DVD PLAYER RETAINING PLATE
Removing
Scheme 195
Remove front backrest cover and upholstery. Refer to BACKREST COVER AND UPHOLSTERY .
Remove the bolts -2-.
Remove the retaining plate -3- for the screen console.
Remove the nut -2-.
Scheme 196
Guide socket -4- and washer -3- out of mount -1-.
Installation
Installation is reverse of removal, noting the following
Pull washer -3- up and slide socket -4- from the side into mount -1-.
- The socket must fit in the center of the mount.
Hold the socket in this position and tighten the nut.
Install the retaining plate hooks into the backrest frame -1- -arrows-.
Tighten the bolts.
Tightening Specifications
| Component | Nm |
|---|---|
| Socket to mount | 0.4 |
| Retaining plate to backrest frame | 6 |
