Multi-function steering wheel, layout Audi A8 D3 рестайлинг

Multi-function steering wheel, layout

Scheme 138

1 - Multifunction Steering Wheel

1. With Multi-function Steering Wheel Control Module J453 under right button
2. Removing and installing multi-function buttons --> «Multi-function buttons, removing and installing»(/audi/a8/d3-2005-2007/remont/accessories-control-systems/#communication__multi-function-buttons-removing-and-installing)
3. Removing and installing Tiptronic switch --> «Tiptronic Switch, removing and installing»(/audi/a8/d3-2005-2007/remont/accessories-control-systems/#communication__tiptronic-switch-removing-and-installing)

2 - Steering Column Electronic Systems Control Module J527

1. On steering column at steering column switches
2. Removing and installing --> «94 - LIGHTS, SWITCHES - EXTERIOR»(/audi/a8/d3-2005-2007/remont/cruise-control-systems/#electrical-equipment)

3 - Data Bus On Board Diagnostic Interface J533

1. Behind glove compartment

4 - Media Player, Position 1 R118

1. In glove compartment

5 - Media Player, Position 2 R119

1. In glove compartment

6 - Radio R

1. Behind luggage compartment left side trim
2. With Speech Input Control Module J507

7 - Front Information Display Control Head Control Module J523

1. Behind glove compartment

8 - Telephone Transceiver R36

1. In foot well, beneath floor mat

9 - Digital Sound System Control Module J525

1. behind luggage compartment left side trim

10 - Sound system

11 - Microphone Unit (in front roof module) R164

1. Overview --> «Microphone Unit (in front roof module) R164 , overview»(/audi/a8/d3-2005-2007/remont/accessories-control-systems/#communication)

12 - Navigation System with CD Drive Control Module J401

1. Behind luggage compartment left side trim

13 - TV Tuner R78

1. Behind luggage compartment left side trim

14 - CAN-Bus (Comfort)
