Interior Trim Audi Q5 I

FRONT DOOR TRIM OVERVIEW

Note. The illustration shows the driver side door trim.

Scheme 1

1. Bolt 2.5 Nm For door trim.
2. Entry Lamp Special equipment Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
3. Active Or Passive Rear Reflector Special equipment
4. Passenger Compartment Monitoring Switch -E183- /Alarm System -Off- Switch -E217- Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
5. Door Trim Removing and installing, refer to «FRONT DOOR TRIM PANEL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__front-door-trim-panel) .
6. Trim Panel Removing and installing, refer to «TRIM MOLDING»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__trim-molding) .
7. Bolt 1.2 Nm For armrest Quantity: 8
8. Clips For trim panel Quantity: 3 Press into the door trim.
9. Retaining Clip With seal For door trim Quantity: 8 WARNING: For proper crash sensor (pressure sensor) function, ensure door does not leak. The door trim clips seal the system closed. Replace the clips if necessary.
10. Bolt 1.2 Nm For pull handle Quantity: 6
11. Sleeve Driver door only For the central locking -SAFE- indicator lamp -K133-. Central locking -SAFE- indicator lamp -K133-, removing and Installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
12. Window Frame
13. Trim For the window frame. Removing and installing, refer to «WINDOW FRAME TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__window-frame-trim) .
14. Bolt 1.2 Nm For inside door release mechanism. Quantity: 4
15. Lane Change Assistance Button -E530- Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
16. Treble Speaker Removing and installing, refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/communication-devices/#communication) .
17. Speaker Trim For high range speaker. Removing and installing, refer to «TREBLE SPEAKER TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__treble-speaker-trim) .
18. Interior Door Mechanism Removing and installing, refer to «INSIDE DOOR RELEASE MECHANISM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__inside-door-release-mechanism) .
19. Interior Locking Button Driver side: driver interior locking button -E308-. Front passenger side: front passenger interior locking button -E309-. Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
20. Bolt 2.5 Nm For door trim Quantity: 2
21. Switch Trim For driver seat memory program control head -E97-. Removing and installing, refer to «DRIVER MEMORY SEAT CONTROL HEAD E97»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__driver-memory-seat-control-head-e97) .
22. Driver Seat Memory Program Control Head -E97- Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
23. Trim Driver door only. For rear lid remote unlock switch -E188-. Removing and installing, refer to «REAR LID REMOTE UNLOCK SWITCH TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__rear-lid-remote-unlock-switch-trim) .
24. Rear Lid Remote Unlock Switch -E188- Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
25. Bolt 1 Nm
26. Speaker Trim For mid range speaker. Special equipment Removing and installing, refer to «MID-RANGE SPEAKER TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__mid-range-speaker-trim) .
27. Pull Handle With switch mount. Removing and installing, refer to «FRONT PULL HANDLE WITH SWITCH MOUNT»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__front-pull-handle-with-switch-mount) .
28. Symbol Trim
29. Mirror Adjustment Switch -E43- Driver door only. Vehicles equipped with: folding mirror adjustment switch -E168-. Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
30. Window Regulator Switch Driver side: power window control head in driver door -E512-. Front passenger side: front passenger door window regulator switch -E107-. Removing and installing, refer «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
31. Armrest Removing and installing, refer to «FRONT ARMREST»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__front-armrest) .
32. Bolt 2.5 Nm For door trim.

Scheme 2

1. Clip for the pull handle
2. Bolt - 2.5 Nm

Scheme 3

1. Center Console Overview, refer to «CENTER CONSOLE OVERVIEW»(/audi/q5/i-2008-2012/remont/seats/#interior-equipment) . Removing and installing, refer to «CENTER CONSOLE»(/audi/q5/i-2008-2012/remont/seats/#interior-equipment) .
2. Driver Side Instrument Panel Cover Overview, refer to «DRIVER SIDE INSTRUMENT PANEL COVER OVERVIEW»(/audi/q5/i-2008-2012/remont/seats/#interior-equipment) . Removing and installing, refer to «DRIVER SIDE INSTRUMENT PANEL COVER»(/audi/q5/i-2008-2012/remont/seats/#interior-equipment__driver-side-instrument-panel-cover) .
3. Trim For steering column switch module. Overview, refer to «STEERING COLUMN SWITCH MODULE TRIM OVERVIEW»(/audi/q5/i-2008-2012/remont/seats/#interior-equipment) . Upper trim, removing and installing, refer to «STEERING COLUMN SWITCH MODULE UPPER TRIM PANEL»(/audi/q5/i-2008-2012/remont/seats/#interior-equipment__steering-column-switch-module-upper-trim) . Lower trim, removing and installing, refer to «STEERING COLUMN SWITCH MODULE LOWER TRIM PANEL»(/audi/q5/i-2008-2012/remont/seats/#interior-equipment__steering-column-switch-module-lower-trim) .
4. Central Tube For instrument panel. Overview, refer to «INSTRUMENT PANEL CENTRAL TUBE OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «INSTRUMENT PANEL CENTRAL TUBE»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) .
5. Instrument Panel WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «GENERAL INFORMATION»(/audi/q5/i-2008-2012/remont/airbag/#passenger-protection-airbags-seat-belts) . Overview, refer to «INSTRUMENT PANEL COMPONENTS OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «INSTRUMENT PANEL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) .
6. Glove Compartment Overview, refer to «GLOVE COMPARTMENT OVERVIEW»(/audi/q5/i-2008-2012/remont/seats/#interior-equipment) . Removing and installing, refer to «GLOVE COMPARTMENT»(/audi/q5/i-2008-2012/remont/seats/#interior-equipment__glove-compartment) .
7. Front Center Armrest Special equipment Component overview, refer to «FRONT CENTER ARMREST OVERVIEW»(/audi/q5/i-2008-2012/remont/seats/#interior-equipment) . Removing and installing, refer to «FRONT CENTER ARMREST»(/audi/q5/i-2008-2012/remont/seats/#interior-equipment) .

Scheme 4

1. Side Instrument Panel Vent Removing and installing, refer to «SIDE INSTRUMENT PANEL VENT»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__side-instrument-panel-vent) .
2. Bolt 3 Nm Quantity: 2
3. Bolt 3 Nm Quantity: 2
4. Mid-Range Speaker Special equipment Removing and installing, refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/communication-devices/#communication) .
5. Side Speaker Trim Special equipment Removing and installing, refer to «SIDE SPEAKER TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__side-speaker-trim) .
6. Bolt 1.5 Nm Quantity: 6
7. Sunlight Photo Sensor -G107- Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/automatic-hvac-system/#air-conditioning-as-of-052012-2-of-2) .
8. Center Speaker Trim Special equipment Removing and installing, refer to «CENTER SPEAKER TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__center-speaker-trim) .
9. Upper Center Defroster Vent Removing and installing, refer to «TOP CENTER DEFROSTER VENT»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__top-center-defroster-vent) .
10. Mid-Range Speaker Special equipment Removing and installing, refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/communication-devices/#communication) .
11. Upper Side Defroster Vent
12. Instrument Panel WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «GENERAL INFORMATION»(/audi/q5/i-2008-2012/remont/airbag/#passenger-protection-airbags-seat-belts) . Follow the allocation of the airbag to the instrument panel. Removing and installing, refer to «INSTRUMENT PANEL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) .
13. Bolt 3 Nm Quantity: 2
14. Passenger Airbag WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «GENERAL INFORMATION»(/audi/q5/i-2008-2012/remont/airbag/#passenger-protection-airbags-seat-belts) . Follow the allocation of the airbag to the instrument panel. Overview, refer to «PASSENGER AIRBAG OVERVIEW»(/audi/q5/i-2008-2012/remont/airbag/#passenger-protection-airbags-seat-belts) . Locking and activating possible with key switch. Removing and installing, refer to «FRONT PASSENGER AIRBAG IGNITER 1 AND 2 N131/N132»(/audi/q5/i-2008-2012/remont/airbag/#passenger-protection-airbags-seat-belts__front-passenger-airbag-igniter-1-and) .
15. Trim Panel For instrument panel. Removing and installing, refer to «INSTRUMENT PANEL TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__instrument-panel-trim) .
16. MMI Screen Removing and installing, refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/communication-devices/#communication) .
17. Cover For MMI screen Removing and installing, refer to «MMI SCREEN»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__mmi-screen) .
18. Center Instrument Panel Vent Removing and installing, refer to «CENTER INSTRUMENT PANEL VENT»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__center-instrument-panel-vent) .
19. Access/Start Authorization Switch -E415- Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/exterior-lights/#exterior-lights-switches) . Trim, removing and installing, refer to «SWITCH FOR ACCESS/START AUTHORIZATION, TRIM PANEL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__switch-for-accessstart-authorization-trim-panel) .
20. Radio/Navigation System Special equipment Removing and installing, refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/communication-devices/#communication) .
21. Front Information Display Control Head Module -J523- Removing and installing, refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/communication-devices/#communication) .
22. Climatronic Control Module -J255- Special equipment Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/automatic-hvac-system/#air-conditioning-as-of-052012-1-of-2) .
23. Bolt 3 Nm Quantity: 4
24. Installation Frame For the radio/navigation system. Special equipment Removing and installing, refer to «RADIO AND NAVIGATION SYSTEM FRAME»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__radio-and-navigation-system-frame) .
25. Bolt 3 Nm
26. Bolt 3 Nm Quantity: 2
27. Instrument Cluster Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/gauges-instrument-panels/#instruments) .
28. Bolt 3 Nm Quantity: 2

Scheme 5

1. Bracket Removing and installing, refer to «MOUNTING BRACKET»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__mounting-bracket) .
2. Bolt 20 Nm Quantity: 4
3. Bolt 3.6 Nm
4. Bolt 20 Nm
5. Central Tube For instrument panel. Removing and installing, refer to «INSTRUMENT PANEL CENTRAL TUBE»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) .
6. Threaded Pin 20 Nm Quantity: 2
7. Nut 20 Nm Quantity: 2 Always replace if removed.
8. Bracket For the air intake chamber.
9. Bolt 9 Nm Quantity: 2
10. Bracket For the glove compartment. Removing and installing, refer to «GLOVE COMPARTMENT BRACKET»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__glove-compartment-bracket) .
11. Bolt 9 Nm Quantity: 2
12. Bolt 3.6 Nm Quantity: 2
13. Bolt 9 Nm Quantity: 2
14. Bracket For the glove compartment.
15. Bolt 20 Nm Quantity: 4
16. Bolt 9 Nm Quantity: 2
17. Bracket For the instrument panel cover.
18. Bolt 20 Nm Quantity: 2
19. Bolt 20 Nm

Scheme 6

1. Central Tube
2. Bolt 9 Nm
3. Right Retainer For the glove compartment. Versions for specific countries. Removing and installing, refer to «GLOVE COMPARTMENT RETAINERS»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__glove-compartment-retainers) .
4. Bolt 9 Nm
5. Left Retainer For the glove compartment. Equipment level Removing and installing, refer to «GLOVE COMPARTMENT RETAINERS»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__glove-compartment-retainers) .
6. Bolt 9 Nm Quantity: 2
7. Grommet Mounted on the impact absorber -item 9-.
8. Bolt Tightening specification. Refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/manual-power-steering/#steering) .
9. Right Shock Absorber Versions for specific countries. Removing and installing, refer to «RIGHT IMPACT ABSORBER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__right-impact-absorber) .
10. Bolt 9 Nm
11. Bolt 9 Nm
12. Left Shock Absorber Versions for specific countries. Removing and installing, refer to «LEFT IMPACT ABSORBER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__left-impact-absorber) .
13. Bolt 9 Nm Quantity: 2

