General Information

Power steering pump is not designed to be serviced. If a customer has reported a problem, determine cause via the pressure test and leak test. If there is a problem, replace the power steering pump.

Oil circulation in Right Hand Drive (RHD) vehicles is identical to Left Hand Drive (LHD) vehicles except that the hydraulic lines are routed from left to right at the steering gear.

Note. If power steering fluid is low in the reservoir, check the steering system for leaks. In case of leaks near line connections, check lines/line connections for proper seal, if necessary tighten and wipe dry. Replacement pumps from the distribution center do not contain any fluid. Before installing, fill pump with G 002 000 hydraulic oil and turn pump by hand. Otherwise, the pump may be noisy when operating or may even get damaged. Oil type: G 002 000 hydraulic fluid

The following list pertains to (Scheme 1).

  1. Power steering gear Assembly Overview, see «POWER STEERING GEAR, ASSEMBLY OVERVIEW»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) Servicing, see «STEERING GEAR, SERVICING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  2. Expansion hose Tighten union nut to 40 Nm (at item 19) while counterholding hex bolt.
  3. Return hose
  4. Cover with dipstick Check fluid level. See «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  5. Hex bolt,9 Nm
  6. Power steering fluid reservoir Capacity 0.85L
  7. Rubber bushing
  8. Return hose Located between power steering fluid reservoir and cooling line
  9. Intake hose Installation position, see «INSTALLATION POSITION, INTAKE HOSE AT POWER STEERING FLUID RESERVOIR, VALID FOR ALL ENGINES»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) Markings must align
  10. Clamp Tighten using VAG1275
  11. Clamp Tighten using VAG1275
  12. Combination bolt 9 Nm
  13. Cooling line
  14. Line Marking must align with the intake hose marking
  15. Intake hose Marking -P- faces toward pump
  16. Power steering pump Before installing, fill with power steering fluid. See «POWER STEERING / OIL CIRCULATION FOR 6-CYLINDER ENGINE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) , Notes: Check delivery pressure. See «POWER STEERING PUMP, ASSEMBLY OVERVIEW»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) . Assembly overview. See «POWER STEERING PUMP, ASSEMBLY OVERVIEW»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  17. Seal, 16 22 Always replace
  18. Banjo fitting, 47 Nm M16 x 1.5
  19. Expansion hose Partial section with line, goes to steering gear
  20. Hex bolt, 6 Nm M6 x 20
  21. Coolant line
  22. Hex-nut, tighten to 20 Nm. M8 Secures expansion hose to coolant line
  23. Sheet-metal screw and washer assembly 2 Nm
  24. Heat shield
  25. Spring nut 1.3 Nm

The marking on intake hose -1- must align with the seam on the power steering fluid reservoir.

Scheme 1

Scheme 1: Installation position, intake hose at power steering fluid reservoir, valid for all engines
Scheme 1: Installation position, intake hose at power steering fluid reservoir, valid for all engines

Special tools and equipment

  1. 3094 hose clamps
  2. VAG1402 power steering tester

Testing pressure

  1. Unclip upper part of engine cover and remove.
  2. Pinch off intake line and return line using 3094 hose clamps.
  3. Unbolt line from expansion hose (arrow), counterhold hex bolt of expansion hose.
  4. Bolt VAG1402 pressure gauge to part of expansion hose that leads to power steering pump.
  5. Close shut-off on pressure gauge (lever faces toward left)
  6. Remove 3094 hose clamps.
  7. If necessary, add fluid to power steering fluid reservoir.

Check pressure

Note. To avoid damaging the pump, note the following: Do not allow the engine to run more than 10 seconds during the test. Start the engine without depressing the accelerator pedal and let the engine idle. Make a note of the pressure immediately after starting the engine when it is idling (this may require a second technician). As the pressure drops during the check, the highest pressure is definitive. Specification: 110 - 120 bar

  1. Turn engine off. If specification is not obtained, replace the power steering pump. See «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  2. Check fluid level. See «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  3. Bleed steering system. See «STEERING SYSTEM, BLEEDING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  4. Check steering system for leaks. See «STEERING SYSTEM, CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .

Vehicles with 5-valve 6-cylinder gasoline engine

Note. Always replace seals Do not reuse fluid you have drained. Hydraulic fluid: Part No. G 002 000

The following list pertains to (Scheme 9).

  1. Expansion hose Partial section with line, goes to steering gear
  2. Hex bolt, 6 Nm
  3. Hex bolt, 9 Nm
  4. Ignition coils with brackets
  5. Power steering pump Before installing, fill with power steering fluid. See «POWER STEERING / OIL CIRCULATION FOR 6-CYLINDER ENGINE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) , Notes: Check delivery pressure. See «DELIVERY PRESSURE OF POWER STEERING PUMP, CHECKING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) . Removing and installing, see «POWER STEERING PUMP, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  6. Clamp Always replace Tighten using VAG1275
  7. Intake hose Marking -P- faces toward pump
  8. Line for intake hose
  9. Socket head bolt, 22 Nm Rear mount for power steering pump to bracket
  10. Bushing, slotted Used to balance out tolerances
  11. Socket head bolt, 22 Nm Mounting of power steering pump bracket to crankcase
  12. Socket head bolt, 22 Nm Mounting of power steering pump bracket to crankcase
  13. Socket head bolt, 22 Nm Front mounting of power steering pump to bracket
  14. Bracket for power steering pump
  15. Socket head bolt, 22 Nm Use 3212 special tool to counterhold when loosening or tightening
  16. Belt pulley
  17. Seal Always replace
  18. Banjo fitting, 47 Nm
  1. 3094 hose clamp
  2. 3204 drift
  3. 3212 spanner wrench
  4. 3312 Open-end wrench
  5. VAG1331 torque wrench Measurement range: 5 to 50 Nm. VAG1332 torque wrench Measurement range: 40 to 200 Nm.
  1. V.A.G1275 hose clamp pliers

Scheme 2

Scheme 2: Removing
Scheme 2: Removing

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9
  1. Unclip upper part of engine cover and remove.
  2. Remove bolts for air duct for air cleaner housing at front apron and lift air duct out.
  3. Disconnect 5-pin connector from ignition coils.
  4. Disconnect three rear connectors -A- from ignition coils.
  5. Remove 4 mounting bolts.
  6. Swing ignition coil bracket toward rear.
  7. Counterhold pulley for viscous fan using 3212 spanner wrench and remove viscous fan using 3312 open-end spanner (FAN HAS LEFT HAND THREADS).
  8. Lift viscous fan up and out.
  9. Remove electric fan by first removing bolt -1
  10. The wiring for electric fan is secured to air guide of the viscous fan using clips. Remove these clips
  11. To remove clips, turn electric fan slightly in direction of (arrow).
  12. Move electric fan aside to right. NOTE: Before removing ribbed belt, note direction of rotation with chalk or felt-tip marker. Reversing the direction of rotation of a run-in belt can destroy the belt. When installing the ribbed belt, make sure it is seated correctly on the pulleys. Turn tensioner toward right using a long torque wrench and 17 mm socket insert. When both bores align (arrows), secure using 3204 drift Remove ribbed belt from belt pulley. Unbolt belt pulley for power steering pump, counterhold with 3212 spanner wrench. Pinch off intake line and return line using 3094 hose clamps. The line for the expansion hose is bolted to cylinder head. See «POWER STEERING PUMP, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) , item no. 20. Remove these bolts. Open clamp -1- and remove intake hose. Unbolt expansion hose -2-. Unbolt power steering pump bracket. Remove pump together with bracket. Unbolt power steering pump from bracket.

When installing, pay particular attention to the following points

Note. Before installing a new pump, fill intake side with hydraulic fluid and turn pump by hand until fluid comes out the pump side. Clean any areas in engine compartment covered with fluid.

Scheme 10

Scheme 10: When installing, pay particular attention to the following points
Scheme 10: When installing, pay particular attention to the following points
  1. Bolt pump to bracket and tighten to 22 Nm.
  2. Install pump together with bracket.
  3. First tighten front two bolts, and then rear two bolts to 22 Nm.
  4. Install new seals on banjo fitting.
  5. Tighten banjo fitting for expansion hose -2- to 47 Nm.
  6. Bolt line for expansion hose to cylinder head and tighten to 6 Nm. See «POWER STEERING PUMP, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) , item no. 20.
  7. Install intake hose -1- with marking -P- facing toward pump
  8. Remove 3094 hose clamps.
  9. Tighten hex-socket bolts for power steering pump belt pulley to 22 Nm.
  10. First install ribbed belt onto crankshaft pulley and idler wheel. Push belt onto tensioning roller last. NOTE: Note previously marked direction of rotation of belt and be sure that it is seated correctly on pulley. Routing of ribbed belt: D1 - without air conditioning D2 - with air conditioning
  11. Remove 3204 drift.
  12. First install electric fan and then viscous fan.
Tightening MethodTorque
1331 torque wrench and 3312 open-end wrench (1)37 Nm
Torque wrench without 3312 open-end wrench (1)70 Nm
(1) Fan has LEFT-HAND threads.
(1)Fan has LEFT-HAND threads.

TIGHTENING TORQUE FOR VISCOUS FAN (6-CYLINDER ENGINE)

  1. Check fluid level. See «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  2. Bleed steering system. See «STEERING SYSTEM, BLEEDING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  3. Check steering system for leaks. See «STEERING SYSTEM, CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .

