Convertible Tops Audi A4 B6

Safety regulations

Convertible top, assembly overview

The following list pertains to (Scheme 2).

1. Convertible top Removing, see «CONVERTIBLE TOP, REMOVING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops) .
2. Front roof frame seal Removing, see «CONVERTIBLE TOP SEALS, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__convertible-top-seals-removing-and-installing) .
3. Center roof frame seal Removing, see «CONVERTIBLE TOP SEALS, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__convertible-top-seals-removing-and-installing) .
4. Rear roof frame seal Removing, see «CONVERTIBLE TOP SEALS, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__convertible-top-seals-removing-and-installing) .
5. Tensioning bar seal Removing, see «CONVERTIBLE TOP SEALS, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__convertible-top-seals-removing-and-installing) .
6. Convertible top box lid
7. Bolt 36 Nm
8. Main mounting The main mounting is used to adjust convertible top position relative to the vehicle. See «CONVERTIBLE TOP, ADJUSTING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__convertible-top-adjusting) .

Scheme 2

Scheme 3

1. Remove rear side trim: See «REAR SIDE TRIM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . NOTE: Remove the convertible top box lid for easier removal. Instructions for convertible top installation are given such that opening of the hydraulic system is not necessary. Upon installation, ensure freedom of movement when convertible top is closed. Ensure that when convertible top is operated, the windows are lowered by at least 50 mm at front and rear.
2. Release the convertible top locks.
3. Unscrew only the hex bolts -2- from the hinge -1-.
4. The bolt -3- must not be unscrewed.
5. This will prevent adjustment procedures becoming necessary upon convertible top box lid installation.
6. Lift off the convertible top box lid. WARNING: Protect the vehicle against paint damage using suitable protective covers and fabric adhesive tape.
7. Move the convertible top into center position.
8. Remove the tensioning bar hydraulic cylinders from the ball mounts.
9. Pull the hydraulic lines from the convertible top frame guides.
10. Lay the hydraulic cylinders toward rear in convertible top box.
11. Detach connectors -arrows- at right side of vehicle.
12. Detach the relevant connector on left side of vehicle.
13. Remove the convertible top wires from the guides and cable ties of the body panel and the convertible top frame. NOTE: All cable ties, which were released or cut open when removing the convertible top frame must be installed in the same position when installing.
14. Remove the cross head screws -1- of the convertible top switch assembly, consisting of switch for convertible top at front -F202- and switch for convertible top stowed -F171-.
15. Carefully pull the convertible top switch assembly from the bolt location mounts.
16. Remove securing pins -2- of the main hydraulic cylinder.
17. Loosen the nuts on the main hydraulic cylinder retainer until these can be removed from their hinge points and laid aside inside the vehicle. NOTE: When installing, make sure the plastic washers are engaged in the main hydraulic cylinder hinge points. The convertible top switch assembly described is located at the right main mounting. Move the convertible top into the appropriate position in order to remove the respective convertible top switch assembly screw. All further installation instructions apply to the right side of the vehicle and are to be carried out in similar or identical fashion for the left side.
18. Loosen the bolts of both main mountings by approx. two turns. Two mechanics must balance the convertible top at left and right.
19. Remove the bolts -1- and -2-. Bolt -3- remains in place to secure in the body panel.
20. Lift the convertible top by approx. 20 cm and pull the convertible top wires upward from the body.
21. Carefully press the convertible top box lid closed.
22. Lift the convertible top rearward over the vehicle.

Convertible top, installing

Installation is carried out in the reverse order; noting the following

1. When inserting the convertible top frame ensure that the hydraulic lines and the electric wires are not damaged.
2. Adjust the convertible top. See «CONVERTIBLE TOP, ADJUSTING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__convertible-top-adjusting) .
3. Reconnect electrical wiring.
4. Adjust door windows. See «ADJUSTING LATERAL TILT»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__adjusting-lateral-tilt) .
5. Adjust the rear side windows. See «ADJUSTING LATERAL TILT»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__adjusting-lateral-tilt) .
6. Perform function test.
7. With the convertible top closed, check whether the windows when run in the up position slide into the seals at front and rear.
8. Reinstall all trims.

Convertible top, adjusting

Checking convertible top setting

1. Close the convertible top as far as shown in the illustration on the side.
2. The locking lug at the convertible top must be inserted centrally into the bore -arrow A- of the locking part.

Adjusting convertible top

1. Loosen the main mounting bolts and move the convertible top into the position shown -arrow A-.
2. Tighten the main mounting bolts. Tightening torque: 36 Nm
3. Check the convertible top adjustment.
4. Perform function test.

Convertible top lock, removing and installing

1. Trim for front bracing hoop removed.
2. For removal press pushrod -1- from ball stud.
3. Unscrew the bolts -2- and remove the convertible top lock.
4. To adjust the convertible top lock loosen the lock nut -arrow- on the rod -1-, adjust the ball stud by screwing the thread in or out.
5. Adjust the ball studs so that the arrester tip tensions the convertible top flush against the roof frame upon closing.
6. Lock the adjustment with the lock nut.

