Navigation System - Except Cabriolet Audi A4 B6

General information

1. Obtain anti-theft radio security code if necessary.
2. Switch the ignition off.
3. Disconnect battery Ground (GND) strap.
4. On vehicles equipped with Audi Telematics by OnStar(R), switch-off the emergency (back-up) battery for the Telematic/Telephone Control Module prior to disconnecting vehicle battery. Use VAS 5051 Vehicle Diagnostic, Testing and Information System in mode "Guided Fault Finding". See «EMERGENCY BATTERY, SWITCHING OFF/ON»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet__emergency-battery-switching-offon) .
5. After reconnecting vehicle battery, re-code anti-theft radio if necessary, and check operation. Also check operation of clock and power windows according to Repair Manual and/or Owner's Manual.
6. After reconnecting vehicle battery on vehicles equipped with Audi Telematics by OnStar,(R) switch-on the emergency (back-up) battery for the Telematic/Telephone Control Module. Use VAS 5051 Vehicle Diagnostic, Testing and Information System in mode "Guided Fault Finding". See «EMERGENCY BATTERY, SWITCHING OFF/ON»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet__emergency-battery-switching-offon) .

Note. Further measures after reconnecting the voltage supply: See PROCEDURE AFTER INTERRUPTION OF VOLTAGE SUPPLY (1.8L), or PROCEDURE FOLLOWING INTERRUPTION OF VOLTAGE SUPPLY (3.0L).

Before troubleshooting or servicing, technicians must be familiar with the functions and operation specifics of the applicable Navigation system. Always read the Navigation system owner's manual and review all navigation functions.

Navigation IV, technical features

All displays appear via the instrument cluster connected to the CAN bus.

All entries are made using the keys on the multi-function switch.

A radio with loudspeakers is required for speech messages.

The system consists of

1. Multi-function switch (operating unit)
2. Instrument cluster (display unit)
3. Control unit for navigation system with CD drive (central unit and navigation unit)
4. GPS antenna

Navigation System IV (Sedan), component overview

The following list pertains to (Scheme 287).

1. Radio -R- In instrument panel, center Removing and installing, see «"CONCERT II" RADIO UNIT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/entertainment-systems/#radio-system-except-cabriolet)
2. Instrument cluster Removing and installing: See «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#instrument-systems-except-cabriolet) .
3. Function Selector Switch II -E272- In center console Removing and installing, see «FUNCTION SELECTOR SWITCH II -E272-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)
4. Antenna for Navigation System (GPS) -R50- Under rear headliner trim Removing and installing, see «ANTENNA FOR NAVIGATION SYSTEM (GPS) -R50- (SEDAN), REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)
5. Control module for navigation with CD- mechanism -J401- In left rear luggage compartment storage Removing and installing, see «CONTROL MODULE FOR NAVIGATION WITH CD-MECHANISM -J401-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)
6. Front Midrange Speakers -R26- & -R27- In upper front door trim Removing and installing, see «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/entertainment-systems/#radio-system-except-cabriolet)
7. Front Bass Speakers - R21- &-R23- In lower front door trim Removing and installing, see «LOUDSPEAKERS IN DOORS, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/entertainment-systems/#radio-system-except-cabriolet__loudspeakers-in-doors-removing-and-installing) .

Navigation System IV (Avant), component overview

Note. In vehicles with Navigation IV and Telematics, the GPS-signal is distributed via an antenna splitter in sub compartment in left luggage compartment. Removing and installing antenna splitter, see GPS ANTENNA SPLITTER -R110- (AVANT), REMOVING AND INSTALLING .

The following list pertains to (Scheme 288).

1. Radio -R- In instrument panel, center Removing and installing, see «"CONCERT II" RADIO UNIT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/entertainment-systems/#radio-system-except-cabriolet)
2. Instrument cluster Removing and installing See «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#instrument-systems-except-cabriolet) .
3. Function Selector Switch II -E272- In center console Removing and installing, see «FUNCTION SELECTOR SWITCH II -E272-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)
4. Antenna for Navigation System (GPS) -R50- Integrated in roof antenna Removing and installing, see «ANTENNA FOR NAVIGATION SYSTEM (GPS) -R50- (AVANT), REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet__antenna-for-navigation-system-gps-r50)
5. Control module for navigation with CD- mechanism -J401- In left rear luggage compartment storage Removing and installing, see «CONTROL MODULE FOR NAVIGATION WITH CD-MECHANISM -J401-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)
6. Front Midrange Speakers -R26- & -R27- In upper front door trim Removing and installing, see «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/entertainment-systems/#radio-system-except-cabriolet)
7. Front Bass Speakers - R21- &-R23- In lower front door trim Removing and installing, see «LOUDSPEAKERS IN DOORS, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/entertainment-systems/#radio-system-except-cabriolet__loudspeakers-in-doors-removing-and-installing)

Navigation System IV, layout

The following list pertains to (Scheme 289).

1. Control unit for navigation system with CD drive (central unit and navigation unit) In left rear luggage compartment storage
2. Instrument cluster (display unit)
3. Function selector switch (operating unit) In center console
4. To the loudspeakers activated for speech messages
5. Antenna for Navigation System (GPS) -R50- Sedan: Under rear headliner trim Avant: Integrated in roof antenna

Connections at rear of Control module for navigation with CD-mechanism -J401

The following list pertains to (Scheme 290).