Power steering pump is not designed to be serviced. If a customer has reported a problem, determine cause via the pressure test and leak test. If there is a problem, replace the power steering pump.

Oil circulation in Right Hand Drive (RHD) vehicles is identical to Left Hand Drive (LHD) vehicles except that the hydraulic lines are routed from left to right at the steering gear.

Note. If power steering fluid is low in reservoir, check steering system for leaks. In case of leaks near line connections, check lines/line connections for proper seal, if necessary tighten and wipe dry. Replacement pumps from the distribution center do not contain any fluid. Before installing, fill pump with G 002 000 hydraulic oil and turn pump by hand. Otherwise, the pump may be noisy when operating or may even get damaged. Oil type: G 002 000 hydraulic fluid

The following list pertains to (Scheme 27).

  1. Power steering gear Assembly Overview, see «POWER STEERING GEAR, ASSEMBLY OVERVIEW»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) Servicing, see «STEERING GEAR, SERVICING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  2. Return hose
  3. Expansion hose Partial section with line, goes to steering gear
  4. Heat shield
  5. Cover with dipstick Check fluid level. See «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  6. Hex bolt, 9 Nm
  7. Power steering fluid reservoir Capacity 0.85L
  8. Rubber bushing
  9. Return hose Located between power steering fluid reservoir and cooling line
  10. Intake hose Installation position see «INSTALLATION POSITION, INTAKE HOSE AT POWER STEERING FLUID RESERVOIR, VALID FOR ALL ENGINES»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) Markings must align
  11. Clamp Tighten using VAG1275
  12. Clamp Tighten using VAG1275
  13. Rubber buffer
  14. Hex-nut, tighten to 9 Nm. M6
  15. Cooling line
  16. Sleeve
  17. Screw and washer assembly, 9 Nm
  18. Torx bolts (T25) 5 Nm M5 x 12
  19. Line Marking must align with intake hose marking
  20. Intake hose Marking -P- must align with flash on pump
  21. Power steering pump Before installing, fill with power steering fluid. See «POWER STEERING / OIL CIRCULATION FOR 6-CYLINDER ENGINE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) , Notes: Check delivery pressure. See «DELIVERY PRESSURE OF POWER STEERING PUMP, CHECKING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) Assembly overview, see «POWER STEERING PUMP, ASSEMBLY OVERVIEW»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  22. Seal, 16 22 Always replace
  23. Banjo fitting, 47 Nm M16 x 1.5
  24. Expansion hose Partial section with line, goes to steering gear
  25. Hex bolt, 7.5 Nm M8 x 15
  26. Union nut Tighten to 40 Nm while counterholding hex bolt. Markings must align with each other
  27. Sheet-metal screw and washer assembly 2 Nm
  28. Heat shield
  29. Spring nut 1.3 Nm

The marking on intake hose -1- must align with the seam on power steering fluid reservoir.

Scheme 11

Scheme 11: Installation position, intake hose at power steering fluid reservoir, valid for all engines
Scheme 11: Installation position, intake hose at power steering fluid reservoir, valid for all engines
  1. VAG1921 hose clip pliers
  2. VAG1402 power steering tester
  3. VAG1402/3 adapter

Pressure checking

  1. Open hose clamps (arrows) and remove intake hose -1-.
  2. Remove union nut -2- while counterholding hex bolt on pressure line.
  3. Use plug to plug line to steering gear.
  4. Screw VAG1402/3 adapter into line to power steering pump.
  5. Install hose from VAG1402 pressure gauge on VAG 1402/3 adapter.
  6. Close shut-off valve on pressure gauge (lever faces toward left).
  7. Reinstall intake hose.
  8. If necessary, add fluid to the power steering fluid reservoir.

Check pressure

Note. To avoid damaging pump, note the following: Do not allow the engine to run more than 10 seconds during the test. Start engine without depressing accelerator pedal and let engine idle. Make a note of pressure immediately after starting engine when it is idling (this may require a second technician). As pressure drops during check, the highest pressure is definitive.

Audi A 6

  1. Specification: 120-130 bar positive pressure.

Audi allroad

  1. Specification: 120-130 bar positive pressure.
  1. Turn engine off. If specification is not obtained, replace the power steering pump. See «POWER STEERING PUMP, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  2. Check fluid level. See «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  3. Bleed steering system. See «STEERING SYSTEM, BLEEDING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  4. Check steering system for leaks. See «STEERING SYSTEM, CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .

Vehicles with 6-cylinder gasoline engine, BiTurbo

Note. Always replace seals Do not reuse fluid you have drained. Hydraulic fluid: Part No. G 002 000

The following list pertains to (Scheme 32).

  1. Expansion hose Partial section with line, goes to steering gear
  2. Hex bolt, 7.5 Nm M8 x 15
  3. Power steering pump Before installing, fill with power steering fluid. See «POWER STEERING / OIL CIRCULATION FOR 6-CYLINDER ENGINE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) , Notes" Check delivery pressure. See «DELIVERY PRESSURE OF POWER STEERING PUMP, CHECKING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) . Removing and installing. See «POWER STEERING PUMP, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  4. Clamp Tighten using VAG1275
  5. Intake hose Marking -P- must align with flash on pump
  6. Line
  7. Socket head bolt, 22 Nm Rear mount for power steering pump to bracket
  8. Bushing, slotted Used to balance out tolerances
  9. Bracket for power steering pump
  10. Socket head bolt, 22 Nm Mounting of power steering pump bracket to crankcase
  11. Socket head bolt, 22 Nm Front mounting of power steering pump to bracket
  12. Hex bolt, 22 Nm Mounting of power steering pump bracket to crankcase
  13. Socket head bolt, 22 Nm Use 3212 special tool to counterhold when loosening or tightening
  14. Belt pulley
  15. Seal Always replace
  16. Banjo bolt, 47 Nm
  1. 3094 hose clamp
  2. 3204 drift
  3. 3212 spanner wrench
  4. 3312 Open-end wrench
  5. VAG1331 torque wrench Measurement range: 5 to 50 Nm. VAG1332 torque wrench Measurement range: 40 to 200 Nm.
  1. VAG1275 hose clamp pliers

Removing

  1. Remove bumper. See «FRONT BUMPER»(/audi/a6/c5-1997-2001/remont/exterior-body-panels/#bumper) .
  2. Bring lock carrier into service position. See «LOCK CARRIER, SERVICE POSITION»(/audi/a6/c5-1997-2001/remont/exterior-body-panels/#body-front__lock-carrier-service-position) .
  3. Remove bolts (arrows) and remove front cover.

Note. The viscous fan has a LEFT-HAND THREAD, unbolt in direction of (arrow).

Scheme 12

Scheme 12
Scheme 12
  1. Counterhold viscous fan pulley using -3212 spanner wrench and remove viscous fan using -3312 open-end wrench.
  2. Lift viscous fan up and out. NOTE: Before removing ribbed belt, note direction of rotation with chalk or felt-tip marker. Reversing the direction of rotation of a run-in belt can destroy the belt. When installing the ribbed belt, make sure it is seated correctly on the pulleys.
  3. To loosen ribbed belt, turn clockwise using 17 mm box wrench until two holes are aligned (arrow). Counterhold in position using 3204 drift.
  4. Remove ribbed belt from belt pulley.
  5. Remove pressure line -1-. NOTE: Pay attention to retaining strips -2-.
  6. Unbolt belt pulley for power steering pump, counterhold with 3212 spanner wrench.
  7. Pinch off intake line using 3094 hose clamp.
  8. Disconnect harness connector at charge air pressure sensor -G31- (arrow).
  9. Remove rubber shroud -1-.
  10. Open clamp (arrow) and disconnect intake hose from pump.
  11. Unbolt pressure line -1-.
  12. Unbolt bracket for power steering pump, items -2-, -3-, and -4-.
  13. Remove pump together with bracket.
  14. Unbolt power steering pump from bracket.

Note. Before installing a new pump, fill intake side with hydraulic fluid and turn pump by hand until fluid comes out the pump side. Clean any areas in engine compartment covered with fluid.

Scheme 13

Scheme 13: When installing, pay particular attention to the following points
Scheme 13: When installing, pay particular attention to the following points
  1. Bolt pump to bracket.
  2. First tighten front two bolts, and then rear two bolts to 22 Nm.
  3. Install pump together with bracket.
  4. Install new seals on banjo bolt.
  5. Tighten banjo bolt for pressure line -1- to 50 Nm. see scheme 43
  6. Install intake hose, marking -P- must align with flash on pump
  7. Remove 3094 hose clamps.
  8. Tighten hex-socket bolts for power steering pump belt pulley to 22 Nm. TIGHTENING TORQUE FOR VISCOUS FAN (2.7L 6-CYLINDER BITURBO ENGINE) Tightening Method Torque 1331 torque wrench and 3312 open-end wrench (1) 37 Nm Torque wrench without 3312 open-end wrench (1) 70 Nm (1) Fan has LEFT-HAND threads.
  9. Install lock carrier. «LOCK CARRIER WITH ATTACHMENTS, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/exterior-body-panels/#body-front__lock-carrier-with-attachments-removing-and).
  10. Install bumper. See «FRONT BUMPER»(/audi/a6/c5-1997-2001/remont/exterior-body-panels/#bumper).
  11. Check fluid level. See «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering).
  12. Bleed steering system. See «STEERING SYSTEM, BLEEDING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering).
  13. Check steering system for leaks. See «STEERING SYSTEM, CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering).