Side windows, adjusting

1. Remove rear side trim: See «REAR SIDE TRIM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
2. Removing front door trim: See «FRONT DOOR TRIMS»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . NOTE: Adjustment procedures are described for rear windows and may be employed for the door windows in like manner.

Special tools and workshop equipment required

1. Adjustment tool for rear window V.A.G 1739

Adjusting lateral tilt

1. Using the adjustment tool for rear windows V.A.G 1739 loosen the locknuts -1- of the adjustment collar bolts.
2. Adjust the tilt angle by turning the Allen screw -2-.
3. Tighten the locknut. Tightening torque: 20 Nm

Scheme 4

Adjusting longitudinal tilt and closing height

1. Remove the hex bolts.
2. Move the side window into the convertible top seal groove.
3. Tighten the hex bolts. Tightening torque: 8 Nm

Scheme 5

Checking the adjustment

1. With the convertible top closed, check whether the windows when run in the up position slide into the seals at front and rear -arrow-.

Scheme 6

Convertible top seals, removing and installing

The following list pertains to (Scheme 14).

1. Front roof frame seal Removing: First unscrew the securing bolts for the front seal retainer strip. See «REMOVE RETAINING STRIP WITH FRONT SEAL»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__remove-retaining-strip-with-front-seal) . Remove sealing rubber sideways from the seal carrier. Remove retaining strip with seal.
2. Bolt
3. Center roof frame seal To remove open convertible top until the center roof frame seal and the rear roof frame seal do not touch at the contact edges. Removing: Pull out seal toward the side and remove.
4. Rear roof frame seal To remove open convertible top until the center roof frame seal and the rear roof frame seal do not touch at the contact edges. Removing: Pull out seal toward the side and remove.
5. Front bracing hoop trim Removing: First unscrew the securing bolts for the front seal retainer strip. See «REMOVE RETAINING STRIP WITH FRONT SEAL»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__remove-retaining-strip-with-front-seal) . Carefully pull off trim.
6. Convertible top lock The left and right guide pins must slide centrally into the locking part guides when closing the convertible top.
7. Tensioning bar seal Can be pulled off if convertible top is partly open or pressed on for assembly.

Scheme 7

Remove Retaining Strip With Front Seal

1. Unscrew the bolts -arrows-.
2. Pull out the front seal to the side.
3. Detach the retaining strip with the seal -1-.

Remove seal from seal carrier.

1. Pull seal -1- off the retaining rail in direction of arrow.

Note. When installing, ensure exact position of seal in seal carrier. Center roof frame seal, rear roof frame seal, and tensioning bar seal are removed in like manner.

Convertible top headliner, removing

1. Move the convertible top into center position.
2. Unscrew the retaining strip bolts for the front seal from the bracing hoop.
3. Carefully pull off the front bracing hoop trim.
4. Remove the bolt -A-.
5. Pull the securing channel -B- from bracing hoop -C-.

Note. The screw -A- retains both the tensioning cable and the front convertible top headliner tab together.

Scheme 8

1. Remove the cross head screw for tensioning strap -A- and rubber cord -B- at the pivot mechanism for roof link 2.
2. Pull the rubber cord -B- from the eyelet at the inside of roof link 2.
3. Disengage the tensioning cable from the spring and pull it forward through the eyelet at the rear end of the roof link.

Note. The spring will become visible at the rear end of roof link 2, if the convertible top is moved to the center position.

Scheme 9

1. Remove the cross head screw -1-.
2. Disengage the spring -2- from the tensioning strap -3-.
3. Pull the tensioning straps from the convertible top frame tensioner guides.
4. Remove the convertible top headliner plastic strips from roof bracing hoops 2 and 3.
5. Undo the staples VAS 6148/1 on the zip fastener ends.
6. Pull the zip fastener apart.

Note. Ensure that the zip fastener is not damaged.

1. Drill open rivet -1- of the convertible top headliner at the tensioning bar.
2. Pull the convertible top headliner securing strip from the groove in the tensioning bar.
3. Push the convertible top headliner out from the rear window guide frame.

1. VAS 6138 Closing pliers
2. VAS 6148 Stapler
3. VAS 6148/1 Staples
4. VAS 5072 Blind rivet pliers

Note. Installation of the convertible top headliner is in reverse order of removal. Ensure correct installation position and proper function of all convertible top components. Perform function test.

Part designation

Note. These part designations are used in the description of removal and installation

The following list pertains to (Scheme 27).

1. Bracing hoop 1
2. Bracing hoop 2
3. Bracing hoop 3
4. Bracing hoop 4
5. Bracing hoop 5
6. Tensioning bar
7. Main mounting
8. Main strut
9. Roof strut -2
10. Roof strut -1
11. Front bracing hoop

1. Move the convertible top into center position.
2. Remove the retaining strip with the front seal, see «Remove Retaining Strip With Front Seal»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__remove-retaining-strip-with-front-seal) .
3. Remove the convertible top headliner tabs -1- at the front bracing hoop.
4. Remove the piping -2- and the convertible top cover -3- from the front bracing hoop groove.
5. Pull the convertible top cover sideways from the convertible top frame.
6. Remove the tensioning band at the roof link between bracing hoop 3 and bracing hoop 4.
7. Remove the tensioning cable -1- from the mounting bore -2- in the roof link 1.
8. Pull the tensioning cable rearward from the convertible top pockets.

