Interior Trim (coupe) Audi A5 I

DOOR TRIM OVERVIEW

Note. The illustration shows the driver side door trim.

Scheme 1

1. Entry Lamp Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)
2. Bolt For armrest Quantity: 9 1.2 Nm
3. Door Trim Removing and installing, refer to «DOOR TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__door-trim) Versions with storage compartment reinforcement The reinforcement must be installed when replacing the door trim. Refer to «DOOR TRIM STORAGE POCKET REINFORCEMENT»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__door-trim-storage-pocket-reinforcement) NOTE: When replacing the door trim panel, a hole for the sleeve -7- must be made in the new panel using the old panel as a sample.
4. Active/Passive Rear Reflector Vehicles with special equipment
5. Interior Monitoring Switch -E183- /Alarm System Deactivation Switch -E217- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)
6. Clip With seal For door trim Quantity: 8 WARNING: For proper crash sensor (pressure sensor) function, ensure door does not leak. The door trim clips seal the system. Replace the clips if necessary. Follow safety measures when working with front side airbag crash sensors (pressure sensors). Refer to «FRONT SIDE AIRBAG CRASH SENSORS, SAFETY PRECAUTIONS»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe__front-side-airbag-crash-sensors-safety) .
7. Sleeve For the central locking -SAFE- indicator lamp -K133- Driver door only Central locking -SAFE- indicator lamp -K133-, Removing and Installing; refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe) NOTE: When replacing the door trim panel, a hole for the sleeve -7- must be made in the new panel using the old panel as a sample.
8. Clips Quantity: 4 Press into the door trim
9. Bolt For inside door release mechanism Quantity: 4 1.2 Nm
10. Trim Panel Removing and installing, refer to «TRIM MOLDING»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__trim-molding)
11. Speaker Trim For high range speaker Removing and installing, refer to «TREBLE SPEAKER TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__treble-speaker-trim)
12. Interior Door Mechanism Removing and installing, refer to «INSIDE DOOR RELEASE MECHANISM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__inside-door-release-mechanism)
13. Switch Mount For the rear lid lock cylinder unlock button -F248- Driver door only Removing and installing, refer to «Rear Lid Remote Release Button -E233- SWITCH MOUNT»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
14. Rear Lid Lock Cylinder Unlock Button -F248- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Interior Lights, Switches»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)
15. Speaker Trim For mid range speaker Removing and installing, refer to «MID-RANGE SPEAKER TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__mid-range-speaker-trim)
16. Bolt For door trim 2.5 Nm
17. Switch Trim Different versions For the driver interior locking button -E308- /driver memory seat control head -E97- Removing and installing, refer to «SWITCH TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__switch-trim)
18. Driver Seat Memory Program Control Head -E97- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)
19. Driver Interior Locking Button -E308- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)
20. Mirror Adjusting Switch -E43- or Folding Mirror Adjustment Switch -E168- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)
21. Power Window Control Head In Driver Door -E512- Front passenger door window regulator switch -E107- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)
22. Bolt For door trim 2.5 Nm
23. Pull Handle With switch mount Removing and installing, refer to «PULL HANDLE WITH SWITCH MOUNT»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__pull-handle-with-switch-mount)
24. Armrest Removing and installing, refer to «ARMREST»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__armrest)
25. Bolt For pull handle Quantity: 6 1.2 Nm
26. Bolt For door trim 2.5 Nm

Scheme 2

Tighten the bolts -1, 2, 3 and 5- to 1.3 Nm

Finally, tighten the bolt -4- in the 16 mm hole to 1.3 Nm.

Scheme 3

1. Center Console Assembly overview, refer to «CENTER CONSOLE OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#interior-equipment-coupe__center-console-overview) Removing and installing, refer to «CENTER CONSOLE»(/audi/a5/i-2007-2011/remont/seats/#interior-equipment-coupe)
2. Driver Side Instrument Panel Cover Assembly overview, refer to «DRIVER SIDE INSTRUMENT PANEL COVER OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#interior-equipment-coupe__driver-side-instrument-panel-cover-overview) Removing and installing, refer to «DRIVER SIDE INSTRUMENT PANEL COVER»(/audi/a5/i-2007-2011/remont/seats/#interior-equipment-coupe__driver-side-instrument-panel-cover)
3. Trim For steering column switch module Assembly overview, refer to «STEERING COLUMN SWITCH MODULE TRIM OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#interior-equipment-coupe) Upper trim, removing and installing «STEERING COLUMN SWITCH MODULE UPPER TRIM PANEL»(/audi/a5/i-2007-2011/remont/seats/#interior-equipment-coupe) Lower trim, removing and installing «STEERING COLUMN SWITCH MODULE LOWER TRIM PANEL»(/audi/a5/i-2007-2011/remont/seats/#interior-equipment-coupe)
4. Central Tube For instrument panel Assembly overview, refer to «INSTRUMENT PANEL CENTRAL TUBE OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «INSTRUMENT PANEL CENTRAL TUBE»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
5. Instrument Panel WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «SAFETY PRECAUTIONS»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) . Assembly overview, refer to «INSTRUMENT PANEL OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «INSTRUMENT PANEL»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
6. Glove Compartment Assembly overview, refer to «GLOVE COMPARTMENT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#interior-equipment-coupe__glove-compartment-overview) Removing and installing, refer to «GLOVE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#interior-equipment-coupe)
7. Front Center Armrest Assembly overview, refer to «FRONT CENTER ARMREST OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#interior-equipment-coupe) Removing and installing, refer to «FRONT CENTER ARMREST»(/audi/a5/i-2007-2011/remont/seats/#interior-equipment-coupe)

Scheme 4

1. Bolt Quantity: 3 1.5 Nm
2. Light Switch -E1- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)
3. Headlamp Range Control Adjuster -E102- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)
4. Bolt Quantity: 6 3 Nm
5. Mounting Bracket For instrument cluster Removing and installing, refer to «INSTRUMENT CLUSTER MOUNTING FRAME»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
6. Left Side Instrument Panel Vent Removing and Installing, refer to «SIDE INSTRUMENT PANEL VENT»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__side-instrument-panel-vent)
7. Bolt Quantity: 2 3 Nm
8. Bolt Quantity: 2 3 Nm
9. Nut Quantity: 6 0.5 Nm NOTE: Tighten the nuts carefully to prevent the mounting pins on the speaker trim from shearing off.
10. Mount For speaker Removing and installing, refer to «SPEAKER MOUNT»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
11. Mid-Range Speaker Vehicles with special equipment Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/communication-devices/#communication-coupe)
12. Side Speaker Trim Vehicles with special equipment Removing and installing, refer to «SIDE SPEAKER TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__side-speaker-trim)
13. Nut Quantity: 6 0.5 Nm NOTE: Tighten the nuts carefully to prevent the mounting pins on the defroster vent from shearing off.
14. Sunlight Photo Sensor -G107- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/automatic-hvac-system/#air-conditioning-coupe-2-of-2)
15. Center Speaker Trim Vehicles with special equipment Removing and installing, refer to «CENTER SPEAKER TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
16. Upper Center Defroster Vent Removing and installing, refer to «TOP CENTER DEFROSTER VENT»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
17. Mid-Range Speaker Vehicles with special equipment Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/communication-devices/#communication-coupe)
18. Upper Side Defroster Vent
19. Bolt Quantity: 2 3 Nm
20. Instrument Panel WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «SAFETY PRECAUTIONS»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) . Follow the allocation of the airbag to the instrument panel, Removing and installing, refer to «INSTRUMENT PANEL»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
21. Right Side Instrument Panel Vent Removing and Installing, refer to «SIDE INSTRUMENT PANEL VENT»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__side-instrument-panel-vent)
22. Passenger Airbag WARNING: Follow all safety precautions when working on pyrotechnic components. Refer to «SAFETY PRECAUTIONS»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) . Follow the allocation of the airbag to the instrument panel. Assembly overview, refer to «PASSENGER AIRBAG OVERVIEW»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) Locking and activating possible with key switch Removing and installing, refer to «FRONT PASSENGER AIRBAG UNIT WITH IGNITERS -N131- / -N132»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
23. Nut For the correct tightening specifications, refer to «PASSENGER AIRBAG OVERVIEW»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
24. Bolt 3 Nm
25. MMI Screen Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/communication-devices/#communication-coupe)
26. Cover For MMI screen Removing and installing, refer to «MMI SCREEN»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__mmi-screen)
27. Center Instrument Panel Vent Removing and installing, refer to «CENTER INSTRUMENT PANEL VENT»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__center-instrument-panel-vent)
28. Radio/Navigation System Vehicles with special equipment Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/communication-devices/#communication-coupe) Installation frame, removing and installing «RADIO AND NAVIGATION SYSTEM FRAME»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
29. Front Information Display Control Head Control Module -J523- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/communication-devices/#communication-coupe)
30. Bolt For the correct tightening specifications, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/communication-devices/#communication-coupe)
31. Climatronic Control Module -J255- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/automatic-hvac-system/#air-conditioning-coupe-1-of-2)
32. Bolt Tightening torque specification, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/gauges-instrument-panels/#instruments-coupe) .
33. Bolt 3 Nm
34. Trim For Access/Start Authorization Switch -E415- Removing and installing, refer to «Access/Start Authorization Switch -E415-, TRIM PANEL»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__accessstart-authorization-switch-e415-trim-panel)
35. Access/Start Authorization Switch -E415- Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/exterior-lights/#exterior-lights-switches-coupe)
36. Instrument Cluster Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/gauges-instrument-panels/#instruments-coupe)
37. Light Switch Trim Removing and installing, refer to «LIGHT SWITCH TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)

