Communication: Wiring Audi Q7 4L facelift

Communication Devices 15 illustrations ~722 words

WIRING HARNESS, REMOVING

The replacement wiring harness is routed according to the current wiring harness.

Remove rear lid trim. Refer to Removal and Installation .

Remove the spoiler. Refer to Removal and Installation .

Remove the headliner. Refer to Removal and Installation .

To make process easier, create photos or sketches of wiring harness routing.

Especially observe the specified fasteners.

Disconnect windshield washer system hose connection -1-.

Scheme 10

Scheme 10: WIRING HARNESS, REMOVING
CAUTIONWasher fluid hose may still be filled with fluid. Have a container nearby.

Unclip wiring harness -2- from retainers -arrows-.

Continue unclip wiring harness -2- accordingly on rear lid -arrows-.

Scheme 11

Scheme 11

Loosen seal to spoiler -1-.

Disconnect the connectors -1- from the Antenna Amplifier 2 -R111- and thread wires with seal -2- inward.

Scheme 12

Scheme 12

Disconnect the connectors -2- and -3- on Antenna Amplifier 3 -R112- -item 4- unclip wiring harness -1-.

Scheme 13

Scheme 13

Unclip the wiring harness -1- at attachment points -arrows- as far as tab on Motor in rear lid control module 2 -V376- -item 2-.

Scheme 14

Scheme 14

Disconnect the wiring harness -1- after tab on branch -arrow-.

Scheme 15

Scheme 15
CAUTIONWasher fluid hose may still be filled with fluid. Have a container nearby.

Installing the replacement wiring harness, refer to WIRING HARNESS, INSTALLING .

WIRING HARNESS, INSTALLING

The replacement wiring harness is routed the same way as the current/faulty wiring harness.

Use the Original attaching points in the rear lid and on the roof up to the C-pillar.

Start at the rear lid.

Attach the hose connection -1- to the connection on the rear window wiper.

Install the cable bracket -arrows-.

Route wiring harness through opening -1- to spoiler.

Install the seal -2- and connect the antenna connector -1-.

Connect the antenna connectors -2- and -3- to Antenna Amplifier 3 -R112- -4- and attach the cable bracket -1-.

Continue installing wiring harness -1- on roof frame -arrows-.

Scheme 16

Scheme 16

Route the wiring harness -1- from area -2- (cloth clover) parallel to existing wiring harness.

Use cable ties if necessary.

Continue routing wiring harness in direction of D-pillar and C-pillar -arrows-.

Scheme 17

Scheme 17

The wiring harness separates at D-pillar: -1- and -4-.

Part -1- leads to the Antenna Amplifier -R24- and part -2- leads to the TV tuner -R78-.

Remove screws -2- and -3- on side curtain airbag and route wiring harness -4- between side curtain airbag and D-pillar along existing wiring harness.

Use cable ties if necessary.

Remove both screws -2- and -3- (4 Nm).

Route wiring harness -1- along existing one on right side window -arrows-.

Use the cable ties.

Scheme 18

Scheme 18

Tighten the ground wire 2 (9 Nm).

The antenna wire (brown connector) leads to TV Tuner -R78-.

The washer fluid line on wiring harness between Digital Sound System Control Module -J525- and side wall leads to wheel housing.

Route antenna wire to TV Tuner -R78-.

Disconnect the brown connector -2- from the TV tuner -R78- -1- and connect the new brown connector -3-.

Scheme 19

Scheme 19

Disconnect removed brown connector -2- from antenna wire and secure this to existing wiring harness.

Route wiring harness -1- at top of right side window and to C-pillar -arrows-.

Use the cable ties.

Scheme 20

Scheme 20

Tighten the ground wire -2- (9 Nm).

Disconnect the antenna connectors -1- (brown) and -2- (blue) from the Antenna Amplifier -R24- and from the current wiring harness -arrow-.

Scheme 21

Scheme 21

Connect the brown and blue antenna connectors from the new wiring harness to the Antenna Amplifier -R24-.

Install the windshield washer fluid hose.

Remove the Digital Sound System Control Module -J525-. Refer to DIGITAL SOUND SYSTEM CONTROL MODULE -J525-, BOSE .

Route washer fluid line -2- on existing wiring harness -1- behind Digital Sound System Control Module -J525- -arrow- to wheel housing.

Scheme 22

Scheme 22

Existing wiring harness is not covered on wheel housing. The connection to the existing washer fluid hose is made there.

Raise existing washer fluid hose -1- slightly out of wiring harness and guide new hose -2- parallel to it.

Scheme 23

Scheme 23

Disconnect both at the specified location.

CAUTIONWasher fluid hose may still be filled with fluid. Have a container nearby.

Water Tight Windshield Washer Fluid Hose Connection

Connect the ends of each windshield washer fluid hose -1- and -4- using connection 1J0.955.875.R -2- and connection 1J0.955.875. -3-.

Scheme 24

Scheme 24

Slide heat shrink sleeve -5- over a hose and connect adapters.

Slide heat shrink sleeve over connection and create a thick connection with Hot Air Gun, 220 V/ 50 Hz VAS 1978/14 from the Wiring Harness Repair Set VAS 1978A

Install washer fluid hose in wiring harness.

Perform a function test.