Note. Use a suitable welding rod to pull in the tensioning cable.

1. Fold back the convertible top cover.
2. Undo the staples VAS 6148/1 on the zip fastener ends.
3. Pull the zip fastener apart (4x).

Note. Ensure that the zip fastener is not damaged.

1. Move the tensioning bar into the upright position (convertible top in center position) and unscrew the bolt -B-.

Note. For ease of illustration, the convertible top frame is shown without convertible top headliner, without convertible cover, and without convertible cushion.

1. Remove the securing disc on the rear window cable guide and pull the cable from its guide -arrow-.
2. Drill open rivet -1- of the convertible top headliner at the tensioning bar.
3. Pull the convertible top headliner securing strip from the groove in the tensioning bar.
4. Push the convertible top headliner out from the rear window guide frame. The convertible top headliner is now detached from the convertible top cover (rear window frame).
5. Remove the rear convertible top frame -1- from the groove in the tensioning bar -2-.
6. Remove the connectors for rear window heating.
7. Pull the convertible top frame downward at the main link.

1. VAS 6138 Closing pliers
2. VAS 6148 Stapler
3. VAS 6148/1 Staples

Note. Installation of the convertible top cover is in reverse order. Ensure correct installation position and proper function of all convertible top components. Perform function test.

Scheme 10

1. Remove convertible top headliner. See «CONVERTIBLE TOP HEADLINER, REMOVING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__convertible-top-headliner-removing) .
2. Remove convertible top cover. See «CONVERTIBLE TOP COVER, REMOVING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops) .
3. Move the convertible top into center position.
4. Remove the beading -1- and pull the convertible top cushion from the groove -2- of the front bracing hoop.
5. Pull the convertible top cushion from the adhesive tape at the main link -1-.
6. Remove the bolt from the rear end of the convertible top cushion in the tensioning bar.
7. Push the convertible top cushion forward out of the top groove in the tensioning bar -2-.
8. Remove cross-head screws -arrow- of the convertible top cushion tensioning straps.
9. Remove cross-head screws -arrows- of the tensioning straps for bracing hoop 2 and bracing hoop 3.
10. Pull the convertible top cover to the side from the bracing hoops.

Convertible top cushion, installing

Note. Installation of the convertible top cushion is in reverse order. Ensure correct installation position and proper function of all convertible top components. Perform function test.

Convertible top emergency release

1. Key for convertible top emergency release in basic setting.
2. Key for convertible top emergency release in operational setting.

Note. The convertible top emergency release key is located on the left under the fuse cover of the dash panel. The following description uses the abbreviation ERK for the convertible top emergency release key.

Scheme 11

Scheme 12

1. Lower the side windows by approx. 20 cm.
2. Close the luggage compartment lid.
3. Open the driver's side door and remove the fuse carrier lid at the dash panel. For purposes of lifting off, a groove is located at the lower edge of the fuse cover, where e.g. a key may be inserted.
4. Pull the ERK from the bracket above the fuse carrier in the dash panel.
5. Remove the center piece of the rear seatback by pushing the small tab slightly downward and toward oneself.
6. Press the handle holes together and fold open the lid.
7. Push the ski bag downward and pull out as necessary Move the ERK to basic setting as follows
8. Rotate the red handle piece to the left up to stop.
9. Insert the ERK into the upper central aperture of the skibag tunnel.
10. Turn the entire ERK until the small lugs at the key head noticeably slide into the groove.
11. Turn the entire ERK a quarter turn clockwise against the stop in the latch.
12. Turn the red handle clockwise, until both ERK handle halves engage audibly. The ERK is fixed in the lock system and may be operated.
13. Open the convertible top box cover by turning the ERK counterclockwise up to stop.
14. Pull the convertible top box lid open up to stop. The convertible top box lid engages in the open position.
15. Lift off the convertible top out of the convertible top box by forcefully pulling the tip of the roof upward. Move the convertible top into center position by hand as follows
16. Close the convertible top until it is half closed and remains stationary without assistance. Push the roof tip forward as far as possible.
17. Lift the convertible top cover tensioning bar until it remains in the fully upright position.
18. Carefully press the convertible top box lid closed.
19. Turn the entire ERK clockwise up to stop. The convertible top box lid is locked. Remove the ERK as follows.
20. Turn the red handle piece counterclockwise up to stop.
21. Turn the complete ERK a quarter turn counterclockwise and pull it downward.

Locking and unlocking convertible top

1. Press the tensioning bar onto the convertible top box lid.
2. Press the convertible top at the front of the vehicle onto the top frame of the windscreen. The convertible may bounce slightly in the process.
3. Remove the cover in the center of the front bracing hoop trim from the vehicle interior.