Scheme 5

1. Bracket Removing and installing, refer to «MOUNTING BRACKET»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
2. Bolt Quantity: 4 20 Nm
3. Bolt 3.6 Nm
4. Bolt 20 Nm
5. Central Tube For instrument panel Removing and installing, refer to «INSTRUMENT PANEL CENTRAL TUBE»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
6. Threaded Pin 20 Nm
7. Nut Replace 20 Nm
8. Bracket For the air intake chamber
9. Bolt Quantity: 2 9 Nm
10. Bolt Quantity: 2 3.6 Nm
11. Bolt Quantity: 2 9 Nm
12. Bracket For the glove compartment
13. Bolt Quantity: 2 20 Nm
14. Bolt Quantity: 2 20 Nm
15. Bolt Quantity: 2 9 Nm
16. Bracket For the instrument panel cover
17. Nut Replace 20 Nm
18. Threaded Pin 20 Nm
19. Bolt 20 Nm
20. Bolt Quantity: 2 20 Nm

Scheme 6

1. Bolt Quantity: 2 9 Nm
2. Left Retainer For the driver knee airbag Removing and installing, refer to «DRIVER KNEE AIRBAG LEFT BRACKET»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
3. Central Tube
4. Right Retainer For the passenger knee airbag Removing and installing, refer to «PASSENGER KNEE AIRBAG RIGHT BRACKET»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
5. Bolt Quantity: 2 9 Nm
6. Bolt Quantity: 2 9 Nm
7. Bolt 9 Nm
8. Right Retainer For the glove compartment Removing and installing, refer to «GLOVE COMPARTMENT BRACKET»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
9. Bolt 9 Nm
10. Left Retainer For the glove compartment Removing and installing, refer to «GLOVE COMPARTMENT BRACKET»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
11. Bolt Quantity: 2 9 Nm
12. Left Retainer For the passenger knee airbag Removing and installing, refer to «PASSENGER KNEE AIRBAG LEFT BRACKET»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
13. Grommet Installed on the impact absorber -15
14. Bolt For the correct tightening specifications, refer to «Steering»(/audi/a5/i-2007-2011/remont/manual-power-steering/#steering-coupe)
15. Right Shock Absorber Removing and installing, refer to «RIGHT IMPACT ABSORBER»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
16. Bolt 9 Nm
17. Bolt 9 Nm
18. Left Shock Absorber Removing and installing, refer to «LEFT IMPACT ABSORBER»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
19. Bolt Quantity: 2 9 Nm
20. Bolt Quantity: 2 9 Nm
21. Right Retainer For the driver knee airbag Removing and installing, refer to «DRIVER KNEE AIRBAG RIGHT BRACKET»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)

Scheme 7

1. Clamps Install in the trim Replace if damaged or deformed
2. Bolt 3.5 Nm Always replace if removed Threaded screw holes must always be cleaned (for example, with thread cutter)
3. Cover With the "Airbag" symbol Carefully unclip Hangs from trim and cannot be detached
4. Upper A-Pillar Trim Removing and installing, refer to «A-PILLAR UPPER TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__a-pillar-upper-trim)

Scheme 8

1. Clips Install in the trim Replace if damaged or deformed
2. Hood Release Lever For the cable Driver side only Removing and installing, refer to «CABLE OPERATING LEVER»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
3. Bolt 2.5 Nm Driver side only
4. A-Pillar Lower Trim Removing and installing, refer to «A-PILLAR LOWER TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__a-pillar-lower-trim)

Scheme 9

1. B-Pillar Trim Removing and installing, refer to «B-PILLAR TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__b-pillar-trim)
2. Coat Hook
3. Bolt 1 Nm
4. B-Pillar Trim Removing and installing, refer to «B-PILLAR TRIM PANEL»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__b-pillar-trim-panel)
5. Belt Extraction Panel Removing and installing, refer to «BELT EXTRACTION PANEL»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__belt-extraction-panel)
6. Bolt Quantity: 2 4.5 Nm Always replace if removed Threaded screw holes must always be cleaned (for example, with thread cutter)

Scheme 10

1. Trim For the sunshade guide Vehicles with special equipment
2. Clips Quantity: 2 Install in the trim Replace if damaged or deformed
3. Expanding Clip With the "Airbag" symbol Carefully unclip Hangs from trim and cannot be detached
4. C-Pillar Trim Vehicles with special equipment Removing and installing, refer to «C-PILLAR TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__c-pillar-trim)

Scheme 11

1. Driver Side Instrument Panel Cover
2. Clips Insert in the footrest
3. Footrest The footrest is destroyed during removal and must be replaced. Removing and installing, refer to «FOOTREST»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__footrest)
4. A-Pillar Lower Trim
5. Carpet One piece Removing and installing, refer to «FLOOR COVERING»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)

Scheme 12

1. Trim For the mid-range speaker Removing and installing, refer to «MID-RANGE SPEAKER TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
2. Trim Panel Removing and installing, refer to «TRIM MOLDING»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
3. Clips Quantity: 4 Press into the side trim
4. Clips Quantity: 8 Insert into the side trim Replace if damaged or deformed
5. Treble Speaker Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/communication-devices/#communication-coupe)
6. Clip With seal For the side trim Quantity: 3 Replace if damaged
7. Insulation
8. Side Trim Removing and installing, refer to «SIDE TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__side-trim)
9. Trim For high range speaker Removing and installing, refer to «TREBLE SPEAKER TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)

Scheme 13

1. Sill Panel Strip Removing and installing, refer to «SILL PANEL»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__sill-panel)
2. Centering Pin
3. Clips Quantity: 3 Insert in the sill panel strip Replace if damaged or deformed

Scheme 14

1. Clips Quantity: 4 Insert in the rear shelf Replace if damaged or deformed
2. Rear Shelf Optional equipment: Without sun shade With sun shade Engaged in the rear window frame Removing and installing, refer to «REAR SHELF»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__rear-shelf)
3. Cover Vehicles with special equipment Removing and installing, refer to «CAP»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__cap)
4. Bolt Quantity: 4 2 Nm
5. Speaker Trim Vehicles with special equipment Removing and installing, refer to «SPEAKER TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__speaker-trim)
6. Speaker Vehicles with special equipment Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/communication-devices/#communication-coupe)
7. Bolt Quantity: 4 For the correct tightening specifications, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/communication-devices/#communication-coupe)

Scheme 15

Vehicles equipped with an additional fastener: tighten the screw -arrow- with 2 Nm.

Scheme 16

Vehicles equipped with an additional fastener: tighten screw -2- for spacer -1- with 2 Nm.

