DRIVER SEAT CONSOLE
Removing
| WARNING | Follow all safety precautions when working on pyrotechnic components. Refer to RESTRAINT SYSTEM COMPONENTS, SAFETY PRECAUTIONS AND GENERAL INFORMATION . |
Remove the front seat.
- Mechanically adjustable seat, refer to «DRIVER SEAT ASSEMBLY OVERVIEW»(/audi/q7/4l-2009-2015/remont/seats/#seat-frames__driver-seat-assembly-overview)
- Memory seat, Power seat and Comfort seat, refer to «DRIVER SEAT ASSEMBLY OVERVIEW»(/audi/q7/4l-2009-2015/remont/seats/#seat-frames) .
Remove front console trim. Refer to FRONT CONSOLE TRIM, DRIVER SEAT .
Remove left console trim. Refer to LEFT CONSOLE TRIM, DRIVER SEAT .
Remove the bolts -1-.
Scheme 170
Remove console -2-.
Installation
| WARNING | Follow all safety precautions when working on pyrotechnic components. Refer to RESTRAINT SYSTEM COMPONENTS, SAFETY PRECAUTIONS AND GENERAL INFORMATION . |
Install in reverse order of removal. Note the following
Note. The screws are microencapsulated and must be replaced after each loosening. Before installing the new screws, the threads of the corresponding nuts must be cleaned.
Position console -2-.
Attach screws -1- in sequence -A-, -B-, -C- and -D-.
Tighten screws -1- in sequence -A-, -B-, -C- and -D- to the specification. Refer to DRIVER SEAT BRACKET ASSEMBLY OVERVIEW .