Move the ERK to basic setting as follows

Scheme 13

1. Turn the red handle piece to the left up to stop.
2. Insert the ERK into the aperture at the center of the front bracing hoop trim.
3. Turn the entire ERK until the small lugs at the key head noticeably slide into the groove.
4. Turn the entire ERK an entire quarter turn clockwise against the stop in the latch.
5. Turn the red handle clockwise, until both ERK handle halves engage audibly. The ERK is fixed in the lock system and can be operated.
6. Turn the entire ERK clockwise up to stop.
7. Pull the convertible top downward over the ERK.
8. Turn the entire ERK counterclockwise up to stop. The convertible top is locked. Remove the ERK as follows.
9. Rotate the red handle piece counterclockwise up to stop.
10. Rotate the complete ERK a quarter turn counterclockwise and pull downward.
11. Reattach the trim cap.
12. Close the side windows.

General information on hydraulic system

The hydraulic system is self-bleeding and maintenance-free.

When the hydraulic cylinder or hoses are replaced, no topping up the hydraulic fluid is necessary. The system contains sufficient hydraulic fluid so that the fluid level does not fall to or below the min. mark.

When operations are performed owing to loss of hydraulic fluid, the fluid level must be checked and rectified if necessary prior to operation.

Rules for cleanliness

1. Thoroughly clean all unions and the adjacent areas before disconnecting.
2. Place removed parts on a clean surface and cover. Use sheeting and paper. Use lint-free cloths.
3. Carefully cover or seal open components if repairs cannot be carried out immediately.
4. Only install clean components: do not remove replacement parts from their wrapping until you are ready to install them.
5. Place containers, plastic film or cloths under connections to be opened so that no hydraulic fluid comes into contact with painted surfaces.
6. Shut off open hydraulic lines with closure caps to prevent hydraulic fluid from leaking out.

Assembly overview

The following list pertains to see scheme 60.

1. Right tensioning bar drive cylinder
2. Right main drive cylinder
3. Right convertible box lid drive cylinder
4. Hydraulic pump with valve block
5. Hydraulic lines
6. Left convertible box lid drive cylinder
7. Left tensioning bar drive cylinder
8. Left main drive cylinder

Hydraulic system, filling and bleeding

Note. The electrohydraulic convertible top actuation is designed as a closed hydraulic system. Filling is generally only necessary following loss of fluid (accident, leak etc.). Owing to the travel and the displacement effect of the piston in the hydraulic cylinder, the hydraulic system must be filled with the convertible top folded in the convertible top box. For this purpose, the convertible top must be moved via electrohydraulic actuation.

Filling

1. Remove luggage compartment trim: See «LUGGAGE COMPARTMENT TRIM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
2. Unscrew oil filler bolt -arrow- (2 Nm).
3. Fill with hydraulic fluid G 002 000 using an oil can until the fluid level is between the "MIN" and "MAX" marks.

Bleeding

Note. The hydraulic system is self-bleeding. When the convertible top has been opened and closed several times, the system is bled.

1. Start the engine.
2. Close and open the convertible top 4... 5 times using the electrohydraulic actuation. It must move continuously and jolt-free.
3. Check the fluid level in the fluid container -2- with the convertible top folded into the convertible top box. The fluid level must be between the "MIN" and "MAX" marks.
4. Top up hydraulic fluid, if necessary.

Hydraulic unit (hydraulic pump), removing and installing

1. Remove luggage compartment trim: See «LUGGAGE COMPARTMENT TRIM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
2. Unscrew the hex bolts.
3. Remove the hydraulic lines from their guides.
4. Remove the connectors.
5. Lift the hydraulic pump out of its position and place it on a protective covering in the luggage compartment.

Hydraulic pump housing, removing and installing

1. Remove the hydraulic pump. See «HYDRAULIC UNIT (HYDRAULIC PUMP), REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__hydraulic-unit-hydraulic-pump-removing-and) .
2. Unscrew the Torx bolts -arrows-.
3. Carefully pull off the pump housing.

Pump gear, removing and installing

1. Remove the hydraulic pump housing. See «HYDRAULIC PUMP HOUSING, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__hydraulic-pump-housing-removing-and-installing) .
2. Check the pump gear -arrow- for damage.
3. Pull off the pump gear upward.

Solenoid valve, removing and installing

For cleanliness rules, see RULES FOR CLEANLINESS .

Removing

1. Remove the hydraulic pump. See «HYDRAULIC UNIT (HYDRAULIC PUMP), REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__hydraulic-unit-hydraulic-pump-removing-and) .
2. Unscrew the TORX bolts -3-.
3. Lift out the solenoid valve -2- from the hydraulic pump -1-.

Installing

1. Plug in the connector -1- at the solenoid valve -2-.
2. Initiate the Output Diagnostic Test Mode (DTM) and activate the solenoid valve to be installed.
3. Insert the actuated solenoid valve -2- into the hydraulic pump -3-.
4. Tighten the TORX bolts -arrows-. Tightening torque: 8 Nm

Hydraulic lines, removing and installing

1. Remove rear side trim: See «REAR SIDE TRIM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
2. Using a pair of pliers, remove the securing plate from the groove.
3. Pull the hydraulic line from the hydraulic cylinder.