1. GPS antenna connection
2. Retainer bar for antenna connection
3. Multi-pin connector I, 20-pin black
4. Fuse
5. Multi-pin connector II, 8-pin, brown
6. Multi-pin connector III, 8-pin, black
7. Multi-pin connector IV, 10-pin, red

Control module for navigation with CD-mechanism - J401-, Multi-pin connector assignments

Note. Connector contacts not listed have not been assigned.

Scheme 287

Multi-pin connector I, 20-pin, black

The following list pertains to (Scheme 292).

1. 2 - CAN Bus - High display (Infotainment)
2. 5 - CAN Bus - Low display (Infotainment)
3. 13 - Low frequency + (speech messages)
4. 14 - Radio mute (output)
5. 15 - Low frequency - (speech messages)
6. 16 - Telephone low frequency (+)
7. 17 - Telephone mute (input)
8. 19 - Telephone low frequency (-)

Multi-pin connector III, 8-pin, black

The following list pertains to (Scheme 292).

1. 1 - Gala (speed signal)
2. 2 - Backup light switch
3. 3 - Data Link Connector (DLC)
4. 4 - Terminal 15
5. 7 - Terminal 30 (B+)
6. 8 - Terminal 31 (GND)

Scheme 288

1. Open cover -2- for cigarette lighter.
2. Press function selector switch -1- from below out of the installation aperture as shown in the illustration.
3. Disconnect electrical connection.

Special tools and workshop equipment required

1. Radio release tool T10057

Removing

1. Open cover for left storage compartment in luggage compartment
2. Push clips of radio release tool T10057 into front of navigation control module with CD drive -2-.
3. Pull the navigation control module with CD drive out of mounting frame -1-.
4. Disconnect electrical connections and the antenna wires at the back of the navigation control module with CD drive.
5. Pull out the release tool from the navigation control module with CD drive - to do this, press in the locking tabs on the control module.

Installing

1. Install in reverse order of removal.

Installation instructions

1. The control module for navigation and mounting frame must be installed as free of vibrations as possible to avoid system malfunctions.
2. Air circulation must also be guaranteed, i.e. the ventilation slots in the control module must not be covered when installed.

1. Remove rear headliner trim. See «MOLDED HEADLINER, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__molded-headliner-assembly-overview) .
2. Release clasps -arrows- and remove antenna -1-.
3. Disconnect electrical connection -2-.

1. Install in reverse order of removal.

Antenna for Navigation System (GPS) -R50- (Avant), removing and installing

Note. Where a roof antenna for Telephone and Navigation is installed, the Telephone cable is connected by the right D-pillar and the navigation cable is routed to the antenna splitter and Navigation control module located in the left rear luggage compartment.

1. Remove luggage compartment light. See «CARGO AREA LIGHT (AVANT), REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#lights-switches-interior-anti-theft-except-cabriolet) .
2. Remove rear headliner trim. See «MOLDED HEADLINER, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) .
3. Remove D-pillar trim. See «D-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) .
4. Remove left luggage compartment trim. See «SIDE LUGGAGE COMPARTMENT TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__side-luggage-compartment-trim-assembly-overview) .
5. Disconnect electrical connections -2- and -3-.
6. Remove nut -1- (6 Nm) and remove antenna upwards.

1. Install in reverse order of removal.
2. Attach the electrical connections according to the colorcoding.

Note. The washer under the retaining nut for the antenna has a gap through which the antenna cables must be guided.

1. Remove left luggage compartment trim. See «SIDE LUGGAGE COMPARTMENT TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__side-luggage-compartment-trim-assembly-overview) .
2. Remove screw -arrows- and sub compartment -1-.
3. Release mounting plate -1-.
4. Remove antenna splitter -2-.

1. Install in reverse order of removal.
2. Tighten sub compartment screws to 14 Nm.

1. Obtain anti-theft radio security code if necessary.
2. Switch the ignition off.
3. Disconnect battery Ground (GND) strap.
4. On vehicles equipped with Audi Telematics by OnStar(R), switch-off the emergency (back-up) battery for the Telematic/Telephone Control Module prior to disconnecting vehicle battery. Use VAS 5051 Vehicle Diagnostic, Testing and Information System in mode "Guided Fault Finding". See «EMERGENCY BATTERY, SWITCHING OFF/ON»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet__emergency-battery-switching-offon) .
5. After reconnecting vehicle battery. re-code anti-theft radio if necessary, and check operation. Also check operation of clock and power windows according to Repair Manual and/or Owner's Manual.
6. After reconnecting vehicle battery on vehicles equipped with Audi Telematics by OnStar(R), switch-on the emergency (back-up) battery for the Telematic/Telephone Control Module. Use VAS 5051 Vehicle Diagnostic, Testing and Information System in mode "Guided Fault Finding". See «EMERGENCY BATTERY, SWITCHING OFF/ON»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet__emergency-battery-switching-offon) .

Note. Further measures after reconnecting the voltage supply

See PROCEDURE AFTER INTERRUPTION OF VOLTAGE SUPPLY (1.8L), or PROCEDURE FOLLOWING INTERRUPTION OF VOLTAGE SUPPLY (3.0L).

Before troubleshooting or servicing, technicians must be familiar with all telematics functions, operating specifics and the particular service plan which the customer subscribes to. Refer to AUDI TELEMATICS BY ONSTAR(R) "Self Study Program (SSP) and "Audi Telematics by OnStar(R) Owner's Manual and/or OnStar(R) "Quick Reference Guide" to become familiar with applicable features and functions.