Scheme 7

1. Rear Sill Panel Trim Overview, refer to «REAR SILL PANEL TRIM ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «REAR SILL PANEL TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__rear-sill-panel-trim) .
2. Lower B-pillar Trim Overview, refer to «B-PILLAR TRIM OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «LOWER B-PILLAR TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__lower-b-pillar-trim) .
3. Upper B-pillar trim Overview, refer to «B-PILLAR TRIM OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «UPPER B-PILLAR TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__upper-b-pillar-trim) .
4. Upper A-pillar trim Overview, refer to «UPPER A-PILLAR TRIM OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «A-PILLAR UPPER TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__a-pillar-upper-trim) .
5. A-pillar Gap Cover Overview, refer to «FRONT SILL PANEL STRIP ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__front-sill-panel-strip-assembly-overview) . Removing and installing, refer to «A-PILLAR GAP COVER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__a-pillar-gap-cover) .
6. Footrest/Floor Covering Overview, refer to «FOOTREST AND FLOOR COVERING OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Footrest, removing and installing, refer to «FOOTREST»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__footrest) . Remove and install the floor covering, refer to «FLOOR COVERING»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__floor-covering) .
7. Front Sill Panel Trim Overview, refer to «FRONT SILL PANEL STRIP ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__front-sill-panel-strip-assembly-overview) . Removing and installing, refer to «FRONT SILL PANEL TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__front-sill-panel-trim) .
8. C-pillar Trim Overview, refer to «C-PILLAR TRIM ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «C-PILLAR TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__c-pillar-trim) .
9. D-pillar Trim Overview, refer to «D-PILLAR TRIM ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «D-PILLAR TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__d-pillar-trim) .

Scheme 8

1. Clips Quantity: 2 Replace Install in the trim. There are different versions. Refer to «Upper A-Pillar Trim Clip»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) .
2. Expanding Clip
3. Expanding Cap With the "Airbag" symbol. Carefully unclip
4. Upper A-pillar Trim Removing and installing, refer to «A-PILLAR UPPER TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__a-pillar-upper-trim) .

Scheme 9

There are different versions of the clips used for attaching the A-pillar trim depending on the date of manufacture

Version A

Clips without a hook -arrow

1. In the center and/or at the bottom on the trim.

Version B

Clips with a hook -arrow

1. In the center and/or at the bottom on the trim.

Scheme 10

1. Slide For the seat belt height adjuster. Part of the upper B-pillar trim. Removing and installing, refer to «UPPER B-PILLAR TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__upper-b-pillar-trim) .
2. Upper B-pillar Trim Removing and installing, refer to «UPPER B-PILLAR TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__upper-b-pillar-trim) .
3. Lower B-pillar Trim Removing and installing, refer to «LOWER B-PILLAR TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__lower-b-pillar-trim) .

Scheme 11

1. Expanding Clip
2. C-pillar trim Removing and Installing, refer to «C-PILLAR TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__c-pillar-trim)
3. Clips Install in the trim Replace if damaged or deformed Remove the remaining clips in the mounting points on the body using T40280
4. Centering pins

Scheme 12

1. Expanding Clip
2. Speaker Trim
3. D-pillar trim Removing and Installing, refer to «D-PILLAR TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__d-pillar-trim)
4. Expanding Clip
5. Clips Quantity: 3 Install in the trim Replace if damaged or deformed Remove the remaining clips in the mounting points on the body using T40280

Scheme 13

1. Driver Side Instrument Panel Cover
2. Clips Insert in the footrest.
3. Footrest Cannot be removed without destroying. Removing and installing, refer to «FOOTREST»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__footrest) .
4. Front Sill Panel Trim
5. Carpet One piece Removing and installing, refer to «FLOOR COVERING»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__floor-covering) .

FRONT SILL PANEL STRIP ASSEMBLY OVERVIEW

Note. The overview is based on the driver side. The passenger side is similar and the components are installed reversed from left to right.

Scheme 14

1. Clips Quantity: 4 Install in the trim Remove any clips still in the body using T40280 and insert them into the sill panel strip for installation Replace if damaged or deformed
2. A-pillar gap cover Removing and Installing, refer to «A-PILLAR GAP COVER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__a-pillar-gap-cover)
3. Hood Release Lever For the cable Driver side only Removing and Installing, refer to «CABLE OPERATING LEVER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__cable-operating-lever)
4. Bolt Driver side only 2.5 Nm
5. Front sill panel trim Removing and Installing, refer to «FRONT SILL PANEL TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__front-sill-panel-trim)

Scheme 15

1. Clips Insert in the sill panel strip Quantity: 5 Replace if damaged or deformed Remove the remaining clips in the mounting points on the body using T40280
2. Centering pins
3. Rear sill panel trim If equipped Rear Passenger Side Airbag (Driver side) Igniter -N201- Rear Passenger Side Airbag (front Passenger side) Igniter -N202- Removing and Installing, refer to «REAR SILL PANEL TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__rear-sill-panel-trim)

Scheme 16

1. Spare Wheel Well Trim Overview, refer to «LUGGAGE COMPARTMENT TRIM PANEL AND BATTERY RECESS COVER OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «SPARE WHEEL WELL TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__spare-wheel-well-trim) .
2. Rear Cross Panel Trim Overview, refer to «REAR LID END PANEL TRIM PANEL ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «REAR CROSS PANEL TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__rear-cross-panel-trim) .
3. Gap Cover Or Retaining Track Equipment level, luggage compartment floor with gap cover, overview. Refer to «LUGGAGE COMPARTMENT FLOOR WITH GAP COVER OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «GAP COVER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__gap-cover) . Equipment level, luggage compartment floor with retaining track, overview. Refer to «LUGGAGE COMPARTMENT FLOOR WITH RAIL OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «RETAINING TRACKS»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__retaining-tracks) .
4. Luggage Compartment Side Trim Overview, refer to «LUGGAGE COMPARTMENT SIDE TRIM ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «LUGGAGE COMPARTMENT SIDE TRIM PANEL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__luggage-compartment-side-trim-panel) .
5. Luggage Compartment Cover Overview, refer to «LUGGAGE COMPARTMENT COVER OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . There are two different versions. Add-on parts, replacing, refer to «LUGGAGE COMPARTMENT COVER ATTACHMENTS»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__luggage-compartment-cover-attachments) .
6. Screen Separator Wall Overview, refer to «SCREEN SEPARATOR WALL OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) .
7. Front Luggage Compartment Floor Equipment level, luggage compartment floor with gap cover, overview. Refer to «LUGGAGE COMPARTMENT FLOOR WITH GAP COVER OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «FRONT LUGGAGE COMPARTMENT FLOOR»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__front-luggage-compartment-floor) . Equipment level, luggage compartment floor with retaining track, assembly overview. Refer to «LUGGAGE COMPARTMENT FLOOR WITH RAIL OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «FRONT LUGGAGE COMPARTMENT FLOOR WITH RAILS»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__front-luggage-compartment-floor-with-rails) .
8. Rear Luggage Compartment Floor

Scheme 17

1. Rear Luggage Compartment Cover NOTE: There are two different versions for the luggage compartment cover. Version 1 The underside is smooth and all attachments are installed. The large bolt is for installing the hinges and the small bolt for the storage net attachments. Version 2 The underside is made of material and, except for the D-pillar protection, all of the attachments are riveted in place. NOTE: With version 2, only the D-pillar protection can be replaced. Riveted components cannot be replaced.
2. Rail For Storage Net 2x Depending on the version: either bolted or riveted in place. Small bolt 1.6 Nm The rails for versions 1 and 2 are different.
3. D-pillar Protector 2x 1.6 Nm Bolted in place Bolt
4. Hinge 3x 1.6 Nm Depending on the version: either bolted or riveted in place. Large bolt The two outside hinges are the same, but the center one is different.
5. Mount For The Storage Net 1.6 Nm Depending on the version: either bolted or riveted in place. Small bolt
6. Mounts For The Storage Net 1.6 Nm Depending on the version: either bolted or riveted in place. Small bolt
7. Small Mount 2x Depending on the version: either bolted or riveted in place. Large bolt 1.6 Nm
8. Large Mount 2x 1.6 Nm Depending on the version: either bolted or riveted in place. Large bolt
9. Front Luggage Compartment Cover There are two different versions for the luggage compartment cover. Version 1 The underside is smooth, the hinges and mounts are installed using the large bolt. Version 2 The underside is made of material and all of the attachments are riveted in place. NOTE: With version 2, only the D-pillar protection can be repaired. Riveted components cannot be replaced.

Scheme 18

1. Bolt 20 Nm Quantity: 2
2. Gap Cover Removing and installing, refer to «GAP COVER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__gap-cover) .
3. Tie-Down Eye Quantity: 2 Removing and installing, refer to «TIE-DOWNS»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__tie-downs) .
4. Bolt Quantity: 4 6 Nm
5. Rear Luggage Compartment Floor
6. Front Luggage Compartment Floor Removing and installing, refer to «FRONT LUGGAGE COMPARTMENT FLOOR»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__front-luggage-compartment-floor) .
7. Bolt Quantity: 2 20 Nm
8. Front Bracket Removing and installing, refer to «FRONT BRACKET»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__front-bracket) .
9. Rear Bracket Removing and installing, refer to «REAR BRACKET»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__rear-bracket) .

Scheme 19

1. Bolt 20 Nm Quantity: 2
2. Gap Cover Removing and installing, refer to «GAP COVER WITH RAIL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__gap-cover-with-rail) .
3. Retaining Tracks Removing and installing, refer to «RETAINING TRACKS»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__retaining-tracks) .
4. Bolt 7 Nm Quantity: 3
5. Rear Luggage Compartment Floor
6. Front Luggage Compartment Floor Removing and installing, refer to «FRONT LUGGAGE COMPARTMENT FLOOR WITH RAILS»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__front-luggage-compartment-floor-with-rails) .
7. Bolt 20 Nm Quantity: 2
8. Front Bracket Removing and installing, refer to «FRONT BRACKET»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__front-bracket) .
9. Rear Bracket Removing and installing, refer to «REAR BRACKET»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__rear-bracket) .