Scheme 14

Note. The hydraulic line seal is pressed into the hydraulic cylinder and cannot be exchanged separately.

Hydraulic lines at the fitting plate, removing and installing

For cleanliness rules, see RULES FOR CLEANLINESS .

Hydraulic pump connection chart, see HYDRAULIC PUMP CONNECTION CHART .

1. 3335 Assembly driver

Scheme 15

1. Remove the hydraulic pump. See «HYDRAULIC UNIT (HYDRAULIC PUMP), REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__hydraulic-unit-hydraulic-pump-removing-and) .
2. Trim of center and side rear panel removed.
3. Lift spring washer -1- at the hydraulic lines to be removed (supply and return) using a small screwdriver above the fitting collar and remove.

Scheme 16

Scheme 17

1. Install the hydraulic line with fitting through the fitting plate.
2. Install the sleeve -1- of the assembly driver 3335 over the fitting.
3. Slide the spring washer -2- onto the sleeve and press it in using the assembly driver 3335. NOTE: The spring washer -2- must be pushed completely over the collar at the fitting -1-.
4. Coat the sealing ring -3- with hydraulic fluid and slide it onto the fitting.

Hydraulic pump connection chart

Fittings viewed from the hose side.

Scheme 18

11 Left piston rod side

12 Left piston side

13 Right piston rod side

14 Right piston side

Tensioning bar drive hydraulic cylinder

21 Left piston rod side

22 Left piston side

23 Right piston rod side

24 Right piston side

Convertible top box lid hydraulic cylinder

31 Left piston rod side

32 Left piston side

33 Right piston rod side

34 Right piston side

Hydraulic cylinder, removing and installing

1. Removing and installing hydraulic lines. See «HYDRAULIC LINES, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__hydraulic-lines-removing-and-installing) .

Tensioning bar drive cylinder

1. Remove the hydraulic cylinders from the ball mounts as illustrated.
2. Pull the hydraulic lines from the convertible top frame guides.
3. Lay the hydraulic cylinders toward rear in convertible top box.

Convertible top box lid cylinder

Note. Assembly of the convertible top box lid cylinders is as described above.

Main drive cylinder

1. Remove the cross head screws -1- of the convertible top switch assembly, consisting of switch for convertible top at front -F202- and switch for convertible top at rest -F171-.
2. Carefully pull the convertible top switch assembly from the bolt location mounts.
3. Remove securing pins -2- of the main hydraulic cylinder.
4. Loosen the nuts on the main hydraulic cylinder retainers until these can be retrieved from their hinge points and laid aside inside the vehicle.

Scheme 19

See BATTERY DISCONNECT PRECAUTIONS .

Attachment parts, assembly overview

1. Cable for guide - rear window Removing (Scheme 34)
2. Belt for tensioning bar - Bracing hoop 4 Removing see scheme 81
3. Belt for tensioning bar - Bracing hoop 5 Removing, see scheme 82
4. Rubber band for bracing hoop 3 - 4 Removing see scheme 83and see scheme 84
5. Belt for dead center strut -Bracing hoop 4 Removing see scheme 83and see scheme 84
6. Convertible top locking mechanism (Motor -V223-/ switch -F294- / switch -F295-) Removing, see «REMOVING CONVERTIBLE TOP LOCKING MECHANISM (MOTOR -V223-/SWITCH -F294-/SWITCH -F295-)»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops).
7. Convertible top lock Removing, see «CONVERTIBLE TOP LOCK, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__convertible-top-lock-removing-and-installing).
8. Eyelet for headliner cable Removing see scheme 86
9. Plastic channel Removing see scheme 85
10. Headliner tensioning wire Removing, see scheme 76
11. Headliner tensioner Removing, see scheme 76
12. Convertible top cover tensioning cable Removing, see scheme 78
13. Spring for headliner cable (longitudinal) Removing see scheme 87
14. Spring for headliner cable (lateral) Removing, see scheme 83
15. Eyelet for headliner cable Removing see scheme 83
16. Spring for bracing hoop 5 dead center strut Removing, see «CONVERTIBLE TOP HEADLINER, INSTALLING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops).
17. Damping element for tensioning bar Removing see scheme 80

Scheme 20

Convertible top cover, removing and pre-assembling

1. Remove convertible top headliner. See «CONVERTIBLE TOP HEADLINER, REMOVING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__convertible-top-headliner-removing) .
2. Remove convertible top cover. See «CONVERTIBLE TOP COVER, REMOVING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops) .
3. Remove convertible top cushion. See «CONVERTIBLE TOP CUSHION, REMOVING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops)
4. Remove seals. See «CONVERTIBLE TOP SEALS, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__convertible-top-seals-removing-and-installing) .

Note. It is not always necessary to perform all the procedures described above in order to repair individual convertible top attachments parts. The instructions describe work on the convertible top frame without convertible top headliner, without convertible top cover, without convertible top cushion, and without seals. The instructions relate to the right side of the convertible top and the left side is repaired similarly. The convertible top frame may be disassembled and preassembled while installed in the vehicle. Disconnect the vehicle battery ground (GND) strap when working on the convertible top electrical system.

