Front Doors Central Locking System - Except Cabriolet Audi A4 B6

Door Locks & Anti-Theft Systems 6 illustrations ~1962 words

Window frame and window lifter, assembly overview

The following list pertains to (Scheme 1).

  1. Window frame
  2. Window lifter Bolted to window frame for installation in door.
  3. Front door
  4. TORX bolt 32 Nm
  5. Cap
  6. Collared shoulder bolt 32 Nm
  7. Collared bolt 6 Nm
  8. TORX bolt 10 Nm
  9. Collared shoulder bolt 32 Nm

Window frame and window lifter, removing and installing

The following list pertains to (Scheme 2).

  1. Window frame Removing: Removing door trim. See «FRONT DOOR TRIM COMPONENTS, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__front-door-trim-components-assembly-overview) . Disconnect connectors. Remove window lifter motor, see «REMOVING AND INSTALLING WINDOW LIFTER MOTOR»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-except-cabriolet__removing-and-installing-window-lifter-motor) Remove bolts -7-. Remove bolts -4-, -8- and -10-. Remove bolts -6- and -9- and lift window frame and window lifter upward out of door. Installing: Insert window frame and window lifter in door from above. Button upper half of profile of door seal in top of window frame. Loosely install in bolts in this order: -6-; -9-;-3-; -8- and -10-. Tighten collared install bolts -6- and -9- hand-tight. Gently press top of window frame -1- inwards. Tighten bolts -4- and -8- to 32 Nm. Tighten collared install bolts -6- and -9- to 32 Nm. Tighten bolt -10- to 10 Nm Tighten locating bolt -arrow- in window frame to 32 Nm

Scheme 1

Scheme 1
Scheme 1

Removing and installing window lifter motor

  1. To remove, remove bolts -2- and remove window lifter motor.
  2. Installing window lifter motor, see «WINDOW LIFTER MOTOR, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-except-cabriolet) .

Upper door hinge

  1. Install TORX bolt (T45) -1-32 Nm (install from inside of vehicle).
  2. Upper door hinge -2-.
  3. Cap -3-.
  4. Install TORX bolt (T45) -4- 32 Nm.
  5. Install collared shoulder TORX bolt (T45) -5- 32 Nm.

Lower door hinge

  1. Install TORX bolt (T45) -1-32 Nm in B-pillar install from inside of vehicle.
  2. Lower door hinge -2-.
  3. Cap -3-.
  4. Install TORX bolt (T45) -4- 32 Nm.
  5. Install collared shoulder bolt (T45) -5- 32 Nm.
  6. Re-grease lubricating points -arrows- during routine servicing.
  7. Front door -6-.

Window lifter and door window, assembly overview

The following list pertains to (Scheme 6).

  1. Window frame Removing: Removing door trim. See «FRONT DOOR TRIM COMPONENTS, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__front-door-trim-components-assembly-overview) . Removing window frame from front door together with window lifter, see «FRONT DOOR»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-except-cabriolet) . Door window -4- removed To remove, remove countersunk head bolts -3- and detach window lifter from window frame. Installing: When installing make sure that both guide rails, arrows -A-, run parallel to guide, arrow -B-. Tighten bolts -3- to 6 Nm.
  2. Window lifter Removing window frame from front door together with window lifter, see «FRONT DOOR»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-except-cabriolet) . Door window removed To remove, remove countersunk head bolts -3- and detach window lifter from window frame.
  3. Countersunk head bolt 6 Nm
  4. Door window Removing: Open door window. Remove bolts -5- and detach door windows from window lifter. Installing: Insert window in window lifter. Install bolts -5- into window lifter but do not yet tighten. Close door window completely. Pull door window backwards into window guide of frame on B-pillar and tighten bolts -5- to 4 Nm.
  5. Hex socket-head bolt 4 Nm

Removing

  1. Door trim removed. See «FRONT DOOR TRIM COMPONENTS, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__front-door-trim-components-assembly-overview) . NOTE: Window lifter motor can be removed or installed with the motor or door window in any position. Disconnect connectors before removing motor.
  2. Remove TORX bolts (T30) -2- and remove motor.

Installing

  1. When installing, make sure that threaded pins -arrows- are engaged in inner door plate.
  2. Slide on window lifter motor -1- and secure using bolts -2-.
  3. Tightening torque 3.5 Nm

Note. After motor has been installed and wires connected, first turn ignition on and off again. Next, close door window completely and continue to pull window lifter switch for approx. 2 seconds. This position is the basic position which activates automatic one-touch function.