Scheme 20

1. Luggage compartment side trim Removing and Installing, refer to «LUGGAGE COMPARTMENT SIDE TRIM PANEL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__luggage-compartment-side-trim-panel)
2. Clips Quantity: 3 Install in the trim Replace if damaged or deformed Remove the remaining clips in the mounting points on the body using T40280
3. Luggage Compartment Light Removing and Installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches)
4. Bolt 3 Nm
5. Coat hooks Removing and Installing, refer to «COAT HOOKS»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__coat-hooks)
6. Rear backrest release Assembly Overview, refer to «BACKREST RELEASE OVERVIEW»(/audi/q5/i-2008-2012/remont/seats/#seat-frames__backrest-release-overview) Removing and Installing, refer to «BACKREST RELEASE ACTUATOR»(/audi/q5/i-2008-2012/remont/seats/#seat-frames__backrest-release-actuator)
7. Cover for the luggage compartment side trim

Scheme 21

1. Battery Recess Cover Removing and installing, refer to «BATTERY RECESS COVER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__battery-recess-cover) .
2. Trim panel For the spare wheel well. Removing and installing, refer to «SPARE WHEEL WELL TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__spare-wheel-well-trim) .
3. Nut For spare wheel mounting. When tightening, it must audibly click into place, otherwise, turn some more.
4. Large Dirt Shield Special equipment
5. Small Dirt Shield Special equipment
6. Clip
7. Tool Box

Scheme 22

1. Centering pins
2. Clips Quantity: 4 Install in the trim Replace if damaged or deformed Remove the remaining clips in the mounting points on the body using T40280
3. Rear cross panel trim With rear lid -closed- sensor 1 -G525- and rear lid -closed- sensor 2 -G526- Removing and Installing, refer to «REAR CROSS PANEL TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__rear-cross-panel-trim)

Scheme 23

1. Tie-Down Eye Removing and installing, refer to «TIE-DOWNS»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__tie-downs) .
2. Mount Quantity: 4 For the screen separator wall. Removing and installing, refer to «SCREEN SEPARATOR MOUNT»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__screen-separator-mount) .
3. Bolt 9 Nm Quantity: 4
4. Screen Separator Wall Special equipment Can only be replaced completely. Installing the tie downs and anchoring lugs.

Scheme 24

1. Rear bracket Removing and Installing, refer to «REAR MOUNT, Q5 HYBRID»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__rear-mount-q5-hybrid)
2. Bolt Quantity: 2 Tightening specifications, refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers)
3. Tie-down eye Quantity: 4 Removing and Installing, refer to «TIE-DOWNS»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__tie-downs)
4. Bolt Quantity: 8 6 Nm
5. Luggage compartment floor Removing and Installing, refer to «LUGGAGE COMPARTMENT FLOOR PANEL, Q5 HYBRID»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__luggage-compartment-floor-panel-q5-hybrid)
6. Tool box Removing and Installing, refer to «TOOL BOX, Q5 HYBRID»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__tool-box-q5-hybrid) Press on until it engages audibly
7. Bolt Quantity: 4 20 Nm
8. Front bracket Quantity: 2 Removing and Installing, refer to «FRONT MOUNT, Q5 HYBRID»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__front-mount-q5-hybrid)

DOOR TRIM OVERVIEW

Note. The rear left door panel is illustrated.

Scheme 25

1. Active Or Passive Rear Reflector Special equipment
2. Retaining Clip With seal For door trim Quantity: 7
3. Trim Panel For door trim Removing and installing, refer to «TRIM MOLDING»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__trim-molding) .
4. Clips For trim panel Quantity: 3 Press into the door trim.
5. Bolt 1.2 Nm For armrest Quantity: 7
6. Bolt 1.2 Nm For pull handle Quantity: 2
7. Bolt 1.2 Nm For inside door release mechanism. Quantity: 4
8. Trim For the window frame. Removing and installing, refer to «WINDOW FRAME TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) .
9. Interior Door Mechanism Removing and installing, refer to «INSIDE DOOR RELEASE MECHANISM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__inside-door-release-mechanism) .
10. Rear Interior Locking Button Special equipment Driver side: left rear interior locking button -E310-. Front passenger side: right rear interior locking button -E311-. Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
11. Bolt 2.5 Nm For door trim Quantity: 2
12. Trim For high range speaker. Removing and installing, refer to «TREBLE SPEAKER TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) .
13. Rear Door Trim Removing and installing, refer to «REAR DOOR TRIM PANEL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-panel) .
14. Speaker trim For mid range speaker. Special equipment Removing and installing, refer to «MID-RANGE SPEAKER TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__mid-range-speaker-trim) .
15. Power Window Switch In The Rear Door Driver side: left rear power window switch in left rear door -E52-. Front passenger side: right rear window switch in right rear door -E54-. Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
16. Pull Handle Removing and installing, refer to «REAR PULL HANDLE»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__rear-pull-handle) .
17. Armrest Removing and installing, refer to «REAR ARMREST»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__rear-armrest) .
18. Bolt 2.5 Nm For door trim
19. Bolt 2.5 Nm For door trim
20. Entry Lamp Special equipment Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) .

1. Clip for the pull handle
2. Bolt - 2.5 Nm

DOOR WINDOW SUNSHADE OVERVIEW

Note. The rear left sunshade is illustrated.

Scheme 26

1. Rear Door Trim Removing and installing, refer to «REAR DOOR TRIM PANEL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__rear-door-trim-panel) .
2. Bolt 1.2 Nm For the sunshade. Quantity: 4
3. Sun Shade For the door window. Removing and installing, refer to «DOOR WINDOW SUN SHADE»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__door-window-sun-shade) .
4. Bolt 1.2 Nm For the sunshade. Quantity: 3
5. Mount For the sunshade. Removing and installing, refer to «SUN SHADE MOUNT»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) .
6. Bolt 1.3 Nm For the mount. Quantity: 2
7. Guide Strip Removing and installing, refer to «DOOR WINDOW SUN SHADE»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__door-window-sun-shade) .

Scheme 27

1. Lower Trim For the rear lid. Overview, refer to «LOWER REAR LID TRIM PANEL ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «LOWER REAR LID TRIM PANEL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__lower-rear-lid-trim-panel) .
2. Upper trim For the rear lid. Overview, refer to «UPPER REAR LID TRIM PANEL ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «UPPER REAR LID TRIM PANEL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__upper-rear-lid-trim-panel) .

Scheme 28

1. Bolt Quantity: 4 2 Nm
2. Rubber buffer Quantity: 4 Install in the trim
3. Clips Quantity: 12 Install in the trim Replace if damaged or deformed Remove the remaining clips in the mounting points on the body using T40280
4. Lower Trim for the rear lid Removing and Installing, refer to «LOWER REAR LID TRIM PANEL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__lower-rear-lid-trim-panel)
5. Cover for tail lamps Removing and Installing, refer to «TAIL LAMP COVER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__tail-lamp-cover)
6. Luggage Compartment Light Removing and Installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches)
7. Cover for the warning triangle Removing and Installing, refer to «WARNING TRIANGLE COVER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__warning-triangle-cover)
8. Cover For the emergency release Removing and Installing, refer to «EMERGENCY RELEASE COVER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__emergency-release-cover)
9. Trim For rear lid lock Removing and Installing, refer to «REAR LID LATCH TRIM PANEL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__rear-lid-latch-trim-panel)
10. Rear Lid Lock Button (in luggage compartment) -E406- Removing and Installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches)

Scheme 29

1. Upper Trim for the rear lid Removing and Installing, refer to «UPPER REAR LID TRIM PANEL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__upper-rear-lid-trim-panel)
2. Clips Quantity: 8 Install in the trim Replace if damaged or deformed Remove the remaining clips in the mounting points on the body using T40280
3. Rubber buffer Quantity: 11 Install in the trim

Scheme 30

1. Headliner Special equipment Removing and installing, refer to «HEADLINER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__headliner) . CAUTION: The headliner bends easily. Replace the headliner if it is bent.
2. Cover Frame Vehicles with sunroof. The marking points to the rear of the vehicle.
3. Roof Reinforcement Vehicles without a sunroof. Attaching to the body. Refer to «ROOF REINFORCEMENT, WITHOUT SUNROOF, ATTACHING TO BODY»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__roof-reinforcement-without-sunroof-attaching-to) .
4. Centering Clip
5. Clips Vehicles with sunroof. Quantity: 23 Insert in the headliner. Replace if damaged or deformed. Release, refer to «HEADLINER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__headliner) .

Scheme 31

1. Roof panel trim Removing and Installing, refer to «ROOF PANEL TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__roof-panel-trim)
2. Clip Push onto the D-pillar trim
3. Clips Quantity: 2 Install in the trim Replace if damaged or deformed Remove the remaining clips in the mounting points on the body using T40280
4. Centering pins

Scheme 32

1. Mount For the screen separator wall. Overview, refer to «SCREEN SEPARATOR WALL OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «SCREEN SEPARATOR MOUNT»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__screen-separator-mount) .
2. Interior Lamp/Rear Reading Lamp Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
3. Roof Grab Handle Removing and installing, refer to «ROOF GRAB HANDLE»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__roof-grab-handle) .
4. Sun Visor Overview, refer to «SUN VISORS OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «SUN VISOR»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__sun-visor) .
5. Interior Lamp/Front Reading Lamp Removing and installing, refer to «[For engine(s) CAEB, CALB] Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches) .
6. Roof Reinforcement Vehicles without a sunroof. Attaching to the body. Refer to «ROOF REINFORCEMENT, WITHOUT SUNROOF, ATTACHING TO BODY»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__roof-reinforcement-without-sunroof-attaching-to)
7. Headliner Special equipment Overview, refer to «HEADLINER OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «HEADLINER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__headliner) . CAUTION: The headliner bends easily. Replace the headliner if it is bent.
8. Roof Panel Trim Overview, refer to «REAR ROOF PANEL TRIM ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . Removing and installing, refer to «ROOF PANEL TRIM»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__roof-panel-trim) .

Scheme 33

1. Expanding Cap Clipped into the sun visor.
2. Connector For the vanity mirror light. Special equipment
3. Center Bracket For the sun visor. Removing and installing, refer to «SUN VISOR CENTER BRACKET»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__sun-visor-center-bracket) .
4. Cover Clipped into the sun visor center bracket.
5. Sun Visor Removing and installing, refer to «SUN VISOR»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__sun-visor) .

DRIVER MEMORY SEAT CONTROL HEAD E97

Removing

Scheme 34

Remove the front door trim panel. Refer to FRONT DOOR TRIM PANEL .

Remove the driver memory seat control head. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Release the switch trim -1- first at the top -arrows A- and then forward and out of the door panel.

Installation

Installation is reverse of removal, but note the following

First insert the switch trim at the bottom -arrows B- and then press it in until it audibly locks in place.

FRONT ARMREST

Special tools and workshop equipment required

1. Removal Wedge 3409

Note. Removal and installation are same for right and left.

Removing

Scheme 35

Remove the front door trim panel. Refer to FRONT DOOR TRIM PANEL .

Remove the bolts -2 through 9- on the rear of the door trim.

Loosen the armrest -1- from the pull handle -arrow- with the 3409 and remove.

Installation

To install, perform the steps used in removal in reverse order.

FRONT DOOR TRIM PANEL

Note. Removing and installing on the left and right sides is identical.

Special tools and workshop equipment required

Scheme 36

1. Pliers 3392

Removing

Scheme 37

Switch the ignition off and remove the ignition key.

Remove the trim panel. Refer to TRIM MOLDING .

Remove the bolts -1 through 4-.

Beginning at the bottom rear curve, unclip the door trim from the door using the pliers 3392 by sliding them between the door trim and the door in the securing clip area.

Scheme 38

Scheme 39

1. Position of the retaining clips -arrows-.

Pull the door trim panel -1- approximately 15 mm off the door all the way around -arrows A-.

Scheme 40

1. The clips must not be left in the inside the door.

Remove the pull handle -2- upward and out of the clamp -3- at the indicated point on the door trim panel -arrow B-.

Disengage and remove the upper door trim panel from the door on the window recess.

Unlock the bracket -4- from the cable bracket -2- -arrow A-.