Telematics, technical features

Telematics is an in-vehicle communication system that uses cellular, internet and Global Positioning System (GPS) technologies to provide the customer with safety, security and convenience services.

GPS is a "constellation" of 24 satellites that orbit the earth and constantly broadcast radio signals. The Telematics/Telephone Control Module receives GPS data, decodes it, and transmits the vehicle's location to the service provider's call center via the national cellular network.

Telematics services for Audi customers are provided by OnStar(R) via a dedicated call center. Service plans may provide route directions and concierge services as well as emergency or vehicle repair services. For details, see AUDI TELEMATICS BY ONSTAR(R) Owner's Manual.

During events where the Airbag Control Module processes a crash signal, the vehicle emergency flashers are activated and the doors are unlocked via the respective door control modules. In addition, the telematics system automatically places an emergency call to the OnStar(R) call center.

Telematics hardware includes the driver operated telematics control head (which contains the OnStar(R) control buttons and system status light), microphone, backup loudspeaker, roof-mounted GPS/Cellular antenna, Telematics/Telephone Control Module (with supporting software) and related wiring.

An emergency (back-up) battery for the telematics control module is also used in case the vehicle battery goes dead or becomes disconnected due to accident, impact etc..

All telematics components are factory installed/integrated into the vehicle electrical system.

Telematics system - Sedan, component overview, see TELEMATIC SYSTEM (SEDAN), COMPONENT OVERVIEW .

Telematics system - Sedan, layout, see TELEMATIC SYSTEM (SEDAN), LAYOUT .

Telematics system - Avant, component overview, see TELEMATIC SYSTEM (AVANT), COMPONENT OVERVIEW .

Telematics system - Avant, layout, see TELEMATIC SYSTEM (AVANT), LAYOUT .

Contact Corrosion

To minimize contact corrosion, only use approved fasteners (screws, nuts, bolts, washers etc.)

Where applicable, fasteners may have a special surface coating recognizable by a greenish color.

Coated fasteners must also be stored separately.

On Board Diagnostic (OBD)

The telematics system has extensive On Board Diagnostic (OBD) capabilities.

The Telematics/Telephone Control Module has a Diagnostic Trouble Code (DTC) memory. If a malfunction occurs in one of the components or wires which is monitored by the system, a record of the type of malfunction is stored in DTC memory.

Perform OBD program using VAS 5051 Vehicle Diagnostic, Testing and Information System in mode "Vehicle Self Diagnosis" and/or "Guided Fault Finding".

Telematics Control Head - OnStar(R) controls

The Telematics Control Head is integrated with the front interior light module. The control head contains three separate buttons as well as a system status indicator light (LED).

The OnStar(R) ("On*") button is used to contact the OnStar(R) call center to request various convenience services. It is also used to initialize/activate the owner's subscription to OnStar(R) services and/or update the customer's account in the event that the Telephone/Telematics Control Module requires replacement.

The Emergency button is used to contact the OnStar(R) call center to request emergency services such as fire department, police etc.

The Communication ("DOT") button is used to end a call to the OnStar(R) call center, place or answer personal calls (in conjunction with the optional digital cellular telephone), or cancel a call if one of the other buttons is accidentally pressed.

Note. Use of certain OnStar(R) services requires a subscriber's Personal Identification Number(s) (PIN).

For complete system operation details, see AUDI TELEMATICS BY ONSTAR(R) Owner's Manual.

Telematics Control Head - OnStar(R) system status light

The system status light is located between the Communication and Emergency buttons. The green light comes on after a self-check routine is performed (approx. 10- 15 seconds after ignition is switched on).

Indicated conditions

1. Green: Indicates system has passed self-test and is ready to place or receive calls. Light remains on even in areas without cellular coverage.
2. Blinking green: Indicates a call has been initiated or is in progress.
3. Red: Indicates system has not passed self-test or indicates system malfunction.

Note. System troubleshooting using system status light, see TELEMATICS SYSTEM, TROUBLESHOOTING USING ONSTAR(R) SYSTEM STATUS LIGHT .

OnStar(R) Personal Calling

An optional digital cellular telephone with specific features integrated into the telematics system is also available.

OnStar(R) and OnStar(R) Personal Calling are activated separately.

Note. Use of certain OnStar(R) services requires a subscriber's Personal Identification Number(s) (PIN).

For complete system operation details, see AUDI TELEMATICS BY ONSTAR(R) Owner's Manual.

Telematics system, troubleshooting using OnStar(R) system status light

The following allows technicians to perform an initial evaluation of Telematics system operation status for troubleshooting using the OnStar(R) system status light (and pre-recorded system messages where applicable).

Note. After pressing either the OnStar(R) or Emergency button, a recorded message announces: "connecting to OnStar," followed by progression tones. Normal connection time is 10 - 15 seconds. However, due to local cellular/GPS conditions, making a connection could take up to three minutes. Be patient.

Condition - system status light "green" plus

1. message "unable to contact OnStar(R) " and disconnect
2. message "OnStar(R) request ended"
3. nothing happens
4. or a cellular message

indicates system cellular reception is affected. Proceed as follows

1. Relocate vehicle to a more elevated or open area and repeat connection attempts. Depending on the local cellular/GPS traffic conditions, several connection attempts may be necessary (and are normal).