Power steering pump is not designed to be serviced. If a customer has reported a problem, determine cause via the pressure test and leak test. If there is a problem, replace the power steering pump.

Oil circulation in Right Hand Drive (RHD) vehicles is identical to Left Hand Drive (LHD) vehicles except that the hydraulic lines are routed from left to right at the steering gear.

Note. If power steering fluid is low in the reservoir, check the steering system for leaks. In case of leaks near line connections, check lines/line connections for proper seal, if necessary tighten and wipe dry. Replacement pumps from the distribution center do not contain any fluid. Before installing, fill pump with G 002 000 hydraulic oil and turn pump by hand. Otherwise, the pump may be noisy when operating or may even get damaged. Oil type: G 002 000 hydraulic fluid

The following list pertains to see scheme 44.

  1. Power steering gear Assembly Overview, see «POWER STEERING GEAR, ASSEMBLY OVERVIEW»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) Servicing, see «STEERING GEAR, SERVICING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  2. Return hose Steering gear - power steering fluid cooler
  3. Pressure line Tighten union nut to 40 Nm (at item 4) while counterholding hex bolt. Note installation position At steering gear, see «INSTALLATION POSITION, RETURN LINE AND PRESSURE LINE AT STEERING GEAR, FOR LEFT HAND DRIVE (LHD) VEHICLES»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  4. Expansion hose Power steering pump - steering gear Note installation position: At power steering pump, see «INSTALLATION POSITION, INTAKE AND EXPANSION HOSES TO POWER STEERING PUMP»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  5. Cover with dipstick Check fluid level. See «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  6. Hex bolt, 9 Nm
  7. Power steering fluid reservoir Capacity 0.85L
  8. Rubber bushing
  9. Return hose Located between power steering fluid reservoir and cooling line Installation position Restrictor (arrow) faces power steering fluid reservoir
  10. Banjo bolt, 47 Nm M16x1.5
  11. Seals Always replace
  12. Intake hose Power steering pump - power steering fluid reservoir Note installation position: At power steering pump, see «INSTALLATION POSITION, INTAKE AND EXPANSION HOSE AT POWER STEERING PUMP»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) At power steering fluid reservoir, see «INSTALLATION POSITION, INTAKE HOSE AT POWER STEERING FLUID RESERVOIR, VALID FOR ALL ENGINES»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  13. Banjo fitting, 47 Nm M18x1.5
  14. Seals Always replace
  15. Clamp Tighten using VAG1275
  16. Power steering fluid cooler
  17. Phillips-head screw 2.5 Nm
  18. Power steering pump Before installing, fill with power steering fluid. Notes, see «POWER STEERING / OIL CIRCULATION FOR 8-CYLINDER ENGINE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) Assembly overview, see «POWER STEERING / OIL CIRCULATION FOR 8-CYLINDER ENGINE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  19. Spring nut 1.3 Nm
  20. Sheet-metal screw and washer assembly 2 Nm
  21. Heat shield Different version for vehicles with parking heater
  22. Heat shield

Expansion hose

  1. Angle -a- : approx. 57°

Intake line

  1. Angle -b- : approx. 90°

Pressure line

  1. Angle -a- : approx. 45°

Return hose

  1. Angle -b- : approx. 116°

The marking on intake hose -1- must align with the seam on the power steering fluid reservoir.

Scheme 14

Scheme 14: Installation position, intake hose at power steering fluid reservoir, valid for all engines
Scheme 14: Installation position, intake hose at power steering fluid reservoir, valid for all engines
  1. 3094 hose clamp
  2. VAG1402 power steering tester
  3. VAG1402/3 adapter
  1. Remove cover for power steering fluid reservoir.
  2. Pinch off intake line using 3094 hose clamp.
  3. Unbolt expansion hose from power steering pump.
  4. Install VAG 1402/3 adapter on power steering pump in place of the banjo bolt.
  5. Install hose from VAG1402 pressure gauge on VAG 1402/3 adapter.
  6. Close shut-off valve on pressure gauge (lever faces toward left).
  7. Remove 3094 hose clamp and add fluid to power steering fluid reservoir if necessary.

Check pressure

Note. To avoid damaging pump, note the following: Do not allow engine to run more than 10 seconds during the test. Start engine without depressing the accelerator pedal and let engine idle. Make a note of pressure immediately after starting engine when it is idling (this may require a second technician). As pressure drops during check, the highest pressure is definitive.

Specification: 120-130 bar

  1. Turn engine off. If specification is not obtained, replace the power steering pump. See «POWER STEERING PUMP, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  2. Check fluid level. See «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  3. Bleed steering system. See «STEERING SYSTEM, BLEEDING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  4. Check steering system for leaks. See «STEERING SYSTEM, CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .

Vehicles with 8-cylinder gasoline engine

Note. Always replace seals Do not reuse fluid you have drained. Hydraulic fluid: Part No. G 002 000 When replacing the power steering pump always check alignment of the pulleys for A/C compressor and power steering pump.

The following list pertains to see scheme 53.

  1. Screw and washer assembly, 22 Nm
  2. Bracket
  3. Socket head bolt, 22 Nm Rear mount for power steering pump to bracket
  4. Bushing, slotted Used to balance out tolerances
  5. Expansion hose Power steering pump - steering gear Note installation position: Angle -a- : approx. 75°
  6. Banjo bolt, 47 Nm
  7. Seals Always replace
  8. Intake hose Power steering pump - power steering fluid reservoir Note installation position: Angle -b- : approx. 90°
  9. Banjo bolt, 47 Nm
  10. Power steering pump Before installing, fill with power steering fluid. Notes, see «POWER STEERING / OIL CIRCULATION FOR 8-CYLINDER ENGINE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) . Check delivery pressure. See «DELIVERY PRESSURE OF POWER STEERING PUMP, CHECKING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) . Removing and installing, see «POWER STEERING PUMP, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  11. Shims Choose shims so that pulleys for A/C compressor and power steering pump align. Check alignment of ribbed belt. See «CHECK AND ADJUST ALIGNMENT OF PULLEY»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering__check-and-adjust-alignment-of-pulley)
  12. Belt pulley
  13. Socket head bolt, 22 Nm Use 3212 special tool to counterhold when loosening or tightening
  1. 3094 hose clamp
  2. 3201 alignment gauge
  3. 3212 spanner wrench
  4. VAG1331 torque wrench Measurement range: 5 to 50 Nm. VAG1332 torque wrench Measurement range: 40 to 200 Nm.

Scheme 15

Scheme 15: Removing
Scheme 15: Removing
  1. Remove bolts (arrows) and remove engine covers -A- and -B
  2. Remove cover -C- from power steering fluid reservoir.
  3. Disconnect green connector for A/C clutch / A/C compressor and remove the lower part of the connector from the bracket.
  4. Open cable tie down (arrow) on line to A/C compressor and let line hang free.
  5. Remove right toothed belt cover.
  6. Cover sharp corners with tape.
  7. Remove electric fan by removing bolt (arrow).
  8. Pull sealing lip away from front end slightly in area near electric fan.
  9. To remove clips, turn electric fan slightly in direction of (arrow).
  10. Move electric fan to side.
  11. Pinch off intake line using 3094 hose clamp.
  12. Remove noise insulation panel NOTE: Before removing ribbed belt, note direction of rotation with chalk or felt-tip marker. Reversing the direction of rotation of a run-in belt can destroy the belt. When installing the ribbed belt, make sure it is seated correctly on the pulleys.
  13. Remove clamp from refrigerant line.
  14. Move tensioner in direction of (arrow) to release tension on ribbed belt.
  15. Remove ribbed belt and release tensioning roller.
  16. Pinch off return lines using 3094 hose clamp.
  17. Place pan underneath vehicle to collect hydraulic fluid.
  18. Unbolt expansion hose -1- and intake hose -2- from pump.
  19. Seal connection holes using plugs.
  20. Remove bolt -3- for power steering pump/bracket.
  21. Unbolt belt pulley for power steering pump, counterhold with 3212 spanner wrench.
  22. Unbolt pump from bracket and remove downward and out.

Note. Before installing a new pump, fill intake side with hydraulic fluid and turn pump by hand until fluid comes out the pump side. Clean areas in engine compartment contaminated with fluid. Installation position, expansion hose, see CHECK AND ADJUST ALIGNMENT OF PULLEY Installation position, intake hose, see INSTALLATION POSITION INTAKE LINE

  1. Place pump in bracket from below and hand-tighten all three bolts.
  2. Install expansion and intake hoses with new seals, but do not tighten all the way.
  3. Tighten two front bolts.

Note. The front of the belt pulley is marked "front".

Scheme 16

Scheme 16
Scheme 16
  1. Bolt on belt pulley for power steering pump, counterhold with 3212 spanner wrench.

Check and adjust alignment of pulley

  1. Install 3201 level on A/C compressor pulley.
  2. Pulley for power steering pump must align with pulley for A/C compressor. If the two pulleys do not align
  3. Unbolt pulley for power steering pump.
  4. Use shims available as replacement parts to adjust distance between two pulleys until they align.