Scheme 41

Remove inside door release cable -3- from the control cable bracket in -direction of arrow B-.

Disengage the ends of the cable -1- from the inside door release mechanism.

To disconnect electrical connector, press catch -1-, rotate retaining bracket in -direction of arrow- and remove connector.

Scheme 42

Remove the door trim.

Installing

Engage the ends of the cable -1- in the inside door release mechanism lever.

1. The open side of the eye on the end of the cable must face up.

Pull the door mechanism release cable -3- in -direction of arrow B- and guide it into the cable bracket -2-.

1. Bracket -4- must engage audibly in the control cable bracket.

Connect the connectors on the door control module.

Position the door trim on the window recess and press it down firmly.

Scheme 43

Carefully install the door trim panel clip on the door and then press the door trim panel into the clip so that they audibly engage.

Install the pull handle -1- into the bracket -2- until it audibly latches into the door.

Install in reverse order of removal.

FRONT PULL HANDLE WITH SWITCH MOUNT

Note. Removal and installation are same for right and left.

Removing

Scheme 44

Remove the front door trim panel. Refer to FRONT DOOR TRIM PANEL .

Remove the front armrest. Refer to FRONT ARMREST .

Remove the window regulator control head. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Driver door: remove the mirror adjustment switch. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Remove the bolts -2 through 7- on the rear of the door trim.

Carefully remove the pull handle -1- with the switch mount from the door trim.

Installation

To install, perform the steps used in removal in reverse order.

INSIDE DOOR RELEASE MECHANISM

Note. Removal and installation is described on the driver door trim. The procedure is similar for the other door trim.

Removing

Scheme 45

Remove the front door trim panel. Refer to FRONT DOOR TRIM PANEL .

Disconnect the connector -2- on the interior locking button.

Vehicles with illumination: disconnect the connector

Remove the bolts -3 through 6-.

Remove the interior door mechanism -1- from the door panel.

Installation

To install, perform the steps used in removal in reverse order.

MID-RANGE SPEAKER TRIM

Note. Removal and installation is described for the driver side of the vehicle. It is the same for the other doors.

Removing

Scheme 46

Remove the front door trim panel. Refer to FRONT DOOR TRIM PANEL .

Remove the screws on the back of the door trim panel -arrows- and remove the speak trim -1-.

Installation

To install, perform the steps used in removal in reverse order.

PASSENGER COMPARTMENT MONITORING SWITCH AND ALARM SYSTEM -OFF- SWITCH, ADDITIONAL CUT-OUT

Note. A replacement drive side door trim panel is supplied without the cut-out for the passenger compartment monitoring switch -E183- / -E217-. If necessary, make a cut-out in the new trim panel as follows

Procedure

Scheme 47

Make the cut-out in the door trim panel for the passenger compartment monitoring switch; make the cut along the marking on the back of the panel.

Install the front door trim panel. Refer to FRONT DOOR TRIM PANEL .

REAR LID REMOTE UNLOCK SWITCH TRIM

Removing

Scheme 48

Remove the driver front door trim panel. Refer to FRONT DOOR TRIM PANEL .

Disconnect the connector -1- on the rear lid remote unlock switch.

Release the clips -2- and push the trim -3- together with the rear lid remote unlock switch out of the door trim panel -arrow-.

Remove the remote rear lid release switch. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Installation

Installation is reverse of removal, but note the following

Press the trim on until it engages audibly.

TREBLE SPEAKER TRIM

Note. Removal and installation are same for right and left.

Special tools and workshop equipment required

1. Removal Wedge 3409

Removing

Scheme 49

Carefully pry off the treble speaker trim -1- from the window frame trim panel -arrow- using the 3409 or a narrow screwdriver.

Installation

Press the treble speaker trim on until it engages audibly.

TRIM MOLDING

Note. Removal and installation is described for the driver side of the vehicle. It is the same for the other doors.

Removing

Scheme 50

Wrap the blade on a small screwdriver with tape to protect the trim panel and decorative trim.

Pry off the decorative trim -1- from the door panel using the screwdriver and starting at the rear -arrow A-.

Remove the decorative trim from the door release mechanism toward the rear -arrow direction B- by gently prying off the trim using a screwdriver and starting at the front so that it lifts the hooks on the inside out of the cut-out.

Installation

First engage the decorative trim on the interior door mechanism and press it into the door panel until it clicks into place.

WINDOW FRAME TRIM

Special tools and workshop equipment required

1. Removal Wedge 3409

Note. Removal and installation are same for right and left.

Removing

Scheme 51

Lower the door window.

Remove the front door trim panel. Refer to FRONT DOOR TRIM PANEL .

Remove the treble speaker trim. Refer to TREBLE SPEAKER TRIM .

Vehicles with treble speakers: Remove the treble speaker. Refer to Removal and Installation .

Versions with lane change assistance: remove the lane change assistance button -E530-. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Pry the window frame trim -1- out using the 3409 starting at the bottom and then all around the window frame guide -arrow A-.

Remove the window frame trim from the window frame -arrow B- at the same time.

Remove the window frame trim -1- from the window guide -arrows-.

Scheme 52

Installation

Scheme 53

Install the window frame trim -1- into the window guide -2- starting on the inside at the bottom -arrow-.

Fold the window frame trim -1- over the window guide -2- -arrow- using the 3409.

Scheme 54

Note. Be careful not to pull the window guide off the door frame.

Pull the 3409 the entire length between the window frame trim -1- and door seal molding -2- and at the same time push the door frame trim toward the door frame.

Scheme 55

Further installation is performed in the reverse order of removal.

CENTER INSTRUMENT PANEL VENT

Special tools and workshop equipment required

1. Hook 3438

Removing

Scheme 56

Note. The instrument panel vent has a hole -arrow- on both sides for attaching the hook 3438.

Alternating on both sides, carefully remove the instrument panel vent -1- from the installation opening using the 3438.

Vehicles with illumination: Disconnect the connector on the instrument panel vent.

Installation

Installation is reverse of removal, but note the following

Note. Check the clips for damage or deformation and replace them if necessary.

When sliding the instrument panel vent into the installation opening, make sure the air duct engages correctly.

Press the instrument panel vent into the installation opening as far as the stop.

CENTER SPEAKER TRIM

Special tools and workshop equipment required

1. Removal Wedge 3409

Removing

Note. Be extremely careful when removing and installing because it is easy to damage the speaker trim.

Carefully detach the speaker -1- on the rear pins in the driver direction -arrow- using the 3409.

Scheme 57

Lift the rear speaker trim slightly, disengage it at the front on the defroster vent and remove it toward the rear.

Installation

First insert the speaker trim in the instrument panel and then press it on until it engages audibly.

INSTRUMENT PANEL

Removing

Move the steering wheel as far down as possible.

Move the seat all the way back and adjust the backrest to a 45° angle.

Switch the ignition on.

Disconnect the battery ground cable with the ignition switched on. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Remove the instrument cluster gap cover. Refer to INSTRUMENT CLUSTER GAP COVER .

Remove the driver side instrument panel cover. Refer to DRIVER SIDE INSTRUMENT PANEL COVER .

Remove the side instrument panel vent. Refer to SIDE INSTRUMENT PANEL VENT .

Remove the MMI screen cover. Refer to MMI SCREEN .

Remove the MMI screen. Refer to Removal and Installation .

Remove the instrument cluster. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Disconnect the electrical connector on the access/start authorization switch. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Remove the center instrument panel vent. Refer to CENTER INSTRUMENT PANEL VENT .

Remove the radio/navigation system. Refer to Removal and Installation .

Remove the Climatronic control module -J255-. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Remove the front information display control head module -J523-. Refer to Removal and Installation .

Remove center console. Refer to CENTER CONSOLE .

Remove the glove compartment. Refer to GLOVE COMPARTMENT .

Remove the instrument panel support. Refer to GLOVE COMPARTMENT BRACKET .

Disconnect the passenger airbag electrical connector. Refer to FRONT PASSENGER AIRBAG IGNITER 1 AND 2 N131/N132 .

Vehicles equipped with speakers: remove the midrange speaker in the center of the instrument panel. Refer to Removal and Installation .

Remove the sunlight photo sensor -G107-. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Remove the upper A-pillar trim. Refer to A-PILLAR UPPER TRIM .

Vehicles with speakers: Remove the center midrange speaker inside the instrument panel. Refer to Removal and Installation .

Remove the top left and right instrument panel bolts -1- in the A-pillar area.

Scheme 58

Remove the bottom left and right instrument panel bolts -2-.

Remove the left and right air duct bolts -arrows- on the instrument panel.

Remove the instrument panel bolts -1- on the center of the instrument panel central tube.

Scheme 59

Remove the instrument panel bolts -2- on the right of the instrument panel central tube.

Remove the instrument panel bolt -3- on the left of the instrument panel central tube.

Note. 2 technicians are needed to remove the instrument panel.

Disengage the instrument panel -1- at the bottom from the bracket -2- and remove it -arrow B-.

Carefully pull the instrument panel back from the instrument panel central tube -A arrows-.

Remove the instrument panel on the passenger side from the vehicle interior and lay it on a soft surface.

Installation

Installation is reverse of removal, but note the following

Position the instrument panel vent and guide the electrical connectors for the sunlight photo sensor -G107- and speaker through the openings in the instrument panel.

Check if there is a rubber buffer -3- on the clamp -2- on the lower windshield frame.

Scheme 60

When sliding the instrument panel -1- on, make sure the clips engage in the box-shaped profiles on the bottom side of the instrument panel.

Note. Make sure the connectors are installed all the way in and are secure.

Align the instrument panel with the door trim panels and tighten the screws.

Connect the battery ground cable with the ignition turned on. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the Vehicle diagnostic tester.

INSTRUMENT PANEL SIDE COVER

Special tools and workshop equipment required

1. Removal Wedge 3409

Note. Removal and installation are same for right and left.

Removing

Scheme 61

Pry the instrument panel side cover -1- off using the 3409 -arrow- and remove it.

Installation

Press the instrument panel side cover on until it engages audibly.

INSTRUMENT PANEL TRIM

Special tools and workshop equipment required

1. Removal Wedge 3409

Removing

Scheme 62

Pry the instrument panel trim -1- off using the 3409 -arrow- and remove it.

Installation

Press the instrument panel trim until it engages audibly.

MMI SCREEN

Special tools and workshop equipment required

1. Removal Wedge 3409

Removing

Scheme 63

Pry the MMI screen cover -1- out at the corners -arrow- using the 3409 and remove it.

Disconnect the front passenger airbag disabled indicator lamp -K145- /emergency flasher button -E229- electrical connector and remove the cover.

Installation

Installation is reverse of removal, but note the following

Note. Check the clips for damage or deformation and replace them if necessary.

Press the MMI screen cover on until it engages audibly.

RADIO AND NAVIGATION SYSTEM FRAME

Removing

Scheme 64

Remove the center instrument panel vent. Refer to CENTER INSTRUMENT PANEL VENT .

Remove the radio/navigation system. Refer to Removal and Installation .

Remove the bolts -1- and -2- on the front of the installation frame.

Remove the side bolts -4-.

Pull the installation frame -3- back and remove it.

Installation

To install, perform the steps used in removal in reverse order.

SIDE INSTRUMENT PANEL VENT

Special tools and workshop equipment required

1. Hook 3438

Note. Removal and installation is described for the driver side of the vehicle. It is identical on the passenger side.