Front door, adjusting

Note. Rear door shell must be adjusted if this has not already been done. Joint dimensions can be checked using special tool 3371.

  1. Dimension A = 3.5 mm +/- 0.5 mm.
  2. Dimension B = 4.5 mm +/- 0.5 mm.
  3. Dimension C = 0 mm+ 1 mm flush when running parallel to body.

Adjusting in relation to body contour

  1. Longitudinal adjustment is achieved by loosening hinge bolts arrow -A- on A-pillar on upper and/or lower door hinge and by moving doors -2- (oversized holes in hinge or in A-pillar)
  2. Tightening torque 32 Nm
  3. Door hinge -1
  4. A-pillar -3
  5. Door -2

Note. Fig. shows lower door hinge.

Scheme 2

Scheme 2
Scheme 2

Adjusting in relation to vehicle center

Note. A collared shoulder bolt is installed into door side of upper and lower door hinges. During repair work, adjustment is therefore generally not required. If adjustment is necessary nevertheless, shoulder bolts can be replaced by bolts of the same size, length and strength (available in Parts List).

  1. Adjust in relation to vehicle center by loosening hinge bolts arrow -B- at top and/or bottom of door and by moving doors (elongated holes in hinge)
  2. Tightening torque 32 Nm NOTE: Adjust rear area of door (in relation to vehicle center) by means of striker plate.
  3. Loosen bolts -2
  4. Use marks arrows -a- or arrows -c- for lateral adjustment.
  5. Move striker plate -1- until door shell is flush with body contour. NOTE: Position may only be adjusted with respect to center of vehicle and not in terms of height.
  6. Use marks arrows -b- or arrows -d- for height adjustment.
  7. When correctly adjusted, striker plate must advance centrally into door lock.
  8. Tighten bolts to 25 Nm.

Front door, adjustment dimensions

The following list pertains to see scheme 12.

  1. Window frame When door is correctly adjusted, contours of sealing lip must lie snugly against roof frame and B-pillar (see arrows).
  2. Door window Adjust door so that dimension -d- = 4 mm in the area -c- = 365 mm. You can check dimension -d- with the aid of an improvised gauge, see «Making improvised gauge»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-except-cabriolet__making-improvised-gauge) . Dimension -b- starting from rear door edge at B-pillar = 200 mm.
  3. Window frame Door window -2-, dimension -a- = 7.5 mm -1 mm, must advance deep into window frame at B-pillar.

Making improvised gauge

  1. Make improvised gauge (e.g. plastic or plywood) in line with specified dimensions.
  2. Dimension -a- = 4 mm
  3. Dimension -b- = 30 mm
  4. If door subframe has been properly adjusted, gauge placed approx. 200 mm from B-pillar must make contact with both door window and roof trim strip over a length of approx. 365 mm.

Front door handle and door lock, assembly overview

The following list pertains to see scheme 14.

  1. Mount for door handle
  2. Door lock Removing, see «DOOR HANDLE MOUNT AND TRIM PANEL, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-except-cabriolet) .
  3. Operating rod Clipping into door lock, see «Hooking operating rod in door lock»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-except-cabriolet__hooking-operating-rod-in-door-lock)
  4. Multi-point socket-head bolt 20 Nm
  5. Lock cylinder cover Remove lock cylinder and unclip cover
  6. Lock cylinder Removing, see «Removing lock cylinder»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-except-cabriolet__removing-lock-cylinder)
  7. Door handle Before disassembling, remove window frame and window lifter. Removing, see «REMOVING»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-except-cabriolet__removing) .
  8. Operating lever
  9. Clip Hook operating rod in clip, swivel clip 90° and snap onto operating rod.

Scheme 3

Scheme 3
Scheme 3

Removing lock cylinder

  1. Open driver's door.
  2. Pry off cap -2-.
  3. Turn TORX bolt -arrow- counter-clockwise as far as it will go.
  4. This moves arm -1- backward and releases lock cylinder.
  5. Pull lock cylinder out of door handle.

Door handle, assembly overview

The following list pertains to see scheme 16.

  1. Door handle
  2. Clip
  3. Operating rod
  4. Collar To lock operating rod -3- in place, push collar upward.
  5. Latching pin Only available with new part. Pull out and discard after you have installed operating rod -3-.
  6. Door lock Removing, see «DOOR HANDLE MOUNT AND TRIM PANEL, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-except-cabriolet) .

