FASTENER TIGHTENING SPECIFICATIONS
| Component | Fastener Size | Nm |
|---|---|---|
| Bolts and Nuts | ||
| M6 | 9 | |
| M7 | 15 | |
| M8 | 20 | |
| M10 | 40 | |
| M12 | 65 | |
| Engine Carrier 1 | 120 + 180° | |
| Engine Mount, Left | 60 | |
| Engine Mount, Right | 50 | |
| Left Engine Support | ||
| Bolt | 50 | |
| Nut | 75 | |
| Right Engine Support | ||
| Bolt | 40 | |
| Nut | 75 | |
| 1 Replace | ||
Ground Connection on the Right Longitudinal Member
Scheme 53
Tighten the nut -2- to 15 Nm.
Engine to Transmission
Scheme 54
| Item | Bolt 1) | Nm |
|---|---|---|
| 1 | M10 x 95 | 15 +90° |
| 2 ••• 5 | M12x75 | 30 +90° |
| 6, 7 | M12x140 | 30 +90° |
| 8, 9, 10 | M10x60 | 15 +90° |
| 11 | M10x45 | 15 +90° |
| A | Alignment sleeves for centering | |
| 1) Aluminum bolts may be used two times ENGINE, INSTALLING => The aluminum bolts -1 through 11- may be used two times. Therefore, the bolts must be marked with two notches "X" made by a chisel after they have been used the first time -arrow-. . | ||