Removing

Scheme 65

Note. There is a hole -arrows- on the side of the instrument panel vent at the top 3438 for attaching the hook.

Carefully remove the instrument panel vent -1- out of its opening alternating from the side to the top using the 3438.

Vehicles with illumination: Disconnect the connector on the instrument panel vent.

Installation

Installation is reverse of removal, but note the following

Note. Check the clips for damage or deformation and replace them if necessary.

When sliding the instrument panel vent into the installation opening, make sure the air duct engages correctly.

Press the instrument panel vent into the installation opening as far as the stop.

SIDE SPEAKER TRIM

Note. Be extremely careful when removing and installing because it is easy to damage the speaker trim. Removal and installation are same for right and left. The illustration shows the left speaker trim.

Removing

Scheme 66

Using a small screwdriver, carefully pry the speaker trim -1- out beginning at the corner -arrow-.

Fold the speaker trim upward and remove it.

Installation

First insert the speaker trim in the instrument panel and then press it on until it engages audibly.

SWITCH FOR ACCESS/START AUTHORIZATION, TRIM PANEL

Special tools and workshop equipment required

1. Special Ignition Lock Pliers VAS 6339

Removing

Scheme 67

Remove the center instrument panel vent. Refer to CENTER INSTRUMENT PANEL VENT .

Insert the VAS 6339 through the trim covers.

Position the tips of the VAS 6339 on both holes -A arrows- on the access/start authorization switch -E415- -2-.

Press the VAS 6339 together -B arrows- to spread the tips of the pliers and release the trim retaining tabs.

Hold the VAS 6339 pressed with one hand and remove the trim -1- with the other hand -arrow C-.

Note. Only use the VAS 6339. Remove the trim by hand.

Installation

Install the upper and lower trim on the switch until they audibly latch.

Install the center instrument panel vents. Refer to CENTER INSTRUMENT PANEL VENT .

TOP CENTER DEFROSTER VENT

Removing

Scheme 68

Remove the center speaker trim. Refer to CENTER SPEAKER TRIM .

Remove the screws -2 through 7- and remove the upper defroster vent in the center -1- from the instrument panel.

Disconnect the sunlight photo sensor -G107- connector.

Installation

Installation is reverse of removal, but note the following

Engage the defrost vent back into the instrument panel into the retaining tabs.

GLOVE COMPARTMENT BRACKET

Removing

Scheme 69

Remove the glove compartment. Refer to GLOVE COMPARTMENT .

Remove the bolts -2-.

Remove the glove compartment bracket -1- from the instrument panel.

Installation

To install, perform the steps used in removal in reverse order.

GLOVE COMPARTMENT RETAINERS

Removing

Scheme 70

Remove the bolts -arrows-.

Remove the left -1- and right -2- glove compartment brackets.

Installation

Position both glove compartment brackets so that tab -4- engages in hole -3- in the instrument panel.

Further installation is performed in the reverse order of removal.

INSTRUMENT PANEL CENTRAL TUBE

Removing

Scheme 71

Remove the instrument panel. Refer to INSTRUMENT PANEL .

Remove the steering column from the central tube and lay it on the floor of the vehicle. Refer to Removal and Installation .

Disengage the left instrument panel vent air duct at the instrument panel central tube. Refer to Removal and Installation .

Remove the right instrument panel vent air duct. Refer to Removal and Installation .

Remove the left fuse panel C -SC- and the right fuse panel D -SD- from the instrument panel central tube. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Remove the data bus on board diagnostic interface -J533- and lay it aside. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Remove the bolts -1- on the left and right of the central tube support and remove the bracket -2-.

Remove the left and right bolts -3- for the central tube support.

Remove the A/C unit bolt -1- on the left and right of the central tube support.

Scheme 72

Remove the center defroster vent air duct. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Scheme 73

Remove the A/C unit bolt -1- on the instrument panel central tube top brace.

Remove the bolt -2- on the top brace on the instrument panel central tube.

Remove the ground wire and left ground point from the tunnel wall and free them up.

Disconnect the connectors on the accelerator pedal module and the brake light switch and free them up.

Remove the front right sill panel trim. Refer to FRONT SILL PANEL TRIM .

Disconnect the connectors on the A-pillar coupling station. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Disconnect the electrical connector on the fresh air blower and free up the wires.

Remove the air intake chamber bracket bolts -1- on the instrument panel central tube.

Scheme 74

Remove the nut -2-.

Remove the bolt -1- and nut -2-.

Scheme 75

Tighten the 2 nuts -2- and -3- on the threaded pin -1- on the driver side A-pillar and remove the threaded pin.

Scheme 76

Note. 2 technicians are needed to remove instrument panel central pipe.

Carefully pull the instrument panel central tube -1- up at the driver side while disengaging it from the A/C unit -3- and the upper -2- and lower -4- stop brackets.

Scheme 77

Remove the instrument panel central tube from the threaded pin on the passenger side A-pillar.

Carefully tilt the top side of the instrument panel central tube back while pulling it up.

Remove the instrument panel central tube from the vehicle interior.

Installation

Carefully insert the instrument panel central tube -1- in the body.

Engage the instrument panel central tube on the A/C unit -3- and on the upper -2- and lower -4- stop brackets.

Align the instrument panel central tube -4- with the A-pillar.

Scheme 78

Tighten the two nuts -2- and -3- on threaded pin -1- and insert the threaded pin in mount -5- on the A-pillar on the driver side and tighten.

1. The threaded pin must be installed all the way until the collar on the mount touches the A-pillar.

Tighten the left and right instrument panel central tube bolts and nuts.

Further installation is performed in reverse sequence of removal, but observe the following

Install the steering column. Refer to Removal and Installation .

Connect the battery ground cable with the ignition turned on. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the Vehicle diagnostic tester.

LEFT IMPACT ABSORBER

Removing

Scheme 79

Remove the driver side instrument panel cover. Refer to DRIVER SIDE INSTRUMENT PANEL COVER .

Remove the bolts -arrows-.

Remove the left impact absorber -1- downward.

Installation

To install, perform the steps used in removal in reverse order.

MOUNTING BRACKET

Removing

Scheme 80

Remove the left instrument panel vent air guide channel. Refer to Removal and Installation .

Remove the bolts -1- and -3- and remove the mounting bracket -2- downward.

Note. The removed steering column is shown in the illustration.

Installation

Installation is reverse of removal, but note the following

The mounting bracket can be correctly positioned only when the central tube is installed.

Attach the steering column and mounting bracket to the central tube. Refer to Removal and Installation first, and then tighten the mounting bracket screws -1- and -3- to the mount on the lower windshield frame.

RIGHT IMPACT ABSORBER

Removing

Scheme 81

Remove the driver side instrument panel cover. Refer to DRIVER SIDE INSTRUMENT PANEL COVER .

Remove the footwell vent on the driver side. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Remove the bolts -arrows-.

Remove the right impact absorber -1- downward.

Installation

To install, perform the steps used in removal in reverse order.

A-PILLAR UPPER TRIM

Special tools and workshop equipment required

1. Pry Lever 80 - 200

Note. Removal and installation are same for right and left.

Removing

Scheme 82

Pry out the expanding cap -1- with the "airbag" symbol about 5 mm with a screwdriver -arrow A-.

Note. The trim be removed from the A-pillar in -direction of arrow B- in different way depending on which clips are installed in the vehicle. Refer to Upper A-Pillar Trim Clip . If clips with a hook are installed, the trim needs to be pulled just a few millimeters until the hooks engage.

Carefully unclip the A-pillar trim -2- beginning at the top using a 80 - 200 -arrow B-.

Push the A-pillar trim upward and remove it -arrow C-.

Note. Depending on the date of manufacture, the clip slides out of the guide on the trim when it is pulled upward.

Installation

Installation is reverse of removal, but note the following

Note. Always replace the clips in the center and at the bottom. Always replace clips without hooks with clips with hooks.

Install the upper A-pillar trim -1- into the instrument panel mount -2- and the front sill panel trim -direction of arrow-.

Scheme 83

Attach the upper A-pillar trim with the "airbag" symbol so that the clips engage.

Fold over the rubber lip on the door seal.

A-PILLAR GAP COVER

Note. Removal and installation are same for right and left.

Removing

Scheme 84

Remove the instrument panel side cover. Refer to INSTRUMENT PANEL SIDE COVER .

Remove the gap cover -1- from the A-pillar trim and the sill trim -arrow-.

Remove the gap cover upward from the clips on the A-pillar.

Installation

To install, perform the steps used in removal in reverse order.

UPPER B-PILLAR TRIM

Special tools and workshop equipment required

1. Removal Wedge 3409

Note. Removal and installation are same for right and left.

Removing

Scheme 85

Press belt height adjuster button and bring height adjuster slide into lowest position.

Unclip the upper B-pillar trim -2- -arrows A- by inserting the 3409 into the lower edge of the trim.

Remove the upper B-pillar trim from the bracket on the body -arrow B- by moving the trim toward the inside and pulling it downward at the same time.

Remove the front belt anchor. Refer to FRONT BELT ANCHOR .

Guide the belt webbing with seat belt latch -1- out through the slide for the seat belt height adjuster -3- and then remove the upper B-pillar trim.

Installation

Guide the belt webbing and seat belt latch -2- in through the slide for the seat belt height adjuster.

Scheme 86

Note. Ensure that the seat belt height adjuster is in the bottom-most position.

Make sure the mount -3- for the sliding piece for the upper B-pillar trim -1- is securely latched into the retaining pins -4- on the seat belt height adjuster.

Further installation is performed in reverse sequence of removal, but observe the following

Install the front belt anchor. Refer to FRONT BELT ANCHOR .

First install the B-pillar trim upward into the cut-out in the headliner and into the bracket.

Stretch the door seal rubber lips over the trim.

Check the seat belt height adjuster function. Refer to BELT HEIGHT ADJUSTER .

LOWER B-PILLAR TRIM

Special tools and workshop equipment required

1. Pry Lever 80 - 200

Note. Removal and installation are same for right and left.

Removing

Scheme 87

Remove the upper B-pillar trim. Refer to UPPER B-PILLAR TRIM .

Unclip the front sill panel trim near the lower B-pillar trim. Refer to FRONT SILL PANEL TRIM .

Starting at the top, unclip the lower B-pillar trim -2- from the B-pillar -arrows A- using the 80 - 200.

Unclip and remove the lower B-pillar trim from the sill -arrow B-.

Open the flap -3- and remove the seat belt webbing -1-.

Installation

Installation is reverse of removal, but note the following

Install the centering pin on the lower B-pillar trim on the sill.

Stretch the door seal rubber lips over the trim.

C-PILLAR TRIM

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

Scheme 88

Scheme 89

1. Pry lever 80 - 200
2. Removal tool T40280 is needed to remove the clips in the body.

Removing

Scheme 90

Remove the luggage compartment side trim panel. Refer to LUGGAGE COMPARTMENT SIDE TRIM PANEL .

Remove the rear outer belt guide. Refer to OUTER REAR BELT GUIDE .

Remove the expanding clip -2-.

Unclip the C-pillar trim -1- using the pry lever 80 - 200 -arrow A-.

Pull the C-pillar trim downward -arrow B- and remove.