Shortcomings in the vehicle's cellular/GPS antenna system also affects connectivity.

1. Check all cellular/GPS antenna connections, and perform OBD program using VAS 5051 Vehicle Diagnostic, Testing and Information System in mode "Vehicle Self Diagnosis" and/or "Guided Fault Finding". Check for DTCs related to antenna function.

If you are still unable to connect

1. Record the VIN and customer details and call the OnStar(R) Customer Care at 1-888-390-4050. Identify yourself to the advisor as an Audi technician. The advisor will verify the customer's OnStar(R) account is active. Further troubleshooting assistance may be given.

Condition - system status light "red"

System hardware (vehicle portion) is affected. Perform OBD program using VAS 5051 Vehicle Diagnostic, Testing and Information System in mode "Vehicle Self Diagnosis" and/or "Guided Fault Finding". Proceed as follows

Using VAS 5051 in mode: "Guided Fault Finding"

1. Select vehicle system 75 - "Telematics"
2. Perform/check

1. DTC memory (function 02)
2. Output DTM (function 03)
3. Read Measuring Value Block (function 08)

Using VAS 5051 in mode: "Guided Fault Finding"

1. Enter appropriate model, equipment and model year information and press ">" to confirm. After all control modules have been registered and DTC memories checked
2. Press "Go to"
3. Select "Function/Component Selection"
4. Select "Body, (Repair Groups 01; 50 to 97)"
5. Select "Electrical Equipment" (Repair Groups 01, 90 to 97"
6. Select "01 - On Board Diagnostic (OBD)"
7. Select "Telematic"
8. Select "Functions -Telematic"
9. Review list and perform applicable guided fault finding function(s).

Note. In the event any of the OnStar(R) control buttons are either inadvertently or deliberately pressed for longer than 15 seconds, the OBD program assumes a button is sticking. The red status light will come on and a DTC loads in memory. Perform OBD program using VAS 5051 and check DTC memory for DTC 01526 "mechanical malfunction". Inform customers accordingly.

Telematic system (Sedan), component overview

The following list pertains to see scheme 14.

1. Radio -R- In instrument panel, center Removing and installing, see «"CONCERT II" RADIO UNIT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/entertainment-systems/#radio-system-except-cabriolet)
2. Instrument cluster Removing and installing See «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#instrument-systems-except-cabriolet) .
3. Telephone/Telematic Control Module -J526- In Electronics box under passenger-side seat Removing and installing, see «TELEPHONE/TELEMATIC CONTROL MODULE -J526-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet__telephonetelematic-control-module-j526-removing-and)
4. Harness connector for cellular telephone preparation In center console storage compartment
5. Telematic Control Head -E264- Integrated with front interior light control module along with Telephone Microphone -R38- Removing and installing, see «TELEMATIC CONTROL HEAD -E264-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet__telematic-control-head-e264-removing-and) Telephone Microphone -R38-, removing and installing, see «TELEPHONE MICROPHONE -R38-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)
6. Roof antenna with Antenna for Navigation System (GPS) -R50- and Auxiliary Antenna (Telematic) -R90- Removing and installing, see «ANTENNA FOR NAVIGATION SYSTEM (GPS) -R50- AND AUXILIARY ANTENNA (TELEMATIC) -R90-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)
7. Antenna for telephone -R65- Under rear headliner trim Removing and installing, see «ANTENNA FOR TELEPHONE -R65- (SEDAN), REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)
8. Multi-function steering wheel Line output via Steering Column Electronic Systems Control Module -J527
9. Front Midrange Speakers -R26- & -R27- In upper front door trim Removing and installing, see «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/entertainment-systems/#radio-system-except-cabriolet)
10. Front Bass Speakers -R21- &-R23- In lower front door trim See «LOUDSPEAKERS IN DOORS, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/entertainment-systems/#radio-system-except-cabriolet__loudspeakers-in-doors-removing-and-installing) .
11. Auxiliary Speaker (Telematic) -R91- (emergency loudspeaker) In driver-side storage compartment Removing and installing, see «AUXILIARY SPEAKER (TELEMATIC) -R91- (EMERGENCY LOUDSPEAKER), REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)

Telematic system (Avant), component overview

Note. In vehicles with Navigation IV and Telematics, the GPS-signal is distributed via an antenna splitter in left luggage compartment sub compartment.

The following list pertains to see scheme 15.

