LOWER BACKREST FAN
Removing
Scheme 250
Remove backrest cover panel. Refer to BACKREST COVER .
Adjust the lumbar support to the highest curve while moving the slider -1- all the way down -arrow A-.
Note. Ignore -2-.
Disconnect the connector -1-.
Scheme 251
Carefully tilt the backrest fan -2- out of the backrest upholstery -arrow-.
Installation
Scheme 252
Install in reverse order of removal. Note the following
- The mounting eyelets on the fan housing -1- face up and down.
- Place electrical wire -2- in the gap in the backrest cushion -arrow-.