1. The pin -arrow- must engage the hole on the body.

Scheme 17

1. Bolt Quantity: 4 2 Nm
2. Front of the Rear Shelf Vehicles with special equipment Removing and installing, refer to «REAR SHELF»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__rear-shelf)
3. Sun Shade Vehicles with special equipment Removing and installing, refer to «SUN SHADE»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
4. Bolt Quantity: 4 2.3 Nm
5. Bolt Quantity: 2 2.3 Nm
6. Bracket For the guide strip
7. Guide Strip Removing and installing, refer to «SUN SHADE»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
8. Rear Shelf Rear Section Vehicles with special equipment Engaged in the rear window frame Removing and installing, refer to «SUN SHADE»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
9. Trim For the rear shelf rear section
10. Nut Quantity: 5 3 Nm

Scheme 18

1. C-Pillar Trim Assembly overview, refer to «C-PILLAR TRIM OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «C-PILLAR TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__c-pillar-trim)
2. Side Trim Assembly overview, refer to «SIDE TRIM PANEL OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «SIDE TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__side-trim)
3. B-Pillar Trim Assembly overview, refer to «B-PILLAR TRIM OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «B-PILLAR TRIM PANEL»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__b-pillar-trim-panel)
4. Sill Panel Strip Assembly overview, refer to «SILL PANEL OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «SILL PANEL»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__sill-panel)
5. Upper A-Pillar Trim Assembly overview, refer to «A-PILLAR UPPER TRIM OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «A-PILLAR UPPER TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__a-pillar-upper-trim)
6. A-Pillar Lower Trim Assembly overview, refer to «A-PILLAR LOWER TRIM OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «A-PILLAR LOWER TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__a-pillar-lower-trim)
7. Footrest/Floor Covering Assembly overview, refer to «FOOTREST AND FLOOR COVERING OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing «FOOTREST»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__footrest) Remove and install the floor covering «FLOOR COVERING»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
8. Rear Shelf Versions without sun shade, assembly overview «REAR SHELF OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «REAR SHELF»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__rear-shelf)

Scheme 19

1. Luggage Compartment Floor Covering Removing and installing, refer to «LUGGAGE COMPARTMENT LINER»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
2. Bracket For the luggage compartment floor mat Removing and installing, refer to «LUGGAGE COMPARTMENT FLOOR MAT BRACKET»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__luggage-compartment-floor-mat-bracket)
3. Mounting Bracket For luggage compartment floor covering retainer
4. Frame For rear panel sill Removing and installing, refer to «REAR PANEL SILL FRAME»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
5. Nut For spare wheel mounting When tightening, it must audibly click into place, otherwise, turn some more
6. Cover For the vehicle tool kit
7. Vehicle Tool Kit Vehicles with special equipment

Scheme 20

1. Clips Quantity: 3 Install in the trim Replace if damaged or deformed
2. Expanding Clip
3. Bolt Quantity: 2 6 Nm
4. Tie-Down Eye Removing and installing, refer to «TIE-DOWNS»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__tie-downs)
5. Luggage Compartment Side Trim Removing and installing, refer to «LUGGAGE COMPARTMENT SIDE TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__luggage-compartment-side-trim)

Scheme 21

Versions with retaining hooks: tighten the screws -arrows- to 1.5 Nm.

Scheme 22

1. Rear Cross Panel Trim Assembly overview, refer to «REAR CROSS PANEL TRIM OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «REAR CROSS PANEL TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__rear-cross-panel-trim)
2. Rear Lid Trim Assembly overview, refer to «REAR LID TRIM OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «REAR LID TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__rear-lid-trim)
3. Luggage Compartment Side Trim Assembly overview, refer to «LUGGAGE COMPARTMENT SIDE TRIM OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «LUGGAGE COMPARTMENT SIDE TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__luggage-compartment-side-trim)
4. Luggage Compartment Floor Covering Assembly overview, refer to «LUGGAGE COMPARTMENT FLOOR MAT OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «LUGGAGE COMPARTMENT LINER»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
5. Frame For rear panel sill Assembly overview, refer to «LUGGAGE COMPARTMENT FLOOR MAT OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «REAR PANEL SILL FRAME»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)

Scheme 23

1. Rear Cross Panel Trim Removing and installing, refer to «REAR CROSS PANEL TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__rear-cross-panel-trim)
2. Clips Quantity: 4 Install in the trim Replace if damaged or deformed

Scheme 24

1. Trim For rear lid lock Removing and installing, refer to «REAR LID LATCH TRIM PANEL»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
2. Trim For the rear lid Removing and installing, refer to «REAR LID TRIM»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__rear-lid-trim)
3. Stop Strip Clipped into the rear lid
4. Clips Quantity: 11 Install in the trim Replace if damaged or deformed
5. Intermediate Piece
6. Wiring Guide
7. Bolt 1.8 Nm
8. Warning Triangle
9. Bracket For the warning triangle Removing and installing, refer to «WARNING TRIANGLE BRACKET»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)

Scheme 25

1. Bolt 1.6 Nm
2. Headliner Optional equipment: Without a sunroof With sunroof Removing and installing, refer to «HEADLINER»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__headliner) CAUTION: The headliner bends easily. Replace the headliner if it is bent.
3. Cover Frame The marking points to the rear of the vehicle
4. Deformation Elements Versions for specific countries: Self-adhesive On the markings onto the headliner and press firmly
5. Limiting Strap Replace if damaged
6. Clamps Insert in the headliner Replace if damaged or deformed
7. Limiting Strap Replace if damaged
8. Clamps Quantity: 15 Insert in the headliner Replace if damaged or deformed Release «HEADLINER =>»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__headliner)

Scheme 26

1. Installed location: on the left and right sides above the windshield.

1. Deformation element
2. Bolt - 3 Nm
3. Bolt - 3 Nm

Scheme 27

1. Interior Light/Front Reading Light Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)
2. Sun Visor Assembly overview, refer to «SUN VISORS OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «SUN VISOR»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)
3. Interior Light/Rear Reading Light Removing and installing, refer to «[For engine(s) CAUA, CAEB, CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)
4. Headliner Optional equipment: Without a sunroof With sunroof Assembly overview, refer to «HEADLINER OVERVIEW»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) Removing and installing, refer to «HEADLINER»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__headliner) CAUTION: The headliner bends easily. Replace the headliner if it is bent.

Scheme 28

1. Expanding Cap Clipped into the sun visor
2. Connector Vehicles with special equipment
3. Center Bracket For the sun visor Removing and installing, refer to «SUN VISOR CENTER BRACKET»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe__sun-visor-center-bracket)
4. Cover Clipped into the sun visor center bracket
5. Sun Visor Removing and installing, refer to «SUN VISOR»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe)

ARMREST

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 29

Remove the door trim, Refer to DOOR TRIM .

Remove the bolts -1 through 8- on the rear of the door trim.

Release the retaining hooks -arrows- on the rear of the door trim.

Remove the bolt -1-.

Scheme 30

Carefully pry the armrest -2- out from the door trim -arrow- using the trim removal wedge 3409 and remove it.

INSTALLING

Install in reverse order of removal.

DOOR TRIM

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Pliers 3392

Scheme 31

Turn off the ignition and remove the key.

Remove the trim panel. Refer to TRIM MOLDING .

Remove the switch trim. Refer to SWITCH TRIM .

Remove the bolts -1 through 5-.

Beginning at the bottom rear curve, unclip the door trim from the door using the pliers 3392 by sliding them between the door trim and the door in the securing clip area.

Scheme 32

Scheme 33

1. Position of the retaining clips -arrows-.

Disengage the top of the door trim from the door in the window recess by pulling the door trim up.

Carefully release bracket -3- on control cable bracket -1-.

Scheme 34

Remove inside door release cable -2- from the control cable bracket in the -direction of the arrow-.

Disengage the ends of the cable -4- from the inside door release mechanism.

Disconnect the electrical connector -1- on the door control module with the window regulator motor -2-.

Scheme 35

Note. Ignore the -arrows-.

Remove the door trim.

Engage the ends of the cable -4- in the inside door release mechanism lever.

1. The open side of the eye on the end of the cable must face up.

Pull the door mechanism release cable -2- in the direction of the -arrow- and guide it into the cable bracket -1-.

1. Bracket -3- must engage audibly in the control cable bracket.

Connect the electrical connector on the door control module with the window regulator motor.

First engage the door trim on the treble speaker bracket.

Position the door trim on the window recess and press it down firmly.

Carefully position the door trim clips on the door and press the door trim onto the door until it engages audibly on the mounting points.

Further installation is performed in the reverse order of removal.

DOOR TRIM STORAGE POCKET REINFORCEMENT

Special tools and workshop equipment required

1. Drill
2. 5 mm drill bit
3. Step drill 4 to 20 mm
4. Protective Eyewear

On vehicles that have a reinforcement in the door trim storage pocket, it must be installed in the new trim after the trim is replaced.