1. Radio -R- In instrument panel, center Removing and installing, see «"CONCERT II" RADIO UNIT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/entertainment-systems/#radio-system-except-cabriolet)
2. Antenna for telephone -R65- Under front bumper cover Removing and installing, see «ANTENNA FOR TELEPHONE -R65- (SEDAN), REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)
3. Antenna Splitter -R87- In Electronics box under front passenger seat. Removing and installing, see «ANTENNA SPLITTER -R87- (AVANT), REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)
4. Instrument cluster Removing and installing: See «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#instrument-systems-except-cabriolet)
5. Telephone/Telematic Control Module -J526- In Electronics box under passenger-side seat Removing and installing, see «TELEPHONE/TELEMATIC CONTROL MODULE -J526-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet__telephonetelematic-control-module-j526-removing-and)
6. Harness connector for cellular telephone preparation In center console storage compartment
7. Telematic Control Head -E264- Integrated with front interior light control module along with Telephone Microphone -R38- Removing and installing, see «TELEMATIC CONTROL HEAD -E264-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet__telematic-control-head-e264-removing-and) Telephone Microphone -R38-, removing and installing, see «TELEPHONE MICROPHONE -R38-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)
8. Telephone Antenna 2 -R127- Under rear bumper cover Removing and installing, see «ANTENNA FOR TELEPHONE -R65- (FRONT) AND ANTENNA 2 FOR TELEPHONE -R127- (REAR) (AVANT), REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)
9. Roof antenna with Antenna for Navigation System (GPS) -R50- and Auxiliary Antenna (Telematic) -R90- Removing and installing, see «ANTENNA FOR NAVIGATION SYSTEM (GPS) -R50- AND AUXILIARY ANTENNA (TELEMATIC) -R90-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)
10. Multi-function steering wheel Line output via Steering Column Electronic Systems Control Module -J527
11. Front Midrange Speakers -R26- & -R27- In upper front door trim Removing and installing, see «FRONT MIDRANGE SPEAKERS -R26- & -R27-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/entertainment-systems/#radio-system-except-cabriolet)
12. Front Bass Speakers -R21- &-R23- In lower front door trim See «LOUDSPEAKERS IN DOORS, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/entertainment-systems/#radio-system-except-cabriolet__loudspeakers-in-doors-removing-and-installing) .
13. Auxiliary Speaker (Telematic) -R91- (emergency loudspeaker) In driver-side storage compartment Removing and installing, see «AUXILIARY SPEAKER (TELEMATIC) -R91- (EMERGENCY LOUDSPEAKER), REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet)

Telematic system (Sedan), layout

The following list pertains to see scheme 16.

1. Cellular telephone Optional equipment (only used in conjunction with telematics system)
2. Harness connector for cellular telephone preparation In center console storage compartment
3. Auxiliary Speaker (Telematic) -R91- (emergency loudspeaker) In driver-side storage compartment
4. Telematic Control Head -E264- With: OnStar(R) ("On*") button System status light (LED) Emergency button Communication ("DOT") button In front interior light module
5. Telephone Microphone -R38- In front interior light module
6. Instrument cluster
7. Telephone/Telematic Control Module -J526- In Electronics box under front passenger seat
8. Multi-function steering wheel
9. Steering Column Electronic Systems Control Module -J527
10. Radio In instrument panel, center
11. To loudspeaker used for speech messages
12. Auxiliary Antenna (Telematic) -R90- Integrated in the roof antenna
13. Antenna for Navigation System (GPS) -R50- Integrated in the roof antenna
14. Antenna for telephone -R65- Under rear headliner trim

Telematic system (Avant), layout

The following list pertains to see scheme 17.

1. Cellular telephone Optional equipment (only used in conjunction with telematics system)
2. Harness connector for cellular telephone preparation In center console storage compartment
3. Auxiliary Speaker (Telematic) -R91- (emergency loudspeaker) In driver-side storage compartment
4. Telematic Control Head -E264- With: OnStar(R) ("On*") button System status light (LED) Emergency button Communication ("DOT") button In front interior light module
5. Telephone Microphone -R38- In front interior light module
6. Instrument cluster
7. Telephone/Telematic Control Module -J526- In Electronics box under passenger-side seat
8. Multi-function steering wheel
9. Steering Column Electronic Systems Control Module -J527
10. Radio In instrument panel, center
11. Loudspeaker
12. Auxiliary Antenna (Telematic) -R90- Integrated in the roof antenna
13. Antenna for Navigation System (GPS) -R50- Integrated in the roof antenna
14. Antenna for telephone -R65- Under front bumper cover
15. Antenna Splitter -R87- In Electronics box under front passenger seat
16. Antenna -2- for telephone -R127- Under rear bumper cover

Terminal assignments/harness electrical connections on Telephone/Telematic Control Module -J526

The following list pertains to see scheme 18.

1. Connection - GPS antenna
2. 42-pin connector
3. Connection - Telematics antenna

Terminal assignment of multi-pin harness connector on Telephone/Telematic Control Module -J526

Note. Terminals which are not listed are vacant/unassigned.

42- pin multi-pin harness connector T42

The following list pertains to see scheme 19.

1. Horn
2. Door lock
3. Portable Telephone Audio Input
4. Portable Telephone Battery Feedback
5. Portable Telephone Ground
6. Portable Telephone RS232 Transmit
7. Portable Telephone Line 1 (Tx)
8. Portable Telephone Cable Shield Ground
9. CAN-Bus - High (Infotainment)
10. Audio out +
11. Emergency Speaker +
12. Hands free mic +
13. Data Link Connector (DLC)
14. Terminal X (Load reduction circuit)
15. LED Red
16. LED Green
17. Battery -, terminal 31
18. Battery -, terminal 31
19. Lights
20. Door unlock
21. Portable Telephone Audio Output
22. Portable Telephone Audio Ground
23. Portable Telephone Power
24. Portable Telephone RS232 Receive
25. Portable Telephone Line 2 (Rx)
26. Portable Telephone Hook Switch
27. CAN Bus - Low (Infotainment)
28. Audio out
29. Emergency Speaker
30. Hands free mic
31. Mute
32. Keypad In
33. Keypad Power
34. Airbag (Crash) Line output
35. Battery +, terminal 30
36. Battery +, terminal 30
37. Backup battery +
38. Backup battery

Scheme 289

Telephone/Telematic Control Module -J526-, removing and installing

Note. If the Telephone/Telematics Control Module is replaced, the OnStar(R) system needs to be reconfigured. See TELEPHONE/TELEMATIC CONTROL MODULE -J526-, REPLACING AND RECONFIGURING . DO NOT exchange Telephone/Telematic Control Modules between vehicles!. Each module contains specific Station Identification (STID) and Electronic Serial Number (ESN) data unique to the VIN. This data is used by OnStar(R) and National Cellular Telephone Network to identify the vehicle and administer the customer's account.

