Communication: Overview Audi Q7 4L facelift

Communication Devices 8 illustrations ~1144 words

MICROPHONE UNIT IN FRONT ROOF MODULE R164, THROUGH 29 MAY 2009, OVERVIEW

The microphone unit in front roof module is installed in the Front Interior Light -W1-. Depending on the equipment, there are up to three microphones installed.

For this, one microphone is connected directly to Telephone Transceiver -R36-. The other microphones are connected to the Digital Sound System Control Module -J525-.

Scheme 1

Scheme 1: MICROPHONE UNIT IN FRONT ROOF MODULE R164, THROUGH 29 MAY 2009, OVERVIEW
  1. Microphone (blue) for the Telephone Transceiver -R36
  2. Radar Interior Monitoring Control Module 1 -G303
  3. Microphone (black) for the Digital Sound System Control Module -J525
  4. Microphone (black) to Digital Sound System Control Module -J525
  5. Blue 6-pin multi-pin connector (T6x)

Scheme 2

Scheme 2

1 - Microphone (black)

2 - Blue 6-pin connector (T6x), pin 1-2: Microphone (black), pin 3-4: Microphone (black), pin 5-6: Microphone (blue)

3 - Microphone (black)

4 - Microphone (blue)

Microphone Unit in front roof module, removing and installing, refer to MICROPHONE UNIT IN FRONT ROOF MODULE R164 .

MICROPHONE UNIT IN FRONT ROOF MODULE R164, FROM 1 JUNE 2009, OVERVIEW

  1. Microphone (blue) to the Information Electronics Control Module 1 -J794
  2. Radar Interior Monitoring Control Module 1 -G303
  3. Microphone (black) to the Information Electronics Control Module 1 -J794
  4. Inside microphone -R74- (black) to the Digital Sound System Control Module -J525- (from BOSE)
  5. Blue 6-pin multi-pin connector (T6x)

1 - Left front microphone -R140- (black)

2 - Blue 6-pin connector (T6x), pin 1-2: Left front microphone -R140- (black), Pins 3 and 4: Inside microphone -R74- (black), pins 5 and 6:front right microphone -R141- (blue)

3 - Inside Microphone -R74- (black)

4 - Right front microphone -R141- (blue)

Microphone Unit in front roof module, removing and installing, refer to MICROPHONE UNIT IN FRONT ROOF MODULE R164 .

Scheme 3

Scheme 3: MULTIFUNCTION STEERING WHEEL, OVERVIEW
  1. Multifunction Steering Wheel Multifunction Steering Wheel Control Module -J453- under right button. Removing and installing multifunction buttons, refer to «MULTIFUNCTION BUTTONS»(ref-491792-S19295325952012073100000) . Removing and installing Tiptronic switch, refer to «TIPTRONIC SWITCH»(ref-491792-S16257256572012073100000) .
  2. Steering Column Electronic Systems Control Module -J527- On steering column at steering column switches. Removing and installing, refer to «[For engine(s) CATA, BHK, CJWC, CJWB, BAR] Removal and Installation»(ref-491789-S27438983732012073100000) .
  3. Data Bus OBD interface -J533- Behind instrument panel cover, drivers side.
  4. Media Player, Position 1 -R118- In the top of the center console.
  5. Radio Optional with Speech Input Control Module -J507- (through 29 May 2009). Behind the luggage compartment right side trim.
  6. Front Information Display Control Head Control Module -J523- (Through 29 May 2009) Behind glove compartment. - Information Electronics Control Module 1 -J794- (From 1 June 2009) In the top of the center console.
  7. Telephone Transceiver -R36- (Through 29 May 2009) Under the right front seat.
  8. Digital Sound System Control Module -J525- Behind the luggage compartment right side trim.
  9. Sound Systems
  10. Microphone Unit In Front Roof Module -R164- Overview (through 29 May 2009), refer to «MICROPHONE UNIT IN FRONT ROOF MODULE R164, THROUGH 29 MAY 2009, OVERVIEW»(ref-491792-S04092419112012073100000) . Overview (from 1 June 2009), refer to «MICROPHONE UNIT IN FRONT ROOF MODULE R164, FROM 1 JUNE 2009, OVERVIEW»(ref-491792-S23971197862012073100000) .
  11. Navigation System With CD Drive Control Module -J401- (Through 29 May 2009) in the luggage compartment beneath the flap on the right.
  12. TV Tuner -R78- Behind the luggage compartment right side trim.
  13. CAN bus (comfort)

