Horn Audi A8 D3 рестайлинг 2

Electrical Equipment 4 illustrations ~330 words

Horn

Observe notes on contact corrosion --> Contact Corrosion .

Signal Horn/Dual Tone Horn, Removing and Installing

Removing

  1. Switch off ignition and remove ignition key.

Vehicles with double grille

Scheme 111

Scheme 111
Scheme 111
  1. Remove bolts - arrows - on top of lock carrier and below Audi rings.

Scheme 112

Scheme 112
Scheme 112
  1. Spray silicone-free lubricant into the gap between radiator grille and bumper cover.
  2. Pull the radiator grille - 1 - first in the places marked with - arrows A - out of the bumper cover.
  3. Next, pull the radiator grille down at - arrows B - out of the bumper cover.

Vehicles with single frame grille

  1. Remove bumper cover --> «63 - BUMPERS»(/audi/a8/d3-2-2007-2010/remont/door-locks-anti-theft-systems/#body-exterior) .

All Vehicles

Scheme 113

Scheme 113
Scheme 113
  1. Disconnect connectors - 1 -.
  2. Remove nut - 2 - and remove Signal Horn/Dual Tone Horn H1 from bracket.

Installing

Install in reverse order of removal, observing the following

Vehicles with gasoline engine

Scheme 114

Scheme 114
Scheme 114
  1. Make sure that outlet opening of signal horns - 1 - and - 9 - are aligned horizontally to the bumper, align if necessary.
  2. Connect electrical connections - 8 - and - 10 - to signal horns.
  3. Secure electrical wiring harness - 7 - to rear of signal horns with cable ties - 6 -.

Note. Ignore - arrows - and - items 2 through 7 -.

Vehicles with double grille

  1. The radiator grille must engage into the bumper cover audibly.

Vehicles with single frame grille

  1. Install bumper cover --> «63 - BUMPERS»(/audi/a8/d3-2-2007-2010/remont/door-locks-anti-theft-systems/#body-exterior) .

Tightening Specifications

ComponentNm
Signal Horn/Dual Tone Horn H1 to bracket11
Radiator grille to lock carrier4

Contact corrosion can occur if incorrect fasteners (bolts, nuts, washers, etc.) are used.

For this reason, only fasteners with a special surface coating are used.

In addition, rubber or plastic parts and adhesive consist of non-conductive materials.

If there are doubts as to whether parts are suitable or not, use new parts .

Note. We only recommend original replacement parts, they have been tested and are compatible with aluminum. We recommend using Audi accessories. Damage resulting from contact corrosion is not covered by warranty.
