S00112395502012073100000)
  12. Multibox trim Cannot be replaced separately Removing and Installing, refer to «MULTIBOX»(ref-491666-S30915524822012073100000)
  13. Clip (quantity: 4)
  14. Mount multibox Cannot be replaced separately
  15. Screws (quantity 4) Tightening specification - 1.3 Nm
  16. Screws (quantity 4) Tightening specification - 1.3 Nm
  17. Screws (quantity 6) Tightening specification - 1.5 Nm
  18. Cupholder liner Removing and Installing, refer to «CUPHOLDER LINER»(ref-491666-S12542237842012073100000)
  19. Cupholder cover trim Removing and Installing, refer to «CUPHOLDER COVER TRIM»(ref-491666-S09109894592012073100000)
  20. Cup holder Removing and Installing, refer to «CUPHOLDER»(ref-491666-S15943946942012073100000)
  21. Cupholder lining mat The lining mat can be removed when the multibox and cupholder are installed.
  22. Bolt Tightening specification - 1.3 Nm
  23. Washer
  24. Lever
  25. Button
  26. Release cable Removing and Installing, refer to «RELEASE»(ref-491666-S21624864492012073100000) Adjusting, refer to «CABLE, ADJUSTING»(ref-491666-S19407039982012073100000)
  27. Spring
  28. Nut (quantity 2) Tightening specification - 2 Nm
  29. Cable tie (quantity 2)
  30. Screw (quantity 4) Tightening specification - 1.1 Nm
  31. Center armrest trim Removing and Installing, refer to «CENTER ARMREST TRIM»(ref-491666-S04094289252012073100000)

INTERIOR REARVIEW MIRROR, GENERAL INFORMATION

There are different versions of the interior rearview mirrors, each with different features

  1. Manual dimming interior rearview mirror
  2. Automatic dimming interior rearview mirror -Y7
  3. Interior rearview mirror with digital compass
  4. Interior rearview mirror with rain/light recognition sensor -G397
  5. Interior rearview mirror with humidity sensor -G355

Scheme 7

Scheme 7: INTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW
Scheme 7: INTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW
  1. Interior Rearview Mirror
  2. Retaining spring
  3. Rain/Light Recognition Sensor -G397- Removing and Installing, refer to «Removal and Installation»(ref-491819-S37855788622012073100000)
  4. Upper cover
  5. Retaining plate Bonded to the windshield
  6. Upper cover
  7. Electric wire
  8. Lower cover

Scheme 8

Scheme 8: INTERIOR REARVIEW MIRROR WITH LANE ASSIST ASSEMBLY OVERVIEW
Scheme 8: INTERIOR REARVIEW MIRROR WITH LANE ASSIST ASSEMBLY OVERVIEW
  1. Interior Rearview Mirror
  2. Retaining spring
  3. Rain/Light Recognition Sensor -G397- Removing and Installing, refer to «Removal and Installation»(ref-491819-S37855788622012073100000)
  4. Upper cover
  5. Retaining plate Bonded to the windshield
  6. Electric wire
  7. Upper cover
  8. Lower cover