Procedure

Scheme 36

Punch markings -1 through 5- at the storage pocket on the rear side of the door trim and drill through them using the 5 mm drill.

Drill the hole -4- using a 16 mm step drill.

Insert the reinforcement -arrow- in the storage pocket as shown and slide it all the way back.

Scheme 37

Note. The magnified section of the illustration shows the reinforcement inserted in the storage pocket (sectional view).

For Tightening Specifications and Sequence Refer to, (Scheme 2)

INSIDE DOOR RELEASE MECHANISM

Note. Removing and installing is identical for the left and right sides.

Scheme 38

Remove the door trim. Refer to DOOR TRIM .

Vehicles with illumination: disconnect the connector -1-.

Remove the bolts -2 through 4- on the rear of the door trim.

Press the inside door release mechanism -1- out of the door trim from behind -arrow- and remove it.

Scheme 39

Install in reverse order of removal.

MID-RANGE SPEAKER TRIM

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 40

Pry the speaker trim -1- out along the door trim seam -arrow- using the trim removal wedge 3409 and remove it.

Install in reverse order of removal. Note the following

Press the speaker trim on until it engages audibly.

PULL HANDLE WITH SWITCH MOUNT

Note. Removing and installing is identical for the left and right sides.

Scheme 41

Remove the door trim. Refer to DOOR TRIM .

Remove the armrest. Refer to ARMREST .

Remove the bolts -1 through 6- on the rear of the door trim.

Release the retaining hooks -arrow- on the rear of the door trim.

Disconnect the electrical connectors -2- and -3-.

Scheme 42

Carefully remove the pull handle -1- with the switch mount from the door trim -arrows-.

Install in reverse order of removal.

Scheme 43

Remove the door trim. Refer to DOOR TRIM .

Release the retaining hooks -arrow- and remove the switch mount -1- from the door trim.

Remove the rear lid remote release button -E233- from the switch mount.

Install in reverse order of removal. Note the following

Press the switch mount on until it engages audibly.

SWITCH TRIM

Note. Removing and installing is identical for the left and right sides.

Scheme 44

Position a small screwdriver -1- at the lower opening on the switch trim.

Carefully pry the switch trim off -arrow-.

Disconnect electrical connectors.

Install in reverse order of removal. Note the following

Press the switch trim on until it engages audibly.

TREBLE SPEAKER BRACKET

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 45

Remove the treble speaker trim. Refer to TREBLE SPEAKER TRIM .

Vehicles with treble speakers: Remove the treble speaker. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Carefully pry the treble speaker bracket -1- off the door using the trim removal wedge 3409 and remove it.

Install in reverse order of removal. Note the following

Press the treble speaker bracket on until it engages audibly.

TREBLE SPEAKER TRIM

Note. Removing and installing is identical for the left and right sides.

Scheme 46

Remove the door trim. Refer to DOOR TRIM .

Carefully pry the treble speaker trim -1- off the bracket -arrow- using a narrow screwdriver and remove it.

Install in reverse order of removal. Note the following

Press the treble speaker trim on until it engages audibly.

TRIM MOLDING

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 47

Pry the trim panel -1- off the door trim beginning at the rear using the trim removal wedge 3409.

Remove the trim panel from the door trim back in the direction of the -arrow- while lifting the rear area of the trim slightly using a trim removal wedge 3409 so the retaining hook inside the trim can be loosened from the opening in the door trim.

Install in reverse order of removal. Note the following

First engage the trim panel on the inside of the door opener and then press it onto the door trim until it engages audibly.

Access/Start Authorization Switch -E415-, TRIM PANEL

Special tools and workshop equipment required

1. Special Pliers VAS 6339

Scheme 48

Remove the MMI screen cover. Refer to MMI SCREEN .

Unclip the instrument cluster gap cover from the instrument panel. Refer to INSTRUMENT CLUSTER GAP COVER .

Remove the bolt -2- for the trim -1-.

Insert the special pliers VAS 6339 through the trim covers.

Scheme 49

Position the tips of the special pliers VAS 6339 on both holes -A arrows- on the access/start authorization switch -E415- -2-.

Press the VAS 6339 together -B arrows- to spread the tips of the pliers and release the trim retaining tabs.

Hold the VAS 6339 pressed with one hand and remove the trim -1- with the other hand -arrow C-.

Note. Only use the special pliers to release VAS 6339. Remove the trim by hand.

Install in reverse order of removal.

CENTER INSTRUMENT PANEL VENT

Special tools and workshop equipment required

1. Hook 3438

Scheme 50

Note. The instrument panel vent has a hole on both sides for attaching the hook 3438.

Remove the MMI screen cover. Refer to MMI SCREEN .

Alternating on both sides, carefully remove the instrument panel vent -1- from the installation opening using the hook 3438.

Vehicles with illumination: Disconnect the connector on the instrument panel vent.

Install in reverse order of removal. Note the following

Note. Check the clips for damage or deformation and replace them if necessary.

When sliding the instrument panel vent into the installation opening, make sure the air duct engages correctly.

Press the instrument panel vent into the installation opening as far as the stop.

REMOVING

Note. Be extremely careful when removing and installing because it is easy to damage the speaker trim.

Using a small screwdriver, carefully release the speaker trim -1- at the rear retaining pins -arrow- but only lift it up approximately 10 mm.

Scheme 51

Insert a long screwdriver under the speaker trim at the very front -arrow A- until it comes into contact directly on the right front retaining pins.

Scheme 52

Carefully rotate the screwdriver -arrow B- until the retaining pin -1- disengages from the guide -2-.

Repeat the procedure on the remaining retaining pins -3-.

Install in reverse order of removal. Note the following

First insert the speaker trim in the instrument panel and then press it on until it engages audibly.

Scheme 53

Remove the instrument cluster. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the light switch trim. Refer to SIDE SPEAKER TRIM .

Remove the MMI screen. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the bolts -1 through 6- and the mounting frame.

Install in reverse order of removal.

Move the steering wheel as far down as possible.

Move the seat all the way back and adjust the backrest to a 45° angle.

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the driver airbag. Refer to DRIVER AIRBAG IGNITERS -N95- / -N250

Remove steering wheel. Refer to Removal and Installation .

Remove the instrument cluster gap cover. Refer to INSTRUMENT CLUSTER GAP COVER .

Remove the driver side instrument panel cover. Refer to DRIVER SIDE INSTRUMENT PANEL COVER .

Disconnect the connector. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Vehicles with headlamp range control: Disconnect the connector on the headlamp range control adjuster -E102-. [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the side instrument panel vent. Refer to SIDE INSTRUMENT PANEL VENT .

Remove the MMI screen cover. Refer to MMI SCREEN .

Remove the MMI screen [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the instrument cluster. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Disconnect the electrical connector on the access/start authorization switch. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the center instrument panel vent. Refer to CENTER INSTRUMENT PANEL VENT .

Remove the radio/navigation system. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the climatronic control module -J255- [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the front information display control head control module -J523- [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove center console. Refer to CENTER CONSOLE .

Remove the glove compartment. Refer to GLOVE COMPARTMENT .

Disconnect the passenger airbag electrical connector. Refer to FRONT PASSENGER AIRBAG UNIT WITH IGNITERS -N131- / -N132 .

Vehicles with speakers: Remove the center midrange speaker inside the instrument panel. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the sunlight photo sensor -G107-. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Vehicles with speakers: Remove the center midrange speaker inside the instrument panel. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the upper A-pillar trim A-PILLAR UPPER TRIM .

Remove the instrument panel central tube brace bolts -2-.

Scheme 54

Disengage the brace -1- at the instrument panel and remove it.

Remove the top left and right instrument panel bolts -1- in the A-pillar area.

Scheme 55

Remove the bottom left and right instrument panel bolts -2-.

Remove the left and right air duct bolts -arrows- on the instrument panel.

Remove the instrument panel bolts -1- on the center of the instrument panel central tube.

Scheme 56

Remove the instrument panel bolts -2- on the right of the instrument panel central tube.

Remove the instrument panel bolt -3- on the left of the instrument panel central tube.

Note. 2 technicians are needed to remove the instrument panel.

Carefully pull the instrument panel -1- back from the instrument panel central tube -A arrows-.

Disengage the bottom of the instrument panel on the bracket -2- -B arrow- at the same time.

Remove the instrument panel from the vehicle interior and lay it on a soft surface.

