BELT TENSION

Serpentine belt tension is automatically adjusted by tensioner.

DRIVE BELT ROUTING

Note. Serpentine belt is self-adjusting. For drive belt routing (Scheme 10)

Scheme 10

Scheme 10: DRIVE BELT ROUTING

BRUSHES

Remove generator. See GENERATOR under REMOVAL & INSTALLATION. Remove voltage regulator from back of generator. See VOLTAGE REGULATOR under REMOVAL & INSTALLATION. Brushes are integrated with voltage regulator. Brush wear limit is 0.2" (5 mm).

1997-99

Before disconnecting the battery, please read the following

  1. Determine the correct coding for the anti-theft radio
  2. Turn ignition OFF.
  3. Disconnect battery ground cable.
  4. After reconnecting the battery cable, the ECM "Basic Setting" must be re-established using the VAG 1551 scan tool, or equivalent aftermarket scan tool.
  5. In the initial learning phase after establishing basic setting, engine idle and driveability may be affected. In this case, let the engine run at idle for a few minutes until the learning process is completed.

2000-03

Before disconnecting the battery, please read the following

  1. Determine the correct coding for the anti-theft radio
  2. Turn ignition OFF.
  3. Disconnect battery ground cable.
  4. On vehicles equipped with Audi Telematics by OnStar, switch-off the emergency (back-up) battery for the Telematic/Telephone Control Module prior to disconnecting vehicle battery. After reconnecting vehicle battery on vehicles equipped with Audi Telematics by OnStar, switch-on the emergency (back-up) battery for the Telematic/Telephone Control Module. The emergency (back-up) battery is mounted behind the Telephone/Telematic Control Module (under rear parcel shelf). (Scheme 11)
  5. After reconnecting vehicle battery, re-code and check operation of anti-theft radio.
  6. Check operation of clock and power windows.

Scheme 11

Scheme 11

VOLTAGE REGULATOR

Note. Manufacturer does not provide specific procedures for removal and installation of voltage regulator. As an aid in removal and installation (Scheme 12)or (Scheme 13).

Scheme 12

Scheme 12: VOLTAGE REGULATOR

Scheme 13

Scheme 13