Installation position expansion hose

  1. Angle -a- : approx. 57°
  1. Align expansion hose and tighten.
  2. Install electric fan.
  3. Route line for A/C clutch - A/C compressor and connect.
  4. Remove adhesive tape.
  5. Install covers for toothed belt, power steering fluid reservoir, and engine.
  6. Tighten rear bolt on power steering pump.

Installation position intake line

  1. Angle -b- : approx. 90°
  1. Align intake line and tighten.
  2. Remove 3094 hose clamps.

Scheme 17

Scheme 17: Installation position ribbed belt
Scheme 17: Installation position ribbed belt
  1. First install ribbed belt onto crankshaft pulley and idler wheel. Push belt onto tensioning roller last. NOTE: Note previously marked direction of rotation of belt and be sure that it is seated correctly on pulley.
  2. Swing tensioner in direction of (arrow).
  3. Position ribbed belt and release tensioning roller again.
  4. Install clamp for refrigerant line.
  5. Check fluid level. See «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  6. Bleed steering system. See «STEERING SYSTEM, BLEEDING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  7. Check steering system for leaks. See «STEERING SYSTEM, CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  8. Install noise insulation panel

General Information

Power steering pump is not designed to be serviced. If a customer has reported a problem, determine cause via the pressure test and leak test. If there is a problem, replace the power steering pump.

Oil circulation in Right Hand Drive (RHD) vehicles is identical to Left Hand Drive (LHD) vehicles except that the hydraulic lines are routed from left to right at the steering gear.

Note. If power steering fluid is low in the reservoir, check the steering system for leaks. In case of leaks near line connections, check lines/line connections for proper seal, if necessary tighten and wipe dry. Replacement pumps from the distribution center do not contain any fluid. Before installing, fill pump with G 002 000 hydraulic oil and turn pump by hand. Otherwise, the pump may be noisy when operating or may even get damaged. Oil type: G 002 000 hydraulic fluid

Scheme 18

Scheme 18: Special tools and equipment
Scheme 18: Special tools and equipment
  1. 10-222 A Support bar
  2. 2024 A/2 Plate
  3. V.A.G 1358 A or V.A.G 1782
  4. T40045 (plastic)
  5. T40045 (6.5 mm plastic pads for edges of wing)
  6. Bolt M10 x 15 mm

Scheme 19

Scheme 19: Removing
Scheme 19: Removing
  1. Remove rear engine cover (arrows)
  2. Extract power steering hydraulic fluid from reservoir using V.A.G 1358 A or V.A.G 1782.
  3. Attach plate 2024 A/2 to rear left engine lifting eye. Screw out bolt at plate and replace with bolt M10 x 15 mm with packing plate.
  4. Remove rubber seal at wing mounting flanges.
  5. To stop support bar from damaging edges of wing, insert special tool T40045on either side between wing mounting flange and splash panel beneath.
  6. Position support bar 10-222 A on wing mounting flanges.
  7. Engage plate 2024 A/2 at spindle of support bar.
  8. Slightly pre-tension engine with spindle of support bar, but do not lift.
  9. Unscrew left front wheel.
  10. Screw out bolts (arrows) for exhaust pipe of auxiliary/additional heater at noise insulation, on vehicles with auxiliary heater.
  11. Unfasten quick-release fasteners -1- to -3- and detach noise insulation (2 sections).
  12. Remove heat shield -1- for drive axle on left.
  13. Remove left drive axle. See «AXLE SHAFTS - FRONT & REAR»(/audi/a6/c5-1997-2001/remont/axle-shafts/#axle-shafts-front-rear) .
  14. Unscrew nuts -1- to -4- for stabilizer bar mounting on left and right.
  15. Unscrew nuts -3-.
  16. Remove bolts -1- and -2- and detach engine bracket.
  17. Disconnect connector -1- at left engine mounting.
  18. Unscrew nut -2- and detach engine mounting. NOTE: Illustration shows engine removed.
  19. Remove bolts -1- and -2-.
  20. Remove return line from power steering pump (arrow).
  21. Unscrew hydraulic pressure line at power steering pump (arrow).
  22. Set aside hydraulic pressure line.
  23. Remove left engine support (arrows).
  24. Disconnect connector -2- at Speedometer Vehicle Speed Sensor (VSS) -G22-. NOTE: Ignore item -1-.
  25. Loosen lock nut -3- by several turns.
  26. Screw out as far as possible stud bolt -4-.
  27. Screw out bolts -1- and -2- and detach power steering pump.

Pay particular attention to the following on installation

  1. In engine compartment clean areas contaminated with fluid.
  2. Before installing new power steering pump, pour in hydraulic fluid on intake end and crank by hand until fluid emerges on discharge end.
  3. Replace O-ring on drive shaft of power steering pump.
  4. Replace oil seals.
  5. Secure all hose connections with standard hose clamps.

See Parts Catalog

  1. Install engine bracket and screw on subframe (see «SUBFRAME & SUBFRAME BUSHINGS»(/audi/a6/c5-1997-2001/remont/suspension-front/#suspension-front) ).
  2. Install stabilizer bar ( «STABILIZER BAR & BUSHINGS»(/audi/a6/c5-1997-2001/remont/suspension-front/#suspension-front) ).
  3. Install drive axle. See «AXLE SHAFTS - FRONT & REAR»(/audi/a6/c5-1997-2001/remont/axle-shafts/#axle-shafts-front-rear) .
  4. Check hydraulic fluid level. See «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  5. Bleed power steering system. See «STEERING SYSTEM, BLEEDING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  6. Check power steering system for leaks. See «STEERING SYSTEM, CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .

Tightening torques

ComponentNm
Power steering pump to engine22
Stud bolt to power steering pump40
Lock nut to stud bolt65
Engine support to cylinder block42
Hydraulic pressure line to power steering pump47
Return lineeEngine support10
ToCoolant pipe10
Engine mountingEngine support23
ToEngine bracket23
Heat shield for drive axle to transmission23

Torque Specifications - Power Steering Pump (8-Cylinder Engine With Chain Drive)

Power steering pump is not designed to be serviced. If a customer has reported a problem, determine cause via the pressure test and leak test. If there is a problem, replace the power steering pump.

Oil circulation in Right Hand Drive (RHD) vehicles is identical to Left Hand Drive (LHD) vehicles except that the hydraulic lines are routed from left to right at the steering gear.

Note. If power steering fluid is low in the reservoir, check the steering system for leaks. In case of leaks near line connections, check lines/line connections for proper seal, if necessary tighten and wipe dry. Replacement pumps from the distribution center do not contain any fluid. Before installing, fill pump with G 002 000 hydraulic oil and turn pump by hand. Otherwise, the pump may be noisy when operating or may even get damaged. Oil type: G 002 000 hydraulic fluid

The following list pertains to see scheme 94.

  1. Power steering gear Assembly overview, see «POWER STEERING GEAR, ASSEMBLY OVERVIEW»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) Servicing, see «STEERING GEAR, SERVICING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  2. Return hose Steering gearing - power steering fluid cooler
  3. Pressure line Tighten union nut to 40 Nm (at item 4 while counterholding hex bolt. Note installation position: At steering gear, see «INSTALLATION POSITION, RETURN LINE AND PRESSURE LINE AT STEERING GEAR, FOR LEFT HAND DRIVE (LHD)VEHICLES»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  4. Expansion hose Power steering pump - steering gear Note installation position: At power steering pump, see «INSTALLATION POSITION, INTAKE AND EXPANSION HOSES TO POWER STEERING PUMP»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  5. Cover with dipstick Check fluid level, see «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  6. Hex bolt, 9 Nm
  7. Power steering fluid reservoir
  8. Rubber bushing
  9. Return hose Located between power steering fluid reservoir and cooling line Installation position: Restrictor (arrow) faces power steering fluid reservoir
  10. Banjo bolt, 47 Nm M16x1.5
  11. Seals Always replace
  12. Intake hose Power steering pump - power steering fluid reservoir Heed installation position: At vane pump, see «INSTALLATION POSITION, INTAKE AND EXPANSION HOSE AT POWER STEERING PUMP»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) At fluid reservoir, see «INSTALLATION POSITION, INTAKE HOSE AT POWER STEERING FLUID RESERVOIR, VALID FOR ALL ENGINES»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  13. Banjo bolt, 50 Nm M18x1.5
  14. Seals Always replace
  15. Clamp Tighten using V.A.G 1275
  16. Power steering fluid cooler
  17. Bolt 1.5 Nm
  18. Power steering pump Before installing fill with fluid, see Notes in «POWER STEERING / OIL CIRCULATION FOR 8-CYLINDER ENGINE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) Checking delivery pressure. See «DELIVERY PRESSURE OF POWER STEERING PUMP, CHECKING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) . Assembly overview, see «POWER STEERING PUMP, ASSEMBLY OVERVIEW»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  19. Spring nut 1.3 Nm
  20. Sheet-metal screw and washer assembly 2 Nm
  21. Heat shield Different version for vehicles with parking heater
  22. Heat shield
  1. Expansion hose Angle -a- : approx. 74°
  2. Suction pipe Angle -b- : approx. 90°
  1. Pressure pipe Angle -a- : approx. 45°
  2. Return hose Angle -b- : approx. 116°
  1. The marking on intake hose -1- must align with the seam on the power steering fluid reservoir.
  1. 3094 Hose clamp
  2. V.A.G 1402 Power steering tester
  3. V.A.G 1402/3 Adapter
  1. Remove underbody guard.
  2. Detach cover from fluid reservoir.
  3. Unclip connector unit (arrow).
  4. Lift off connector unit.
  5. Unfasten both hose clamps and remove air hose (arrow).
  6. Unfasten both hose clamps (arrows) and remove air hose.
  7. Install VAG 1402/3 adapter on power steering pump in place of the banjo bolt.
  8. Install hose from VAG1402 pressure gauge on VAG 1402/3 adapter.
  9. Close shut-off valve on pressure gauge (lever faces toward left).
  10. Remove 3094 hose clamp and fluid to power steering fluid reservoir if necessary.
  11. Re-attach lower air hose.