Scheme 4

Scheme 4
Scheme 4

The following list pertains to see scheme 17.

  1. Door handle
  2. Clip Unclip operating rod -3- to remove door handle -1-.
  3. Operating rod Before removing door handle -1-, unhook operating rod at clip -2-. After installing a new door handle -1-, first insert operating rod -3- in collar -4- and lock in place. Then, pull latching pin -5- out of door lock and discard.
  4. Collar
  5. Latching pin
  6. Door lock Removing, see «DOOR LOCK, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-except-cabriolet__door-lock-removing-and-installing) .

Scheme 5

Scheme 5
Scheme 5
  1. Installation is the reverse of removal.

Removing door handle mount from door panel

  1. Door trim, window frame and window lifter removed.
  2. Insert screwdriver through door panel and release slider -2- from door handle -1- in direction of -arrow-.
  3. Installation is reverse of removal.

Removing trim panel

  1. To remove, pull handle -1- up and pull lock -3- out longitudinally using a small screwdriver.
  2. Disengage upper side of trim panel -2- and pull downward and out of door handle.
  3. Installation is reverse of removal.

Door lock, removing and installing

The following list pertains to see scheme 20.

Scheme 6

Scheme 6: Door lock, removing and installing
Scheme 6: Door lock, removing and installing
  1. M8 multi-point socket head bolt 20 Nm
  2. Backing plate
  3. Door lock Door trim removed. Window frame and window lifter removed. Disconnect connector at door lock. NOTE: To re-install door lock, unhook upper clip of swivelling lever from door handle to release operating rod. If you are installing a new door lock, release operating rod from door lock by unfastening collar, see «HOOKING OPERATING ROD IN DOOR LOCK»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-except-cabriolet__hooking-operating-rod-in-door-lock) Release operating rod from door lock by unclipping collar. Remove multi-point head cap bolts -1- and remove door lock.
  4. Release lever
  5. Bowden cable for interior door handle mechanism To install, first insert vertically in release lever then swivel 90° and secure in place by clipping into door lock (see exploded view).

Hooking operating rod in door lock

  1. If installing a new door lock, clip operating rod -1- into collar.
  2. To lock operating rod in place, push slider -2- of collar upward.
  3. Pull pin -3- out of door lock and discard.

Components, assembly overview

The following list pertains to see scheme 22.

  1. Door control module, front right -J387- Integrated in window lifter motor.
  2. Door control module, rear right -J389- Integrated in window lifter motor.
  3. Tank cap release motor - V155- Removing, see «Removing tank cap release motor -V155»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-except-cabriolet__removing-tank-cap-release-motor-v155)
  4. Rear lid release motor -V139
  5. Door control module, rear left -J388- Integrated in window lifter motor.
  6. Door control module, front left side -J386- Integrated in window lifter motor.
  7. Convenience system central control module -J393- Disassemble front left seat before removing Remove lower A-pillar trim. See «LOWER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__lower-a-pillar-trim-assembly-overview) . Removing, see «REMOVING CONVENIENCE SYSTEM CONTROL MODULE -J393»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-except-cabriolet__removing-convenience-system-control-module-j393)
  8. Hood contact switch -F266- Location: in lock carrier

Removing convenience system control module -J393

  1. Front left seat and lower A-pillar trim removed.
  2. Ignition off.
  3. Open control module box -1-.
  4. Disconnect connector from control module -2- and take out.

Removing tank cap release motor -V155

  1. Disconnect connector.
  2. Loosen bolts -arrows- using special tool T 10010, pull actuator -1- forward and remove.
  3. Before installing actuator, push emergency release -3- over locking pin.
  4. Locking pin of actuator must advance cleanly into closed tank cap -2-.

Central locking, servicing

  1. The central locking in the A4 is now electric, instead of pneumatic as before.
  2. The actuators in the doors are integrated in the door lock and feature two motors.
  3. The actuators cannot be replaced individually.
  4. The first motor locks the door and the second motor locks the interior door mechanism (deadlock function).
  5. In addition, the doors can now no longer be opened from the inside.
  6. The tank cap and rear lid actuators each have one motor and can be replaced individually.
  7. After an accident involving airbag triggering, the central locking control module opens any locked doors.
  8. The central locking control module is situated in front of the driver's seat on the left beneath the floor covering.