Installing

Install in reverse order of removal. Note the following

Scheme 91

Note. If the trim clamp remains in the body mounting points, remove them and insert them in the trim. Check the clamps for damage or deformation and replace them if necessary.

When installing the C-pillar trim -item 3-, make sure the retaining strip -2- fits into the cut-out in the body -arrow- and in the headliner -1-.

First mount the C-pillar trim on the centering pins and then press until it engages audibly.

Pull the door seal rubber lip over the edge of the trim.

D-PILLAR TRIM

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Pry lever 80 - 200
2. Removal tool T40280 is needed to remove the clips in the body.

Removing

Remove the luggage compartment side trim panel. Refer to LUGGAGE COMPARTMENT SIDE TRIM PANEL .

Remove the rear roof panel trim. Refer to ROOF PANEL TRIM .

Remove the expanding clips -1- and -3-.

Scheme 92

Remove the D-pillar trim -2- from the body -arrows- using the pry lever 80 - 200

Versions with a speaker: Disconnect the connector.

Installing

Install in reverse order of removal. Note the following

Note. If the trim clamps remain in the body mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Install the D-pillar trim and press on it until the audibly latches.

Pull the rubber lip of the luggage compartment seal over the edge of the trim.

CABLE OPERATING LEVER

Removing

Scheme 93

Pull the securing clip -2- out of the operating lever -1- slightly -arrow A- using a small screwdriver.

Pull the operating lever back -arrow B- to release the hood and hold it in this position.

At the same time pull the lever toward the center of the vehicle horizontally -arrow C-.

Installation

Installation is reverse of removal, but note the following

Slide the clip completely into the operating lever.

Press the operating lever onto the mount in the mounting bracket and engage it.

FLOOR COVERING

Removing

Remove the front seat

1. Standard seat and Sport seat (manually adjustable) as well as front folding seat - passenger seat, refer to «MANUAL STANDARD FRONT SEAT»(/audi/q5/i-2008-2012/remont/seats/#seat-frames) .
2. Standard seat, Sport seat (power) and Comfort seat, refer to «POWER STANDARD FRONT SEAT»(/audi/q5/i-2008-2012/remont/seats/#seat-frames__power-standard-front-seat) .

Remove the rear seats. Refer to SEAT FRAME .

Remove the driver side instrument panel cover. Refer to DRIVER SIDE INSTRUMENT PANEL COVER .

Remove center console. Refer to CENTER CONSOLE .

Remove the center console bracket and lower the shift mechanism. Refer to CENTER CONSOLE BRACKET .

Remove the rear center console vent on the center tunnel. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Remove the front sill panel trim. Refer to FRONT SILL PANEL TRIM .

Remove the B-pillar lower trim. Refer to LOWER B-PILLAR TRIM .

Remove the rear sill panel trim. Refer to REAR SILL PANEL TRIM .

Disengage the floor covering at brackets -1- and -2-.

Scheme 94

Pull the floor covering -3- back.

Note. Make sure the floor covering does not tear at the openings.

Fold the floor covering lengthwise and remove it through a door.

Installation

Fold the floor covering lengthwise and lay it in the vehicle.

First slide the floor covering forward until the air duct and shift mechanism openings are aligned.

Then attach the floor covering at brackets -1- and -2-.

Further installation is performed in the reverse order of removal.

FOOTREST

Special tools and workshop equipment required

1. Removal Wedge 3409

Removing

Scheme 95

Note. The footrest is destroyed during removal and must be replaced.

Remove the driver side instrument panel cover. Refer to DRIVER SIDE INSTRUMENT PANEL COVER .

Remove the front driver side sill panel trim. Refer to FRONT SILL PANEL TRIM .

Unclip the footrest -1- using the 3409 -arrow- and remove it.

Installation

Installation is reverse of removal, but note the following

Replace the footrest and make sure it engages completely in the mounts.

FRONT SILL PANEL TRIM

Special tools and workshop equipment required

Scheme 96

1. Trim removal wedge 3409
2. Removal tool T40280 is needed to remove the clips in the body.

Removing

Scheme 97

Remove the instrument panel side cover. Refer to INSTRUMENT PANEL SIDE COVER .

Remove the A-pillar gap cover. Refer to A-PILLAR GAP COVER .

Driver side

Remove the cable operating lever. Refer to CABLE OPERATING LEVER .

Remove the front sill panel trim screw -2-.

Procedure for both sides of vehicle

Unclip the front sill panel strip -1- from the sill panel beginning at the front using the trim removal wedge 3409 -arrows-.

Pull the front sill panel trim toward the rear and out of the footrest/floor covering.

Disengage the front sill panel trim on the operating lever mount and remove it.

Installing

Install in reverse order of removal. Note the following

Note. If the sill panel trim clamps remain in the body mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Driver side

Engine the front sill panel trim to the operating lever mount and push it into the footrest.

Front passenger side

Slide the front sill panel trim guide into the carpet.

Procedure for both sides of vehicle

Mount the front sill panel trim onto the sill panel and cover the rubber lip with the door seal.

REAR SILL PANEL TRIM

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Pry lever 80 - 200
2. Removal tool T40280 is needed to remove the clips in the body.

Removing

Remove the rear seat. Refer to SEAT FRAME .

Remove the luggage compartment side trim panel. Refer to LUGGAGE COMPARTMENT SIDE TRIM PANEL .

With rear side airbag

Turn on the ignition.

Disconnect the ground cable from the battery with the ignition on. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Remove the screw -1-.

Scheme 98

Carefully pry off the cap -2- with the "airbag" symbol with a screwdriver and remove the screw for the side airbag.

All vehicles

Scheme 99

Unclip the sill panel strip -1- from the sill panel beginning at the front using the pry lever 80 - 200 -arrow A-.

Remove the rear sill trim -arrows B- downward and remove it from the seat belt guide -arrow C-.

Open the flap -2- on the sill trim strip and disengage the seat belt webbing.

With rear side airbag

Scheme 100

Lift the sill trim just enough until it is possible to connect the bracket -1- to the sill trim connector.

Open the bracket, remove the connector and disconnect it.

Push connector lock -3- to stop -arrow- ; this disconnects electrical connection -2- and -4- and it can be removed.

Remove the rear sill trim strip.

Installing

With rear side airbag

Note. Make sure the connectors are installed correctly and are secure.

All vehicles

Install in reverse order of removal. Note the following

Note. If the sill panel trim clamps remain in the body mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Install the sill trim strip into the belt guide and press on it until the audibly latches into the clips.

Fold over the rubber lip on the door seal.

With rear side airbag

Turn on the ignition and connect the battery ground cable. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault, check the DTC memory, erase it and check it again. Refer to Vehicle diagnostic tester.

BATTERY RECESS COVER

Removing

Scheme 101

Remove the spare wheel well trim panel. Refer to SPARE WHEEL WELL TRIM .

Remove the battery recess cover -1-.

Installation

To install, perform the steps used in removal in reverse order.

COAT HOOKS

Special tools and workshop equipment required

1. Pry Lever 80 - 200

Note. Removal and installation are same for right and left.

Removing

Scheme 102

Lift the rear coat hook -1- slightly off the side trim panel using the 80 - 200 -arrow A- and then pull it off toward the rear -arrow B-.

Installation

Install the coat hook into the side trim panel and push it in until it audibly latches.

FRONT BRACKET

Note. Removal and installation are same for right and left.

Removing

Scheme 103

Remove the gap cover

1. Vehicles without a retaining rail. Refer to «GAP COVER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__gap-cover) .
2. Vehicles with retaining rail. Refer to «GAP COVER WITH RAIL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__gap-cover-with-rail) .

Remove the screws -1 and 2- and remove the front bracket -3-.

Installation

To install, perform the steps used in removal in reverse order.

GAP COVER

Note. Removal and installation are same for right and left.

Removing

Scheme 104

Remove the front luggage compartment floor. Refer to FRONT LUGGAGE COMPARTMENT FLOOR .

Remove the dirt shield, if applicable.

Remove the tie-downs. Refer to TIE-DOWNS .

Move the front gap cover -1- to the rear -arrow-, disengage it and remove.

Installation

To install, perform the steps used in removal in reverse order.

GAP COVER WITH RAIL

Note. Removal and installation are same for right and left.

Removing

Scheme 105

Remove the front luggage compartment floor. Refer to FRONT LUGGAGE COMPARTMENT FLOOR WITH RAILS .

Remove the dirt shield, if applicable.

Remove the retaining track. Refer to RETAINING TRACKS .

Move the front gap cover -1- to the rear -arrow-, disengage it and remove.

Installation

To install, perform the steps used in removal in reverse order.

LUGGAGE COMPARTMENT COVER ATTACHMENTS

Note. With version 2, only the D-pillar protection can be replaced. Riveted components cannot be replaced. To repair the attachments in version 1 that are bolted on, there is a repair kit that contains all of the attachments (hinges, mount, attachments for the storage net and the bolts). Just repair the damaged attachment. The mounts and hinges come with positioning aids

Replacing bolted on attachments

1. Luggage compartment removed

Remove the bolts from the damaged attachment. Replace the attachment and install it using the specified torque. Refer to LUGGAGE COMPARTMENT COVER OVERVIEW .

LUGGAGE COMPARTMENT SIDE TRIM PANEL

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Pry lever 80 - 200
2. Trim removal wedge 3409
3. Removal tool T40280 is needed to remove the clips in the body.

Removing

Vehicles with a partition net: remove the partition net.

Fold the backrest forward.

Remove the rear cross panel trim. Refer to REAR CROSS PANEL TRIM .

Remove the gap cover

1. Vehicles without a retaining rail. Refer to «GAP COVER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__gap-cover) .
2. Vehicles with retaining rail. Refer to «GAP COVER WITH RAIL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__gap-cover-with-rail) .

Remove the rear backrest release and let the cable hang down. Refer to BACKREST RELEASE ACTUATOR .

Remove the luggage compartment lamp. Refer to [For engine(s) CAEB, CALB] Interior Lights, Switches .

Remove the coat hook. Refer to COAT HOOKS .

Remove the cover for the luggage compartment side panel.

Scheme 106

Remove the screw -2-.

Pry off the luggage compartment side trim -1- using the pry lever 80 - 200 from the body -arrows A-.

Remove the luggage compartment side trim panel around the D-pillar -arrow B- and the rear sill trim strip -arrow C- using the trim removal wedge 3409.

Installing

Install in reverse order of removal. Note the following

Note. If the trim clamps remain in the body mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Mount the luggage compartment side trim panel and press on it until it audibly latches.

Fold the rubber lip from the rear lid rear lid seal over the luggage compartment trim panel.

FRONT LUGGAGE COMPARTMENT FLOOR

Removing

Scheme 107

Fold the backrests forward.

Remove the rear luggage compartment floor.

Lift the luggage compartment floor at the front -1- -arrow A- and remove it -arrows B-.

Installation

To install, perform the steps used in removal in reverse order.

FRONT LUGGAGE COMPARTMENT FLOOR WITH RAILS

Removing

Scheme 108

Fold the backrests forward.

Remove the rear luggage compartment floor.

Lift the luggage compartment floor at the front -1- -arrow A- and remove it -arrows B-.

Installation

To install, perform the steps used in removal in reverse order.

REAR BRACKET

Note. Removal and installation are same for right and left.