Note. Engine is not to be started without lower air hose installed, to avoid damaging turbocharger.

Checking pressure

To avoid damaging pump, note the following

  1. Do not allow the engine to run more than 10 seconds during the test.
  2. Start engine without depressing accelerator pedal and let engine idle.
  3. Make a note of pressure immediately after starting engine when it is idling (this may require a second technician).
  4. As pressure drops during check, the highest pressure is definitive. Specification: 120 - 130 bar
  1. Turn engine off. If specification is not obtained, replace the power steering pump. See «POWER STEERING PUMP, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  2. Check fluid level. See «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  3. Bleed steering system. See «STEERING SYSTEM, BLEEDING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  4. Check steering system for leaks. See «STEERING SYSTEM, CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .

Vehicles with 8-cyl. engine, biturbo

Note. Always replace seals Do not reuse fluid you have drained. Hydraulic fluid: Part No. G 002 000 When replacing the power steering pump always check alignment of the pulleys for A/C compressor and power steering pump.

The following list pertains to see scheme 105.

  1. Sheet-metal screw and washer assembly, 22 Nm
  2. Bracket
  3. Socket-head bolt, 22 Nm Rear mount for power steering pump to bracket
  4. Slotted bushing For tolerance compensation
  5. Expansion hose Power steering pump - steering gear Note installation position: Angle -a- : approx. 75°
  6. Banjo bolt, 47 Nm
  7. Seals Always replace
  8. intake hose Power steering pump - fluid reservoir Note installation position: Angle -b- : approx. 90°
  9. Banjo bolt, 50
  10. Power steering pump Fill with fluid before installing. See «POWER STEERING / OIL CIRCULATION FOR 8-CYLINDER ENGINE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) , Notes: Checking delivery pressure, see «DELIVERY PRESSURE OF POWER STEERING PUMP, CHECKING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) . Removing and installing, see «POWER STEERING PUMP, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  11. Shims Choose shims so that pulleys for A/C compressor and power steering pump align. Check alignment of ribbed belt. See «CHECK AND ADJUST ALIGNMENT OF PULLEY»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering__check-and-adjust-alignment-of-pulley) .
  12. Belt pulley
  13. Socket-head bolt, 22 Nm Use 3212 special tool to counterhold when loosening or tightening
  1. 3094 Hose clamp
  2. 3201 Alignment gauge
  3. 3204 Drift
  4. 3212 Pin wrench
  5. V.A.G 1331 Torque wrench Measuring range: 5...50 Nm V.A.G 1332 Torque wrench Measuring range: 40...200 Nm

Scheme 20

Scheme 20: Removing
Scheme 20: Removing
  1. Pull lock carrier forward. See «LOCK CARRIER, SERVICE POSITION»(/audi/a6/c5-1997-2001/remont/exterior-body-panels/#body-front__lock-carrier-service-position) .
  2. Disconnect connector -5- at charge air pressure sensor -G31-.
  3. Unfasten hose clamps -3- and -4-.
  4. Detach hoses at air recirculation valves.
  5. Screw out bolts -1- and -2- and detach air line.
  6. Remove air hose (arrows). NOTE: Before removing ribbed belt, note direction of rotation with chalk or felt-tip marker. Reversing the direction of rotation of a run-in belt can destroy the belt. When installing the ribbed belt, make sure it is seated correctly on the pulleys.
  7. To loosen ribbed belt swing tensioner in direction of (arrow).
  8. Insert drift 3204 into locating holes (arrow) to lock tensioners.
  9. Detach ribbed belt from power steering pump pulley.
  10. Remove bolts (arrows) from power steering pump ribbed belt pulley.
  11. Counterhold with pin wrench 3212, when loosening and tightening bolts (arrows).
  12. Take connectors (arrows) out of holder.
  13. Remove holder for connectors.
  14. Use hose clamps 3094 to pinch off hydraulic hoses. NOTE: Place cloth under disconnection points to catch hydraulic fluid.
  15. Disconnect intake hose -1- and expansion hose -2- at power steering pump.
  16. Remove bolts (arrows-).
  17. Take out power steering pump.
  1. Before installing a new pump, fill intake side with hydraulic fluid and turn pump by hand until fluid comes out the pump side.
  2. Clean areas in engine compartment contaminated with fluid.
  3. Installation position of expansion hose, see «INSTALLATION POSITION OF RIBBED BELT»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering__installation-position-of-ribbed-belt)
  4. Installation position of suction hose, see «INSTALLATION POSITION OF RIBBED BELT»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering__installation-position-of-ribbed-belt)
  5. Replace oil seals and O-rings.
  6. Secure all hose connections with standard hose clamps.

See Parts Catalog

Scheme 21

Scheme 21
Scheme 21
  1. Place pump in bracket and screw in all three bolts (arrows).
  2. Install expansion and intake hoses with new seals, but do not tighten all the way. NOTE: The front of the belt pulley is marked "front".
  3. Screw on power steering pump pulley while counterholding with pin wrench - 3212-.

Checking and adjusting pulley alignment

  1. Position alignment gauge 3201 on ribbed belt pulley of air conditioner compressor. Ribbed belt pulley of power steering pump must coincide with ribbed belt pulley of air conditioner compressor If the two ribbed belt pulleys do not coincide
  2. Align ribbed belt pulleys for power steering pump and air conditioner compressor by installing 0.5, 1.0 and 1.5 mm thick shims. For Part no., see Parts Catalog.
  3. Check alignment of ribbed belt pulleys again with alignment gauge 3201. Repeat adjustment if necessary.
  4. Installation position of intake line Angle -b- : approx. 90°
  5. Align and tighten intake line.
  6. Installation position of expansion hose Angle -a- : approx. 75deg
  7. Align and tighten expansion hose.
  8. Detach hose clamps -3094-.

Installation position of ribbed belt

  1. First position ribbed belt over crankshaft pulley and other pulleys and then on tensioning roller last. NOTE: Make sure ribbed belt is properly seated on pulleys, when installing ribbed belt.
  2. Install ribbed belt and loosen tensioning roller again.

Note. Replace O-ring for front air line. Before installing hose connections and hoses for charge air system must be free from oil and grease. Never use lubricant.

  1. Check hydraulic fluid level. See «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  2. Bleed steering system. See «STEERING SYSTEM, BLEEDING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  3. Check steering system for leaks. See «STEERING SYSTEM, CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  4. Check belt routing and start engine.
  5. Install lock carrier. See «LOCK CARRIER, SERVICE POSITION»(/audi/a6/c5-1997-2001/remont/exterior-body-panels/#body-front__lock-carrier-service-position) .
ComponentNm
Power steering pump to bracket22
Pulley to power steering pump22
Hydraulic lineM1650
To power steering pumpM1847
Front air line to cylinder block9
Clamps for air hoses5

Torque Specifications - Power Steering Pump (8-Cylinder Engine Bi-Turbo)

For vehicles through model year 1998

Note. For vehicles from model year 1999, see FOR VEHICLES FROM MODEL YEAR 1999 .

The following list pertains to see scheme 123.

  1. Hex bolt, 67 Nm
  2. Boot seal Check for tears and scuffing
  3. Eccentric bolt Torx T50 To release tension, turn clockwise. To tension, turn counterclockwise.
  4. Steering column
  5. Self-locking hex nut, 30 Nm Always replace
  6. Screw and washer assembly, 7 Nm For adjusting toe-in
  7. Bolt
  8. Self-locking nut, 45 Nm Always replace
  9. Return hose
  10. Expansion hose
  11. Cylinder bolt, 13 Nm Locking screw for centering steering, see «LOCKING SCREW FOR CENTERING STEERING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  12. Power steering gear with tie rods Removing and installing, see «POWER STEERING GEAR, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) Servicing, see «STEERING GEAR, SERVICING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  13. Banjo bolt, 40 Nm With integrated checkvalve
  14. Seal, 14 x 20 Always replace
  15. Banjo bolt, 47 Nm
  16. Seal, 16 x 22 Always replace
  17. Hex bolt, 35 Nm
  18. Outer steering shock absorber Only for 6- cylinder models
  19. Socket
  20. Rubber bushing Two-piece
  21. Hex-nut, tighten to 10 Nm. To loosen and tighten, counterhold hex bolt on piston rod for steering shock absorber.
  1. Locking bolt for centering steering, 13 Nm.
  2. Thread hole in steering gear

For vehicles from model year 1999

Note. For vehicles through model year 1998 (inclusive), see POWER STEERING GEAR, ASSEMBLY OVERVIEW .

The following list pertains to see scheme 125.