See BATTERY DISCONNECT PRECAUTIONS .

Scheme 21

1. Remove the convertible top locks. See «CONVERTIBLE TOP LOCK, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__convertible-top-lock-removing-and-installing) .
2. Remove the convertible top locking mechanism. See «REMOVING CONVERTIBLE TOP LOCKING MECHANISM (MOTOR -V223-/SWITCH -F294-/SWITCH -F295-)»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops) .
3. Remove the bolts for tensioning wire and tensioner -arrow- at the main link pivot linkage.

1. The threaded connection -arrow B- ties the tensioning wire and the tensioner together.

Note. For installation of the convertible top headliner, several models require removal of the bolt -arrow B- in order to slide the tab on the convertible top side over the tensioning wire.

Scheme 22

Scheme 23

1. Move the tensioning bar into the upright position (convertible top in center position) and unscrew the bolt -B-.
2. Unscrewthe bolt -arrow A- at the bracing hoop 5.
3. Pull the tensioning cable -1- upward out of the guide -2- at the main link.
4. Unscrew the bolt -3- and detach the tensioning cable.

Note. Upon installation, attach the tensioning cable -1- into the guide -2- using super glue.

Scheme 24

Scheme 25

1. Unscrew the bolt -A- for tensioning cable -1- and wiring trough -2-.
2. Pull the wiring trough -2- from the linkage.
3. Unscrew the bolt -B- and remove the tensioning bar position sensor-G256- item -3-.
4. Remove the wiring harness from its brackets on the tensioning bar.
5. Pull the band -3- from the tensioning bar eyelet.
6. Unscrew bolt -2-.
7. Remove the tensioning bar damping element from the ball mount -1-.

Note. On installation ensure that the rubber cord for the threaded connection -2- is routed under the linkage.

Scheme 26

Scheme 27

Scheme 28

Scheme 29

1. Remove the common screwed connection of belts for bracing hoop 4 to tensioning bar, and bracing hoop 5 to tensioning bar at the tensioning bar -arrow-. NOTE: Both belts must be re-attached to the common securing point in the tensioning bar -arrow-.
2. Unscrew the bolt -B- of the spring for bracing hoop 5 dead centerstrut -A-.
3. Check the adhesive tapes -arrows- at the dead center linkage and at the bracing hoop 5 for damage.
4. Unscrew the bolt at the bracing hoop 5. The following components are attached to this bolt: - 1 - Belt for bracing hoop 5 to tensioning bar - 2 - Spring for headliner cable (lateral) - 3 - Eyelet for headliner cable - 4 - Spring for bracing hoop 5 dead center strut
5. Slide the rubber band -2- from the side of bracing hoop 3.
6. Unscrew the bolt -A- at the bracing loop 4 and remove the belt-1-.
7. Unscrew the bolt -C- from the dead center strut and the bolt -B- from the bracing hoop 4.
8. Remove the band -2- and the belt -3-.

Note. The rubber band -2- is pushed in place at bracing hoop 3 upon installation of the convertible top cushion.

Scheme 30

1. Unscrew the bolt -A- at the roof link 2 and remove the eyelet.
2. Pull the plastic channel -B- off the lower roof link 2.

Note. Upon installation, the plastic channel -B- must be attached using a suitable adhesive compound.

Scheme 31

1. Open the convertible top until roof link 2 and main link do not touch at the contact edges.
2. Unscrew the bolt -arrow- of the headliner cable eyelet in longitudinal direction.

Note. For some versions, the eyelet may be riveted to the main link.

Scheme 32

Scheme 33

Scheme 34

1. Unscrew the bolt -arrow- at the inside of the main link.
2. Remove the spring for the headliner cable in longitudinal direction.
3. Unclip the wiring harness from the convertible top locking mechanism from its guide -arrow- starting with the front bracing hoop at the main link.
4. Remove the bolt -A- and detach the wiring holder -1- from the roof link 2.
5. Remove the bolt -B- and pull the wiring trough -2- from the pivot linkage at the inside of the main link and from the main mounting.
6. Remove the wiring harness.

Note. Upon installation, ensure a sufficient excess wiring loop between wiring holder -1- and wiring trough -2- in order to prevent chafing or pinching of the wiring harness.

Scheme 35

1. Check the two-sided adhesive tape on the outside of the main link -arrows- for damage.
2. Remove the convertible top frame. See «CONVERTIBLE TOP, REMOVING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops) . NOTE: The adhesive tape serves to attach the convertible top cushion to the main link.

See BATTERY DISCONNECT PRECAUTIONS .

