DRIVE AXLE HEX BOLT CONNECTION, LOOSENING AND TIGHTENING

Special tools and workshop equipment required

  1. Angle Wrench V.A.G 1756

Vehicles without a drive axle must not be moved, otherwise the wheel bearing will be damaged. If vehicle does have to be moved, always note the following points

Install an outer joint in place of the drive axle.

Tighten outer joint to 200 Nm.

Loosening

Scheme 21

Scheme 21

With the vehicle resting on its wheels, loosen the bolt -arrow- maximum 90° otherwise the wheel bearing will get damaged.

Lift the vehicle just enough so that the wheels are hanging free.

Apply the brakes (a second technician required).

Remove hex bolt -arrow-.

Note. Before installing, clean the threads in the CV joint with a tap.

Tightening

Replace hex bolt.

Note. Wheels must not yet touch the ground to tighten the drive axle, wheel bearing may otherwise be damaged.

Apply the brakes (a second technician required). Tighten hex bolt to 200 Nm.

Lower the vehicle onto its wheels.

Turn bolt an additional 180°.

DRIVE AXLE TWELVE-POINT BOLT WITH RIBS, LOOSENING AND TIGHTENING

Special tools and workshop equipment required

  1. Socket XZN 24 T10361
  2. Angle Wrench V.A.G 1756

Characteristics between a Twelve-Point Bolt with Ribs and a Twelve-Point Bolt without Ribs

Scheme 22

Scheme 22

The contact surfaces -arrow A- and -arrow B- are different on the two-point bolts.

I - twelve-point bolt with ribs -arrow A

II - twelve-point bolt without ribs -arrow B

The wheel bearing must not be under a load while the drive axle threaded connection on the wheel side is loose.

If the bearings are loaded by the vehicle's own weight the wheel bearing will be damaged. This reduces the service life of the wheel bearings. Therefore observe the following

  1. Procedure for loosening 12-point bolt.

Vehicles without a drive axle must not be moved, otherwise the wheel bearing will be damaged. If the vehicle does have to be moved, always note the following points

Install an outer joint in place of the drive axle.

Tighten outer joint to 120 Nm.

Loosening

With the vehicle still resting on wheels, loosen 12-point bolt -arrow- with T10361 maximum 90° otherwise the wheel bearing will get damaged.

Lift the vehicle just enough so that the wheels are hanging free.

Apply the brakes (a second technician required).

Remove 12-point bolt -arrow-.

Note. Before installing, clean the threads in the CV joint with a tap.

Tightening

Replace 12-point bolt.

Note. Wheels must not yet touch the ground to tighten the drive axle, wheel bearing may otherwise be damaged.

Apply the brakes (a second technician required).

Tighten 12-point bolt to 70 Nm.

Lower the vehicle onto its wheels.

Tighten 12-point bolt an additional 90°.

DRIVE AXLE TWELVE-POINT BOLT WITHOUT RIBS, LOOSENING AND TIGHTENING

Special tools and workshop equipment required

  1. Socket XZN 24 T10361
  2. Angle wrench V.A.G 1756

Characteristics between a Twelve-Point Bolt with Ribs and a Twelve-Point Bolt without Ribs

The contact surfaces -arrow A- and -arrow B- are different on the two-point bolts.

I - twelve-point bolt with ribs -arrow A

II - twelve-point bolt without ribs -arrow B

Vehicles without a drive axle must not be moved, otherwise the wheel bearing will be damaged. If the vehicle has to be moved, always note the following points

Install an outer joint in place of the drive axle.

Tighten outer joint to 120 Nm.

Loosening

With the vehicle resting on its wheels, loosen the twelve-point bolt -arrow- maximum 90° otherwise the wheel bearing will get damaged.

Lift the vehicle just enough so that the wheels are hanging free.

Apply the brakes (a second technician required).

Remove 12-point bolt -arrow-.

Note. Before installing, clean the threads in the CV joint with a tap.

Tightening

Replace 12-point bolt.

Note. Wheels must not yet touch the ground to tighten the drive axle, wheel bearing may otherwise be damaged.

Apply the brakes (a second technician required). Tighten 12-point bolt to 200 Nm.

Lower the vehicle onto its wheels.

Tighten 12-point bolt an additional 180°.

FASTENER TIGHTENING SPECIFICATIONS

ComponentFastener SizeNm
Ball Joint to Transverse Link Nut
Cast Steel or Aluminum Transverse Link60
Sheet Steel Transverse Link100
Ball Joint to Wheel Bearing Housing Nut (1)60
Console to Body Bolt (1)70 + 90° turn
Coupling Rod to Stabilizer Bar Nut (1)65
Diagonal Brace to Body Bolt, Cabriolet Only (1)90 + 45° turn
CV Joint Boot Clamp
All Except with Inner CV Joint Attached20
With Inner CV Joint Attached25
Drive Axle to Transmission Bolt 1, 4M840
M1070
Drive Axle to Wheel Hub Bolt
Hex Bolt200 + 180° turn
12-Point Bolt with Ribs70 + 90° turn
12-Point Bolt without Ribs200 + 180° turn
Heat Shield to Subframe Bolt6
Level Control System Sensor to Transverse Link Nut9
Level Control System Sensor to Subframe Bolt9
Pendulum Support to Subframe Bolt (1)100 + 90° turn
Stabilizer Bar to Subframe Bolt (1)20 + 90° turn
Steering Gear to Subframe Bolt (1)50 + 90° turn
Strut to Body Bolt (1)15 + 90° turn
Strut to Strut Bearing Nut (1)60
Strut to Wheel Bearing Housing Bolt (1)70 + 90° turn
Subframe to Body Bolt (1)70 + 90° turn
Tie Rod End to Wheel Bearing Housing Nut (1)
All Except Audi S3 and RS320 + 90° turn
Audi S3 (3)100
RS3110
Transverse Link to Console Bolt 1, 270 + 180° turn
Transverse Link Mounting Bracket to Body Bolt (1)70 + 90° turn
Transverse Link Mounting Bracket to Console Bolt (1)50 + 90° turn
Wheel Hub to Wheel Bearing Housing Bolt (1)70 + 90° turn
(1) Always replace after removal. (2) Tighten only in curb weight position. (3) First tighten to 100 Nm; then loosen 180° and tighten again to 100 Nm. (4) Pre-tighten diagonally to 10 Nm.
(1)Always replace after removal.
(2)Tighten only in curb weight position.
(3)First tighten to 100 Nm; then loosen 180° and tighten again to 100 Nm.
(4)Pre-tighten diagonally to 10 Nm.