  1. Hex bolt, 67 Nm
  2. Boot seal Check for tears and scuffing
  3. Eccentric bolt Torx T50 To release tension, turn clockwise. To tension, turn counterclockwise.
  4. Steering column
  5. Self-locking hex nut, 30 Nm Always replace
  6. Screw and washer assembly, 7 Nm For adjusting toe-in
  7. Bolt
  8. Self-locking nut, 45 Nm Always replace
  9. Steering knuckle from wheel bearing housing
  10. Pressure line Tighten union nut to 40 Nm. See item no. 4 on «POWER STEERING GEAR, ASSEMBLY OVERVIEW»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) Note installation position: At steering gear, see «INSTALLATION POSITION, RETURN LINE AND PRESSURE LINE AT STEERING GEAR, FOR LEFT HAND DRIVE (LHD) VEHICLES»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  11. Return hose Note installation position: At steering gear, see «INSTALLATION POSITION, RETURN LINE AND PRESSURE LINE AT STEERING GEAR, FOR LEFT HAND DRIVE (LHD) VEHICLES»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  12. Cylinder bolt, 13 Nm Locking screw for centering steering, see «LOCKING SCREW FOR CENTERING STEERING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  13. Power steering gear with tie rods Removing and installing, see «POWER STEERING GEAR, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) Servicing, see «STEERING GEAR, SERVICING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  14. Seal, 16 x 22 Always replace
  15. Banjo bolt, 47 Nm
  16. Seal, 14 x 20 Always replace
  17. Banjo bolt, 40 Nm With integrated checkvalve
  1. Locking bolt for centering steering, 13 Nm.
  2. Thread hole in steering gear

Pressure line

  1. Angle -a-: approx. 45°

Return hose

  1. Angle -b-: approx. 116°

Scheme 22

Scheme 22
Scheme 22
  1. 3094 hose clamps
  2. VAG1907 bolt for centering steering

Before beginning repairs on the electrical system

CAUTIONBefore beginning repairs on the electrical system: Obtain the anti-theft radio security code. Switch the ignition off. Disconnect the battery Ground (GND) strap. On vehicles equipped with Audi Telematics by OnStar®, switch-off the emergency (back-up) battery for the Telematic/Telephone Control Module prior to disconnecting vehicle battery. See EMERGENCY BATTERY, SWITCHING OFF/ON . After reconnecting vehicle battery, re-code and check operation of anti-theft radio. Also check operation of clock and power windows according to Repair Manual and/or Owner's Manual. After reconnecting vehicle battery on vehicles equipped with Audi Telematics by OnStar®, switch-on the emergency (back-up) battery for the Telematic/Telephone Control Module. See EMERGENCY BATTERY, SWITCHING OFF/ON .

Scheme 23

Scheme 23: Removing
Scheme 23: Removing

Scheme 24

Scheme 24
Scheme 24
  1. Remove plenum chamber cover.
  2. Remove battery.
  3. Remove driver's side storage compartment. See «DRIVER'S STORAGE COMPARTMENT, REMOVING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__drivers-storage-compartment-removing)
  4. Put wheels in straight-ahead position
  5. Remove nut -1- at universal joint.
  6. Release tension on eccentric bolt by turning adjusting bolt (Torx T50) clockwise and remove bolt.
  7. Swing universal joint to side.
  8. Remove ignition key when steering wheel is centered.
  9. Move steering wheel slightly to engage steering lock. NOTE: If the steering wheel is turned too much with the steering gear removed, the spiral spring from the airbag may get turned too far and damaged.
  10. Pinch off intake line and return line using 3094 hose clamps.
  11. Remove front wheels.
  12. Remove hex bolt -1- and bolt -2-.
  13. Remove tie rod.
  14. Remove nut -1-. see scheme 134
  15. Pry out clip -2-.
  16. Remove cover. NOTE: Shown without wheel bearing housing and strut for the sake of illustration. Work outline only valid for 2.7 BiTurbo
  17. Lower subframe at rear. Work outline, see «6 SPD. MANUAL TRANSMISSION 01E - TRANSMISSION REMOVAL»(ref-233085)
  18. Removing left exhaust pipe See appropriate Exhaust System article.
  19. Remove shielding panel. Work outline is valid for all vehicles
  20. Place pan underneath vehicle to collect hydraulic fluid.
  21. Unbolt banjo bolt for return hose (22 mm wrench) from steering gear.
  22. Unbolt banjo bolt for pressure hose (19 mm wrench) from steering gear.
  23. For vehicles with servotronic, disconnect connector from servotronic valve.
  24. Unbolt mounting points -1-, -2-, and -3- from steering gear.
  25. Remove steering gear through left wheel housing (second technician required).

Installing

Use VAG1907 to removed center steering gear.

Scheme 25

Scheme 25: Installing
Scheme 25: Installing
  1. Remove socket-head bolt -1- from steering gear.
  2. Move rack until centering position on rack (arrow) aligns with thread -2-.
  3. Hand-tighten VAG1907.
  4. Pay attention to bulkhead boot. NOTE: Always replace damaged seals. Check seal for proper seating!
  5. Position steering gear on plenum. NOTE: Make sure threads and contact surfaces of bolts are free of oil and grease.
  6. Install bolts -1- and -2-, but do not tighten. see scheme 139
  7. Screw in bolt -3- and tighten.
  8. Tighten bolts -1- and -2-. see scheme 139
  9. Screw on return hose and tighten banjo bolt (22 mm wrench) to 50 Nm.
  10. Screw on pressure hose and tighten banjo fitting (19 mm wrench) to 40 Nm.
  11. Release steering lock.
  12. Center steering wheel, then install universal join on steering pinion.
  13. Install adjusting bolt (Torx T50) and tighten counterclockwise.
  14. Unbolt VAG1907 tool from steering gear. 1 - Socket head bolt 2 - Thread bore in steering gear
  15. Seal steering gear using hex socket bolt - 1-; Tighten to 13 Nm.
  16. Tighten hex nut for adjusting bolt to 30 Nm.
  17. Install driver's side storage compartment.
  18. Install wheel housing cover.
  19. After completing installation of steering gear, remove 3094 hose clamps
  20. For the 2.7 BiTurbo, secure exhaust pipe, shielding panel and subframe. See «EXHAUST SYSTEM COMPONENTS, REMOVING AND INSTALLING»(ref-196252-S16273128932005100700000). See Caution for connecting Telematics battery in «REMOVING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering).
  21. Install battery.
  22. Check fluid level. See «POWER STEERING FLUID LEVEL, CHECKING; STEERING SYSTEM, BLEEDING AND CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering).
  23. Bleed steering system. See «STEERING SYSTEM, BLEEDING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering).
  24. Check steering system for proper seal. See «STEERING SYSTEM, CHECKING FOR LEAKS»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering).
  25. Check alignment. See «SPECIFICATIONS & PROCEDURES»(/audi/a6/c5-1997-2001/remont/wheel-alignment/#specifications-procedures).
  1. Remove engine. See «ENGINE, REMOVING AND INSTALLING»(ref-196257-S42209693462005100700000) .
  2. Detach shields.
  3. Further removal operations are the same as for all other vehicles, see «INSTALLING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering__installing) .

Scheme 26

Scheme 26: Installing
Scheme 26: Installing
  1. Installation is the same as for all other vehicles, see «INSTALLING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering__installing) .
  2. Attach shields. Tightening torque: 2 Nm
  3. Install engine. See «ENGINE, REMOVING AND INSTALLING»(ref-196257-S42209693462005100700000) .

This overview is valid for both Left Hand Drive (LHD) and Right Hand Drive (RHD) vehicles.

Note. Always replace self-locking nuts and bolts. Welding or straighten work on any steering components is not permissible. To grease the rack, only use steering gear grease AOF 063 000 04. Hydraulic fluid: Part No. G002 000

The following list pertains to see scheme 142.

  1. Tie rod end Check dust caps for damage and proper seating
  2. Hex-nut, tighten to 40 Nm.
  3. Spring clip Open using VAG1921
  4. Boot Check for damage Must not be twisted after toe is adjusted
  5. Clamp Tighten using VAG1275 Always replace
  6. Inner tie rod ball joint, 100 Nm Grease joint using steering gear grease A0F 063 000 04.
  7. Sealing ring Always replace
  8. Power steering gear Grease rack using steering gear grease A0F 063 000 04. Different versions with and without steering dampers, see Parts Catalog
  9. Cylinder bolt, 13 Nm Locking screw for centering steering

This overview is valid for both Left Hand Drive (LHD) and Right Hand Drive (RHD) vehicles.

Note. Always replace self-locking nuts and bolts. Welding or straighten work on any steering components is not permissible. To grease the rack, only use steering gear grease AOF 063 000 04. Hydraulic fluid: Part No. G 002 000

The following list pertains to see scheme 143.

  1. Tie rod end Check dust caps for damage and proper seating Version with and without ring, only new version available as replacement part
  2. Hex-nut, tighten to 40 Nm.
  3. Spring clip Open using VAG1921
  4. Boot Check for damage Must not be twisted after toe is adjusted
  5. Clamp Tighten using VAG1275 Always replace
  6. Sealing ring Always replace
  7. Inner tie rod ball joint, 100 Nm Grease joint using steering gear grease A0F 063 000 04.
  8. Bracket for steering damper
  9. Sealing ring Always replace
  10. Dished washer
  11. Clamp Tighten using VAG1275 Always replace
  12. Boot Check for damage
  13. Power steering gear Grease rack using steering gear grease A0F 063 000 04.
  14. Hex-nut, tighten to 10 Nm. To loosen and tighten, counterhold hex bolt on piston rod for steering damper.
  15. Socket
  16. Rubber bushing Two-piece
  17. Steering damper
  18. Hex bolt, 35 Nm
  19. Cylinder bolt, 13 Nm Locking screw for centering steering

Servotronic, assembly overview

The following list pertains to see scheme 144.