1. Remove A-pillar trim. See «LOWER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__lower-a-pillar-trim-assembly-overview) .
2. Remove front passenger's seat. See «FRONT SEATS»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-except-cabriolet) . NOTE: Seat belt need not be removed from seat frame.
3. Pull back floor carpet.
4. Release electronics box cover, passenger's side -arrows-.
5. Open lid -1- of mounting box -2- in direction of -arrow-.

Avant only

1. Disconnect cable connection to antenna splitter.

All models

1. Disconnect electrical connections -2-, -3- and -4-.
2. Remove control module -1- from mounting box.

Scheme 290

1. Install in reverse order of removal.

Note. Ensure correct seating and fit of electrical connections. Antenna connections (couplings) must be properly aligned and tight to ensure proper reception.

Scheme 291

Telephone/Telematic Control Module -J526-, replacing and reconfiguring

After replacing the Telephone/Telematic Control Module, the OnStar(R) system needs to be reconfigured and the emergency battery must be switched on as described below. Have the VIN and customer details on hand.

Note. DO NOT exchange Telephone/Telematic Control Modules between vehicles!. Each module contains specific Station Identification (STID) and Electronic Serial Number (ESN) data unique to the VIN. This data is used by OnStar(R) and National Cellular Telephone Network to identify the vehicle and administer the customer's account. Failure to reconfigure the control module after replacement will prevent OnStar(R) services and features from functioning, and will result in a customer return for repair. Always replace the emergency (back-up) battery when replacing the Telephone/Telematics Control Module.

Replacing

1. Where applicable, carefully record the 8-character Station Identification (STID) number and Electronic Serial Number (ESN) from labels on replacement module.
2. Remove and replace control module (see «TELEPHONE/TELEMATIC CONTROL MODULE -J526-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#navigation-system-except-cabriolet__telephonetelematic-control-module-j526-removing-and) ) and emergency (back-up) battery.
3. Use VAS 5051 Vehicle Diagnosis, Testing and Information System in mode: "Guided Fault Finding"
4. Enter appropriate model, equipment and model year information and press ">" to confirm. After all control modules have been registered and DTC memories checked
5. Press "Go to"
6. Select "Function/Component Selection"
7. Select "Body, (Repair Groups 01; 50 to 97)"
8. Select "Electrical Equipment" (Repair Groups 01, 90 to 97"
9. Select "01 - On Board Diagnostic (OBD)"
10. Select "Telematic"
11. Select "Functions -Telematic"
12. Select "J526 - Telephone/Telematic Ctrl. Module, coding"
13. Follow the tester's coding procedure prompts. Ensure applicable vehicle equipment information is entered as requested. When coding is complete
14. Return to "Functions -Telematic" list
15. Select "J526 - Telephone/Telematic Ctrl. Module, service mode disc. battery"
16. If necessary, press ">" to advance
17. Select/press button 2 - "New emergency battery has been installed (reset counter)"
18. Follow the tester's adaptation prompts. If the STID number and ESN do not appear on the new control module, proceed as follows
19. Return to select "Functions -Telematic" list
20. Select "J526 - Telephone/Telematic Ctrl. Module, measuring value block"
21. Select/read display group 78 data, extract/record 8-character ESN from displayed data.

Example of display group 78 data:098000A84E7941USA3

Designations

1. 098 = Build Group prefix
2. 000 = Placeholders
3. A84E7941 = 8-character Electronic Serial Number (ESN) (example only!!!! - each control module ESN is different).
4. USA = USA telematics version
5. 3 = Check digit

1. Select/read display group 79 data, extract/record 8-character STID number from displayed data. Example of display group 79 data:09900007A14CBF Designations: 099 = Build Group prefix 00 = Placeholders 007A14CB = 8-character Station Identification (STID) number (example only!!!! - each control module STID is different). F = Check digit

Continued for all

1. Select "Guided Fault Finding"
2. Select vehicle system 75 - "Telematics"
3. Select function 05 - "Erase DTC Memory".
4. Select function 06 "End Output".
5. Switch off ignition and wait a few moments.
6. Switch on ignition.
7. Return to select vehicle system 75 - "Telematics"
8. Select function 02 - "Check DTC Memory". No DTCs must be present.
9. Check and confirm the green status indicator light in Telematics Control Head is on.
10. Select function 06 - "End Output".
11. Disconnect VAS 5051 from Data Link Connector (DLC).

