FASTENER TIGHTENING SPECIFICATIONS
| Component | Bolt Size | Nm |
|---|---|---|
| Bolts and Nuts | ||
| M6 | 9 | |
| M7 | 15 | |
| M8 | 20 | |
| M10 | 40 | |
| M12 | 65 | |
| Bracket for the Electrical Connector | ||
| Nut | 23 | |
| Double Bolt 1 | 50 + 90° | |
| Engine Carrier 1 | 120 + 180° | |
| Engine Mount, Left | 60 | |
| Engine Mount, Right | 60 | |
| Ground Strap | 15 | |
| Left Engine Support, Nut | 75 | |
| Right Engine Support | ||
| Nut | 75 | |
| Bolt 1 | 50 + 90° | |
| 1 Always replace | ||
Battery Jump Start Terminal -U6- Pins
Tighten the bolt -1- for the battery jump start terminal to 15 Nm.
Scheme 312
Ground Connection in the Right of the Plenum Chamber
Tighten the nut -2- to 9 Nm.
Scheme 313
Ground Connection on the right Longitudinal Member
Scheme 314
Tighten the nut -1- to 15 Nm.
Engine to Automatic Transmission 09D
Scheme 315
| Item | Bolt | Nm |
|---|---|---|
| 1, 2 | M10x70 | 45 |
| 3, 4, 5, 7 | M12 x 80 | 80 |
| 6 | M12x70 | 80 |
| 8, 9, 10 | M10x70 | 45 |
| A | Alignment sleeves for centering | |
Engine and 8-Speed Automatic Transmission 0C8
Scheme 316
| Item | Bolt | Nm |
|---|---|---|
| 1 | M10x70 | 65 |
| 2 | M10x90 | 65 |
| 3, 4, 5, 7 | M12 x 80 | 80 |
| 6 | M12x70 | 80 |
| 8, 9, 10 | M10x70 | 45 |
| A | Alignment sleeves for centering | |
