SUN SHADE
Removing
Scheme 61
Switch off ignition and remove ignition key.
Remove door trim. Refer to REAR DOOR TRIM .
Carefully release guide strip -1- at left and right with a small screwdriver -arrow-.
Pull sun shade -2- out of door trim slightly and remove guide strip from door trim.
Remove screws -2 to 5-.
Scheme 62
Remove sun shade -1- by lightly tipping outward -arrows- out of door trim.
Installation
Scheme 63
Installation is reverse of removal, but note the following
The mounting grooves in the sun shade housing -2- must engage in door trim guide pins -1- -arrows-.
The guide strip -2- can only be inserted in one position in door trim -1-.
Scheme 64
- How to recognize: the beveled edge -arrow- must face toward window side.
Pull sun shade -3- out of door trim slightly and insert guide strip in door trim as shown in illustration.
Tightening Specifications
| Component | Nm |
|---|---|
| Sun shade to door trim | 2.5 |