Reconfiguration

1. Drive vehicle outside to area away from tall buildings, and with no overhead obstructions (trees, bridges, etc.)
2. Press the blue OnStar(R) ("On*") button. A recorded introduction will be heard.
3. Press the "On*" button again at any time during the recording (it is not necessary to wait for the recording to finish).
4. When an OnStar(R) call center advisor answers, identify yourself as an Audi Technician, and that you have replaced the "Vehicle Communications Interface Unit (VCIM)".
5. Supply advisor with STID number and ESN from new module. Supply the VIN and customer details if necessary. The advisor will guide you through the system reconfiguration and update of the customer's account.
6. When reconfiguration is complete, end call by pressing the Communications ("DOT") button.
7. Wait ten minutes and press the "On*" button again to verify system operation. Inform call center advisor you are an Audi Technician performing a quality check after TCM replacement/system reconfiguration.
8. End call by pressing the Communications ("DOT") button

Note. Normal connection time is 10 - 15 seconds. However, depending on local cellular/GPS conditions, making a connection could take up to three minutes. Be patient. If the message: "unable to contact OnStar" is heard, try relocating vehicle to a more elevated or open area and repeat connection attempts. Depending on the local cellular/GPS traffic conditions, several connection attempts may be necessary (and are normal). If the message: "OnStar request ended" is heard, the cellular connection was interrupted before the connection was completed. Wait for a short period of time before repeating connection attempt. If you are still unable to connect, call OnStar(R) Customer Care at 1-888-390-4050. The advisor will verify the customer's OnStar(R) account is active.

Emergency battery, switching off/on

In order to avoid unnecessary discharge of the emergency (back-up) battery, it must always be switched off prior to disconnecting the vehicle battery, and switched back on after the vehicle battery is reconnected.

1. Use VAS 5051 Vehicle Diagnosis, Testing and Information System in mode: "Guided Fault Finding"
2. Enter appropriate model, equipment and model year information and press ">" to confirm. After all control modules have been registered and DTC memories checked
3. Press "Go to"
4. Select "Function/Component Selection"
5. Select "Body, (Repair Groups 01; 50 to 97)"
6. Select "Electrical Equipment" (Repair Groups 01, 90 to 97"
7. Select "01 - On Board Diagnostic (OBD) systems"
8. Select "Telematic"
9. Select "Functions -Telematic"
10. Select "J526 - Telephone/Telematic Ctrl. Module, service mode disc. battery"

1. If necessary, press ">" to advance

Switch off emergency battery

1. Select/press button 3 - "Service mode activating (no load on emergency battery)"
2. Follow the tester's prompts.

Switch on emergency battery

1. Select/press button 1 - "Service mode deactivating (normal operating condition)".
2. Follow the tester's prompts.

1. Remove A-pillar trim. See «LOWER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__lower-a-pillar-trim-assembly-overview)
2. Remove front passenger's seat. See «FRONT SEATS»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-except-cabriolet)

Note. Seat belt need not be detached from seat frame.

1. Pull back floor carpet.
2. Release electronics box cover, passenger's side-arrows-.
3. Open lid -1- of mounting box -2- in direction of -arrow-.

Avant only

1. Disconnect cable connection to antenna splitter.

All models

1. Disconnect electrical harness connector -3-.
2. Remove emergency battery -2- from bracket.

Scheme 292

1. Install in reverse order of removal.

Note. Ensure correct seating of electrical connections.

1. Use VAS 5051 Vehicle Diagnosis, Testing and Information System in mode: "Guided Fault Finding"
2. Enter appropriate model, equipment and model year information and press ">" to confirm.

After all control modules have been registered and DTC memories checked

Scheme 293

1. Press "Go to"
2. Select "Function/Component Selection"
3. Select "Body, (Repair Groups 01; 50 to 97)"
4. Select "Electrical Equipment" (Repair Groups 01, 90 to 97"
5. Select "01 - On Board Diagnostic (OBD)"
6. Select "Telematic"
7. Select "Functions -Telematic"
8. Select "J526 - Telephone/Telematic Ctrl. Module, service mode disc. battery"
9. If necessary, press ">" to advance

Reinstalling existing emergency battery

1. Select/press button 3 - "Service mode deactivating (normal operating condition)"
2. Follow the tester's prompts.

Installing new emergency battery

1. Select/Press button 2 - "New emergency battery has been installed (reset counter)"
2. Follow the tester's prompts.

1. Remove A-pillar trim. See «LOWER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__lower-a-pillar-trim-assembly-overview) .
2. Remove front passenger's seat. See «FRONT SEATS»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-except-cabriolet) .

Note. Seat belt need not be detached from seat frame.

1. Pull back floor carpet.
2. Release electronics box cover, passenger's side-arrows-.

1. Open lid -1- of mounting box -2- in direction of -arrow-.
2. Disconnect cable connection to antenna splitter and remove splitter.

1. Install in reverse order of removal.

Telematic Control Head -E264-, removing and installing

The Telematic Control Head is located in the front interior light module.

Note. In the event any of the OnStar(R) control buttons are either inadvertently or deliberately pressed for longer than 15 seconds, the OBD program assumes a button is sticking. The red status light will come on and a DTC loads in memory. Perform OBD program using VAS 5051 and check DTC memory for DTC 01526 "mechanical malfunction". Inform customers accordingly. A faulty control button cannot be replaced separately. Replace complete telematics control head.

1. Remove front interior light module See «FRONT INTERIOR LIGHT/READING LIGHT, REMOVING & INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#lights-switches-interior-anti-theft-except-cabriolet).
2. Carefully lift connector guide -1- and press off in direction of arrow.
3. Where present, unclip sensors for interior monitoring system -2- - arrows-. see scheme 28

1. Release retaining hooks -arrows- and remove button -1-.
2. Disconnect electrical harness connector -2-.

1. Install in reverse order of removal.

Hook 3370 for front end

Scheme 294

1. Carefully remove cover for reading lamp using special tool 3370.

1. Detach electrical connector -1- for hands-free microphone.
2. Unclip the hands-free microphone -3- from the bracket in the reading lamp cover -2-.