Convertible top box lid, Assembly overview

1. Left convertible top box lid lock The left convertible top box lid switch -F290- is attached to the lock. Removing, see «REMOVING LEFT AND RIGHT CONVERTIBLE TOP BOX LID LOCKS»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__removing-left-and-right-convertible-top) .
2. Locking plate
3. Left lock bolt 3x
4. Left pushrod
5. Switch for latch (motor/switch) 6x
6. Right lock bolt 3x
7. Locking plate
8. Right pushrod
9. Right convertible top box lid lock The right convertible top box lid locked switch -F200- is attached to the lock. Removing, see «REMOVING LEFT AND RIGHT CONVERTIBLE TOP BOX LID LOCKS»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__removing-left-and-right-convertible-top) .
10. Right puller tab Removing, «CONVERTIBLE TOP BOX LID»(/audi/a4/b6-2000-2006/remont/exterior-body-panels/#hood-lids-cabriolet)
11. Convertible top box lid-latch (motor -V222- / switch -F293-) Removing, see «REMOVING CONVERTIBLE TOP BOX LID LATCH»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops) .
12. Left puller tab Removing, «CONVERTIBLE TOP BOX LID»(/audi/a4/b6-2000-2006/remont/exterior-body-panels/#hood-lids-cabriolet)

Scheme 36

Convertible top box lid latch, removing and installing

Note. Disconnect the vehicle battery ground (GND) strap when working on the convertible top electrical system. All cable ties, which were released or cut open when removing must be installed in the same position when installing.

Removing left and right convertible top box lid locks

The illustration shows the leftlock in the installed position.

Scheme 37

Scheme 38

1. Move the convertible top into center position.
2. Remove the convertible top box pan front trim.
3. Remove the securing disc -1-.
4. Pull off the pushrod -2-.
5. Mark the exact installation positions of the bolts -3- and remove them.
6. Unscrew the switch -F290- (-F200- on right) and retrieve the lock.

The illustration shows the rightlock in the installed position; left side similar.

Note. Assembly is as for the left lock.

Installing left and right convertible top box lid locks

Installation is carried out in the reverse order; note the following

1. Tighten the bolts precisely at the previously made marks, adjustment of the locks will not be necessary as a result.
2. Ensure that the convertible top box lid aligns with the side panel after closing.
3. Check whether the switches work with the convertible top box lid closed.
4. The switches may be adjusted by changing pushrod length, by loosening the locknuts and adjusting the ball mount threaded connections.

Scheme 39

1. Move the convertible top into center position.
2. Remove the convertible top box pan front trim.
3. For removal press push rod -1- from ball stud.
4. Detach connector.
5. Unscrew the bolts (6x).
6. Remove the convertible top box lid-latch (motor -V222-/switch -F293-assembly)
7. Push the connector out of its bracket.
8. Drill open rivet of microswitch.
9. Remove the bolts -1-.
10. Pull the motor -2- out of bracket in direction of arrow -3-.

See BATTERY DISCONNECT PRECAUTIONS .

1. Convertible top locking mechanism Consists of: Convertible top locking motor -V223- Convertible top open switch -F294- Convertible top closed switch -F295- Removing, see «REMOVING CONVERTIBLE TOP LOCKING MECHANISM (MOTOR -V223-/SWITCH -F294-/SWITCH -F295-)»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops)
2. Convertible top operation control module -J256- Removing, see «REMOVING CONVERTIBLE TOP OPERATION CONTROL MODULE -J256»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__removing-convertible-top-operation-control-module)
3. Switch for convertible position Consists of: Convertible top stowed switch -F171- Front convertible top switch -F202- Removing, see «REMOVING CONVERTIBLE TOP POSITION SWITCH (SWITCH -F171-/SWITCH -F202-)»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__removing-convertible-top-position-switch-switch) .
4. Tensioning bar position sensor-G356- Removing, see «REMOVING TENSIONING BAR POSITION SENSOR -G356»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops) .
5. Convertible top box lid up switch -F201- Removing, see «REMOVING UPPER CONVERTIBLE TOP BOX LID SWITCH -F201»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__removing-upper-convertible-top-box-lid) .
6. Convertible top operation hydraulic unit Consists of: Convertible top operation hydraulic pump -V118- Convertible top operation hydraulic pump relay -J321- Convertible top operation hydraulic pump relay -2- -J588- Power operated convertible top valve -1--N272- Power operated convertible top valve -2--N341- Power operated convertible top valve -3- -N342- Removing, see «HYDRAULIC UNIT (HYDRAULIC PUMP), REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__hydraulic-unit-hydraulic-pump-removing-and)
7. Convertible top box pan position switch -F292- Removing See «MICROSWITCH FOR VARIABLE CONVERTIBLE TOPCOMPARTMENT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
8. Convertible top box lid locked switch, right side -F200- Removing, see «REMOVING LEFT -F290- AND RIGHT -F200-CONVERTIBLE TOP BOX LID SWITCHES»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__removing-left-f290-and-right-f200-convertible)
9. Convertible top box lid latch Consists of: Convertible top box lid latch unlocked switch -F293- Front convertible top box lid latch motor -V222- Removing, see «REMOVING CONVERTIBLE TOP BOX LID LATCH»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops) .
10. Left convertible top box lid switch -F290- Removing, see «REMOVING LEFT -F290- AND RIGHT -F200-CONVERTIBLE TOP BOX LID SWITCHES»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__removing-left-f290-and-right-f200-convertible) .
11. Front convertible top locking mechanism switch -F172- Removing, see «REMOVING FRONT CONVERTIBLE TOP LOCK SWITCH -F172»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops) .
12. Convertible top operation button -E137- Removing, see «REMOVING CONVERTIBLE TOP OPERATION BUTTON -E137»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__removing-convertible-top-operation-button-e137) .

