SPEAKER TRIM
Special tools and workshop equipment required
- Trim Removal Wedge 3409
Removing
Scheme 47
Switch off ignition and remove ignition key.
Pry speaker trim -1- out of door trim with 3409.
If present, raise trim molding locking spring -3- upward -arrows-.
Scheme 48
Carefully slide trim molding -2- in -direction of arrow- off speaker trim -1-.
Installation
Installation is reverse of removal, but note the following
Position trim molding and carefully slide it onto speaker trim until it engages.
First engage speaker trim at storage compartment and then press evenly into door trim.
Special tools and workshop equipment required
- Trim Removal Wedge3409
Removing
Scheme 49
Switch off ignition and remove ignition key.
Carefully loosen trim panel -1- from door trim -arrow- with 3409.
Installation
To install, perform the steps used in removal in reverse order.