Removing

Scheme 109

Remove the gap cover

1. Vehicles without a retaining rail. Refer to «GAP COVER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__gap-cover) .
2. Vehicles with retaining rail. Refer to «GAP COVER WITH RAIL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__gap-cover-with-rail) .

Remove the screws -1 and 2- and remove the rear bracket -3-.

Installation

To install, perform the steps used in removal in reverse order.

REAR CROSS PANEL TRIM

Special tools and workshop equipment required

1. Pry lever 80 - 200
2. Removal tool T40280 is needed to remove the clips in the body.

Removing

Scheme 110

Remove the rear luggage compartment floor.

Unclip rear cross panel trim -1- upward vertically using a pry lever 80 - 200 -arrows-.

Carefully remove the rear cross panel trim panel upward and disconnect the connector for the rear lid closed sensor 1 -G525- / -G526-.

Installing

Install in reverse order of removal. Note the following

Note. If the trim clamps remain in the body mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Push on the rear cross panel trim until it engages audibly and stretch the lip of the rear lid seal over the rear cross panel trim.

RETAINING TRACKS

Note. Removal and installation are same for right and left.

Removing

Scheme 111

Remove the rear luggage compartment floor.

Remove the bolts -1 and 2- and then remove the retaining track -3-.

Installation

To install, perform the steps used in removal in reverse order.

SCREEN SEPARATOR MOUNT

Note. Removal and installation are same for right and left.

Removing

Scheme 112

Press the cover -1- toward the inside and remove the screws on the screen separator mount -2-.

Installation

To install, perform the steps used in removal in reverse order.

SPARE WHEEL WELL TRIM

Special tools and workshop equipment required

1. Pry Lever 80 - 200

Removing

Scheme 113

Remove the gap cover

1. Vehicles without a retaining rail. Refer to «GAP COVER»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__gap-cover) .
2. Vehicles with retaining rail. Refer to «GAP COVER WITH RAIL»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim__gap-cover-with-rail) .

Remove the rear cross panel trim. Refer to REAR CROSS PANEL TRIM .

Remove the subwoofer, if applicable. Refer to Removal and Installation .

Remove the expanding clips -1 through 6- with the 80 - 200.

Remove the trim panel -7- for the spare wheel well under the luggage compartment side trim panels -arrows-.

Installation

Installation is reverse of removal, but note the following

Install the trim panel -7- for the spare wheel well under the luggage compartment side trim panels -arrows-.

TIE-DOWNS

Note. Removal and installation are same for right and left.

Removing

Scheme 114

Fold the tie-downs -1- upward.

Remove screws -arrows- and remove tie-down mount -2-.

Installation

To install, perform the steps used in removal in reverse order.

LUGGAGE COMPARTMENT FLOOR PANEL, Q5 HYBRID

Removing

Scheme 115

Fold the backrests forward.

Remove the tie downs -1- and -2-, refer to TIE-DOWNS .

Lift up and remove the luggage compartment floor panel and tool box -3- towards the rear.

Installing

Install in reverse order of removal.

FRONT MOUNT, Q5 HYBRID

Removing

Remove the luggage compartment floor panel, refer to LUGGAGE COMPARTMENT FLOOR PANEL, Q5 HYBRID .

Remove the screws -1 and 2- and remove the front bracket -3-.

Installing

Install in reverse order of removal.

REAR MOUNT, Q5 HYBRID

Removing

Remove the luggage compartment floor panel, refer to LUGGAGE COMPARTMENT FLOOR PANEL, Q5 HYBRID .

Left retainer

Scheme 116

Remove the bolts -arrows- and the left bracket -1-.

Right mount

Scheme 117

Unclip the wire holder -1- from the bracket.

Remove the bolts -arrows- and the right mount -2-.

Installing

Install in reverse order of removal.

REAR LID END PANEL TRIM PANEL, Q5 HYBRID

Special tools and workshop equipment required

1. Pry lever 80 - 200
2. Removal tool T40280 is needed to remove the clips in the body.

Removing

Remove the luggage compartment floor panel, refer to LUGGAGE COMPARTMENT FLOOR PANEL, Q5 HYBRID .

Unclip rear cross panel trim -1- upward vertically using a pry lever 80 - 200 -arrows-.

Carefully remove the rear cross panel trim panel upward and disconnect the connector for the rear lid closed sensor 1 -G525- / -G526-.

Installing

Install in reverse order of removal. Note the following

Note. If the trim clamps remain in the body mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Push on the rear cross panel trim until it engages audibly and stretch the lip of the rear lid seal over the rear cross panel trim.

TOOL BOX, Q5 HYBRID

Removing

Scheme 118

Open the cover for the tool box -1- and remove the tools.

Release the tabs -arrows- using a screwdriver pull the tool box upward and out of the luggage compartment floor panel.

Installing

Install in reverse order of removal.

DOOR WINDOW SUN SHADE

Special tools and workshop equipment required

1. Removal Wedge 3409

Note. Removal and installation are same for right and left.

Removing

Scheme 119

Remove the rear door trim. Refer to REAR DOOR TRIM PANEL .

Carefully release the guide strip -2- using the 3409 from the door panel -arrow-.

Pull the sunshade -1- out of the door panel and guide the strap through the guide strip.

Remove bolts -1 through 6- and -8-.

Scheme 120

Remove the sunshade -7- from the door panel by gently swiveling it toward the outside.

Guide the sunshade strap through the gap in the door panel and remove it.

Installation

Installation is reverse of removal, but note the following

The guide strip can only be inserted in one position in door trim.

REAR ARMREST

Special tools and workshop equipment required

1. Removal Wedge 3409

Note. Removal and installation are same for right and left.

Removing

Scheme 121

Remove the rear door trim. Refer to REAR DOOR TRIM PANEL .

Remove the bolts -2 through 8-.

Loosen the armrest -1- from the pull handle -arrow- with the 3409 and remove.

Installation

To install, perform the steps used in removal in reverse order.

REAR DOOR TRIM PANEL

Note. Removing and installing on the left and right sides is identical.

Special tools and workshop equipment required

1. Pliers 3392

Removing

Scheme 122

Switch the ignition off and remove the ignition key.

Remove the trim panel. Refer to TRIM MOLDING .

Remove the bolts -1 through 4-.

Beginning at the bottom rear curve, unclip the door trim from the door using the pliers 3392 by sliding them between the door trim and the door in the securing clip area.

Scheme 123

1. Position of the retaining clips -arrows-.

Pull the door trim panel -1- approximately 15 mm off the door all the way around -arrows A-.

Scheme 124

1. The clips must not be left in the inside the door.

Remove the pull handle -3- upward and out of the clamp -2- at the indicated point on the door trim panel -arrow B-.

Disengage and remove the upper door trim panel from the door on the window recess.

Unlock the bracket -4- from the cable bracket -2- -arrow A-.

Remove inside door release cable -3- from the control cable bracket in -direction of arrow B-.

Disengage the ends of the cable -1- from the inside door release mechanism.

Versions with a treble speaker: Disconnect the treble speaker electrical connector.

Disconnect the connector -1- on the door control module by removing the fuse -2- -arrow- and pressing the release -3-.

Scheme 125

Remove the door trim.

Installing

Engage the ends of the cable -1- in the inside door release mechanism lever.

1. The open side of the eye on the end of the cable must face up.

Pull the door mechanism release cable -3- in -direction of arrow B- and guide it into the cable bracket -2-.

1. Bracket -4- must engage audibly in the control cable bracket.

Connect the connectors on the door control module.

Position the door trim on the window recess and press it down firmly.

Carefully install the door trim panel clip on the door and then press the door trim panel into the clip so that they audibly engage.

Install the pull handle -1- into the bracket -2- until it audibly latches into the door.

Install in reverse order of removal.

REAR PULL HANDLE

Note. Removal and installation are same for right and left.

Removing

Scheme 126

Remove the rear door trim. Refer to REAR DOOR TRIM PANEL .

Remove the rear armrest. Refer to REAR ARMREST .

Remove the bolts -1- and -2-.

Remove the pull handle -1- from the door panel.

Scheme 127

Disconnect the connector -2- on the power window switch.

Installation

To install, perform the steps used in removal in reverse order.

SUN SHADE MOUNT

Removing

Scheme 128

Unscrew screws -1- and remove mount -2- from the window frame.

Installation

To install, perform the steps used in removal in reverse order.

Special tools and workshop equipment required

1. Removal Wedge 3409

Note. Removal and installation are same for right and left.

Removing

Scheme 129

Unclip the treble speaker trim -1- using the 3409 or a screwdriver -arrow- and remove.

Installation

Press the trim on until it engages audibly.

Special tools and workshop equipment required

1. Removal Wedge 3409

Note. Removal and installation are same for right and left.

Removing

Scheme 130

Lower the door window.

Remove the rear door trim. Refer to REAR DOOR TRIM PANEL .

Vehicles equipped with sun shade: remove the sun shade mount. Refer to SUN SHADE MOUNT .

Pry off the window frame trim -1- along the window guide starting at the front end using the 3409 -arrow A-.

Remove the window frame trim from the window frame -arrow B- at the same time.

Remove the window frame trim -1- from the window guide -arrows-.

Scheme 131

Installation

Scheme 132

Install the window frame trim -2- -arrow- into the window guide -1-.

Fold the window frame trim -2- over the window guide -1- ; the window frame trim must fit into the groove -arrow-.

Scheme 133

Pull the 3409 the entire length between the window frame trim -1- and the door seal molding -2- and at the same time push the window frame trim toward the door frame and into the groove inside the window guide.

Scheme 134

Further installation is performed in the reverse order of removal.

EMERGENCY RELEASE COVER

Special tools and workshop equipment required

1. Removal Wedge 3409

Removing

Scheme 135

Place the 3409 on the opening and unclip the emergency release cover -1- from the lower trim panel.

Installation

Press the emergency release cover until it engages audibly.

REAR LID LATCH TRIM PANEL

Removing

Scheme 136

Remove the lower rear lid trim panel. Refer to LOWER REAR LID TRIM PANEL .

Release the tabs -arrows A- with a screwdriver and remove the trim panel -1- the rear lid lock -arrow B-.

Installation

Installation is reverse of removal, but note the following

Press the trim onto the rear lid lock until it engages audibly.

LOWER REAR LID TRIM PANEL

Special tools and workshop equipment required

1. Pry lever 80 - 200
2. Removal tool T40280 is needed to remove the clips in the body.

Removing

Scheme 137

Remove the luggage compartment lamp. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Remove the rear lid lock button in luggage compartment -E406-, where applicable. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Remove the tail lamp covers. Refer to TAIL LAMP COVER .

Remove the emergency triangle and its cover. Refer to WARNING TRIANGLE COVER .

Remove the bolts -1- and -3-.

Remove the lower trim -2- from the rear lid -arrows- by using the pry lever 80 - 200 to loosen the trim clips out of the rear lid.

Grab between the trim and the rear lid and disengage the remaining clips.

Remove the lower rear lid trim panel.

Installing

Scheme 138

Install in reverse order of removal. Note the following

Note. If the trim clamps -1- remain in the rear lid mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Make sure all the rubber buffers -5- are in the trim.

First mount the rear lid lower trim -4- onto the centering pins -2- and -3- and press until it engages audibly.

UPPER REAR LID TRIM PANEL

Special tools and workshop equipment required

1. Pry lever 80 - 200
2. Removal tool T40280 is needed to remove the clips in the body.

Removing

Scheme 139

Remove the lower rear lid trim panel. Refer to LOWER REAR LID TRIM PANEL .

