Speech Input Control Module J507 , removing and installing Audi A8 D3 рестайлинг

Communication 1 illustration ~317 words

Speech Input Control Module J507 , removing and installing

  1. If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine.

Use the Vehicle Diagnosis, Testing and Information System VAS 5051 to do so.

CAUTIONSwitch off all electrical components. Switch off ignition and remove ignition key.

Removing

  1. Remove Radio R --> «Radio R , removing and installing»(/audi/a8/d3-2005-2007/remont/accessories-control-systems/#communication__radio-r-removing-and-installing) .

Scheme 148

Scheme 148
Scheme 148
  1. Open cover - 2 - of Radio R and fold it downward - arrow -.
  2. Carefully pull Speech Input Control Module J507 - 1 - out of Radio R in - direction of arrow -.

Installing

  1. Install in reverse order.
  2. Make sure that harness connector between Speech Input Control Module J507 and Radio R engages correctly in Radio R.

Perform the following function test

  1. Switch on Radio R.
  2. Press PTT button briefly on multi-function steering wheel.

A "ping" tone sounds, the speech dialog system is active.

  1. Speak the command "Help"

Since the Radio R is active, the speech dialog system responds with "Radio commands are...".

Can be switched to other sources, depending on equipment

  1. If a telephone is installed, say "Telephone".

The speech dialog system changes to Telephone mode.

  1. Press the PPT button for approx. 1 second.

The speech dialog system responds with "Cancel" and is deactivated.

The "Rear Seat Entertainment system" consists of

  1. Rear DVD Changer R162 with remote control
  2. Monitors in headrests of front seats
  3. Headphone connections in rear center console
  4. Connections for video or game consoles in rear center console

The playback of picture and sound information of Rear DVD Changer R162 is also performed via the MMI and the vehicle sound system.

If TV Tuner R78 is installed, playback may be viewed on all displays.

DVD navigation can also be played back over the additional monitors in the headrests.

Additional information RSE operating instructions.

Repairing fiber optic cables --> 97 - WIRING .

Repairs on antenna wires --> 97 - WIRING .