Install in reverse order of removal. Note the following

Position the instrument panel vent and guide the electrical connectors for the sunlight photo sensor -G107- and speaker through the openings in the instrument panel.

Check if there is a rubber buffer -3- on the clamp -2- on the lower windshield frame.

Scheme 57

When sliding the instrument panel -1- on, make sure the clips engage in the box-shaped profiles on the bottom side of the instrument panel.

Note. Make sure the connectors are installed all the way in and are secure.

Align the instrument panel and tighten the bolts.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

INSTRUMENT PANEL SIDE COVER

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 58

Pry the instrument panel side cover -1- off using the trim removal wedge 3409 -arrow- and remove it.

Install in reverse order of removal. Note the following

Press the instrument panel side cover on until it engages audibly.

Scheme 59

Remove the side cover on the driver side instrument panel. Refer to INSTRUMENT PANEL SIDE COVER .

Remove the driver side instrument panel cover. Refer to DRIVER SIDE INSTRUMENT PANEL COVER .

Unclip the instrument cluster gap cover from the instrument panel. Refer to INSTRUMENT CLUSTER GAP COVER .

Remove the light switch. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Vehicles with headlamp range control: Remove the headlamp range control adjuster -E102- [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the bolts -arrows- and the light switch trim -1-.

Install in reverse order of removal.

MMI SCREEN

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 60

Pry the MMI screen cover -1- out at the corners -arrow- using the trim removal wedge 3409 and remove it.

Disconnect the front passenger airbag -disabled- indicator lamp -K145- /emergency flasher button -E229- electrical connector and remove the cover.

Install in reverse order of removal. Note the following

Note. Check the clips for damage or deformation and replace them if necessary.

Press the MMI screen cover on until it engages audibly.

Scheme 61

Remove the center instrument panel vent. Refer to CENTER INSTRUMENT PANEL VENT .

Remove the radio/navigation system. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the bolts -1- and -2- on the front of the installation frame.

Remove the side bolts -4-.

Pull the installation frame -3- back and remove it.

Install in reverse order of removal.

SIDE INSTRUMENT PANEL VENT

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Hook 3438

Scheme 62

Note. The instrument panel vent has a hole on both sides for attaching the hook 3438.

Alternating between the sides, carefully remove the instrument panel vent -1- from the installation opening using the hook 3438.

Vehicles with illumination: Disconnect the connector on the instrument panel vent.

Install in reverse order of removal. Note the following

Note. Check the clips for damage or deformation and replace them if necessary.

When sliding the instrument panel vent into the installation opening, make sure the air duct engages correctly.

Press the instrument panel vent into the installation opening as far as the stop.

SIDE SPEAKER TRIM

Note. Be extremely careful when removing and installing because it is easy to damage the speaker trim. Removing and installing is identical for the left and right sides. The illustration shows the right speaker trim.

Scheme 63

Using a small screwdriver, carefully pry the speaker trim -1- out beginning at the corner -arrow-.

Carefully fold the speaker trim upward and remove it.

Install in reverse order of removal. Note the following

First insert the speaker trim in the instrument panel and then press it on until it engages audibly.

Scheme 64

Remove the instrument panel. Refer to INSTRUMENT PANEL .

Remove the nuts -2 through 4- on the bottom of the instrument panel.

Remove the speaker mounts -1- and -5- upward from the instrument panel.

Install in reverse order of removal. Note the following

Note. When tightening the nuts, make there is an even distance between the upper side of the instrument panel and the upper edge of the speaker vent as well as an even gap all the way around.

Scheme 65

Remove the instrument panel. Refer to INSTRUMENT PANEL .

Remove the nuts -2 through 7- on the bottom of the instrument panel.

Remove the top center defroster vent -1- from the instrument panel.

Install in reverse order of removal. Note the following

Note. When tightening the nuts, make sure there is an even distance between the upper side of the instrument panel and the upper edge of the top center defroster vent as well as an even gap all the way around.

Scheme 66

Remove the passenger knee airbag. Refer to FRONT PASSENGER KNEE AIRBAG IGNITER -N296 .

Remove the bolts -arrows-.

Remove the left -1- and right -2- glove compartment brackets.

Position both glove compartment brackets so that tab -4- engages in hole -3- in the instrument panel.

Further installation is performed in the reverse order of removal.

Remove the instrument panel. Refer to INSTRUMENT PANEL .

Remove the steering column. Refer to Removal and Installation .

Disengage the left instrument panel vent air duct at the instrument panel central tube. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the right instrument panel vent air duct. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the left fuse panel C -SC- and the right fuse panel D -SD- from the instrument panel central tube. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the data bus on board diagnostic interface -J533- and lay it aside. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the bolts -1- on the left and right of the central tube support and remove the bracket -2-.

Scheme 67

Remove the left and right bolts -3- for the central tube support.

Remove the A/C unit bolt -1- on the left and right of the central tube support.

Scheme 68

Remove the center defroster vent air duct. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Scheme 69

Remove the A/C unit bolt -1- on the instrument panel central tube top brace.

Remove the bolt -2- on the top brace on the instrument panel central tube.

Remove the ground wire and left ground point on the tunnel wall and free them up.

Disconnect the electrical connectors on the accelerator pedal module and the brake light switch and free them up.

Remove the right lower A-pillar trim. Refer to A-PILLAR LOWER TRIM .

Disconnect the multi-pin electrical connectors from the right coupling station on the A-pillar. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Disconnect the electrical connector on the fresh air blower and free up the wires.

Remove the air intake chamber bracket bolts -1- on the instrument panel central tube.

Scheme 70

Remove the nut -2-.

Remove the bolt -1- and nut -2-.

Scheme 71

Tighten the 2 nuts -2- and -3- on the threaded pin -1- on the driver side A-pillar and remove the threaded pin.

Scheme 72

Note. 2 technicians are needed to remove instrument panel central pipe.

Carefully pull the instrument panel central tube -1- up at the driver side while disengaging it from the A/C unit -3- and the upper -2- and lower -4- stop brackets.

Scheme 73

Remove the instrument panel central tube from the threaded pin on the A-pillar on the front passenger side.

Carefully tilt the top side of the instrument panel central tube back while pulling it up.

Remove the instrument panel central tube from the vehicle interior.

Carefully insert the instrument panel central tube -1- in the body.

Engage the instrument panel central tube on the A/C unit -3- and on the upper -2- and lower -4- stop brackets.

Align the instrument panel central tube -4- with the A-pillar.

Scheme 74

Tighten the two nuts -2- and -3- on threaded pin -1- and insert the threaded pin in mount -5- on the A-pillar on the driver side and tighten.

1. The threaded pin must be installed completely and its collar must make contact with the mount on the A-pillar.

Tighten the left and right instrument panel central tube bolts and nuts.

Further installation is performed in reverse sequence of removal, but observe the following

Install the steering column. Refer to Removal and Installation .

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Scheme 75

Remove the driver side instrument panel cover. Refer to DRIVER SIDE INSTRUMENT PANEL COVER .

Remove the bolts -arrows-.

Remove the left impact absorber -1- downward.

Install in reverse order of removal.

Scheme 76

Remove the left instrument panel vent air guide channel. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the bolts -1- and -3- and remove the mounting bracket -2- downward.

Note. The removed steering column is shown in the illustration.

Install in reverse order of removal. Note the following

The mounting bracket can only be positioned properly when the central tube is installed.

Attach the steering column and mounting bracket to the central tube first, and then tighten the mounting bracket screws -1- and -3- to the mount on the lower windshield frame. Refer to Removal and Installation

Scheme 77

Remove the driver side instrument panel cover. Refer to DRIVER SIDE INSTRUMENT PANEL COVER .

Remove the driver knee airbag. Refer to DRIVER KNEE AIRBAG IGNITER -N295 .

Remove the bolts -arrows-.

Remove the right impact absorber -1- downward.

Install in reverse order of removal.

A-PILLAR LOWER TRIM

Note. Removal and installation is described for the driver side of the vehicle. The procedure on the passenger side is the same.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 78

Remove the instrument panel side cover. Refer to INSTRUMENT PANEL SIDE COVER .

Remove the driver side instrument panel cover. Refer to DRIVER SIDE INSTRUMENT PANEL COVER .

Remove the cable operating lever. Refer to CABLE OPERATING LEVER .

Remove lower A-pillar trim bolt -1-.