  1. Power steering gear with tie rods Assembly Overview, see «POWER STEERING GEAR, ASSEMBLY OVERVIEW»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering)
  2. Connector for servotronic
  3. Relay carrier, 13-pin Located under trim in driver's footwell See appropriate System Wiring Diagrams article. Relay for servotronic control module - J236- (position 13) Checking voltage supply, see «SERVOTRONIC, CHECKING VOLTAGE SUPPLY»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) Checking speed signal, see «SPEED SIGNAL, CHECKING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering__speed-signal-checking)
  4. Socket-head bolt, 3 Nm 2.5 mm NOTE: Do not open Torx bolts!
  5. Servotronic solenoid valve - N119- Steering gear must be removed to replace servotronic valve. Checking, see «SERVOTRONIC VALVE, CHECKING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering__servotronic-valve-checking) NOTE: DO NOT open Torx bolts!
  6. Seal Always replace
  7. Seal Always replace
  8. Sieve Always replace

Servotronic, servicing

  1. For vehicles with servotronic, the power steering contribution is electronically regulated according to vehicle speed.
  2. If electronics fail, steering works like a traditional power steering.
  3. Relay for servotronic control module -J236- is not On Board Diagnostic (OBD) capable.

Scheme 27

Scheme 27: Servotronic, checking voltage supply
Scheme 27: Servotronic, checking voltage supply
  1. Remove driver's side storage compartment. See «DRIVER'S STORAGE COMPARTMENT, REMOVING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__drivers-storage-compartment-removing) . For Right Hand Drive (RHD) vehicles
  2. Unbolt mounting bracket and remove.
  3. Remove relay for servotronic control module -J236-, position 13.
  4. Switch ignition on
  5. Adjust VAG1526 digital multimeter to voltage range up to 20 volts.
  6. Measure at relay connector between terminals 6 and terminal 8. Specification: approx. 12 volts.
  7. If specified value is not obtained, check electrical wiring. See appropriate System Wiring Diagrams article.

Speed signal, checking

The speed signal comes from the speedometer -G21- in the instrument cluster.

  1. Remove driver's side storage compartment. See «DRIVER'S STORAGE COMPARTMENT, REMOVING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__drivers-storage-compartment-removing) . For Right Hand Drive (RHD) vehicles
  2. Unbolt mounting bracket and remove.
  3. Remove relay for servotronic control module -J236-, position 13.
  4. If the voltage supply, the servotronic valve and the speed indication at the speedometer are OK, check electrical wire between terminal 4 and speedometer -G21-. See appropriate System Wiring Diagrams article.
  5. If electrical wire between terminal 4 and speedometer -G21- is OK, replace relay for servotronic.

Servotronic valve, checking

  1. Remove driver's side storage compartment. «DRIVER'S STORAGE COMPARTMENT, REMOVING»(/audi/a6/c5-1997-2001/remont/mirrors/#interior-equipment__drivers-storage-compartment-removing) . For Right Hand Drive (RHD) vehicles
  2. Unbolt mounting bracket and remove.
  3. Remove relay for servotronic control module -J236-, position 13.
  4. Adjust VAG1526 digital multimeter to resistance range up to 200 Ohm.
  5. Measure at relay connector between terminals 2 and terminal 5. Specification: 5 to 20 Ohm. If specified value is not obtained
  6. Disconnect connector for servotronic, (in left wheel housing, see «SERVOTRONIC VALVE, CHECKING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering__servotronic-valve-checking) ).
  7. Check wire between relay connector and servotronic valve for short circuit and open circuit. See appropriate System Wiring Diagrams article.
  8. If the wire connection is OK, remove steering gear and replace servotronic valve.
  1. VAG1923 open end wrench insert
  2. VAG1332 torque wrench Measurement range: 40 to 200 Nm.

Note. Tie rods at left and right are identical. Tie rods can be removed and installed with steering gear installed.

Scheme 28

Scheme 28: Removing
Scheme 28: Removing
  1. Remove front wheel.
  2. Remove hex bolt -1- and bolt -2-.
  3. Remove tie rod.
  4. Unscrew plastic nut -1-. see scheme 155
  5. Pry out clip -2-.
  6. Remove cover for tie rod. NOTE: Shown without wheel bearing housing and strut for the sake of illustration.
  7. Open clamps at boot.
  8. Pull boot as far toward outside as possible.
  9. Remove tie rod using VAG1923 special tool.
  10. Now replace boot or tie rod depending on extent of damage.
  1. Tighten tie rod to 100 Nm
  2. When installing boot, be sure: The smaller diameter of boot snaps into groove at tie rod. The boot does not get twisted.
  3. Replace inner (large) clamp.
  4. Check alignment. See «SPECIFICATIONS & PROCEDURES»(/audi/a6/c5-1997-2001/remont/wheel-alignment/#specifications-procedures) .

Note. Two technicians are required for adjustments. Adjust with engine off.

Scheme 29

Scheme 29: Power steering gear, adjusting
Scheme 29: Power steering gear, adjusting
  1. Raise vehicle on platform.
  2. Wheels in straight-ahead position.
  3. Turning the steering wheel back and forth (approx. 30° off center axis) will produce a rattling noise if steering play is too large.
  4. Second technician turns adjustment bolt (arrow) carefully during this, until rattling noise cannot be heard in vehicle interior anymore.
  5. Road test vehicle.
  6. Be sure that steering returns to straight-ahead position on its own, without catching, after vehicle is maneuvered or driven in a curve. Correct adjustment if necessary.
  1. With engine not running, bring front wheels into straight ahead position.

Fluid, when cold

  1. Remove cap.
  2. Clean off dip stick with a clean rag.
  3. Tighten cap by hand and remove again. NOTE: Fluid level is only valid if cap has been screwed on.
  4. Check oil level: Fluid level must be near -MIN- marking (up to 2 mm above or below marking).

Scheme 30

Scheme 30
Scheme 30

Fluid, at operating temperature (from approx. 50°C)

  1. Check oil level: Fluid level must be between "MIN" and "MAX" markings.

Note. If fluid level is above specified range, oil must be drained. If fluid level is below specified range, hydraulic system must be checked for leaks. It is not enough to simply top off with fluid. Do not reuse fluid you have drained.

On completion of steering system repair work, system is to be bled in different ways depending on extent of repair work.

  1. Check hydraulic fluid level and top off, if necessary.
  2. Raise vehicle enough that front wheels turn without resistance.
  3. Start engine briefly (max. 2 s). Steering wheel must not be turned, pump must not draw in air. Waiting time between individual engine starts approx. 30 seconds.
  4. Check hydraulic fluid level and top off, if necessary.
  5. Keep repeating this procedure until fluid level remains constant.
  6. Turn steering wheel 10 times from end position to end position.
  7. Check hydraulic fluid level and top off, if necessary.
  8. Start engine.
  9. Turn steering wheel 10 times from end position to end position.
  10. Check hydraulic fluid level and top off, if necessary. Residual air trapped in the steering system will dissipate on its own during driving operation after approx. 10 to 20 km.
  1. Check hydraulic fluid level and top off, if necessary.
  2. Start engine briefly (max. 2 s). Steering wheel must not be turned, pump must not draw in air. Waiting time between individual engine starts approx. 30 seconds.
  3. Check hydraulic fluid level and top off, if necessary.
  4. Keep repeating this procedure until fluid level remains constant.
  5. Start engine and let it run for 2 - 3 minutes; do not turn steering wheel. Residual air trapped in the steering system will dissipate on its own during driving operation after approx. 10 to 20 km.
  1. Start engine.
  2. Turn steering wheel to stop in both directions and hold briefly.

This builds up the largest possible pressure.

Note. To avoid damage to the pump, do not allow the engine to run more than 10 seconds during the test.

In this position, the following components must be checked for leaks

  1. Seal for steering pinion at valve housing of steering gear.
  2. All wire connections
  3. Rack seals

Note. This test can only be performed if hose clamps for boots are easily accessible.

  1. Open hose clamps for boot.
  2. Slide back boot.

If fluid is visible in steering gear housing and/or in boots, steering gear must be replaced.

The steering column is only available as a complete unit for a replacement part. Servicing is not possible.

Steering lock housing can be modified.

The following list pertains to see scheme 160.

  1. Shear bolt, 20 Nm
  2. Steering column
  3. Ignition/starter switch Different versions See Parts Catalog
  4. Bolt, 22 Nm
  5. Secure for transport
  6. Control module for steering column-belt height adjustment -J352- No self-diagnosis capability NOTE: Sliding splining between upper and lower steering column must not be separated under any circumstances. Sliding over a range in excess of +/- 5 cm can lead to damage of the steering column.
  7. Tolerance adjusting screw Tightening torque: 22 Nm Provided with electrically adjustable steering column All 4 bolts for attaching steering column to cross member must have been tightened to torque, before tightening tolerance adjusting screw Do not apply force to steering column or steering wheel while tightening tolerance adjusting screw

An electrically adjustable steering column is available as an option.