First unclip the upper side trim -1- using the pry lever 80 - 200 from the rear lid -arrows A-.

Then unclip the upper trim using the pry lever 80 - 200 from the rear lid -arrows B- and remove it.

Installing

Scheme 140

Install in reverse order of removal. Note the following

Note. If the trim clamps -2- remain in the rear lid mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Make sure all the rubber buffers -1- are in the trim.

Insert the trim panel first behind the side window frame in the rear lid.

Install the upper rear lid trim first at the top and then along the sides.

TAIL LAMP COVER

Special tools and workshop equipment required

1. Removal Wedge 3409

Removing

Scheme 141

Place the 3409 or a screwdriver -2- on the opening and pry off the cap -1- in -direction of arrow-.

Installation

Press the cap on until it engages audibly.

WARNING TRIANGLE COVER

Removing

Scheme 142

Turn the quick release -1- 90° counter-clockwise, unclip the cover -2- from the lower trim panel and move it in -direction of arrow-.

Disengage the cover on the lower trim and remove it.

Remove the warning triangle from its mount.

Installation

Install the emergency triangle cover -2-, press on it until it audibly latches and then turn the quick release -1- 90° clockwise.

HEADLINER

Special tools and workshop equipment required

1. Pry Lever 80 - 200

Removing

Fold the backrests forward.

Adjust the front seat backrest to a 45° angle

Remove the upper A-pillar trim. Refer to A-PILLAR UPPER TRIM .

Remove the upper B-pillar trim. Refer to UPPER B-PILLAR TRIM .

Remove the C-pillar trim. Refer to C-PILLAR TRIM .

Remove the rear roof panel trim. Refer to ROOF PANEL TRIM .

Remove the D-pillar trim. Refer to D-PILLAR TRIM .

Remove the screen separator mounts. Refer to SCREEN SEPARATOR MOUNT .

Remove sun visors. Refer to SUN VISOR .

Remove the front interior lamp/reading lamp. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Remove the sun visor center bracket. Refer to SUN VISOR CENTER BRACKET .

Remove the roof grab handle. Refer to ROOF GRAB HANDLE .

With a sunroof

Scheme 143

Open the sunroof -1- all the way.

Open the sun shade -2- about 2 / 3 .

Clean 80 - 200 to avoid soiling headliner.

Scheme 144

Let the 80 - 200 slide along between the sunroof opening cover frame -2- and the headliner -1- until it touches one of the clips -3-.

Release the cover frame form the clips one after the other using the 80 - 200 -arrow-, as illustrated.

Remove the bolt -1- in the front interior/reading light roof opening.

Scheme 145

All vehicles

Scheme 146

Note. 2 technicians are needed to disconnect the last connections and remove headliner.

Release the clips -arrows- on the rear centering clip with a small screwdriver.

Lower the headliner on the left side of the vehicle -arrow 1-.

Scheme 147

Remove the headliner through the opening for the rear lid -arrow 2-.

Installation

Note. If the headliner clamps remain in the body mounting points, remove them and insert them in the headliner. Check clamps for damage or deformation, replace if necessary.

Further installation is performed in reverse sequence of removal, but observe the following

Align the headliner and press on the clips on the cover frame for the sunroof opening until they engage audibly.

ROOF GRAB HANDLE

Special tools and workshop equipment required

1. Offset screwdriver

Removing

Scheme 148

Unclip expanding caps -1- and -3- to the locking position using an offset screwdriver -2-.

Remove the roof grab handle -4- from the body opening.

Installation

Insert the grab handle in the body cut-out.

Press the roof grab handle expanding caps on until they engage completely.

ROOF PANEL TRIM

Special tools and workshop equipment required

1. Pry lever 80 - 200
2. Removal tool T40280 is needed to remove the clips in the body.

Removing

Scheme 149

Carefully unclip the rear roof panel trim -1- in the center off the roof frame using the pry lever 80 - 200 -arrow-.

Installing

Scheme 150

Note. If the trim clamps remain in the body mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Mount the rear roof panel trim -1- so that the hooks touch the D-pillar trim.

Position the rear roof panel trim on the pins, then press on it until the clips audibly engage.

ROOF REINFORCEMENT, WITHOUT SUNROOF, ATTACHING TO BODY

Special tools and workshop equipment required

1. AK adhesive D 190 MKD A3

Procedure

Scheme 151

Remove headliner. Refer to HEADLINER .

Apply a bead of adhesive -arrow- onto the roof reinforcement as illustrated.

1. Distance between the adhesive beads -a- = approximately 3.5 inches (90 mm).
2. Distance of the outer bead of adhesive to the edge of the roof reinforcement, dimension -b- = approximately 0.75 inch (20 mm).

Mount the roof reinforcement -1- centered to outer sides and at distance -a- to the bow -2- of the front edge of the roof.

Scheme 152

1. Dimension -a- = approximately 4 inches (100 mm).

Press the roof reinforcement onto the roof from inside.

Install the headliner. Refer to HEADLINER .

SUN VISOR

Removing

Scheme 153

Disengage the sun visor -1- in the center of the vehicle from at the sun visor center bracket -2-.

Unclip the expanding cap -3- using a screwdriver.

Tilt the sun visor bracket down -arrow- and remove it.

Vehicles with illumination: Disconnect the connector and remove the sun visor.

Installation

Installation is reverse of removal, but note the following

Engage the sun visor bracket tab in the opening in the headliner.

Press the sun visor expanding cap on until it engages completely.

SUN VISOR CENTER BRACKET

Special tools and workshop equipment required

1. Pry Lever 80 - 200

Removing

Scheme 154

Disengage the sun visor in the center of the vehicle at the center bracket and fold it to the side.

Unclip the sun visor center bracket cover -1- by sliding the 80 - 200 only approximately 1 mm under the cap -2 arrows-.

Note. If the 80 - 200 is shoved further underneath, it will then be under the center bearing for the sun visor. At that point, it is not possible to pry off the cover.

Remove sun visor center bracket -3- -arrow 4-.

Installation

Make sure the expanding clips are not damaged when inserting the sun visor center bracket.

Press the cap -1- on until it engages audibly.

Removing

Remove the screws -1- and remove mount -2- from the window frame.

Installing

Install in reverse order of removal.

Scheme 155

Scheme 156

1. Pliers 3392
2. Removal Wedge 3409
3. Hook 3438
4. Pry Lever 80 - 200
5. Special Ignition Lock Pliers VAS 6339

See also:
• [For engine(s) CAEB, CALB] Removal and Installation
• Removal and Installation
• CENTER CONSOLE OVERVIEW
• DRIVER SIDE INSTRUMENT PANEL COVER
• STEERING COLUMN SWITCH MODULE UPPER TRIM PANEL
• STEERING COLUMN SWITCH MODULE LOWER TRIM PANEL
• GENERAL INFORMATION
• GLOVE COMPARTMENT
• [For engine(s) CAEB, CALB] Removal and Installation
• FRONT PASSENGER AIRBAG IGNITER 1 AND 2 N131/N132
• [For engine(s) CAEB, CALB] Removal and Installation
• [For engine(s) CAEB, CALB] Removal and Installation
• [For engine(s) CAEB, CALB] Removal and Installation
• Removal and Installation
• BACKREST RELEASE OVERVIEW
• BACKREST RELEASE ACTUATOR
• Removal and Installation
• [For engine(s) CAEB, CALB] Removal and Installation
• INSTRUMENT CLUSTER GAP COVER
• Removal and Installation
• [For engine(s) CAEB, CALB] Removal and Installation
• FRONT BELT ANCHOR
• BELT HEIGHT ADJUSTER
• OUTER REAR BELT GUIDE
• MANUAL STANDARD FRONT SEAT
• POWER STANDARD FRONT SEAT
• CENTER CONSOLE BRACKET
• SIDE AIRBAG SAFETY PRECAUTIONS
• AIRBAG, BELT TENSIONER AND BATTERY CUT-OUT UNITS, STORAGE, TRANSPORTING AND DISPOSAL
• FRONT DOOR TRIM PANEL
• TRIM MOLDING
• WINDOW FRAME TRIM
• TREBLE SPEAKER TRIM
• INSIDE DOOR RELEASE MECHANISM
• DRIVER MEMORY SEAT CONTROL HEAD E97
• REAR LID REMOTE UNLOCK SWITCH TRIM
• MID-RANGE SPEAKER TRIM
• FRONT PULL HANDLE WITH SWITCH MOUNT
• FRONT ARMREST
• SIDE INSTRUMENT PANEL VENT
• SIDE SPEAKER TRIM
• CENTER SPEAKER TRIM
• TOP CENTER DEFROSTER VENT
• INSTRUMENT PANEL TRIM
• MMI SCREEN
• CENTER INSTRUMENT PANEL VENT
• SWITCH FOR ACCESS/START AUTHORIZATION, TRIM PANEL
• RADIO AND NAVIGATION SYSTEM FRAME
• MOUNTING BRACKET
• GLOVE COMPARTMENT BRACKET
• GLOVE COMPARTMENT RETAINERS
• RIGHT IMPACT ABSORBER
• LEFT IMPACT ABSORBER
• REAR SILL PANEL TRIM
• LOWER B-PILLAR TRIM
• UPPER B-PILLAR TRIM
• A-PILLAR UPPER TRIM
• FRONT SILL PANEL STRIP ASSEMBLY OVERVIEW
• A-PILLAR GAP COVER
• FOOTREST
• FLOOR COVERING
• FRONT SILL PANEL TRIM
• C-PILLAR TRIM
• D-PILLAR TRIM
• CABLE OPERATING LEVER
• SPARE WHEEL WELL TRIM
• REAR CROSS PANEL TRIM
• GAP COVER
• RETAINING TRACKS
• LUGGAGE COMPARTMENT SIDE TRIM PANEL
• LUGGAGE COMPARTMENT COVER ATTACHMENTS
• FRONT LUGGAGE COMPARTMENT FLOOR
• FRONT LUGGAGE COMPARTMENT FLOOR WITH RAILS
• TIE-DOWNS
• FRONT BRACKET
• REAR BRACKET
• GAP COVER WITH RAIL
• COAT HOOKS
• BATTERY RECESS COVER
• SCREEN SEPARATOR MOUNT
• REAR MOUNT, Q5 HYBRID
• LUGGAGE COMPARTMENT FLOOR PANEL, Q5 HYBRID
• TOOL BOX, Q5 HYBRID
• FRONT MOUNT, Q5 HYBRID
• REAR DOOR TRIM PANEL
• REAR PULL HANDLE
• REAR ARMREST
• DOOR WINDOW SUN SHADE
• LOWER REAR LID TRIM PANEL
• UPPER REAR LID TRIM PANEL
• TAIL LAMP COVER
• WARNING TRIANGLE COVER
• EMERGENCY RELEASE COVER
• REAR LID LATCH TRIM PANEL
• HEADLINER
• ROOF REINFORCEMENT, WITHOUT SUNROOF, ATTACHING TO BODY
• ROOF PANEL TRIM
• ROOF GRAB HANDLE
• SUN VISOR
• SUN VISOR CENTER BRACKET
• INSTRUMENT PANEL SIDE COVER
• SUN SHADE MOUNT