Unclip lower A-pillar trim -2- from the side member -arrow- using the trim removal wedge 3409.

Pull the lower A-pillar trim back and remove it from the upper A-pillar trim.

Install in reverse order of removal. Note the following

Note. If the trim clamps remain in the body mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Driver Side

Slide the lower A-pillar trim into the upper A-pillar trim and into the footrest.

Passenger Side

Slide the lower A-pillar trim into the upper A-pillar trim and into the floor covering.

Procedure for Both Sides of Vehicle

Clip the lower A-pillar trim in on the side member and stretch the door seal lip over.

A-PILLAR UPPER TRIM

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 79

Carefully unclip cap -1- with the "Airbag" symbol from the upper A-pillar trim using a screwdriver.

Remove the bolt -2-.

Carefully unclip upper A-pillar trim -3- beginning at the top using a trim removal wedge 3409 -arrow A-.

Pull the upper A-pillar trim out of the instrument panel -arrow B- and remove.

Install in reverse order of removal. Note the following

Note. If the trim clamps remain in the body mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Remove any locking compound residue inside the threaded hole for the upper A-pillar trim bolt using a thread tap.

Note. If the threaded hole is not cleaned, the new bolt could seize up during installation and shear off when removed again.

Insert upper A-pillar trim -1- into instrument panel mount -2- and the lower A-pillar trim in the direction of the -arrow-.

Scheme 80

Clip the upper A-pillar trim in and stretch the door seal lip over.

B-PILLAR TRIM

Note. Removing and installing is identical for the left and right sides.

Scheme 81

Unclip B-pillar trim -1- beginning at the top using a screwdriver -arrow- and remove it.

Install in reverse order of removal. Note the following

Press the trim on until it engages audibly.

B-PILLAR TRIM PANEL

Note. Removing and installing is identical for the left and right sides.

Scheme 82

Remove the B-pillar trim. Refer to B-PILLAR TRIM .

Remove side trim. Refer to SIDE TRIM .

Hold the belt webbing -2- to the side and remove the bolts -3-.

Remove B-pillar trim -1- from the mount on the headliner -arrow-.

Remove the front belt anchor. Refer to FRONT BELT ANCHOR .

Thread the belt webbing with the locking tongue through the belt extraction panel and remove the B-pillar trim.

Install in reverse order of removal. Note the following

Thread the belt webbing with seat belt latch through the belt extraction panel.

Install the front belt anchor. Refer to FRONT BELT ANCHOR .

First insert the top of the B-pillar trim in the mount on the headliner and then tighten the bolts.

BELT EXTRACTION PANEL

Note. Removing and installing is identical for the left and right sides.

Scheme 83

Remove the B-pillar trim. Refer to B-PILLAR TRIM PANEL .

Press the retaining hooks -arrows- and belt extraction panel -2- forward out of B-pillar trim -1-.

Install in reverse order of removal.

C-PILLAR TRIM

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 84

Fold the backrest forward.

Vehicles equipped with sun shade: unclip sun shade guide trim -1- using a screwdriver and remove it.

Pry the "Airbag" symbol -2- approximately 5 mm out of the expanding clip using a screwdriver.

Unclip C-pillar trim -3- using the trim removal wedge 3409 -A arrow-.

Pull the C-pillar trim out of the rear shelf and the side trim -B arrows- and remove it.

Install in reverse order of removal. Note the following

Note. If the trim clamps remain in the body mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Position the C-pillar trim first on the rear shelf and then the side trim.

Press the C-pillar trim on until it engages audibly.

Vehicles equipped with a rear shade: make sure the holes in C-pillar trim -2- engage in the centering pins -arrows- on rear shade guide rail -1-.

Scheme 85

Press the "Airbag" symbol in so the expanding clip locks.

Scheme 86

Pull the securing clip -2- out of the operating lever -1- slightly -arrow A- using a small screwdriver.

Pull the operating lever back -arrow B- to release the hood and hold it in this position.

At the same time, pull the operating lever level with the center of the vehicle and out of the mount -arrow C-.

Install in reverse order of removal. Note the following

Slide the clip completely into the operating lever.

Press the operating lever onto the mount in the mounting bracket and engage it.

CAP

Note. Removing and installing is identical for the left and right sides.

Scheme 87

Fold the backrest forward.

Unclip the cap -1- using a screwdriver -arrows- and remove it.

Install in reverse order of removal. Note the following

Press the cap on until it engages audibly.

Remove the front seat

1. Standard seat and Sport seat (manual), refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Standard seat, Sport seat (power) and Comfort seat, refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .
3. Super Sport seat, refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) .

Remove the right 2/3 backrest. Refer to BACKREST .

Remove the left 1/3 backrest. Refer to BACKREST .

Remove center console. Refer to CENTER CONSOLE .

Remove the air ducts on the center tunnel. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the center console bracket and lower the shift mechanism CENTER CONSOLE BRACKET .

Remove the lower A-pillar trim. Refer to A-PILLAR LOWER TRIM .

Remove the sill panel strips. Refer to SILL PANEL .

Remove the left and right front belt anchors. Refer to FRONT BELT ANCHOR .

Disengage the floor covering at brackets -1- and -2-.

Scheme 88

Pull the floor covering -3- back.

Note. Make sure the floor covering does not tear at the openings.

Fold the floor covering lengthwise and remove it through a door.

Fold the floor covering lengthwise and lay it in the vehicle.

First slide the floor covering forward until the air duct and shift mechanism openings are aligned.

Then attach the floor covering at brackets -1- and -2-.

Further installation is performed in the reverse order of removal.

FOOTREST

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 89

Note. The footrest is destroyed during removal and must be replaced.

Remove the driver side instrument panel cover. Refer to DRIVER SIDE INSTRUMENT PANEL COVER .

Remove the lower A-pillar trim on the driver side. Refer to A-PILLAR LOWER TRIM .

Unclip the footrest -1- using the trim removal wedge 3409 -arrow- and remove it.

Install in reverse order of removal. Note the following

Replace the footrest and make sure it engages completely in the mounts.

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 90

Unclip the mid-range speaker trim -1- beginning at the top using the trim removal wedge 3409 -arrow- and remove it.

Install in reverse order of removal. Note the following

Press the mid-range speaker trim on until it engages audibly.

REAR SHELF

Special tools and workshop equipment required

1. Pry Lever - RMV Outside Mirror 80 - 200

Scheme 91

Fold the backrest forward.

Remove the C-pillar trim. Refer to C-PILLAR TRIM .

Remove left and right speaker trim. Refer to SPEAKER TRIM .

Vehicles equipped with a speaker: remove screws -1 ••• 4-.

Vehicles equipped with an additional fastener: remove the bolt -arrow- on the left of the rear shelf (under the speaker trim).

Unclip the rear shelf at the front using the pry lever 80 - 200 -A arrows-.

Scheme 92

Disengage the left and right of the rear shelf at the side trim.

Vehicles equipped with a sun shade: detach the rear shelf from the sun shade.

Pull the rear shelf forward -B arrows- and remove it.

Install in reverse order of removal. Note the following

Note. If the rear shelf clips remain in the body mounting points, remove them and insert them in the rear shelf. Check clamps for damage or deformation, replace if necessary.

Insert the rear of the rear shelf in the rear window frame or the sun shade.

Press the front of the rear shelf on until it engages audibly.

For the correct tightening specifications, refer to REAR SHELF OVERVIEW, (Scheme 15) and [For engine(s) CAUA, CAEB, CALA] Removal and Installation.

SIDE TRIM

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 93

Remove the sill panel strip. Refer to SILL PANEL .

Remove the C-pillar trim. Refer to C-PILLAR TRIM .

Remove the rear bench seat. Refer to BENCH SEAT .

Depending on the side, remove the 2/3 right backrest, refer to BACKREST or the 1/3 left backrest, refer to BACKREST .

Remove the luggage compartment side trim. Refer to LUGGAGE COMPARTMENT SIDE TRIM .

Unclip the side trim -1- beginning at the front using the trim removal wedge 3409 -arrows-.

Remove the rear belt anchor. Refer to REAR BELT ANCHOR .

Thread the belt webbing with seat belt latch out through the belt extraction panel.

Vehicles equipped with a treble speaker: Disconnect the harness connector and remove the side trim.

Install in reverse order of removal. Note the following

Note. If any clamps and clips remain in the body, remove them and insert them in the trim. Check clamps and securing clips for damage or deformation, replace if necessary.