1. Install in reverse order of removal.

1. Unbolt driver's side storage compartment and fold down. See «DRIVER-SIDE STORAGE COMPARTMENT (WITH AND WITHOUT KNEE BOLSTER), ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__driver-side-storage-compartment-with-and-without) .
2. Detach electrical connector -2-.
3. Remove bolts -1- and remove retaining bracket -3- and additional loudspeaker -4-.

1. Install in reverse order of removal.

Special tools and equipment

Hook 3370 for front end

Scheme 295

Note. Roof antenna cables are routed differently. The telematics cable is connected by the right D-pillar and the navigation cable is routed to the antenna splitter and Navigation control module located in the left rear luggage compartment.

1. Sedan: Carefully remove rear interior/reading light from opening of roof liner using special tool 3370.

1. Avant: Carefully remove luggage compartment light from headliner opening using special tool 3370.
2. Remove rear headliner trim. See «MOLDED HEADLINER, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__molded-headliner-assembly-overview) (Sedan), or «MOLDED HEADLINER, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) (Avant).
3. Remove D-pillar trim. See «D-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__d-pillar-trim-assembly-overview) (Sedan), or «D-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) (Avant).
4. Remove left luggage compartment trim. See «LUGGAGE COMPARTMENT SIDE TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__luggage-compartment-side-trim-assembly-overview) (Sedan), or «SIDE LUGGAGE COMPARTMENT TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__side-luggage-compartment-trim-assembly-overview) (Avant).
5. Disconnect electrical connections at D-pillar and at sub compartment in left luggage compartment.
6. Remove nut -1- (6 Nm) and remove antenna upwards.

1. Install in reverse order of removal.
2. Attach the electrical connections according to the colorcoding.

Note. The washer under the retaining nut for the antenna has a gap through which the antenna cables must be guided.

1. Remove roof end trim. See «MOLDED HEADLINER, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__molded-headliner-assembly-overview) .
2. Disconnect harness connector -1- for antenna wire.
3. Remove antenna downward from roof panel edge -arrows-.

1. Install in reverse order of removal.
2. Make sure the retaining clips grip into mounts on roof panel edge when installing.

1. Remove front or rear bumper cover. See «BUMPERS - EXCEPT CABRIOLET»(/audi/a4/b6-2000-2006/remont/exterior-body-panels/#bumpers-except-cabriolet) .
2. Disconnect electrical harness connector.
3. Remove bolt (arrow) and unclip antenna wire.

Note. Depicted on rear bumper in illustration.

Scheme 296

1. Install in reverse order of removal.

Note. Antenna wiring set to front and rear telephone antennas is forked at antenna splitter -R-87- in passenger-side footwell at height of A-pillar. Antenna splitter is a component of the wiring harness and cannot be replaced by itself.

See also:
• PROCEDURE AFTER INTERRUPTION OF VOLTAGE SUPPLY
• PROCEDURE FOLLOWING INTERRUPTION OF VOLTAGE SUPPLY
• "CONCERT II" RADIO UNIT, REMOVING AND INSTALLING
• INSTRUMENT CLUSTER, REMOVING AND INSTALLING
• LOUDSPEAKERS IN DOORS, REMOVING AND INSTALLING
• MOLDED HEADLINER, ASSEMBLY OVERVIEW
• CARGO AREA LIGHT (AVANT), REMOVING AND INSTALLING
• MOLDED HEADLINER, ASSEMBLY OVERVIEW
• SIDE LUGGAGE COMPARTMENT TRIM, ASSEMBLY OVERVIEW
• LOWER A-PILLAR TRIM, ASSEMBLY OVERVIEW
• FRONT SEATS
• DRIVER-SIDE STORAGE COMPARTMENT (WITH AND WITHOUT KNEE BOLSTER), ASSEMBLY OVERVIEW
• D-PILLAR TRIM, ASSEMBLY OVERVIEW
• LUGGAGE COMPARTMENT SIDE TRIM, ASSEMBLY OVERVIEW
• BUMPERS - EXCEPT CABRIOLET
• EMERGENCY BATTERY, SWITCHING OFF/ON
• FUNCTION SELECTOR SWITCH II -E272-, REMOVING AND INSTALLING
• ANTENNA FOR NAVIGATION SYSTEM (GPS) -R50- (AVANT), REMOVING AND INSTALLING
• TELEMATIC SYSTEM (SEDAN), COMPONENT OVERVIEW
• TELEMATIC SYSTEM (SEDAN), LAYOUT
• TELEMATIC SYSTEM (AVANT), COMPONENT OVERVIEW
• TELEMATIC SYSTEM (AVANT), LAYOUT
• TELEMATICS SYSTEM, TROUBLESHOOTING USING ONSTAR(R) SYSTEM STATUS LIGHT
• TELEPHONE/TELEMATIC CONTROL MODULE -J526-, REMOVING AND INSTALLING
• TELEMATIC CONTROL HEAD -E264-, REMOVING AND INSTALLING
• TELEPHONE/TELEMATIC CONTROL MODULE -J526-, REPLACING AND RECONFIGURING