Scheme 40

Electrical components for convertible top operation, removing and installing

Note. Disconnect the vehicle battery ground (GND) strap when working on the convertible top electrical system. All cable ties, which were released or cut open when removing the convertible top must be installed in the same position when installing.

Scheme 41

1. Lay the convertible top into the convertible top box. The convertible top box lid remains in the open position.
2. Unscrew the front roof frame seal screws.
3. Carefully pull off the front bracing hoop trim.
4. Remove the wire ball joint retainers and press the pushrods from the convertible top lock ball studs.
5. Disconnect the electrical connection.
6. Unscrew the convertible top lock screws and remove the convertible top lock.

Removing convertible top position switch (switch -F171-/switch -F202-)

1. Remove rear side trim: See «REAR SIDE TRIM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
2. Detach connector at convertible top operation control module-J256-.
3. Remove the convertible top wires from the guides and cable ties of the body panel and the convertible top frame.
4. Remove the switch cross head screws.
5. Carefully pull the convertible top position switch from the bolt location mounts.

Note. The convertible top switch assembly is located at the right main mounting. Move the convertible top into the appropriate position, in order to remove the respective convertible top switch assembly screw.

Scheme 42

1. Move the convertible top into center position.
2. Detach the connector at the sensor.
3. Remove the sensor securing bolt carefully and pull it from its mounting cavity.

Note. When installing, ensure that the sensor is pushed over the convertible top linkage lug.

Removing upper convertible top box lid switch -F201

1. Move the convertible top into center position.
2. Remove the right side trim in the convertible top box See «TRIM FOR CONVERTIBLE TOP COMPARTMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
3. Detach connector.
4. Remove the switch securing screw.
5. Carefully lift switch out of its bracket.

Scheme 43

Removing convertible top operation control module -J256

1. Remove rear side trim: See «REAR SIDE TRIM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
2. Detach connectors.
3. Remove the control module securing nuts.

Scheme 44

Removing left -F290- and right -F200-convertible top box lid switches

The illustration shows left lock with switch.

Scheme 45

1. Move the convertible top into center position.
2. Remove the rear seat backrest See «REAR SEAT BACKREST, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__rear-seat-backrest-assembly-overview) . WARNING: Observe safety regulations for handling pyrotechnic belt tensioners.
3. Remove the left rear seat belt retractor.
4. Detach the connector behind the seat belt retractor.
5. Remove the left side convertible top box lid lock. See «REMOVING LEFT AND RIGHT CONVERTIBLE TOP BOX LID LOCKS»(/audi/a4/b6-2000-2006/remont/sun-rooft-topconvertible-top/#convertible-tops__removing-left-and-right-convertible-top) .

Scheme 46

The illustration shows right lock with switch.

Note. Assembly is as for the left switch.

Scheme 47

1. Open the convertible top.
2. Remove the upper roof frame trim at the inside of the windscreen See «WINDSHIELD TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__windshield-trim-assembly-overview) .
3. Detach connector.
4. Remove the bolts (3x) and remove the switch.

Scheme 48

Removing convertible top operation button -E137

1. Carefully pry out button-carrier assembly on the center console.
2. Detach the connector.
3. Slide the convertible lock switch button from the carrier assembly.

See also:
• BATTERY DISCONNECT PRECAUTIONS
• REAR SIDE TRIM
• CONVERTIBLE TOP BOX LID
• REAR SEAT BACKREST, ASSEMBLY OVERVIEW
• WINDSHIELD TRIM, ASSEMBLY OVERVIEW
• CONVERTIBLE TOP, REMOVING
• CONVERTIBLE TOP SEALS, REMOVING AND INSTALLING
• CONVERTIBLE TOP, ADJUSTING
• ADJUSTING LATERAL TILT
• REMOVE RETAINING STRIP WITH FRONT SEAL
• CONVERTIBLE TOP HEADLINER, REMOVING
• HYDRAULIC UNIT (HYDRAULIC PUMP), REMOVING AND INSTALLING
• HYDRAULIC PUMP HOUSING, REMOVING AND INSTALLING
• RULES FOR CLEANLINESS
• HYDRAULIC PUMP CONNECTION CHART
• HYDRAULIC LINES, REMOVING AND INSTALLING
• CONVERTIBLE TOP LOCK, REMOVING AND INSTALLING
• REMOVING LEFT AND RIGHT CONVERTIBLE TOP BOX LID LOCKS
• REMOVING CONVERTIBLE TOP OPERATION CONTROL MODULE -J256
• REMOVING CONVERTIBLE TOP POSITION SWITCH (SWITCH -F171-/SWITCH -F202-)
• REMOVING UPPER CONVERTIBLE TOP BOX LID SWITCH -F201
• REMOVING LEFT -F290- AND RIGHT -F200-CONVERTIBLE TOP BOX LID SWITCHES
• REMOVING CONVERTIBLE TOP OPERATION BUTTON -E137