Thread the belt webbing with seat belt latch through the belt extraction panel.

Install the rear belt anchor. Refer to REAR BELT ANCHOR .

Position the side trim and press it on until all the mounting points engage.

Stretch the door seal lip over the side trim.

SILL PANEL

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 94

Remove the lower A-pillar trim. Refer to A-PILLAR LOWER TRIM .

Unclip sill panel strip -1- from the side member beginning at the front using the trim removal wedge 3409 -A arrows-.

Disengage the sill panel strip from the side trim -B arrow- and remove it.

Install in reverse order of removal. Note the following

Note. If the sill panel strip clips remain in the body mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Engage the sill panel strip in the side trim and press it onto the side member until it engages audibly.

Stretch the door seal lip over.

SPEAKER TRIM

Note. Be extremely careful when removing and installing because it is easy to damage the speaker trim. Removing and installing is identical for the left and right sides.

Scheme 95

Fold the backrest forward.

Unclip the speaker trim -1- using a screwdriver -arrow-.

Vehicles equipped with a speaker: disconnect the electrical connector and remove the speaker trim in a forward direction.

Install in reverse order of removal. Note the following

Press the speaker trim on until it engages audibly.

Remove the C-pillar trim. Refer to C-PILLAR TRIM .

Remove rear shelf. Refer to REAR SHELF .

Vehicles equipped with an additional rear shelf mount: remove screw -2- and spacer -1-.

Vehicles equipped with a subwoofer: remove the subwoofer in rear shelf -R157- [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Remove the bolts -arrows- on the sun shade guide strip.

Scheme 96

Tilt the guide strip -3- in slightly and disengage both latches -2- and -4- by rotating slightly.

Scheme 97

Remove the guide strip from the connecting piece -1- on the sun shade.

Repeat the procedure on the opposite guide strip.

Disconnect the electrical connector -arrow- on the sun shade.

Scheme 98

Using a flat-head screwdriver, press the retaining tab -1- and pry out the luggage compartment light -2-.

Scheme 99

Note. The electrical connector -3- remains connected.

Remove the bolts -arrows-.

Scheme 100

Remove the sun shade carefully. Be careful with the rear window defroster electrical wires.

Scheme 101

Install in reverse order of removal. Note the following

If removed, install the rear of the rear shelf -2- on the sun shade -1- -arrows-, aligning both parts to each other.

Insert the sun shade -1- with the rear shelf into the rear shelf mount -2- -arrows-.

Scheme 102

Tighten the sun shade bolts -arrows-.

Carefully insert the guide strip -1- into the sun shade connecting piece -2- -arrow-.

Scheme 103

1. The sun shade guide channel must run into the guide strip without the connecting piece being offset.

Clip guide piece -3- at both retaining hooks -2- and -4- on the front and rear with connecting piece -1-.

To ensure the retaining hooks -1- are seated securely, pull them forward until they engage completely using an offset screwdriver -arrow-.

Scheme 104

Note. Removing and installing is identical for the left and right sides.

Scheme 105

Unclip the treble speaker trim -1- using a screwdriver -arrow- and remove it.

Install in reverse order of removal. Note the following

Press the trim on until it engages audibly.

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 106

Unclip the trim panel -1- beginning at the front using the trim removal wedge 3409 -arrow- and remove it.

Install in reverse order of removal. Note the following

Press the trim panel on until it engages audibly.

LUGGAGE COMPARTMENT FLOOR MAT BRACKET

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 107

Remove the luggage compartment liner. Refer to LUGGAGE COMPARTMENT LINER .

Release the mounting bracket -1- using the trim removal wedge 3409 -arrows-.

Disengage mounting bracket and remove luggage compartment floor covering retainer -2-.

Install in reverse order of removal. Note the following

Mounting bracket can be pressed down in one position on luggage compartment floor covering retainer.

Scheme 108

Unclip the front luggage compartment mat -1- -arrows-.

Remove the luggage compartment floor covering.

Install in reverse order of removal.

LUGGAGE COMPARTMENT SIDE TRIM

Note. Removing and installing is identical for the left and right sides.

Special tools and workshop equipment required

1. Pry Lever - RMV Outside Mirror 80 - 200

Scheme 109

Remove the luggage compartment liner. Refer to LUGGAGE COMPARTMENT LINER .

Remove the rear cross panel trim. Refer to REAR CROSS PANEL TRIM .

Remove the tie-down. Refer to TIE-DOWNS .

Loosen the release cable with the remote unlocking handle and let it hang by the attached release cable. Refer to RELEASE CABLE WITH REMOTE CONTROL UNLOCK HANDLE .

Remove the expanding clip -1- with the pry lever 80 - 200.

Pry off the luggage compartment side trim -2- using the pry lever 80 - 200 from the body -A arrows-.

Remove the luggage compartment trim form the side trim -B arrows-.

Disengage the luggage compartment side trim at the hinges and remove it.

Install in reverse order of removal. Note the following

Note. If the trim clamps remain in the body mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Press the luggage compartment side trim until it engages audibly.

Stretch the rear lid seal lip over the luggage compartment side trim.

REAR CROSS PANEL TRIM

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 110

Remove the luggage compartment liner. Refer to LUGGAGE COMPARTMENT LINER .

Remove the lip of the rear lid seal in the area of the rear cross panel trim.

Unclip rear cross panel trim -2- upward vertically using a trim removal wedge 3409 -arrows-.

Install in reverse order of removal. Note the following

Note. If the trim clamps remain in the body mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Guide the left and right rear cross panel trim retaining tabs in the openings on luggage compartment side trim -1-.

Insert the rear cross panel trim so that the left and right tabs engage in pins -3-.

Push on the rear cross panel trim until it engages audibly and stretch the lip of the rear lid seal over the rear cross panel trim.

Scheme 111

Remove rear lid lock trim -1- in the direction of the -arrow-.

Install in reverse order of removal.

REAR LID TRIM

Special tools and workshop equipment required

1. Pry Lever - RMV Outside Mirror 80 - 200

Remove the warning triangle bracket. Refer to WARNING TRIANGLE BRACKET .

Remove the rear lid lock trim. Refer to REAR LID LATCH TRIM PANEL .

Vehicles with an Emergency Release Inside the Luggage Compartment

Scheme 112

Unclip cover -1- on operating lever -2-.

Disengage actuating link nipple -3- on operating lever.

Remove screw behind operating lever.

All vehicles

Scheme 113

Unclip the stop rails using a screwdriver.

Remove the bolt -2-.

Pry rear lid trim -1- out using a pry lever 80 - 200 -arrows-.

Disengage the rear lid trim at the hinges and remove it.

Vehicles with an Emergency Release Inside the Luggage Compartment

Disengage rear housing on operating lever handle recess.

Install in reverse order of removal. Note the following

Note. If the trim clamps remain in the rear lid mounting points, remove them and insert them in the trim. Check clamps for damage or deformation, replace if necessary.

Position the rear lid trim and push on it until it engages audibly.

Scheme 114

Remove the luggage compartment side trim. Refer to LUGGAGE COMPARTMENT SIDE TRIM .

Press the rear sill panel frame -1- back out of the pins -arrows- and remove it.

Install in reverse order of removal.

Remove screws -arrows- and remove retaining hook -1-.

Install in reverse order of removal.

TIE-DOWNS

Note. Removing and installing is identical for the left and right sides.

Scheme 115

Fold the tie-downs -1- upward.

Remove screws -arrows- and remove tie-down mount -2-.

Install in reverse order of removal.

Scheme 116

Remove the warning triangle from the bracket by pressing the release.

Release the retaining tabs using a screwdriver -arrows- and remove the warning triangle bracket -1-.

Install in reverse order of removal. Note the following

Press the warning triangle bracket on until it engages audibly.

HEADLINER

Special tools and workshop equipment required

1. Release Lever T10039

Remove the right front door Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual), refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Standard seat, Sport seat (power) and Comfort seat, refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .
3. Super Sport seat, refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) .

Remove center console. Refer to CENTER CONSOLE .

Remove the center console bracket and lower the shift mechanism. Refer to CENTER CONSOLE BRACKET .

Remove the upper A-pillar trims. Refer to A-PILLAR UPPER TRIM .

Remove the C-pillar trims. Refer to C-PILLAR TRIM .

Remove the B-pillar trims. Refer to B-PILLAR TRIM PANEL .