The control module for steering column-belt height adjustment -J352- has no self-diagnosis capability.

In the event of problems, use wiring diagram to perform fault-finding.

Description of operation

The automatic function simultaneously adjusts seat belt and steering column (vertically/horizontally).

Safety functions

To avoid overloading vehicle battery, the positioning motors are not activated simultaneously on implementing automatic adjustment, but rather in quick succession.

If voltage drops below 10.5 V, the motors are adjusted separately in turn.

Blockage detection (1.5 s) and running time error (max. 30 s/motor) result in direct deactivation of the motor concerned.

To make it easier to get into and out of vehicle, breaking of S contact (ignition off) causes steering column to move to its horizontal and tilt end position and, to return to its original position when S contact is made (ignition on).

Switching off easy-entry facility switch completely deactivates easy-entry function or immediately terminates current adjustment process.

Special features

Only belt height is adjusted if P button is pressed with S contact off. Steering column only assumes memory position with "S contact on".

If entry position has been altered beforehand, steering column does not return to original position with "S contact on" for example by way of manual adjustment.

Installation location

Behind glove box at center support

Scheme 31

Scheme 31: Installation location
Scheme 31: Installation location

Electrical adjustment

Switch -A- can be used to electrically adjust height and length of steering column. Adjustment is also possible with ignition switched off.

Height adjustment

  1. Press switch up/down.

Height is adjusted for as long as switch is pressed.

Longitudinal adjustment

  1. Press switch to front/rear.

Height is adjusted for as long as switch is pressed.

On vehicles with seat memory, corresponding setting can be stored together with seat position.

Scheme 32

Scheme 32: Steering column adjustment memory
Scheme 32: Steering column adjustment memory

Easy-entry facility

The easy-entry facility adjusts steering column to make it easier to get into and out of the vehicle.

  1. The easy-entry facility can be activated/deactivated by pressing button -B-.

If easy-entry facility is active (button -B- pressed), steering column moves into park position (forward and upward) when ignition key is removed.

Following entry into vehicle, the steering column moves to stored position as soon as vehicle key is turned to switch on ignition system.

The stored steering wheel position is only called up if seat memory button is in ON position (pressed).

If easy-entry facility is not active, steering column moves into stored position as soon as seat memory button is pressed.

Scheme 33

Scheme 33
Scheme 33

The steering column is only available as a complete unit for a replacement part. Servicing is not possible.

Steering lock housing can be modified.

WARNINGBefore removing steering wheel, wheels must be positioned in the straight-ahead position Observe safety precautions for working on airbags. See appropriate Air Bag article in RESTRAINTS. If these procedures are not observed, the airbag system may not function properly during vehicle operation!
  1. Remove airbag unit for sport steering wheel. See appropriate Air Bag article in RESTRAINTS.
  2. Remove steering wheel for sport steering wheel. See appropriate Air Bag article in RESTRAINTS.
  3. Observe procedures for removing steering angle sensor in vehicles with Electronic Stabilization Program (ESP). See «STEERING ANGLE SENSOR -G85-, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/anti-locktraction-control/#brake-system-abs) .

Scheme 34

Scheme 34: Removing steering column switch
Scheme 34: Removing steering column switch
  1. Disengage steering column adjustment.
  2. Remove steering column completely.
  3. Remove bolt -1- (2x). Tightening torque 3 Nm.
  4. Remove handle -2-.
  5. Remove two Phillips head screws (arrows).
  6. Tightening torque: 0.6 Nm
  7. Remove upper trim for steering wheel switch -1-. To install, insert upper shell into catch in lower shell, swing down and bolt.
  8. Remove bolts -2- (2x). Tightening torque 0.6 Nm.
  9. Remove hex bolt -1-. Tightening torque: 0.6 Nm
  10. Remove lower trim for steering wheel switch -3-.
  11. Disconnect connector -1-. see scheme 167
  12. Loosen bolt -2-. see scheme 167 Tightening torque: 3 Nm
  13. Disconnect connector -3-. see scheme 167
  14. Remove steering column switch -4-. see scheme 167
  15. Release cable ties and connectors located at steering column. For vehicles with automatic transmission, locking cable must be disengaged
  16. Place selector lever in park position.
  17. Switch ignition key to position -B- "Ignition ON".
  18. Lift locking lever -1- slightly and pull locking cable -2- from ignition lock housing.
  19. Remove nut -1- at universal joint.
  20. Release tension on eccentric bolt by turning adjusting bolt (Torx T50) clockwise and remove bolt.
  21. Disengage steering column adjustment.
  22. Swing universal joint to side.
  23. Remove socket head bolts -1- for steering column and remove steering column. Removing and installing steering lock housing, see «STEERING LOCK HOUSING, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering).
  24. Check steering column for damage. See «STEERING COLUMN, CHECKING FOR DAMAGE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering). Lock cylinder, removing and installing: See «LOCK CYLINDER FOR IGNITION/STARTER SWITCH, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#lights-switches-exterior-up-to-2000) (up to 2000), or «LOCK CYLINDER AND IGNITION/STARTER SWITCH»(ref-196302-S03040719852005100900000) (2001 and up).

Scheme 35

Scheme 35: Installing
Scheme 35: Installing
  1. Attach steering column to crossmember using 4 socket head bolts -1-.
  2. Disengage steering column adjustment.
  3. Attach universal joint to pinion gear of steering gear.
  4. Insert locking screw (Torx T50) through lower part and pretension by counter clockwise.
  5. Insert hex nut and tighten to 30 Nm. For vehicles with automatic transmission, engage locking cable
  6. Switch ignition key to position -B- "Ignition ON" to engage locking cable.
  7. Place selector lever in park position.
  8. Insert locking cable -2- in ignition lock housing. Make sure locking bracket -1- engages.

Scheme 36

Scheme 36: Functional check of locking cable
Scheme 36: Functional check of locking cable

Scheme 37

Scheme 37
Scheme 37
  1. Switch ignition key to position -B- "Ignition ON". It must be possible to switch selector lever out of park position without it catching. It must not be possible to remove ignition key with selector lever in any position other than park.
  2. Place selector lever in park position. Ignition lock must operate smoothly, without catching. With ignition key in position -A- "Ignition off", it must not be possible to move the selector lever out of park. The ignition key can be removed. Basic setting and routing of locking cable See appropriate Automatic Transmission , SERVICING article.
  3. Install steering column switch with trim.
  4. Position steering column so that gaps in trim are uniform.
  5. Tighten socket head bolts -1- for steering column to 25 Nm.
  1. Tighten tolerance adjusting screw. See «STEERING COLUMN, CHECKING FOR DAMAGE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) , item 7.
  2. Connect wiring of servo motors.
  3. Use cable tie to attach wires to steering column.

All vehicles (continued)

  1. Install driver's side storage compartment.
  2. Install steering wheel for sport steering wheel.
  3. Install airbag control module for sport steering wheel. See appropriate Air Bag article in RESTRAINTS.
  4. Zero steering angle sensor. See «BASIC SETTING (SCAN TOOL FUNCTION 04)»(/audi/a6/c5-1997-2001/remont/anti-locktraction-control/#brake-system-on-board-diagnostic-obd-abs-esp__basic-setting-scan-tool-function-04) .

Optical test

  1. Check whether parts of steering column indicate damage.

Function test

  1. Check whether steering column can be turned without catching or difficulty of movement.
  2. Check whether length and height of steering column are adjustable.
  3. Check whether a gap -dimension A- is present between carriage and mounting bracket. If dimension -A- is larger than 0.5 mm, steering column is damaged and must be replaced.
WARNINGBefore removing steering wheel, wheels must be positioned in the straight-ahead position. Observe safety precautions for working on airbags. See appropriate Air Bag article in RESTRAINTS. If these procedures are not observed, the airbag system may not function properly during vehicle operation!
  1. Remove airbag control module for sport steering wheel. See appropriate Air Bag article in RESTRAINTS.
  2. Remove steering wheel for sport steering wheel. See appropriate Air Bag article in RESTRAINTS.
  3. Remove steering column switch. See «STEERING COLUMN, ELECTRICALLY ADJUSTABLE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  4. For vehicles with automatic transmission, disengage locking cable. See «STEERING COLUMN, CHECKING FOR DAMAGE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  5. Drill out snap-off screws -1- or chisel out using appropriate chisel. Lock cylinder, removing and installing: See «LOCK CYLINDER FOR IGNITION/STARTER SWITCH, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#lights-switches-exterior-up-to-2000) (up to 2000), or «LOCK CYLINDER AND IGNITION/STARTER SWITCH»(ref-196302-S03040719852005100900000) (2001 and up).
  1. Install new snap-off screws.
  2. Tighten snap-off screw until head breaks off
  3. For vehicles with automatic transmission, engage locking cable. See «STEERING COLUMN, CHECKING FOR DAMAGE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  4. Perform a function test of locking cable. See «STEERING COLUMN, CHECKING FOR DAMAGE»(/audi/a6/c5-1997-2001/remont/steering-column-switches/#steering) .
  5. Install steering column switch.
  6. Install steering wheel for sport steering wheel. See appropriate Air Bag article in RESTRAINTS.
  7. Install airbag control module for sport steering wheel. See appropriate Air Bag article in RESTRAINTS.