Scheme 4

Scheme 4: MMI NAVIGATION, BASIC PLUS PREPARATION, THROUGH 29 MAY 2009
  1. Instrument Cluster Control Module -J285- In The Instrument Panel
  2. Steering Column Electronic Systems Control Module -J527- On Steering Column At Steering Column Switches
  3. Multifunction Steering Wheel
  4. Front Information Display Control Head -J685- In Center Of The Instrument Panel
  5. Multimedia System Control Head -E380- In Center Console
  6. Radio, Telephone, Navigation System Antenna -R52- Roof Antenna
  7. Window Antenna
  8. Antenna Amplifier -R24- Behind Right C-Pillar Trim
  9. Navigation System With CD Drive Control Module -J401- Contains Front Information Display Control Head Control Module -J523- /Radio -R- Under Center Armrest.
  10. Data Bus On Board Diagnostic Interface -J533- Behind Instrument Panel Cover On Drivers Side
  11. Digital Sound System Control Module -J525- Behind The Luggage Compartment Right Luggage Compartment Side Trim Panel
  12. Sound Systems
  13. Microphone Unit In Front Roof Module -R164- In Front Interior Light -W1

Scheme 5

Scheme 5: MMI NAVIGATION MINIMAL EQUIPMENT, FROM 1 JUNE 2009
  1. Radio, Telephone, Navigation System Antenna -R52- Roof Antenna
  2. Front Information Display Control Head -J685- In Center Of The Instrument Panel
  3. Information Electronics Control Module 1 -J794- In The Top Of The Center Console
  4. Multimedia System Control Head -E380- In Center Console
  5. Data Bus On Board Diagnostic Interface -J533- Behind Instrument Panel Cover On Drivers Side
  6. MOST Bus
  7. Radio Inside The Luggage Compartment Under The Right Flap
  8. Digital Sound System Control Module -J525- Behind The Luggage Compartment Right Luggage Compartment Side Trim Panel
  9. CD Changer -R41- Under The Center Armrest
  10. External Audio Source Connection -R199- (Interface) In The Glove Compartment

Scheme 6

Scheme 6: MMI NAVIGATION, THROUGH 29 MAY 2009
  1. Front Information Display Control Head -J685- In Center Of The Instrument Panel
  2. Front Information Display Control Head Control Module -J523- Behind Glove Compartment
  3. Multimedia System Control Head -E380- In Center Console
  4. Data Bus On Board Diagnostic Interface -J533- Behind Instrument Panel Cover On Driver's Side
  5. Instrument Cluster Control Module -J285- In The Instrument Panel
  6. Steering Column Electronic Systems Control Module -J527- On Steering Column At Steering Column Switches
  7. Multifunction Steering Wheel
  8. Radio with Speech Input Control Module -J507- Behind Right Luggage Compartment Side Trim
  9. Navigation System With CD Drive Control Module -J401- Located In Luggage Compartment Beneath The Flap (Right)
  10. Radio, Telephone, Navigation System Antenna -R52- Roof Antenna
  11. Digital Sound System Control Module -J525- Behind The Luggage Compartment Right Luggage Compartment Side Trim Panel
  12. Sound Systems

Scheme 7

Scheme 7: MMI NAVIGATION, MAXIMUM EQUIPMENT, FROM 1 JUNE 2009
  1. Radio, Telephone, Navigation System Antenna -R52- Roof Antenna
  2. Front Information Display Control Head -J685- In Center Of The Instrument Panel
  3. Information Electronics Control Module 1 -J794- In The Top Of The Center Console
  4. Multimedia System Control Head -E380- In Center Console
  5. Data Bus On Board Diagnostic Interface -J533- Behind Instrument Panel Cover On Driver's Side
  6. Steering Column Electronic Systems Control Module -J527- On Steering Column At Steering Column Switches
  7. Multifunction Steering Wheel
  8. Instrument Cluster Control Module -J285- In The Instrument Panel
  9. Digital Sound System Control Module -J525- Behind The Luggage Compartment Right Luggage Compartment Side Trim Panel
  10. Radio -R- Inside The Luggage Compartment Under The Right Flap
  11. Microphone Unit (In Front Roof Module) -R164- (Right Front Microphone -R141-) Inside The Front Interior Light -W1

Scheme 8

Scheme 8: MMI NAVIGATION SYSTEM CONNECTORS, THROUGH 29 MAY 2009

A - GPS connection (blue) from Radio, Telephone, Navigation System Antenna -R52

B - Black 8-pin connector (T8n)

C - MOST bus

Note. Unlisted connector terminals are not used.

1 - Terminal 31

2 - Terminal 30

5 - Ring-break diagnostic cable

1 - Input

2 - Output

GENERAL INFORMATION

The antenna wires from Antenna Amplifier 2 -R111- (spoiler) and Antenna Amplifier 3 -R112- (right rear window) to Antenna Amplifier -R24- /TV Tuner -R78- are integrated into wiring harness to rear lid.

Tab on Motor In Rear Lid Control Module 2 -V376- consists of wiring harness for antenna wires and rear window wiper system corrugated tube.

The wiring harness must be replaced if one antenna wire/tube is faulty.

It is not possible to replace individual antenna wires.