Remove sun visors. Refer to SUN VISOR .

Remove the sun visor center bracket. Refer to SUN VISOR CENTER BRACKET .

Remove the roof grab handle. Refer to ROOF GRAB HANDLE .

Remove the front interior lamp/reading lamp. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Versions Equipped with a Sunroof

Scheme 117

Open the sunroof -1- all the way.

Open the sun shade -2- about 2 / 3 .

Clean release lever T10039 to avoid soiling headliner.

Scheme 118

Let the release lever T10039 slide along between the sunroof opening cover frame -2- and the headliner -1- until it touches one of the clips -3-.

Release the clips one after another using the release lever T10039 as shown in the illustration -arrow-.

All Vehicles

Scheme 119

Remove the bolt -1- in the front interior/reading light roof opening.

Scheme 120

Unclip the headliner -1- at the rear of the body -arrows- and let it hang by the limiting straps.

Carefully lower the front of the headliner.

Scheme 121

Note. A second technician is needed to loosen the limiting straps and remove the headliner.

Disengage the headliner limiting straps -2- by pressing the catches together using needle nose pliers -arrows- and removing the clips from the body.

Note. If it is difficult to reach the limiting straps, cut them and replace them during installation.

Note. Remove the headliner -1- through the passenger door opening.

Lower the front of the headliner and rotate it while tilting the left side down and guiding the left front corner of the headliner under the instrument panel -3-.

Remove right door seal -2- in the area of the B-pillar and the roof frame.

Remove the right front corner of the headliner at the B-pillar and roof frame until the opening comes into contact on the B-pillar.

Press the top of the headliner up on the B-pillar and the roof frame while guiding the bottom out at the side member and A-pillar.

Press the top of headliner -1- up on the B-pillar/roof frame and continue pulling out until the opening -arrow- comes into contact with the B-pillar.

Scheme 122

Remove the headliner through the passenger door.

Note. If the headliner clamps remain in the body mounting points, remove them and insert them in the headliner. Check clamps for damage or deformation, replace if necessary.

Country-specific with deformation elements: position self-adhesive deformation elements on the marks on the headliner and press firmly.

Position the top of the headliner on the B-pillar and roof frame and on the side member and A-pillar through the front passenger door opening.

Press the top of the headliner up on the opening on the B-pillar and the roof frame while guiding the bottom in at the side member and A-pillar.

Scheme 123

Rotate the headliner and bring it into the installation position by pressing the top of it up on the B-pillar and roof frame and then guiding the lower left front corner under instrument panel -3-.

Clip the limiting straps on the rear of the headliner into the body.

Further installation is performed in reverse sequence of removal, but observe the following

Align the headliner before securing and press it into the body mounting points until the clips engage.

ROOF GRAB HANDLE

Special tools and workshop equipment required

1. Long Reach Special Wrench for Slotted Bolts VAS 6543

Scheme 124

Unclip expanding caps -1- and -3- to the locking position using an offset screwdriver -2-.

Remove the roof grab handle -4- from the body opening.

Insert the roof grab handles in the body cut-outs.

Press the roof grab handle expanding caps on until they engage completely.

ROOF REINFORCEMENT, VEHICLES WITHOUT SUNROOF, INSTALLING ON BODY

Special tools and workshop equipment required

1. Assembly adhesive AK Adhesive -D 190 MKD A3

Procedure

Scheme 125

Remove headliner. Refer to HEADLINER .

Apply the beads of adhesive -arrow- to roof reinforcement as illustrated.

1. Distance between the adhesive beads -a- = approximately 90 mm (3.5 in).
2. Distance of the outer bead of adhesive to the edge of the roof reinforcement, dimension -b- = approximately 20 mm (0.75 in).

Mount the roof reinforcement -1- centered to outer sides and at distance -a- to the bow -2- of the front edge of the roof.

Scheme 126

1. Dimension -a- = 45 mm (1.75 in).

Push roof reinforcement from inside onto body roof.

Install the headliner HEADLINER .

Scheme 127

Disengage the sun visor -1- in the center of the vehicle from at the sun visor center bracket -2-.

Unclip the expanding cap -3- using a screwdriver.

Tilt the sun visor bracket down -arrow- and remove it.

Vehicles with illumination: Disconnect the connector and remove the sun visor.

Install in reverse order of removal. Note the following

Engage the sun visor bracket tab in the opening in the headliner.

Press the sun visor expanding cap on until it engages completely.

SUN VISOR CENTER BRACKET

Special tools and workshop equipment required

1. Pry Lever 80 - 200

Scheme 128

Disengage the sun visor in the center of the vehicle at the center bracket and fold it to the side.

Unclip the sun visor center bracket cover -1- by sliding the pry lever 80 - 200 only approximately 1 mm under the cap -2 arrows-.

Note. If the pry lever 80 - 200 is shoved further underneath, it will then be under the center bearing for the sun visor. At that point, it is not possible to pry off the cover.

Remove sun visor center bracket -3- -arrow 4-.

Install in reverse order of removal. Note the following

Note. Make sure the expanding clips are not damaged when inserting the sun visor center bracket.

FASTENER TIGHTENING SPECIFICATIONS

SPECIAL TOOLS

Special tools and workshop equipment required

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

1. Trim Removal Wedge 3409
2. Pliers 3392
3. Hook 3438
4. Special Pliers VAS 6339
5. Pry Lever - RMV Outside Mirror 80 - 200
6. Release Lever T10039
7. Long Reach Special Wrench for Slotted Bolts VAS 6543

See also:
• [For engine(s) CAUA, CAEB, CALA] Removal and Installation
• FRONT SIDE AIRBAG CRASH SENSORS, SAFETY PRECAUTIONS
• CENTER CONSOLE OVERVIEW
• CENTER CONSOLE
• DRIVER SIDE INSTRUMENT PANEL COVER OVERVIEW
• DRIVER SIDE INSTRUMENT PANEL COVER
• SAFETY PRECAUTIONS
• GLOVE COMPARTMENT OVERVIEW
• [For engine(s) CAUA, CAEB, CALA] Removal and Installation
• [For engine(s) CAUA, CAEB, CALA] Removal and Installation
• [For engine(s) CAUA, CAEB, CALA] Removal and Installation
• [For engine(s) CAUA, CAEB, CALA] Removal and Installation
• [For engine(s) CAUA, CAEB, CALA] Removal and Installation
• Steering
• INSTRUMENT CLUSTER GAP COVER
• [For engine(s) CAUA, CAEB, CALA] Removal and Installation
• [For engine(s) CAUA, CAEB, CALA] Removal and Installation
• FRONT BELT ANCHOR
• MANUAL STANDARD FRONT SEAT
• POWER STANDARD FRONT SEAT
• SUPER SPORT FRONT SEAT
• BACKREST
• BENCH SEAT
• REAR BELT ANCHOR
• RELEASE CABLE WITH REMOTE CONTROL UNLOCK HANDLE
• Removal and Installation
• DOOR TRIM
• DOOR TRIM STORAGE POCKET REINFORCEMENT
• TRIM MOLDING
• TREBLE SPEAKER TRIM
• INSIDE DOOR RELEASE MECHANISM
• Rear Lid Remote Release Button -E233- SWITCH MOUNT
• MID-RANGE SPEAKER TRIM
• SWITCH TRIM
• PULL HANDLE WITH SWITCH MOUNT
• ARMREST
• SIDE INSTRUMENT PANEL VENT
• SIDE SPEAKER TRIM
• MMI SCREEN
• CENTER INSTRUMENT PANEL VENT
• Access/Start Authorization Switch -E415-, TRIM PANEL
• A-PILLAR UPPER TRIM
• A-PILLAR LOWER TRIM
• B-PILLAR TRIM
• B-PILLAR TRIM PANEL
• BELT EXTRACTION PANEL
• C-PILLAR TRIM
• FOOTREST
• SIDE TRIM
• SILL PANEL
• REAR SHELF
• CAP
• SPEAKER TRIM
• LUGGAGE COMPARTMENT FLOOR MAT BRACKET
• TIE-DOWNS
• LUGGAGE COMPARTMENT SIDE TRIM
• REAR CROSS PANEL TRIM
• REAR LID TRIM
• HEADLINER
• SUN VISOR CENTER BRACKET
• INSTRUMENT PANEL SIDE COVER
• ROOF GRAB HANDLE
• DOOR TRIM OVERVIEW
